OM-USB-1208FS, OM-USB-1408FSU L ow Cost, MultifunctionUSB Devices with 4 Differential or 8 Single-Ended Analog Inputs U P rovides 12-Bit (OM-USB-1208FS) or 14-Bit (OM-USB-1408FS) Analog Input Resolution U M aximum Sampling Rates Ranging from 1.2 kS/s to 50 kS/s U 2 Analog Outputs U 16 Digital I/O Lines U O ne 32-Bit Counter Input Channel U N o External Power RequiredThe OM-USB-1208FS and OM-USB-1408FS dataacquisition modules offer four differential (DIFF) or eight single-ended (SE) analog inputs, two analog outputs, 16 digital I/O channels, and one counter input.These modules are USB 2.0 full speed voltage input data acquisition modules (fully compatible with both USB 1.1 and USB 2.0 ports). These are plug-and-play modules which draw power from the USB cable - no external power supply is required. All configurable options (including individual channel ranges) are software programmable, and the modules are fully software calibrated.Both modules feature eight analog voltage input channels that are processed through a single A/D converter. The analog inputs to the OM-USB-1208FS are software configurable for either eight 11-bit single-ended or four 12-bit differential inputs. The analog inputs to the OM-USB-1408FS are software configurable for either eight 13-bit single-ended or four 14-bit differential inputs.These modules have one 32-bit counter channel. The digital I/O channels are software programmable for input or output. Both models have two 12-bit analog outputs. The packaging for the OM-USB-1208FS and OM-USB-1408FS ensures ease of use in a variety of applications.OM-USB-1208FS shown actual size.The OM-USB-1208FS and OM-USB-1408FS data acquisition modules are supplied with TracerDAQsoftware which is a collection of four virtual instrument applications used to graphically display and store input data and generate output signals:• S trip Chart—Log and graph values acquire from analog inputs, digital inputs, temperature inputs and counter inputs• O scilloscope—Display values acquired fromanalog inputs• F unction Generator—Generate waveforms for analog outputs•R ate Generator—Generate waveforms for counter outputsT racerDAQ PRO is an enhanced version of TracerDAQ. A comparison of some of the features included in TracerDAQ vs TracerDAQ PRO is shown on the next page.TracerDAQ Pro Strip Chartwith Measurements.TracerDAQ Strip Chart.digital input, event counter digital input, event counter Time-of-Day Triggering No YesMath Channel No YesFeatures ComparisonSOFTWAREOM-USB-1208FS and OM-USB-1408FS modules ship with an impressive array of software, including the new TracerDAQ®, a full-featured, out-of-the-box data logging, viewing, and analysis application. Driver support and detailed example programs are included for Universal Library programming libraries for Microsoft® Visual Studio® programming languages, and other languages, including DASYLab®, and ULx for NI LabVIEW®(comprehensive library of Vls and example programs compatible with 32-bit and 64-bit LabVIEW v8.5 through 2013) and InstaCal™ installation, calibration andtest utility - powerful solutions for programmers and nonprogrammers alike. These modules operate under Microsoft Windows® XP (32-bit only) and VIST A/7/8 (32-bit and 64-bit) operating systems.ANALOG INPUTOM-USB 1208FS: These devices provide eight, 11-bit single-ended analog inputs or four, 12-bit differential analog inputs.OM-USB 1408FS: These devices provide eight, 13-bit single-ended analog inputs or four, 14-bit differential analog inputs.All devices support software selectable ranges that provide inputs from ±1V to ±20V in a differential configuration, and ±10V in a single-ended configuration.OM-USB-1408FS8 SE/4 