派克比例阀参数-概述说明以及解释1.引言1.1 概述概述部分:派克比例阀是一种常用的工业控制阀，用于调节液体或气体流量。

其特点是通过改变阀门的开度来控制介质的流量，以达到精确控制的目的。

派克比例阀广泛应用于自动化控制系统中，特别是在需要准确控制流量的场合，如工厂生产线、机械加工、化工以及液压系统等领域。

派克比例阀的参数是指影响其性能和控制精度的各项指标。

常见的派克比例阀参数包括响应时间、线性度、灵敏度、控制精度等。

响应时间是指控制信号作用到阀门上所需的时间，通常以毫秒为单位。

线性度是指阀门在不同开度下流量的变化关系，通常以百分比表示，线性度越好，阀门的流量控制越精确。

灵敏度是指阀门对控制信号的响应程度，灵敏度越高，阀门的调节范围越大。

控制精度是指阀门输出流量与期望流量之间的误差，通常以百分比表示，控制精度越高，阀门的流量控制越准确。

了解派克比例阀的参数对于正确选择和使用该阀门至关重要。

根据实际需求，我们可以根据阀门参数来判断适合的使用场景和控制要求，从而保证流体系统的稳定运行和可靠性。

在接下来的文章中，我们将重点介绍派克比例阀的各项参数，并探讨其对流体控制的影响，帮助读者深入理解和应用派克比例阀。

1.2 文章结构文章结构部分的内容如下：文章结构是指整篇文章的组织方式和内容的排列顺序。

一个良好的文章结构可以使读者更容易理解和把握文章的主题和要点。

本文将按照以下结构来组织内容：引言部分（Introduction）：该部分主要对派克比例阀参数进行概述，介绍派克比例阀的基本概念及其在实际应用中的重要性。

同时还会介绍文章的结构和目的，让读者对全文有一个整体的了解。

正文部分（Body）：正文部分是整篇文章的核心部分，将详细介绍派克比例阀参数的相关内容。

其中，第一个要点将重点介绍派克比例阀的工作原理、结构特点以及参数的定义和计算方法；第二个要点将深入讨论派克比例阀参数在实际应用中的影响因素和调节方法。

结论部分（Conclusion）：结论部分将对正文部分的内容进行总结，并提炼出文章的主要观点和结论。

派克比例阀 D1FBE01FC0NF0016 - Parker派克
派克比例阀 D1FBE01FC0NF0016 是Parker派克公司生产的一种比例阀。

以下是该比例阀的详细规格：
型号：D1FBE01FC0NF0016
制造商：Parker派克
阀体材质：铝合金
最大工作压力：350 bar
最大流量：80 l/min
最大控制电流：1.6 A
电源电压：24 VDC
电气接口：插座式连接器
阀芯类型：比例阀芯
比例阀芯控制方式：电控
比例范围：0-100%
阀芯位置反馈：霍尔效应传感器
阀口连接方式：法兰连接
阀口尺寸：G1/2"
防护等级：IP65
工作温度范围：-20°C 至+80°C
这些规格可以帮助您了解派克比例阀 D1FBE01FC0NF0016 的基本特性和适用范围。

