开式(普通)冲床基本参数表

冲床技术参数解释J23系列开式双柱可倾压力机J21系列开式双柱固定台压力机，主要参数说明以下几个问题：1反映了一台压力机的工艺能力和加工零件的尺寸范围2反映压力机生产效率3是设计压力机重要依据4用户根据成型工艺要求和生产率选择压力机参数是否合适1、公称压力滑块离下死点某一特定距离（公称力行程）或曲柄转角离下死点前某一特定角度（公称压力角）时，滑块上所有容许承受的最大作用力。

例如：J21-110，1100千牛开式单点压力机，公称力1100千牛，公称力行程S P离下死点距离为5mm。

公称力是压力机主要工作性能参数，是计算压力机零件强度和刚度基本根据压力机受力零件可以分成三类：一类零件——床身、滑块、连杆、调节螺杆和保险块，此类零件的强度和刚度按公称力设计，它的强度和刚度不受曲柄转角变化而变化，作用力常数。

二类零件——齿轮、传动轴和离合器制动器、旋转零件，此类零件的强度与刚度，按公称力作用下产生的公称扭矩设计的，它的零件强度和刚度随着曲柄转角变化而变化。

扭矩为常数(忽略弯距的影响)三类零件——曲轴，它的强度于刚度既要考虑公称力作用下的弯距，又要考虑曲轴传递的扭矩，属于弯扭联合作用，所以曲轴强度也是随着曲柄转角变化而变化。

根据以上三种零件的强度可以绘制出滑块允许负荷图，用户厂的加工零件的工艺负荷图不能超过滑块允许负荷图曲线之外，否则会损坏压力机零件。

举例说明：Sp=5mm(α=18度)——离下死点距离为5mm时产生公称力（吨位）S P<S ;S>S P当公称行程S在这两种情况下压力机有关零件受力情况有所不同2、滑块行程滑块行程指滑块从上死点到下死点所经过的距离，行程是曲轴偏心的2倍1滑块行程大小，随着工艺用途和公称力的不同而变化，落料与冲孔工序一般不需要大的滑块行程。

2浅拉伸要求滑块行程大点，此时滑块行程一般不应小于拉伸件高度的3倍，此外还要考虑到上模在上死点时不与模具导柱脱开。

3大吨位的压力机一般都有工件顶出装置，为了使工件在顶出过程中不损坏工件而且便于取出，滑块行程也要增加。

冲床知识讲座一、主要技术参数1．公称压力Pg曲柄压力机的公称压力（即额定压力）是指滑块离下死点前某一特定距离（即公称压力行程Sg）或曲柄旋转到离下死点前某一特定角度（即公称压力角αg）时，滑块所容许承受的最大作用力，单位N或kN。

2．滑块行程S滑块行程为滑块从上死点到下死点直线距离，单位mm。

3．滑块单位时间的行程次数n行程次数为滑块每分钟从上死点到下死点再回到上死点的往返次数。

压力机的行程次数应能保证生产率，同时必须考虑操作者的操作频率不能超过承受能力，造成疲劳作业。

4．装模高度H装模高度为滑块在下死点时，滑块底平面到工作垫板上表面的距离，单位mm。

当滑块调节到上极限位置时，装模高度达到最大值，称为最大装模高度。

封闭高度是指滑块在下死点时，滑块底平面到工作台上表面的距离，单位mm。

封闭高度和装模高度之差恰好是垫板厚度。

其他参数还有工作台板和滑块底面尺寸、喉深及立柱间距等。

压力机装设安全装置时要考虑这些参数。

二、曲柄压力机组成根据压力机的传动方式、结构形式及产生压力的方式等不同，可有多种类型。

按传动方式不同，可分为机械传动、液压传动、电磁及气动压力机；按机身结构不同，可分为开式和闭式机身压力机；按产生压力的方式不同，机械压力机又可分为摩擦压力机和曲柄压力机。