DIFF48 kS/s max2±6.0 mA per Pin1GENERAL INFORMATIONSAMPLING RATE: When scanning continuously to computer memory (hardware-paced mode), theOM-USB-1208FS can sample at a maximum of50 kS/s, and the OM-USB-1408FS can sample ata maximum of 48 kS/s.CHANNEL-GAIN QUEUEThe channel-gain queue feature lets you configure a list of channels and gains for each scan. Each channel can have a different gain setting. The gain settings are stored in a channel-gain queue list that is written to local memory on the device.The OM-USB-1208FS and OM-USB-1408FS channel-gain queue can contain up to 16 channels listed in any order.ANALOG OUTPUTThe maximum analog output update rate for all devices depends on several factors, including USB port speed. Both devices offer two 12-bit analog outputs with a range of 0V to 4.096V.When updating continuously from computer memory (hardware-paced mode), one analog output updates at a maximum rate of 10 kS/s; two analog outputs update simultaneously at a maximum rate of 5 kS/s each. DIGITAL I/OAll devices provide 16 TTL-level digital I/O lines. Digital I/O can be programmed on each 8-bit port (Port A and Port B) for either input (default) or output.EVENT COUNTER INPUTEach device supports one 32-bit TTL-level counter that accepts inputs up to 1 MHz.SPECIFICATIONSANALOG INPUTA/D Converter Type: Successive approximation Channels: 8 single-ended (SE) or 4 differential (DIFF), software programmableInput Common-Mode Voltage Range for Linear Operation:SE Mode: CHx to GND, ±10V maxDIFF Mode: CHx to GND, -10V min, 20V max Absolute Maximum Input Voltage: CHx to GND,±28V maxInput Impedance: 122 kΩRanges: Software selectable on a per-channel basis SE Mode: ±10VD IFF Mode: ±20V, ±10V, ±5V, ±4V, ±2.5V, ±2.0V,±1.25V, ±1.0VThroughput: Maximum throughput scanning to computer memory depends on the computer being used. Software Paced: 250 S/s typ, system-dependentHardware Paced:OM-USB-1208FS: 50 kS/sOM-USB-1408FS: 48 kS/sChannel Gain Queue: Up to 16 elements, software-selectable channel and rangeResolution:OM-USB-1208FS:DIFF: 12 bits, no missing codesSE: 11 bitsOM-USB-1408FS:DIFF: 14 bits, no missing codesSE: 13 bitsCAL Accuracy (OM-USB-1208FS Only):CAL = 2.5 V, ±36.25 mV maxIntegral Linearity ErrorOM-USB-1208FS: ±1 least significant bit (LSB) typ OM-USB-1408FS: ±2 LSB typDifferential Linearity Error: ±0.5 LSB typ Repeatability: ±1 LSB typCAL Current (OM-USB-1208FS Only):Source: 5 mA maxSink: 20 μA min, 100 μA typ2.5VREF Accuracy (OM-USB 1408FS Only):±36.25 mV max2.5VREF Output Current (OM-USB 1408FS Only): Source: 5 mA maxSink: 20 μA min, 100 μA typTrigger Source (Software-Selectable):External Digital: TRIG_INClock Source: Internal; External (SYNC), rising edgetriggeredANALOG OUTPUTNumber of Channels: 2Output Range: 0V to 4.096V, 1 mV per LSB Resolution: 12 bits, 1 in 4096Throughput: Maximum throughput scanning to computer memory depends on the computer being used S oftware Paced: 250 S/s single channel typ, system-dependentHardware Paced:Single Channel: 10 kS/sDual Channel: 5 kS/s Power On and Reset VoltageOM-USB-1208FS: Initializes to 000h codeO M-USB-1408FS: 0V, ±20 mV typ, initializes to 000h codeOutput Drive (Each D/A OUT): 15 mASlew Rate: 0.8V/μs typAccuracy (All Values are ±): 0V to 4.096V: 4.0 LSB typ, 45.0 LSB maxAnalog Output Accuracy Components(All Values are ±): 0V to 4.096V% of FSR: 0.1 typ, 0.9 maxGain Error at Full Scale: 4.0 mV typ, 36.0 mV max Offset: 1.0 mV typ, 9.0 mV max% of at Full Offset Scale ±2V0.2 4 9.766 13.766Least Significant Bit- Least Significant Bit-DIGITAL I/O Digital Type: CMOSNumber of I/O: 16 (Port A0 through A7, Port B0 through B7)Configuration: 2 banks of 8Pull Up/Pull-Down Configuration: All pins