请注意，具体的应用和安装要求可能需要根据您的实际需求进行进一步确认。

建议您在购买和使用该比例阀之前，与Parker派克公司或其授权代理商联系，以获取更详细的技术信息和支持。

气动比例调节阀工作原理气动比例调节阀是一种通过压缩空气来控制液体流量的装置。

它由三个主要部分组成：阀体、控制阀芯和气动执行器。

本文将详细介绍气动比例调节阀的工作原理。

1.阀体：气动比例调节阀的阀体通常由铸铁、钢材或不锈钢制成，并通过法兰连接到管道系统。

阀体包含进口和出口口径，中间有一个流道。

流道的直径可以根据流量要求和系统需求进行调整。

2.控制阀芯：控制阀芯是通过压缩空气信号来控制阀门的开度，并调节流量。

控制阀芯通常由不锈钢或其他耐腐蚀材料制成，以确保长时间的使用寿命。

控制阀芯的运动由气动执行器驱动。

3.气动执行器：气动执行器是将气动信号转换为机械运动的装置。

它通常由气缸和气动阀组成。

气缸通过压缩空气的力推动阀芯的运动。

气动阀用于控制压缩空气的进出，从而控制气缸的运动。

工作原理：当气动比例调节阀通电后，控制系统会根据要求发送信号给气动执行器。

气动执行器中的气动阀会打开，允许压缩空气进入气缸。

气缸中的压缩空气推动活塞向右运动，同时推动阀芯向右移动。

阀芯向右移动时，阀芯的底部会打开阀体上的流道，使流体通过。

流体的流量大小取决于阀芯的位置，当阀芯向右移动时，流道的开口会增大，导致流量增加。

当阀芯向左移动时，流道的开口会减小，导致流量减小。

阀芯的移动速度取决于气缸中的压缩空气的压力和流量。

通过控制气动执行器中压缩空气的压力和流量，可以控制阀芯的运动速度和位置，从而实现对液体流量的精确调节。

除了流量调节外，气动比例调节阀还具有反馈控制功能。

反馈控制是通过安装在气动执行器上的位置传感器来实现的。

传感器可以监测阀芯的位置，并将实际位置信息反馈给控制系统。

控制系统会根据反馈信息与设定值进行比较，并调整气动执行器中压缩空气的压力和流量，以实现对阀芯位置的精确控制。

总结：气动比例调节阀通过压缩空气信号来控制阀门的开度，并调节流量。

它由阀体、控制阀芯和气动执行器组成。

控制系统通过发送信号给气动执行器，控制气缸中压缩空气的压力和流量，从而实现对阀芯的运动控制，最终实现对液体流量的精确调节。

P33系列美国PARKER安全阀如何操作使用三个点来介绍P33系列美国PARKER安全阀如何操作使用三个点来介绍：派克PARKER安全阀P33系列是特种设备（锅炉、压力容器、压力管道等）上的一种限压、泄压起到安全保护作用的重要附件。

派克PARKER安全阀P33系列一般直接安装在特种设备上的，他的设计、制造、安装、使用、检验等都要符合特种设备相关规定的要求，因为它的动作可靠性和性能好坏直接关系到设备和人身的安全，并与节能和环境保护紧密相关。

一、常见的派克PARKER安全阀P33系列一般有以下几种：1、按整体结构和加载结构的形式可分为重锤杠杆式派克PARKER安全阀P33系列、弹簧式派克PARKER安全阀P33系列和控制式3种。

2、按阀瓣式开启高度与阀流通直径之比可分为微启式和全启式派克PARKER安全阀P33系列。

3、按派克PARKER安全阀P33系列气体排放的方式可以分为全封闭式、半封闭式和敞开式3种二、选用合适的派克PARKER安全阀P33系列应从以下几个方面考虑:1、结构形式，主要取决于设备的工艺条件以及工作介质、特性。

一般锅炉、压力容器泄放量不大的情况多选用弹簧式派克PARKER安全阀P33系列，否则选择全启式派克PARKER安全阀P33系列比较好。

2、如果介质有毒、易燃易爆，应选封闭式派克PARKER安全阀P33系列3、每个派克PARKER安全阀P33系列都有自己的工作压力范围，选用时应按照实际需求进行选择。

4、选用的派克PARKER安全阀P33系列的排放量必须大于设备的泄放量，这样才能保证部分介质被排除，避免压力继续升高。

三、安装注意事项1、各种派克PARKER安全阀P33系列都应垂直安装。

2、派克PARKER安全阀P33系列出口处应无阻力，避免产生受压现象。

3、派克PARKER安全阀P33系列在安装前应专门测试，并检查其密封性。

4、对使用中的派克PARKER安全阀P33系列应作定期检查四、应用中派克PARKER安全阀P33系列常见故障：在对派克PARKER安全阀P33系列正常使用以及进行校验时，由于设计、制造或者使用不当会造成各种故障。

