HP ProLiant 服务器 务驱动企业业务高速增长的源动力1©2009 HP Confidential2©2009 HP Confidential市场份额：ISS绝对领先，更好的服务让我们始终保持优势根据IDC的数据，惠普 的数据 惠普2010年度服务器销售收入和发货量均名列全球第 年度服务器销售收入和发货量均名列全球第一，连续 连续59个季度， 个季度 HP ProLiant服务器一直处于x86服务器市场的领先地位。

ISS在全球累计发货超过2000万台 • 2010全年销售台数市场份额达37%，在有 销售记录以来连续13年位居第一 • 2010全年厂商销售总额市场份额达40% • 每三台服务器就有一台是ProLiant服务器 • 每15秒就销售一台服务器 ©2009 HP Confidential• •ISS在中国自2001年以来累计发货超过100万台 • 2010全年销售台数市场份额达26%，位居 第一 • 2010全年厂商销售总额市场份额达31% • 每4台服务器就有一台为ProLiant服务器*资料来源：IDC全球服务器市场季度追踪报告，2010年8月；3ISS 产品家族最完整产品组合传递给用户“适能”IT的理念AMDBL680c BL620cBL685cBL490cAMDPositioning and per rformanceDL1000SL6000BL460c BL280cBL465cAMD - Designed for VMs - Large RAM support - SSD requirement AMDDL580DL585BL2 220 BL2x220cAMDDL360/SE1120 DL160 DL165DL380/388DL385ML370- Enterprise-class availability - Database application - Server consolidation - Cost effective alternative to UnixDL320 DL120ML110 MicroServer- Highest density - HPC application li i - Web hosting - Power thirsty- Mainstream application servers DL180/DL180 non-Raid - Best price/performance - enterprise - Department application application Full functional features - virtualization - Cost effective ML350 -High expansibility - Mainstream - Front-end application - Storage optimizedML330ML150- Low cost - First server in SMBAMD4 ©2009 HP Confidentialprice明天的业务将基于融合的基础设施 将电源和散热融合基础设施存储管 管理软件 软件服务 服务器网络虚拟化 • 弹性化• 协同的 • 优化的 • 模块化5 ©2009 HP Confidential当今基础设施面临诸多挑战您的基础设施能否帮助您实现出色的业务成效? 利用率平均值为每个系统15-20% *灵活性每个任务耗时数周乃至数月能耗支出占数据中心成本的40% **可用空间>至2012年50% 的企业将面临空间短缺难题***资料来源：弗雷斯特研究公司的“大型企业如何实现IT基础设施的整合”，2007年12月 **资料来源：IDC公司的“所以你想创建一个数据中心”（ “So You Want to Build a Datacenter,”），2008年11月66©2009 HP Confidential2011年8月G7关键技术前所未有的强大功能与先进技术 采用最新CPU，性能 提升50%-200% 50% 200%•英特尔至强5600和3400系列 •AMD Opteron 6100系列 •能效更高最佳远程管理-iLo3•更高的性能•远程控制台性能提升8倍 •虚拟介质速度提升3倍Powerful. Intelligent.•更易用的界面 •更安全•硬件AES数据加密数据更安全高效精确的电源管理•高效-通过能源之星白金认证的电源 模块 •减少业务风险 •优先保障关键应用 •轻松降低功耗 •insight control+功率调节•G7 smart array的无电池高速缓存 •512MB和1G闪存 •无限期数据保留功能77©2009 HP Confidential2011年8月只有惠普能够优化数据中心容量借助Insight Control电源管理降低能耗，收回未使用的容量，延长数据中心的寿命准确地测量能耗安全地设置功耗最高值通过调节降低能耗安全性确保电路不会受到 损坏可靠性内建于硬件之内，与 操作系统无关兼容性可支持任何操作系统 和Hypervisor避免构建新的数据中心8 ©2009 HP Confidential只有惠普能够持续不断地效率优化借助“海洋式传感器”32个智能传感器管理服 务器温度自动调节风扇 自动调节I/O和内存插槽防止过度散热并最大程度降低能耗9 ©2009 HP ConfidentialPROLIANT：借助INSIGHT CONTROL 实现最佳的服务器管理部署12x Proliant服务器部署速度管理减少计划外停机时间达77%包括 Systems y Insight g Manager g和Insight Remote支持iLO Advanced功能将数据中心的容量扩充3倍 降低系统管理成本和差旅费用控制优化集成在三年的时间内，每100名用户的ProLiant和 BladeSystem运营费用可降低48,300美元*/go/iceroipaper10 ©2009 HP Confidential1*由惠普委托撰写的IDC白皮书，“Gaining Business Value and ROI with HP Insight Control,” 文档编号210479，2009年5月 三年实际节约48,480美元经济高效的网络 济高效的网络传统服务器 服务器VIRTUAL CONNECT服务器PROCURVE + VIRTUAL CONNECT交换机 LANVirt tual Connec ctVi irtual Conne ect交换机 LANProCurve LAN交换机 LAN50%94%75%54%42%网络 边缘成本 资料来源： 惠普和IDC研究11 ©2009 HP Confidential网络 线缆成本网卡与交换 机年度网络基础设施成 电源/空间成本降 本降低 低HP Prolaint+ EVA 4400 total solution 所实现的信息存储架构解决方案•虚拟化存储解决方案• • • •Email 系统CRM系统ERP系统SCM系统Portal系 统虚拟化EVA存储 SAN 交换机整合 NAS Gateway iSCSI LeftHandWindows Linux Solaris WindowsSolaris•备份解决方案− Data Protector•近线备份方案数据库/虚拟化平台− VLS 虚拟带库•容灾方案离线备份方案− MSL 磁带库•数据级容灾方案− Continuous Access − BusinessCopyHP D2D 虚拟带库C ti Continuous Access A /EVA备份方案•资源管理解决方案•Storage EssentialMSL 磁带库虚拟化存储 方案HP EVA虚拟阵列HP EVA虚拟阵列12©2009惠普机密 模板版本。