机械传动的曲柄压力机使用量最大，是我国工业部门中最基本、最常见的压力机械类型。

其中，中、小吨位开式机身机械式曲柄压力机使用量多，手工操作比例大，相应的事故率也高。

本章将重点讨论开式机身机械式曲柄压力机。

曲柄压力机由机身、动力传动系统、工作机构和操纵系统组成。

1．机身机身由床身、底座和工作台三部分组成，工作台上的垫板用来安装下棋。

机身大多为铸铁材料，而大型压力机采用钢板焊接而成。

机身首先要满足刚度、强度条件，有利于减振降噪，保证压力机的工作稳定性。

2．动力传动系统动力传动系统由电动机、传动装置（齿轮传动或带传动）以及飞轮组成，其中电动机和飞轮是动力部件。

125t冲床参数全文共四篇示例，供读者参考第一篇示例：125t冲床是一种用于冲压加工的机械设备，它具有高效、精度高、使用方便等优点，被广泛应用于汽车、家电、电子、五金等行业。

冲床的参数设置对产品加工质量和生产效率有很大影响，下面我们将详细介绍125t冲床的参数设置及其对产品加工的影响。

1. 冲床的额定冲击力：125t冲床的额定冲击力是指在正常工作状态下，冲床在一次完整冲裁过程中所施加的最大力量。

额定冲击力直接影响到产品的成形效果和加工效率，如果冲床的额定冲击力过小，可能导致产品冲裁不完整或变形，严重影响产品质量；如果冲床的额定冲击力过大，会增加机械设备的负荷，可能损坏设备或缩短设备的使用寿命。

2. 冲床的最大冲床行程：125t冲床的最大冲床行程是指冲床上下运动的最大距离，也就是冲床的最大有效冲裁部分的高度。

最大冲床行程的设置要根据产品的设计要求和加工工艺来确定，过小会导致产品无法完整冲裁，过大会浪费材料和加工时间。

3. 冲床的冲击频率：125t冲床的冲击频率是指在单位时间内冲床的冲击次数，一般以每分钟冲击次数来表示。

冲击频率的设置要根据产品的加工要求来确定，过高的冲击频率会增加机械设备的磨损和噪音，过低的冲击频率会降低生产效率。

4. 冲床的极限冲裁厚度：125t冲床的极限冲裁厚度是指冲床能够冲裁的最大材料厚度。

极限冲裁厚度的设置要考虑到材料的硬度和强度，过厚的材料会导致冲床受力过大，可能损坏设备或产生危险；过薄的材料则会影响产品的成形效果。

125t冲床的参数设置对产品加工质量和生产效率有很大影响，正确合理地设置冲床的参数可以提高产品的成形质量和加工效率，减少生产成本，提高企业竞争力。

希望本文对您了解125t冲床的参数设置有所帮助。

第二篇示例：125t冲床是一种用于金属加工的机械设备，其参数是决定其工作性能和加工效果的重要因素。

下面将详细介绍125t冲床的参数及其影响。

125t冲床的参数包括冲击力、冲床床身尺寸、冲模间距等。

技术方案NTC-80、110、160 吨高精密冲床南通锻压设备股份有限公司2013年7月1 综述本高精密冲床是我公司根据市场需求和发展方向，集合国外先进的设计工而成，具有精持好，机床钢性强的特点，适用于冲孔、落料、浅拉伸等加工。

附机器照片：地址：江苏省如皋经济开发区柴湾工业园区ADD:Chaiwan Industrial Zone,Rugao City,Jangsu Province，P.R.China地址：江苏省如皋经济开发区柴湾工业园区ADD:Chaiwan Industrial Zone,Rugao City,Jangsu Province，P.R.China主要结构及技术性能情况1.1机身采用高质Q235A钢板焊接结构，熱时效消除内应力处理，钢性好，机身加工是采用进口机床（捷克落地镗床）一次装夹加工完成，主要传动轴承采用合金铜，经液氮速冻后再组入机身，让它在一定时间内膨胀到二者合一后，进行精加工。

所以精度完全保证在0.03mm之内。

底脚配置减震垫，具有高强的减震效果。

1.2曲轴纵放，结构紧凑，外形美观；材质为42CrMo锻打而成、后经专业检测仪器对材料进行探视，确保材质及密度达标，完成强度检验后，再经过调质、高频处理、精密研磨加工而成，完全精度保证在0.01mm之内。