派克比例阀价格表派克PARKER电磁阀、派克PARKER止回阀、派克PARKER比例阀、派克PARKER单向阀、派克PARKER 伺服阀、D41FHB31C1NE00D41FHB31E1NE00D41FHE01C1NB00D41FHB31C1NE0048D41FHB31E1NB0048D41FHE01C1NB00D41FHE01C1NE00D41FHE01E1NB00D41FHE01E1NE00D41FHE01F1NE00D41FHE01F4NB00D31FBE01CC4NF00D31FHE01A4NB00D3FXE01HCNBJ00D91FBE01HC1NF00D41FHB31C1NB00D41FHB31E1NE00D41FHB31F1NB00D41FHB31F1NE00D91FBE01HC1NG00D91FHB31F1NE00D31FBE01CC1NF00D31FBE01CC1NG00D41FBE01FC1NF00D41FBE01FC1NG00D41FBE01FC4NF00D41FBE02FC1NF00D91FBB32HC4NG00D91FBE01HC4NF00D111FBB32LC1NG00D111FHE01L4NB00BD15AAABN10D1FVE02BCVFOA37PGP517A0330CD1H3NL3L2B1B1PV016R1K1T1NMMCPV028R1K1JHNMMCPV028R1L1T1NMMCPV032R1K1T1NMMCPV046R1K1T1NMMCPV046R1L1T1NMMCPV080R1K1T1NMMCPV092R1K1T1NMMCPV140R1K1T1NMR1PV180R1K1T1NMMCSSRB080E065004072TE0330CW260AAABBD15AAANB10PV046R1K1T1NMRDD41FTE01FC2NF0038TE0330CW260AAABPCD00A-400PV140R1K1T1NFR1RE10R25W4SN1XWMPVS25AZ140C1E015 N3571A1E010 N35870D1400520171D0059422 PWD00A-400VRD350-010-006 D31FTE02CC4NG00D31FTE01CC4NG00RE32E17T1SNG0D91FTE02HC4NG00D91FTE01HC4NF0040SD500A06V+H06SDVD3W004CNJWRDM2PT35KVG15D1VW011CNJWPRDM2PP16SVGCVH161PSVH101S20FV102SCV102PD31FHE02C1NB0040TE0330CW260AAABSD500A06V+H06SDVPVS08AZ140C2R4R03-535-11B1D3W1CNJP30D31FHE02C1NB00404D01-3208-0302-B1-GOQBD15AAABN10PV016R9K1T1NMMCK0188R4V03-533-10-P2GOPA1DWEE527P20ELAFPV023R1K1T1NMM1EPP34CC1I60010PV140R1K1TINFR1BD15AAABN10派克PARKER Herl T5F-CO2 DN50 PV140R1K1TINFR1PV023R1K1T1NMR1D3W1CNJP30PS100-POHO DBD1VW20DVJW75D41VW004C1NJWFM2DDSVZDV-ABS-02-5-S0-D1V-C1DB101E320S9900D91FWB32HC4NLW028D1VW020DNJWD41VW020D1NJWR4V1053511A1D1FVE02BCF0A37CPOM6AAVDK-D1VW75-10D3W4CNJWD41FTE01FC1NF0040D3W004CVJWCPOM4AAHTVC032BN12VPRDM2PP16SVGD3W20BNJWD1VW020HVJWD81VW020D1VJWCPOM6DDVC063AA20VSVLB1086E32SD3W4CNJWPVCRER1N1PVACPPCMN35R4V03-533-10-P2GOPA1PRDM2PP06SVGPRDM2PP16KVG15D1VW034CNJWD3W001CNTWPRDM2PT35KVGD31FHE02C1NBOOD1VW020BNJW91FM3DDSV51PD140PS02SRS5AC00S100D3W004CNJWD3W020BNJW42PD100PS02SRS5AC10S300公司主要做欧美品牌，我们在德国、美国有公司，可以采购欧洲任何国家的品牌，比如德国的优势品牌有：德国宝德BURKERT，德国DEMAG德马格、德国HAWE哈威，德国REXROTH力士乐，德国HYDAC贺德克，德国PILZ皮尔兹继电器，德国FESTO费斯托,德国IFM易福门传感器，德国E+H恩德斯豪斯，德国海德汉HEIDENHAIN,德国P+F倍加福传感器，德国施克SICK,德国TURCK图尔克，德国HIRSCHMANN赫斯曼工业交换机。