12.10.09惠普数据中心及基础架构—HP 机柜和电源机柜及水冷 G2 机柜系统 系列机柜10000 100系列机 柜v142 水冷 机柜HP Rack R & Po ower电源 UPS PDU通用电源模块 塔式UPS 机架式UPS三相UPS (up to 60kVA)机柜PDU解决方案机柜选件-机柜 选件KVM机柜用显示器13 13©2009 HP Confidential ©2010 Hewlett-Packard*HP Rack & Power products** – like rack, rack console, KVM, UPS - are covered from HP Server (ISS, BCS) and StorageWorks Care Pack - at no additional costs. **Exception: HP MCS, HP 3phase parallel UPS and HP PDRIntel® Xeon® 5600 系列处理器升级图示现有产品组主频优化型号 X5680 6核 130W 3.33 GHz升级后产品组主频优化型号 X5690 6核 130W 3.46 GHz高级型号•6.4 GT/s QPI •12MB L3 缓存 •DDR3 1333 •睿频加速 •超线程技术X5677 4核 130W 3.46 GHz X5667 4核 95W 3.06 GHz X5670 6核 2.93 GHz X5660 6核 2.80 GHz X5650 6核 2.66 GHz95W 95W 95W升级变化:主频提升X5687 4核 130W 3.60 GHz X5672 4核 95W 3.20 GHz升级变化:主频提升此处理器继续保留,不升级 此处理器继续保留 保 ,不升级性能提升33% 新增DDR31333支持X5675 6核 95W 3.06 GHz X5660 6核 95W 95W 2.80 GHz X5650 6核 95W 95W 2.66 GHz E5649 6核 80W 2.53 GHz 80W E5645 6核 80W 2.40 GHz E5620 4核 80W 2.40 GHz E5607 4核 80W 2.26 GHz E5606 4核 80W 2.13 GHz E5603 4核 80W 1.60 GHzL5600 型号 (不升级)性能提升 +14%†X5647 4核 130W 2.93 GHzX5647 supports DDR3 1066L5640 6核 2.26 GHz160W标准型号•5.86 GT/s QPI •12MB L3 缓存 •DDR3 1066 •睿频加速 •超线程技术E5640 4核 80W 2.66 GHz 80W E5630 4核 80W 2.53 GHz E5620 4核 2.40 GHz E5507 4核 2.26 GHz E5506 4核 2.13 GHz E5503 2核 2.00 GHz80W 80W 80W 80W升级变化:升级至6核此处理器继续保留,不升级性能提升 +30%† 性能提升 +39% 39%†L5630 4核 2.13 GHz2 40W L5609 4核 1.86 GHz3 40W基本型号•4.8 GT/s QPI •4M L3 缓存 •DDR3 800升级变化:性能提升14% 新增支持到 缓存 (E5603为 4M) DDR3 1066 AES-NI, TXT升级至32纳米制程工艺 最大8MB 处理器141 SKU supports 5.86 GT/s QPI speed and DDR3 1333MHz 2 SKU supports 5.86 GT/s QPI speed and DDR3 1066MHz 3 SKU 4.80 GT/s QPI speed and DDR3 1066MHz, no Turbo and HT. ©2009 HPsupports Confidential全新“HP PROLIANT无忧服务”开启中国X86服务器产业服务化时代 行业标准几乎涵盖全系列产品 服务级别业内领先9 3年现场让客户更省心 9 4小时响应让客户更安心 9 安装服务让客户更放心DL/ML1xx 系列服务器DL/ML3xx/5xx 系列服务器全线刀片产品 ¾ 自2011年2月1日起在中国大陆地区销售的正规订单中已包含HP ProLiant“无忧服务”,客户无需另行购买.15 ©2009 HP Confidential磨刀不误砍柴功---Sales TOOL产品竞争信息，产品投标信息，产品销售工具，产品信息库，市场和培训， 销售流程及重要通知16©2009 HP Confidential全新的入门级服务器—ML110G7&DL120G7; 全新的Sandy Bridge平台,32nm架构(至强E3-12xx系列，8MB缓存) ; 全面支持热插拔硬盘 ; 板载集成2块NC112i 千兆以太网 适用器 ; 升级到全新的iLO 3远程管理模块 ; 已包含3年7*24*4服务级别 ; 更好的散热和噪音控制17©2009 HP Confidential我们能卖什么？？？ML110; ML110 绝对是1路服务器中的全明星，无论从质量， 路服务器中的全明星 无论从质量销量和口碑都处于行业领先地位。