pulled up to 5V through 47 kΩ resistors (default); change to pull-down using internal user-configurable jumpers.Input High Voltage: 2.0V min, 5.5V absolute max Input Low Voltage: 0.8V max, -0.5V absolute min,0V recommended minOutput High Voltage (IOH = -6.0 mA): 3.84V min Output Low Voltage (IOL = 6.0 mA): 0.33V max Power On and Reset State: InputEXTERNAL TRIGGERTrigger Source: External digital, TRIG_INTrigger Mode: Edge sensitive; software-selectable for CMOS-compatible rising or falling edgeTrigger Latency: 10 μs maxTrigger Pulse Width: 1 μs minInput Type: Schmitt trigger, 47 kΩ pull-down to ground Schmitt Trigger Hysteresis: 1.01V typ, 0.6V min, 1.5V maxInput High Voltage Threshold: 2.43V typ, 1.9V min, 3.1V maxInput High Voltage Limit: 5.5V absolute maxInput Low Voltage Threshold: 1.42V typ, 1.0V min, 2.0V maxInput Low Voltage Limit: -0.5V absolute min, 0V recommended min EXTERNAL CLOCK INPUT/OUTPUTPin Name: SYNCPin Type: BidirectionalDirection (Software-Selectable):I nput (Default): Receives A/D clock from external source; active on rising edgeO utput: Outputs internal A/D clock; active on rising edgeInput Clock Rate:OM-USB-1208FS: 50 kHz, maxOM-USB-1408FS: 48 kHz, maxClock Pulse Width:Input Mode: 1 μs minOutput Mode: 5 μs minInput Type: Schmitt trigger, 47 kΩ pull-down to ground Schmitt Trigger Hysteresis: 1.01V typ, 0.6V min, 1.5V maxInput High Voltage Threshold: 2.43V typ, 1.9V min, 3.1V maxInput High Voltage Limit: 5.5V absolute maxInput Low Voltage Threshold: 1.42V typ, 1.0V min, 2.0V maxInput Low Voltage Limit: -0.5V absolute min,0V recommended minOutput High Voltage: 4.4V min (IOH = –50 μA),3.80V min (IOH = –8 mA)Output Low Voltage: 0.1V max (IOL = 50 μA),OM-USB-1408FSshown actual size.Ordering Example: OM-USB-1208FS 12-bit voltage input USB data acquisition module (4 DE/8 SE analog input channels, 16 digital I/O, 1 counter, 2 analog outputs) and OCW-1, OMEGACARE SM extends standard 1-year warranty to a total of 2 years.Input Type: Schmitt trigger, 47 k Ω pull-down to ground Input Source: CTR screw terminal Resolution: 32 bitsMaximum Input Frequency: 1 MHz High Pulse Width: 500 ns min Low Pulse Width: 500 ns minSchmidt Trigger Hysteresis: 1.01V typ, 0.6V min, 1.5V maxInput High Voltage Threshold: 2.43V typ, 1.9V min, 3.1V maxInput High Voltage Limit: 5.5V absolute maxInput Low Voltage Threshold: 1.42V typ, 1.0V min, 2.0V maxInput Low Voltage Limit: -0.5V absolute min, 0V recommended minPOWERSupply Current: 80 mA (total current requirement; includes up to 10 mA for the status LED)+5V USB Power Available: C onnected to Self-Powered Hub: 4.5V min, 5.25V max C onnected to Bus-Powered Hub: 4.1V min, 5.25V maxOutput Current (total amount of current that can be sourced from the USB 5 V , analog outputs and digital outputs): C onnected to Self-Powered Hub or Externally Powered Root Port Hub: 420 mA maxConnected to Bus-Powered Hub: 20 mA max NON-VOLATILE MEMORY EEPROM: 1024 bytesGENERALOperating Temperature Range: 0 to 70°C (32 to 158°F), 0 to 90% RH non-condensing Storage Temperature Range: -40 to 70°C (-40 to 158°F), 0 to 90% RH non-condensing Communications: USB 2.0 Hi-speed mode (480 Mbps) is recommended; otherwise USB 1.1 full-speed mode (12 Mbps)Microcontroller Type: High performance 32-bit RISC Signal I/O Connector Type: Screw terminal USB Cable Length: 3 m (9.84') max Dimensions: 79 L x 82 W x 27 mm H (3.10 x 3.20 x 1.05") Weight: 91 g (3.2 oz)TracerDAQ Pro Strip Chartwith Measurements.TracerDAQ Strip Chart.OMEGACARE SM extended warranty program is available for models shown on this page. Ask your sales representative for full details when placing an order. OMEGACARE SM covers parts,labor and equivalent loaners.。