!DescriptionProportional valve (Electronic Pressure Regulator)with micro processor which enables you to adjust all parameters settings by means of push buttons.Features•Alarm Output Signal 24VDC when Required Pressure is Reached•Connector M12 4P Male (Plug and Cable are Not Supplied)•Fits in the Parker Pneumatic Frame-block (Air Service Unit)•Free Programmable Software•Integrated and Adjustable Slow-Start FunctionsAccuracyLinearity...................................................< 0.3% of F .SAir ConsumptionUnder normal conditions and in steady state there is no air consumption.Alarm Output SignalWithin the signal band an output signal is available:24VDC, PNP open collector, max 50mA, prevented against short-circuit (accepts inductive loads).Available OptionsAnalog Output:0 - 10 VoltsFor additional information, please contact factory.Change the Control SignalFrom 0 - 10 V to 4 - 20mA (Ri = 500.): (Parameter 4)EPDN SeriesProportional ValveWARNINGDo not adjust any of the other parameters. These are factorysettings. Any other change can have a big influence on the performance of the regulator.Parker Pneumatic does not warranty units which have not been properly used and / or adjusted.Class of Protection ...............................IP 65Control Signal0 - 10V , Ri = 100K or 4 - 20mA, Ri = 500The control signal can be changed.Dimensions: See page 18Electrical ConnectionsUse plug M12: 4-Pole female(Other connectors available on request)The electrical connections are as follows:Pin No.Function Color 124V SupplyBrown 20-10V Control signal Ri = 100kWhite 30V (GND)SupplyBlue 424VAlarm Output SignalBlackFlow Capacity:1/2" = 63.6 SCFM, 1" = 148.3 SCFM Hidden Functions EPDN4-MPDuring start-up unit. (Power goes on)When keys DOWN and UP are pressed during start-up, (connecting to the 24V power supply) manual mode is activated. This means that the user is able to increase / decrease the output pressure of the EPD,by pressing the UP or DOWN key. During this action the display will blink, indicating that the manual mode is activated.Pressing the UP and DOWN key againsimultaneously will cause the EPD to terminate manual mode.After Start-up (Power is on)Parameter 0 = 3Entering this value in parameter 0 will store the calibrated factory data into the working parameters.(Default calibration data is used)Behavior ControlThe regulation speed of the pressure regulator can be modified by means of one parameter. (P 20)The value in this parameter has a range from 0-5, a higher value means slower regulation speed (but more accurate). When the value 0 is entered, you are able to create your own custom settings. For details see page 12, parameter 20.Materials Housing......................Anodized Aluminum and PlasticSeals....................................................................NBRValves......................................................PolyurethaneOthers....................................Delrin, Brass, AluminumMountingThe unit preferably is to be mounted vertically with the electrical connection to the top.Parameters.Functonality of EPD can be manipulated by means of parameter settings. These settings can be changed by means of the 3 buttons at the front side of the EPD.For details see page 12 “How to Change Parameters”.Pilot Valve ProtectionWhen the required output pressure can not be achieved because of a lack of input pressure the unit will display “No.P”. The output pressure will then approximately be equal to the inlet pressure. As soon as the input pressure is back on the required level the normal control function follows.Pressure RangePrimary (Input Pressure):..........................max. 16 barSecondary (Output Pressure):.....................0 to 12 barThe output pressure is indicated on a built-in digital display. Pressure drop input / output min. 0,5 bar Response TimesFor a volume of 330 cm³ directly on the outlet of the regulator:Pressure increase from 2 to 4 bar.................32 msecsPressure increase from 2 to 8 bar...............137 msecsPressure decrease from 4 to 2 bar................64 msecsPressure decrease from 8 to 2 bar..............159 msecsFor a volume of 330 cm³ on a distance of 20 meters from the regulator (Connected with tubing -inner Ø 10 mm)Pressure increase from 2 to 4 bar.................56 msecsPressure increase from 2 to 8 bar...............200 msecsPressure decrease from 4 to 2 bar................69 msecsPressure decrease from 8 to 2 bar................96 msecsSupply Voltage..........................24V DC ± 10%Reverse Protected.....................Max. 200 mA. Safety ExhaustThe valve will force exhaust at a control signal below 0.1 volt or 4.2 Ma.SettingsThe regulator is pre-set at the factory as indicated on label. If required, adjustments can be made, seepage 12.Dead Band:..± 1% of FS (= ± 0 to12 bar) = Hysteresis Proportional Band:...............±10% of FS (= ± 1,2 bar) Signal Band:.........................±10% of FS (= ± 1,2 bar)Specific ApplicationsSo far the EPD has been used in a wide variety of applications such as:1.Regulating welding forces on spot weld guns.2.Regulating protective gases in laser cuttinginstallations.3.Maintaining pressure in cutting head chamberson tunnel drilling equipment.4.Maintaining a small overpressure in clean rooms.5.Regulating air-humidity in storage and handlingrooms for e.g. tobacco or wood.6.Regulating sprays of paint through the nozzles ofpainting installations.7.Maintaining a protective shield of inert gases infurnaces in steel mills to avoid the contaminationwith air of gas in the metal.8.Adjusting of braking forces on ships winches.9.Adjusting governors on marine diesel engines.10.Blowing plastic of glass bottles.11.Controlling specific gas mixtures in laboratories.12.Regulating speed control on a roll of carpetwhilst rolling up in order to maintain the samestretch through the entire cloth.13. Controlling vacuum in tube expansion purposes.Temperature Range...................14°F to 122°F(-10°C to 50°C) Type......................................................EPDN Working MediumCompressed air or inert gases, filtered to min. 40µ, lubricated or non-lubricated, once lubricated air is supplied, this must be maintained.Parameter Setting ChangeableStandard User SettingValue Description Unit Action Resultparameters*000N/A1N/A2N/A3Back to factory settings Back to NormalSettings 401mA Set Setpoint Input to mA0(4)-20mA, (P29) 1V Set Setpoint Input to volt0-10V 600Alarm Output Set Output to Digital Alarm Output24V= In Band 1Analog Output Set Output to Analog Output0-10V~P_out 880 to 120100% F.S.Set Analog Output Span Span = 0-11V 1250 to 250100x 10 mbar Set Proporitonal Area0,5 to 2,5 bar13 2 to 4015x 10mbar Set Deadband Area20 to 400 mbar1400bar Change Display Reading bar 1PSI PSI15 1 to 2501x 10 mbar Set Slow Area0 to 2,5 bar1615*****Set Slow Steps Highest Speed to 20Lowest Speed 180 to 2000x 10 mbar Set Preset Pressure (x10 mbar)0 to 2 bar 190 to 100100 % F.S.Pressure Correction0 to P-max 200Custom Set Set Behavior Control P 12,13, 21 1Fastest Adjustable2Fast Only with33Normal0 Custom Set4Slow5Slowest21510Set Proportional Value Fastest Regulation to 100Slowest Regulation *Other parameter settings are available. Consult factory.How to Change Parameters:Pressing Accept key for more than 3 sec, will activateparameter change mode. User can select parameterby pressing up or down key on EPD. (display showsPxx). When parameter number is correct, pressingaccept again will enter parameter number. (displayshows parameter value now). Pressing the up or downkey will change the parameter. (blinking display pointshows parameter editing mode). Pressing the acceptkey will accept the new parameter value. (all digits willblink during acception). After releasing all keys , thenext parameter number will be presented on thedisplay. When no key is pressed, after 3 sec thedisplay will show the actual output pressure.Ordering-key SpecialsTypePassage Flow RateConnections SCFM Internal Thread 412 mm 63.61/2" BSPP 512 mm 63.61/2" NPT 825 mm 148.31" BSPP 925 mm148.31" NPTEPDN 4M 0145P 0U 10CMinimum Maximum MicroPressure Pressure Control Type ProcessorControlControlSignalOptionPressure Control-required minimum pressure,expressed in B bar of M mbar or PSI (preset pressure)-required maximum pressure (=F .S.*),expressed in B bar of M mbar or PSI (max. 12 bar or 174 PSI)Control Signal0U100 ± 10 VDC, Ri = 100 kohm 4I 20 4 ± 20 mA, Ri = 500 ohm 8BIT 8 Bit DigitalB bar P PSIOptionBlank No Option C Slow Start Function DSuitable for OxygenWelding Products EPDN Dimensions。