合集下载

HP ProLiant ML350 Gen9服务器产品介绍说明书

HP ProLiant ML350 Gen9服务器产品介绍说明书

Right-fit server for growing small- to medium-sized businesses To help you focus on what’s important—running the business—your growing company needs IT that is easy to manage, affordable, and highly reliable. Get what you need with HP Just Right IT solutions . Choose right-fit servers, storage, networking, and services, tailored to meet your unique requirements at each stage of your business growth.One of HP’s right-fit servers is the HP ProLiant ML350 Gen9—delivering a class-leading combination of performance, availability, expandability, manageability, reliability, and serviceability. Offering standard HP Integrated Lights-Out (iLO) capabilities for simplified IT infrastructure management, 24 slots for DDR4 HP SmartMemory with up to 14 percent greater performance 1 (a maximum of 48 drives), and an embedded 4x 1GbE NIC, the HP ProLiant ML350 Gen9 Server offers the ideal set of features for your growing business needs today and tomorrow.Exceeds the requirements of remote offices/branch offices Today’s distributed organizations face significant cost and functionality tradeoffs. With limited onsite IT staff, each remote office/branch office (ROBO) must be managed and operated from the data center. Installing and configuring new infrastructure at each edge location is critically important, but it creates a substantial drain on IT resources in terms of time and effort. To free up time, money, and human resources—while also providing a better infrastructure—today’s enterprises need to centralize management for all remote sites; automate system setup to speed branch rollout; minimize hardware, while also expanding application and data services; and ensure continuity for business-critical functions.Designed to deliver simplified expandability, easy manageability, and proven reliability, the HP ProLiant ML350 Gen9 Server leverages the latest Intel ® Xeon ® processor E5-2600 v3 processors with up to 70 percent 2 performance gain and additional support for 12 GB/s serial-attached SCSI (SAS) with a broad range of graphics and compute options. You can manage your HP ProLiant ML350 Gen9 Server in any IT environment by automating themost essential server lifecycle management tasks—deploy, update, monitor, and maintain.Providing the ideal platform for everything from infrastructure to mission-critical applications,you can deploy the ProLiant ML350 Gen9 Server with confidence.Availability, expandability, andserviceability—a winning combinationHP is all about choice. And so is the HP ProLiantML350 Gen9 Server—offering supportfor 8–24 large form factor (LFF) or 8–48 smallform factor (SFF) drive options, as well asimproved storage expansion. You can also choosefrom many other options including:• Nine PCIe expansion slots• Eight USB ports• 5U rack conversion• Numerous power supply options• Y our choice of PCIe standup 1GbE or 10GbEnetwork adapters• F our graphics processing unit (GPU) options forboosting performance in graphics and virtualdesktop infrastructure (VDI) apps• Complete HP Care Pack support options1 Based on similar-capacity DIMM comparingHP server to a non-HP server with DDR4,July 2014.2 Intel performance testing, comparingmeasurements on platform