1.3滑块采用高质原材料铸造结构，具有极高的吸震效果。

经回火消除内应力处理。

采用六面体矩形导轨，导轨材质均采用合金铜，耐磨性高、稳定性好、精度高。

装模高度调节装置：封闭式高度电动调节，滑块装模高度的显示精度为0.1mm。

内置传动涡轮，确保在调节模高时的平稳度和精度。

滑块内采用日本昭和液压过载保护装置：气液式超过额定吨位约10％产生过载反应，滑块自动停止，确保机身等主要部件不受任何损坏。

采用气动平衡缸来平衡滑块及上模的重量，稳定性强、精度保持性好；1.4采用意大利进口气动组合式摩擦离合器——制动器，为低惯量干式离合器、制动器、双阀故障检测。

冲床知识讲座一、主要技术参数1．公称压力Pg曲柄压力机的公称压力（即额定压力）是指滑块离下死点前某一特定距离（即公称压力行程Sg）或曲柄旋转到离下死点前某一特定角度（即公称压力角αg）时，滑块所容许承受的最大作用力，单位N或kN。

2．滑块行程S滑块行程为滑块从上死点到下死点直线距离，单位mm。

3．滑块单位时间的行程次数n行程次数为滑块每分钟从上死点到下死点再回到上死点的往返次数。

压力机的行程次数应能保证生产率，同时必须考虑操作者的操作频率不能超过承受能力，造成疲劳作业。

4．装模高度H装模高度为滑块在下死点时，滑块底平面到工作垫板上表面的距离，单位mm。

当滑块调节到上极限位置时，装模高度达到最大值，称为最大装模高度。

封闭高度是指滑块在下死点时，滑块底平面到工作台上表面的距离，单位mm。

封闭高度和装模高度之差恰好是垫板厚度。

其他参数还有工作台板和滑块底面尺寸、喉深及立柱间距等。

压力机装设安全装置时要考虑这些参数。

二、曲柄压力机组成根据压力机的传动方式、结构形式及产生压力的方式等不同，可有多种类型。

按传动方式不同，可分为机械传动、液压传动、电磁及气动压力机；按机身结构不同，可分为开式和闭式机身压力机；按产生压力的方式不同，机械压力机又可分为摩擦压力机和曲柄压力机。