3-Way High-Response Valve withVCD ® TechnologyOperation Manual Series TPQDesign ≥ 46Bulletin HY11-5715-653/UKParker HannifinManufacturing Germany GmbH & Co. KG Hydraulic Controls Division Europe Gutenbergstr. 3841564 Kaarst, Germany Tel.: (+49) 181 99 44 43 0E-mail:********************Copyright © 2017, Parker Hannifin Corp.23-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin Corporation Hydraulics GroupTPQ 5715-653 UK 21.07.17Offer of SalePlease contact your Parker representation for a detailed ”Offer of Sale”.33-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin Corporation Hydraulics GroupTPQ 5715-653 UK 21.07.1743-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin Corporation Hydraulics GroupTPQ 5715-653 UK 21.07.171. IntroductionParker T PQ 3-way high-response valves with V C D ® technology have an integral electronic and requires only one sole electrical common for the control system. Different flow sizes are available to achieve an optimal adaption for different applications.Characteristics of Valve DriverThe described integral electronic driver combines all necessary functions for the optimal operation of the valve. Thanks to its excellent dynamic the valve is usable within closed loop control applications. The most important features are:Ordering CodePilot oil(supply external,drain external)SealDesign series(not required for ordering)Standard electronics Input signal2Code Seal N NBR V FPM Hfor HFC fluidsCode Signal range B 0...±10 V E 0...±20 mA S4...+20 mA• high dynamic actuator principle with special designed electronic driver• closed loop controlled spool position• constant current actuator control with overcur-rent shutoff• excellent properties for response sensitivity and temperature drift• differential input stage with various command signal options• diagnostic output for spool stroke • standard central connection• compatible to the relevant European EMC -standardsPlease order connector separatelyAngle female connector must be used for NG25 to NG50.53-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin Corporation Hydraulics GroupTPQ 5715-653 UK 21.07.17Blockdiagram of integrated electronicsE:mA0...20S:±1) Do not connect with the supply voltage zero.63-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin Corporation Hydraulics GroupTPQ 5715-653 UK 21.07.17Technical data1) If valves with onboard electronics are used in safety-related parts of control systems, in case the safety function is requested, the valveelectronics voltage supply is to be switched off by a suitable switching element with sufficient reliability.2) Accu port XX: Please contact Parker for installation recommendation.73-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin Corporation Hydraulics GroupTPQ 5715-653 UK 21.07.172. Safety InstructionsPlease read the operation manual before instal-lation, startup, service, repair or stocking! Paying no attention may result in damaging the valve or incorporated system parts.SymbolsThis manual uses symbols which have to be fol-lowed accordingly:Instructions with regard to possibledamaging of the valve or linked system components Helpful additional instructions Work at the ValveWorkings in the area of installation, commissioning, maintenance and repair of the valve may only be allowed by qualified personnel. T his means persons which have, because of education, experience and instruction, sufficient knowledge on relevant direc-tives and approved technical rules. 3. Important Details Intended UsageThis operation manual is valid for 3-way high-response valves TPQ series. Any different orbeyond it usage is deemed to be as not intended. The manufacturer is not liable for warranty claimsresulting from mon InstructionsWe reserve the right for technical modifications ofthe described product. Illustrations and drawings within this manual are simplified representations.Due to further development, improvement andmodification of the product the illustrations might not match precisely with the described valve. The technical specifications and dimensions are notbinding. No claim may resulting out of it. Copyrights are reserved.LiabilityThe manufacturer does not assume liability for damage due to the following failures:• incorrect mounting / installation • improper handling• lack of maintenance• operation outside the specificationssuspicion for a defect please contact Parker.Storage In case of temporary storage the valve must beprotected against contamination, atmospheric ex-posure and mechanical damages. Each valve has been factory tested with hydraulic oil, resulting in protection of the core parts against corrosion. Y etthis protection is only ensured under the following conditions: climate will lead to corrosion and might disable the valve!Storageperiod Storage requirements12 months constant humidity < 60 % as wellas constant temperature < 25 °C 6 months varying humidity as well as vary-ing temperature < 35 °C83-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin CorporationHydraulics GroupTPQ 5715-653 UK 21.07.17Available Bolt Kits• Remove protection plate from the valve mounting surface • C heck the proper position of the valve portsand the O-rings.