with two E5-2697 v2(12C, 2.7 GHz), 8x8 GB DDR3-1866, RHEL 6.3 vs.platform with two E5-2697 v3 (14C, 2.6 GHz,145 W), 8x8 GB DDR4-2133, RHEL 6.3, April 2014.Data sheetHP ProLiant ML350 Gen9 ServerHigh performance with unmatched capacity and reliabilityRate this documentShare with colleagues Sign up for updates /go/getupdated Data sheet | HP ProLiant ML350 Gen9 Server© Copyright 2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The onlywarranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing hereinshould be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.Intel Xeon is a trademark of Intel Corporation in the U.S. and other countries. ENERGY STAR is a registered mark owned by the U.S. government. SD and microSD are trademarks or registered trademarks of SD-3C in the United States, other countries or both.4AA5-4081ENW, September 2014HP ProLiant ML350 Gen9 ServerComputeUp to two Intel Xeon E5-2600 v3 series, 4/6/8/10/12/14/16/18 cores. PCIe 3.0, up to nine available slot(s)MemoryHP SmartMemory (24) DDR4, up to 2,133 MHz (768 GB max.)StorageStandard HP Dynamic Smart Array B140i Choice of HP Flexible Smart Array or HP Smart Host Bus Adapter Controllers for performance or additional features HP Smart Drives48 SFF/24 LFF max., hard disk drive (HDD)/solid-state drive (SSD)Networking4x 1GbE embedded + Standup VGA/serial/USB ports/SDFront VGA opt., rear VGA and Serial Standard , eight USB, and one microSD GPU supportSingle/double-wide and active /passive, up to 10.5" (4)On premise managementHP Insight Control and HP iLO Advanced On cloud managementHP Insight Online with enhanced mobile application On system managementChanges in HP iLO, HP SUM, Intelligent Provisioning and scripting tools; plus the new UEFI and HP RESTful Interface Tool Power and coolingUp to 94 percent efficient (Platinum Plus) with Flexible Slot FF Industry complianceASHRAE A3 and A4, lower idle power, and ENERGY STAR ®Form factor/Chassis depthTower or Rack (5U)/28.5" (SFF), 28.5" (LFF)Warranty 3/3/3Technical specificationsIn the following table, bold italic text denotes new features or functions, as compared to the HP ProLiant ML350p Gen8 Server.HP ServicesLet HP help guide you to the New Style of IT. HP Technology Services delivers confidence,reduces risk, and helps you realize greater agility and stability.• Our Consulting services provide advice and guidance to safely move your workloads tonewer technologies.• HP implementation and installation services enable faster, more reliable startup of your newProLiant Gen9 servers, and our support portfolio allows you to get connected and get back tobusiness fast.• We recommend HP Proactive Care for ProLiant Gen9 servers to prevent issues and resolveproblems quickly and efficiently.• HP Foundation Care provides a choice of coverage levels and response times for hardwareand software support.• HP Datacenter Care enables you to operate and evolve your IT environment at a lowercost and with more agility, including our HP Flexible Capacity Service to acquire IT withoutimpacting capital budget.• Our support technology lets you to tap into the knowledge of millions of devices andthousands of experts to stay informed and in control, anywhere, any time.Learn more at /servers//servers/ml350gen9/qs/qref/ml350gen9。