机械传动的曲柄压力机使用量最大，是我国工业部门中最基本、最常见的压力机械类型。

其中，中、小吨位开式机身机械式曲柄压力机使用量多，手工操作比例大，相应的事故率也高。

本章将重点讨论开式机身机械式曲柄压力机。

曲柄压力机由机身、动力传动系统、工作机构和操纵系统组成。

1．机身机身由床身、底座和工作台三部分组成，工作台上的垫板用来安装下棋。

机身大多为铸铁材料，而大型压力机采用钢板焊接而成。

机身首先要满足刚度、强度条件，有利于减振降噪，保证压力机的工作稳定性。

2．动力传动系统动力传动系统由电动机、传动装置（齿轮传动或带传动）以及飞轮组成，其中电动机和飞轮是动力部件。

通用设备经济寿命年限参考表专用设备经济寿命年限参考表注：1.根据设备单价的大小及其体积重量及所处地区交通条件选定具体费率。

单价高、体积小、重量轻、交通方便地区的取低值，反之取高值。

2.特殊情况或用空运等可按实估算。

人民币存贷款利率调整表2011年4月6日表一机动车总成、部件价值权分参考表（英文版）Two regulations promulgated for implementation is in the party in power for a long time and the rule of law conditions, the implementation of comprehensive strictly strategic plan, implementation in accordance with the rules and discipline to manage the party, strengthen inner-party supervision of major initiatives. The two regulations supporting each other, the < code > adhere to a positive advocate, focusing on morality is of Party members and Party leading cadres can see, enough to get a high standard; < rule > around the party discipline, disciplinary ruler requirements, listed as "negative list, focusing on vertical gauge, draw the party organizations and Party members do not touch the" bottom line ". Here, the main from four square face two party rules of interpretation: the first part introduces two party Revised regulations the necessity and the revision process; the second part is the interpretation of the two fundamental principles of the revision of laws and regulations in the party; the third part introduces two party regulations modified the main changes and needs to grasp several key problems; the fourth part on how to grasp the implementation of the two regulations of the party. < code > and < Regulations > revised the necessity and revised history of the CPC Central Committee the amendment to the Chinese Communist Party members and leading cadres honest politics several guidelines > and < Chinese Communist Party discipline and Punishment Regulations > column 1 by 2015 to strengthenparty laws and regulations focus. Two party regulations revision work lasted a Y ears, pooling the wisdom of the whole party, ideological consensus, draw historical experience, respect for the wisdom of our predecessors, which reflects the unity of inheritance and innovation; follow the correct direction, grasp the limited goals, adhere to the party's leadership, to solve the masses of the people reflect a focus on the problem. The new revision of the < code > and < rule >, reflects the party's 18 and the eighth session of the third, the spirit of the fourth plenary session, reflecting the experience of studying and implementing the General Secretary Xi Jinping series of important speech, reflects the party's eighteen years comprehensive strictly practice. (a) revised two regulations of the party need of < the ICAC guidelines > in < in 1997 Leaders as members of the Communist Party of China clean politics certain criteria (Trial) > based on revised, the promulgation and implementation of January 2010, to strengthen the construction of the contingent of leading cadres play an important role. But with the party to manage the party strictly administering the deepening, has not been able to fully meet the actual needs. Content is too complicated, "eight prohibition, 52 are not allowed to" hard to remember, and also difficult to put into practice; the second is concisely positive advocated by the lack of prohibited provisions excessive, no autonomy requirements; the third is banned terms and discipline law, both with the party discipline, disciplinary regulationsrepeat and Criminal law and other laws and regulations repeat; the fourth is to "clean" the theme is not prominent, not for the existing problems, and is narrow, only needle of county-level leading cadres above. < rule > is in 1997 < Chinese Communist Party disciplinary cases (Trial) > based on revision, in December 2003 the promulgation and implementation, to strengthen the construction of the party play very important role. Along with the development of the situation, which many provisions have been unable to fully meet the comprehensive strictly administering the practice needs. One is Ji law, more than half of the provisions and criminal law and other countries laws and regulations Repetition; two is the political discipline regulations is not prominent, not specific, for violation of the party constitution, damage the authority of Party Constitution of misconduct lack necessary and serious responsibility to pursue; third is the main discipline for the leading cadres, does not cover all Party members. Based on the above situation, need to < the criterion of a clean and honest administration > and < rule > the two is likely to be more relevant regulations first amendment. By revising, really put the authority of Party discipline, the seriousness in the party tree and call up the majority of Party members and cadres of the party constitution of party compasses party consciousness. (II) two party regulations revision process the Central Committee of the Communist Party of China attaches great importance to two regulations revision . Xi Jinping, general books recorded in the FifthPlenary Session of the eighth session of the Central Commission for Discipline Inspection, on the revised regulations < > made clear instructions. According to the central deployment, the Central Commission for Discipline Inspection from 2014 under six months begin study two regulations revision. The Standing Committee of the Central Commission for Discipline Inspection 4 review revised. Comrade Wang Qishan 14 times held a special meeting to study two regulations revision, amendment clarifies the direction, major issues of principle, path and target, respectively held a forum will listen to part of the province (area) secretary of the Party committee, Secretary of the Discipline Inspection Commission, part of the central ministries and state organs DepartmentThe first party committee is mainly responsible for people, views of experts and scholars and grassroots party organizations and Party members. Approved by the Central Committee of the Communist Party of China, on 7 September 2015, the general office of the Central Committee of the Party issued a notice to solicit the provinces (autonomous regions, municipalities) Party, the central ministries and commissions, state ministries and commissions of the Party (party), the General Political Department of the military, every 3 people organization of Party of two regulations revision opinion. Central Commission for