•Mounting bolts: use property class 12.9, ISO 4762surface might create malfunction!Incorrect mounting resp. bolt torque mayresult in abrupt leakage of hydraulic fluid onthe valve ports.Y -port has always to be tied directly and separately to tank!Limits of Use The valve may be operated within the determined limits only. Please refer to the “technical data“ sec-tion as well as to the “characteristic curves“ in the Parker catalogue HY11-3500/UK "Hydraulic V alvesIndustrial Standard". lowable temperatures, shock load, aggresivechemicals exposure, radiation exposure, illegal electromagnetic emissions may result in operating trouble and may lead to failure!Follow the operating limits listed in the “speci-fications“ table!4. Mounting / InstallationScope of SupplyPlease check immediately after receiving the valve,if the content is matching with the specified scopeof supply. The delivery includes:• valve• operation manualThe central connector has to be ordered separately and is not included in the delivery. Please check the delivery immediately after receiving the shipment for apparent damages due to shipping. Report shipment losses atonce to the carrier and the supplier!Mounting• C ompare valve type (located on the name plate) with part list resp. circuit diagram.• The valve may be mounted fix or movable in any direction.• Verify the mounting surface for the valve. Uneve-ness of 0.01 mm/100 mm, surface finish of 6.3 µm are tolerable values. Keep valve mounting surface and work envi-ronment clean!Pressure FluidsThe following rules applies for the operation withvarious pressure fluids:does not substitute user tests among the particular operating conditions. Particularly no liabiliy for media compatibility may be derived out of it.Mineral oil: usable without restriction.HFC: choose the right seal option.For operation with the following pressure fluidsplease consult Parker: For detailed information concerning pressure fluids note V DMA-document 24317 as well as DIN 51524 & 51502.Special gaskets may be available depending onthe utilized fluid.In case of doubt please consult Parker.93-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin Corporation Hydraulics GroupTPQ 5715-653 UK 21.07.17The connecting cable has to comply to the follow-ing specification:Cable type control cable, flexible, 7 conductors, overall braid shield Cross section min. AWG16Outer dimension 8...12 mm Cable length max. 50 m For cable lengths > 50 m consult factory.The connection cable is coupled to the female connector by solder joints.Skinning lengths for the connecting cable:Electrical ConnectionThe electrical connection of the valve takes place by one common cable, which is coupled to the integrated electronic driver by a central connector assembly. The connection requires a 6 + PE female connector EN 175201-804.Female connector (ordering no. 5004072)For NG63 and NG807/8-20required! Plastic made models may create function problems due to insufficient EMC-characteristics.Do not disconnect cable socket under tension!Angled female connector (ordering no. 5005160)For NG25 to NG50103-Way high-response valve with VCD ®Series TPQOperation ManualParker Hannifin Corporation Hydraulics GroupTPQ 5715-653 UK 21.07.17Wiring diagram of supply voltageElectrical InterfacingSupply VoltageThe supply voltage for the valve has to cover the range of 22...30 V . Valve is de-energized below 19 V . The residual ripple may not exceed 5 % eff.The applied power supply must comply to the relevant regulations (DIN EN 61558) and must carry a CE-mark. The operating voltage for the valve must be free of inductive surges. Do not exceed the max. value of 30 V!Higher voltage can lead to failure of the valve.should be considered when selecting the power supply. A stabilized power supply with overcurrent limiting feature should not be used. Due to the inrush current of the valve the current limit circuit may respond prema-turely and create problems during energizingof the supply voltage.supply voltage polarity is interchanged.Each valve requires a separate pre-fuse of 4 Amp semi time-lag. Failure to observe this instruction may create irreparable damage of valve respectively incorporated system parts.The backshell nut of the cable gland has to be tighten with a suitable tool. The target value forthe tightening torque is 4 Nm. Tighten the cap nut with a torque of 5 Nm after attaching the female connector on the socket.Incomplete tightening of backshell nut respec-tively cap nut may result in undesired release of the connection as well as degradation of the water tightness.When using female connectors of other manufacturers, the relevant regulations must be observed. The cable may only be connected to the female connector by authorized and qualified person-nel. A short between individual conductors resp. to the connector housing , bad soldering as well as improper shield connection may result in malfunction and breakdown of the valve.The mounting surface of the valve has to be connected to the earth grounded machine frame. The earth ground wire from the valve connecting cable as well as the cable shield have to be tied to the protective earth termi-nal within the control unit. It is necessary to use a low ohmic potential connection between control unit and machine frame to prevent earth loops (cross section AWG 6).Command signal inputThe spool stroke behaves proportional to the com-mand signal amplitude.The command input signal needs to be filtered as well as free of inductive surges and modu-lations. Due