HPE ProLiant服务器安装与启动服务说明书

HPE ProLiant服务器安装与启动服务说明书

Service overviewHPE Installation and Startup of HPE ProLiant servers provides for the installation of your new HPE ProLiant server and eligible operating system. This service will assist you in bringing your new HPE ProLiant server and operating system into operation in a timely and professional manner.Service benefitsThis service provides a trained HPE service specialist to perform an installation that meets HPE quality standards, for:• Delivery of the service at a mutually scheduled time convenient to your organization• Helps you effectively utilize HPE products from the knowledge gained during on-site delivery of the service• Custom installation as detailed in “Delivery specifications’’ or in a Statement of Work (SOW)• Verification prior to installation that all service prerequisites are metService feature highlights• Service planning• Service deployment• Installation verification tests (IVTs)• Customer orientation sessionHPE Installation and Startup of HPE ProLiant servers HPE Support ServicesData sheetTable 1. Service featuresFeature Delivery specificationsService planning An HPE service specialist will confirm with the Customer that the prerequisites have been met and schedule the delivery of theservice at a time mutually agreed upon by HPE and the Customer, which shall be during local HPE standard business hoursexcluding HPE holidays, unless otherwise agreed by HPE. Any services provided outside of HPE standard business hours may besubject to additional charges.Service deployment The deployment activities will include:Hardware• Installation of the server: Unpacking the server, inspecting it for damage, and installing it according to the product specifications(If the server is part of a rack system, it will be inserted into the rack.)• Installation of hardware options: System hardware options purchased with the system will be installed at the same time• Physical connection of the product to a LAN, as appropriate• Consolidation of all packaging material and notification to the Customer that the materials are ready for removalSoftwareInstallation of one eligible Operating System. Eligible Operating Systems are defined below:• For Microsoft® Windows Server®:–Installation of the operating system and the appropriate network protocols, as required–Creation of a Windows Server account with up to three user accounts–Creation and setup of one Windows Server file share on a local disk–For ProLiant DL380 Packaged Cluster only, installation and configuration of Microsoft Cluster software according to theproduct installation guide• For Linux® server operating systems:*–Installation of the operating system and the appropriate network protocols, as required–Installation of HPE drivers, as applicable–Creation of a Linux server account with up to three user accountsThe supported Linux distributions for installation as part of this service are Red Hat® Enterprise Linux (RHEL) and SUSE LinuxEnterprise Server (SLES).*For systems with multiple servers per chassis, one operating system (OS) image will be installed on one server node within thechassis. If an established HPE Insight Cluster Management Utility (CMU) or Microsoft WDS environment exists with a functionalPXE boot environment and server provisioning capabilities to load an OS image, then the HPE installation engineer will load oneOS image to all server nodes within the chassis.Enable remote support to allow for automatic case creation for hardware failures, and for proactive deliverables provided underapplicable service levels. This enablement is for supported devices only and is conditional on the existence of a foundationalHPE remote support application already established in the Customer’s server environment.For more information on remote support, go to /services/getconnected.Installation verification tests (IVTs)HPE will run the appropriate installation verification tests required for this service, such as Power-On Self-Tests (POSTs) specificto the product being installed, verification of product operation, and verification that the current device software and firmwareare loaded.Customer orientation session Upon completion of the deployment activities, the HPE service specialist will provide an orientation session, up to one hour, on theproduct and/or technology, to include information on basic hardware product usage and hardware features.Service eligibilityThe Customer must meet the following prerequisites for the delivery of this service:• Have a new HPE ProLiant server and a supported version of Microsoft or Linux operating system and valid licenses• Have no earlier version of the operating system installed on the new HPE ProLiant server for which this service is to be applied• Have all cabling and network connections installed and functionalService limitationsExcluded from this service are activities such as, but not limited to, the following:• Service deployment on hardware not covered by an HPE warranty or HPE support agreement• Service deployment on hardware covered by a third-party maintenance contract• Operating system provisioning with a third-party or customized software tool• Installation of ineligible operating systems or more than one operating system• Planning, design, implementation, or assessment of the Customer’s overall SAN or fabric architecture• Services that, in the opinion of Hewlett Packard Enterprise, are required due to unauthorized attempts by non-HPE personnel to install, repair, maintain, or modify hardware, firmware, or software• Site inspection activities such as a comprehensive analysis of the Customer facility’s power, cooling humidity, airborne contaminant, vibration levels, and determination of whether the data center’s raised floor has sufficient structural capability to accommodate the weight of newly installed equipment• Environmental compliance or site preparation• External cabling• Application integration or integration of third-party products or peripherals not included with the system• Assembly of external storage devices• Assembly of racks or other computer room site preparation• Software training, troubleshooting, repair, tuning, or customization• Any services not clearly specified in this documentCustomer responsibilitiesThe Customer will:• Contact an HPE specialist within 90 days of date of purchase to schedule the delivery of the service• Coordinate service deployment on third-party-maintained products (if applicable) with Hewlett Packard Enterprise• Designate a person from the Customer’s staff who, on behalf of the Customer, will grant all approvals, provide information, and otherwise be available to assist HPE in facilitating the delivery of this service• Ensure that all service prerequisites as identified under “Service eligibility’’ are met• Ensure that all site preparation, power supply compatibility requirements, network cabling and configuration, and other specified service prerequisites, as listed in the “Service eligibility” section have been met• Allow Hewlett Packard Enterprise full and unrestricted access to all locations where the service is to be performed• Provide a suitable work area for delivery of the service, including access to an outside telephone line, power, and any network connections required• Be responsible for all data backup and restore operationsGeneral provisions/other exclusionsHPE reserves the right to charge, on a time and materials basis, for any additional work over and above this service package pricing that may result from work required to address service prerequisites or other requirements that are not met by the Customer.HPE reserves the right to reprice this service if the Customer does not schedule and provide for subsequent delivery within 90 days of purchase.HPE’s ability to deliver this service is dependent upon the Customer’s full and timely cooperation with HPE, as well as the accuracy and completeness of any information and data the Customer provides to HPE.Travel charges may apply; please consult your local office.Learn more at /services/support Data sheet© Copyright 2005, 2007, 2014, 2016–2017 Hewlett Packard Enterprise Development LP. The information contained herein is subjectto change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warrantystatements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.This data sheet is governed by the Hewlett Packard Enterprise current standard sales terms, which include the supplemental data sheet,or, if applicable, the Customer’s purchase agreement with Hewlett Packard Enterprise.Microsoft and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or othercountries. Red Hat is a registered trademark of Red Hat, Inc. in the United States and other countries. Linux is the registered trademarkMake the right purchasedecision. Chat with ourpresales specialists.。

HPProliant系列服务器配置阵列卡过程

HPProliant系列服务器配置阵列卡过程

H P P r o l i a n t系列服务器配置阵列卡过程Last updated on the afternoon of January 3, 20211.从自检信息中可以判断出，机器加的阵列卡为SmartArray642阵列卡一块。