to the sensitivity of the valve ahigh signal quality is recommended, this will prevent malfunction.Enable inputA signal voltage enables the actuator drive of the valve. Continuous operation of the valve requires a permanent voltage 5...30 V (i.e. the supply voltage). In case of disabling the signal the valve will reach its power down position spring-actuated independentlyfrom the command signal value.The enable function represents no safety ar-rangement against unwanted valve operation in terms of rules for accident prevention! The option 4...20 mA uses the “3.6 mA“ condition as breakdown-information. If the input signal line is interrupted, an evaluable failure information is available. In this case the actuator drive will be switched off. The drive will switch on when the input signal reaches a value of 3.8 mA, it switches off when the command falls below 3.6 mA. This determination follows the NAMUR-specifica-tion NE43.Diagnostics outputA diagnostics signal is available. Its voltage repre-sents the operating condition of the valve.Exceeding of this limit leads to malfunction.Valves NG25 to NG50Valves NG63 and NG80ProPxD parameterizing softwareThe ProPxD software permits comfortable param-eter setting for the module electronic. V ia the clearly arranged entry mask the parameters can be noticed and modified. Storage of complete parameter sets is possible as well as printout or record as a text file for further documentation.The PC software can be downloaded free of charge at /euro_hcd - see page “Support” or directly at /propxd. Please check periodical for updates.Cable SpecificationUSB interface, but can only be parametrized via an RS232C connection. Therefore the usage of USB standard cables is not allowed and may result in damaging of valve resp. PC .Hardware requirements• PC with operating system from Windows ® XP upwards• interface RS232C• display resolution min. 800 x 600• connection cable between PC and electronic module• storage requirement approx. 40 MBIf your PC has no serial interface according to RS232 standard you require in addition an USB-RS232C adapter.ParametrizingOrdering code: 40982923completion of the parametrizing work.Plug forparametering interface5. Operating InstructionsSupply pressure must be ensured before valve is energized.Solenoid Current MonitoringIf the actuator current time interval exceeds 10 seconds, the actuator is switched off to prevent overheating. For normal operating conditions thisstate will not reached, but it may occur with a con-taminated sluggish valve.In this case the reason for the contaminationshould be repaired (hydraulic fluid exchange, filtration review, valve flushing).The overcurrent shutoff condition may be resetted by temporary disconnection of the enable signal.The shutoff of the V C D actuator due to overload will be indicated via the diagnostics output.Air Bleeding of Hydraulic SystemDuring initial startup, after an oil change as well as after the opening of lines or valves the hydraulic system must be air bleeded.FilterThe function and lifetime of the valve are strongly affected by the cleanliness of the fluid.Purity level class of 18/16/13 acc. ISO4406 is required. Flushing It is recommended to flush the pipelines by short circuiting the pressure and return lines. T his prevents the installation dirt from entering the valve.malfunction at hydraulic load runtime - generally no function - high frequent oscillation - low frequent oscillation- speed variations at unchanging command - different speeds depending on travel direction - speed too low- drifting without command possible reasons for malfunctioncorrective actionsX hydraulic pump resp. motor defective replace hydraulic pump resp. motorX X X X X drive overloadedreduce pressure resp. speed, increase valve size X X X X X X valve contaminatedclean pressure fluid, filter / flush valveX Xhydraulic fluid too viscous / too cold change fluid grade, provide operational temperature X Xtoo low oil level within tank refill pressure fluid X X X filter contaminatedclean resp. replace filter X XX X supply voltage too lowkeep supply voltage range X supply voltage carries too much ripple reduce rippleX Xcommand signal too lowincrease command signal Xcommand signal carries too much ripple reduce rippleXcenter position adjustment incorrect check center position adjustment X X XX X contacts of central connector contaminatedclean contacts / replace plug Xfeed cable interrupted fix feed cableX X X X X X wiring sequence incorrect correct wiring sequence XX feed cable without shielding change cable grade6. TroubleshootingBasis of troubleshooting is always a systematicapproach.For suspect of a sluggish spool the valve maybe flushed with clean pressure fluid.T roubleshooting in a hydraulic system requiresdetailed knowledge about function and con-struction of the system. Therefore the work may exclusively be performed by qualified personnel.7. AccessoriesThe following accessories are available for the valve series TPQ*H:female connector 6+PE ordering code 5004072 Mounting bolts see table on page 8.Spare parts / seal kitsPlease direct technical product enquiries to: Parker HannifinManufacturing Germany GmbH & Co. KG Hydraulic Controls Division Europe Gutenbergstr. 3841564 Kaarst, GermanyT el.: (+49) 181 99 44 43 0E-mail:********************Hotline in EuropeTel.: 00800-2727-5374。