2.上面提示信息说明，进入阵列卡的配置程序需要按F8进入阵列卡的配置程序。

可以看到机器阵列卡的配置程序有4个初始选项:•CreateLogicalDrive创建阵列•ViewLogicalDriver查看阵列•DeleteLogicalDriver删除阵列•SelectasBootController将阵列卡设置为机器的第一个引导设备注意：最后一个选项,将阵列卡设置为机器的第一个引导设备。

这样设置后，重新启动机器，就会没有该选项。

3.选择"SelectasBootController",出现红色的警告信息。

选择此选项，服务器的第一个引导设备是阵列卡(SmartArray642),按"F8"进行确认。

4.按完"F8"，确认之后，提示，确认改变，必须重新引导服务器，改变才可以生效。

5.按"ESC"之后，返回到主界面，现在看到三个选项了。

6.进入"CreateLogicalDrive"的界面,可以看到4部分的信息7.按回车进行确认，提示已经创建一个RAID0的阵列，逻辑盘的大小为，按F8进行保存即可。

8.按"F8"进行保存。

9.提示配置已经保存，按回车。

10.进入"ViewLogicalDrive"界面，可以看到刚才配置的阵列,状态是"OK"，RAID的级别是RAID0,大小为。

11.按回车，查看详细信息。

12.选择第三个选项"DeleteLogicalDrive"，进入删除阵列的界面。

13.按"F8"，把刚才设置的阵列删除掉。

hp proliant 系列服务器阵列配置

hp proliant 系列服务器阵列配置

HP ProLiant 系列服务器F8阵列配置过程ProLiant 服务器分DL（机架式）和ML（机座式），其阵列配置方法都是一样。

DL系列集成阵列卡，ML系列则需要添加阵列卡。

ML系列加阵列卡过程：将阵列卡插到PCI插槽上，然后将主板和硬盘笼的SCSI连线（主板端）改接到阵列卡通道上。

F8(ORCA)配置方法服务器加电开机，自检到阵列卡时，会有按F8的提示。

例如画面显示是：Slot 2 smart array642 controller … … … … ….0 logical driversPress F8 to run the Option ROM Configuration for Arrays utilityPress ESC to cancel进入F8后，是蓝色的界面。

主菜单上一般有三个选项：1. Create logical drivers（建立逻辑磁盘）2. View logical drivers （查看逻辑磁盘）3. Delete logical drivers （删除逻辑磁盘）ML系列第一次加阵列卡时，在进入ORCA界面后，除了有以上3项外，还会有第四项：4、Selcet as boot controller （选择当前阵列卡为引导控制器）但此选项（第四选项）选上确认以后，就不会再出现，以后再进入ORCA只会出现以上3个选项。

1、建立阵列进入（1、Create logical drivers）选项，在左边是硬盘的信息，右边的做阵列的选项及参数，最下端则是操作提示。

界面如下：Controller: HP Smart Array 642, slot 2Direct-Attached, storage=======Arailable Physical Drives======= ===Raid Configurations=== （可用的物理磁盘） （阵列配置） [×] SCSI port 2, ID 0, COMPAQ 72.8 GB [×] RAID 5(SCSI通道2，ID 0，COMPAQ硬盘 72.8 GB) (阵列级别 5) [×] SCSI port 2, ID 1, COMPAQ 72.8 GB [ ] RAID 1 (1+0)[×] SCSI port 2, ID 2, COMPAQ 72.8 GB [ ] RAID 0= = = [ ] Use one drive as spare = = =（用一块硬盘作为热备份盘） = = =Maximum Boot Parition= = =（最大引导分区）[×] Disable (4 GB maximum)（关闭） （最大4 GB）[ ] Enable (8 GB maximum)（开启） （最大 8 GB）<Enter> to create a logical drive; <Tab> to navigate按<Enter>建立一个逻辑磁盘；按<Tab>换下一个项目<Up/Down ARROW) to scroll,<ESC> to return,<Space Bar> to select.按<Up/Down键>移动；按<ESC>返回，按<Space Bar>为选定次选项。