派克比例阀中文说明书引言：派克比例阀是一种用于控制流体流量的重要装置。

它通过调节阀芯的位置，使流体流经阀体时的流量与输入信号的比例保持一致。

本文将详细介绍派克比例阀的工作原理、结构组成、安装使用注意事项等内容，以便用户能更好地了解和操作派克比例阀。

第一部分：派克比例阀的工作原理派克比例阀采用先进的电磁比例调节技术，通过控制阀芯的位置来调节流体流量。

当输入信号改变时，阀芯位置也会相应地改变，从而实现流量的调节。

该阀具有快速响应、精确控制的特点，能够满足各种工况下的流量控制需求。

第二部分：派克比例阀的结构组成派克比例阀主要由阀体、阀芯、驱动器、比例电磁铁等组成。

阀体是整个阀的主体部分，用于容纳阀芯和驱动器。

阀芯是控制流体流量的关键部件，通过电磁铁的驱动来实现位置的调节。

比例电磁铁是阀芯的驱动器，能够根据输入信号的变化产生相应的电磁力，从而使阀芯运动。

第三部分：派克比例阀的安装使用注意事项1. 安装前应仔细检查派克比例阀的外观是否完好，阀体是否有损坏或漏油现象，阀芯是否灵活。

2. 在安装时，应确保派克比例阀与管道连接牢固，不得有松动或泄漏现象。

3. 安装位置应选择在通风良好、无腐蚀性气体和振动的环境中，以确保派克比例阀的正常运行。

4. 在使用过程中，应注意定期检查派克比例阀的工作状态，如有异常应及时处理。

5. 在操作派克比例阀时，应遵守相应的操作规程，避免过大的冲击力或过大的负荷对阀芯造成损坏。

6. 定期清洗和维护派克比例阀，保持其良好的工作状态。

7. 使用派克比例阀时应遵循相关的安全操作规范，确保人员和设备的安全。

结论：派克比例阀是一种重要的流量控制装置，具有快速响应、精确控制的特点。

本文介绍了派克比例阀的工作原理、结构组成和安装使用注意事项，希望能为用户提供一些有用的信息。

在使用派克比例阀时，用户应仔细阅读产品说明书，并按照相关规范进行操作，以确保其正常运行和延长使用寿命。