Discipline Inspection of extensive solicitation of opinions, careful study, attracting, formed a revised sent reviewers. In October 8 and October 12, Central Committee PoliticalBureau Standing Committee and the Political Bureau of the Central Committee After consideration of the two regulations revised draft. On October 18, the Central Committee of the Communist Party of China formally issued two regulations. Can say, two laws amendment concentrated the wisdom of the whole party, embodies the party. Second, < code > and < Regulations > revision of the basic principles of two party regulations revision work and implement the party's eighteen, ten eight plenary, the spirit of the Fourth Plenary Session of the Eleventh Central Committee and General Secretary Xi Jinping important instructions on the revised < low political criterion > and < Regulations >, highlighting the ruling party characteristics, serious discipline, the discipline quite in front of the law, based on the current, a long-term, advance as a whole, with Bu Xiuding independent < rule > and < rule >. Main principle is: first, adhere to the party constitution to follow. The constitution about discipline and self-discipline required specific, awaken the party constitution of party compasses party consciousness, maintaining the authority of the constitution. General Secretary Xi Jinping pointed out that "no rules, no side round. Party constitution is the fundamental law, the party must follow the general rules. In early 2015 held the eighth session of the Central Commission for Discipline Inspection Fifth Plenary Session of the 16th Central Committee, Xi Jinping again pointed out that constitution is the party must follow the general rules, but also the general rules." the revisionof the < code > and < rule > is Method in adhere to the regulations established for the purpose of combining rule of virtue is to adhere to the party constitution as a fundamental to follow, the constitution authority set up, wake up the party constitution and party rules the sense of discipline, the party constitution about discipline and self-discipline specific requirements. 4 second is to adhere to in accordance with the regulations governing the party and the party. The Party of rule of virtue "de", mainly refers to the party's ideals and beliefs, excellent traditional style. The revised the < code > closely linked to the "self-discipline", insisting on the positive initiative, for all members, highlight the "vital few", emphasized self-discipline, focusing on the morality, and the majority of Party members and the ideological and moral standards. The revised < > Ji method separately, Ji, Ji Y an to Method, as a "negative list", emphasizing the heteronomy, focusing on vertical gauge. Is this one high and one low, a positive reaction, the strict party discipline and practice results transformation for the integration of the whole party to observe moral and discipline requirements, for the majority of Party members and cadres provides benchmarking and ruler. Third, insist on to. In view of the problems existing in the party at the present stage, the main problems of Party members and cadres in the aspect of self-discipline and abide by the discipline to make clearly defined, especially the party's eighteen years strict political discipline and political rules, organization and discipline andto implement the central eight provisions of the spirit against the four winds and other requirements into Disciplinary provisions. Not one pace reachs the designated position, focusing on in line with reality, pragmatic and effective. After the revision of major changes, major changes in the < code > and < rule > modified and needs to grasp several key problems (a) < code > < code > adhere to according to regulations governing the party and party with morals in combination, for at the present stage, the leadership of the party members and cadres and Party members in existing main problems of self-discipline, put forward principles, requirements and specifications, showing Communists noble moral pursuit, reflected at all times and in all over the world ethics from high from low 5 common requirements. One is closely linked to the "self-discipline", removal and no direct relation to the provisions of . the second is adhere to a positive advocate, "eight prohibition" 52 are not allowed to "about the content of the" negative list moved into synchronization amendment < cases >. Three is for all the party members, will apply object from the leadership of the party members and cadres to expand to all Party members, fully embodies the comprehensive strictly required. The fourth is prominent key minority, seize the leadership of the party members and cadres is the key, and put forward higher requirements than the ordinary Party members. Five is to simplify, and strive to achieve concise, easy to understand, easy to remember. The revised < code > is the ruling Party since the first insists ona positive advocate forAll Party members and the self-discipline norms, moral declaration issued to all members of the party and the National People's solemn commitment. > < criterion of a clean and honest administration consists of 4 parts, 18, more than 3600 words. After the revision of the < code >, a total of eight, 281 words, including lead, specification and Party member cadre clean fingered self-discipline norms, etc. Part 3 members low-cost clean and self-discipline, the main contents can be summarized as "four must" "eight code". Lead part, reiterated on ideal and faith, fundamental purpose, the fine traditions and work style, noble sentiments, such as "four must" the principle of requirements, strong tone of self-discipline, The higher request for 6 and supervised tenet, the foothold in permanent Bao the party's advanced nature and purity, to reflect the revised standards requirements. Members of self-discipline norms around the party members how to correctly treat and deal with the "public and private", "cheap and rot" thrifty and extravagance "bitter music", put forward the "four norms". Party leader cadre clean fingered self-discipline norms for the leadership of the party members and cadres of the "vital few", around the "clean politics", from civil servant of the color, the exercise of power, moral integrity, a good family tradition and other aspects of the leadership of the party members and cadres of the "four norms" < > < norm norm. "The Party member's self-discipline norms" and "party members and leading cadre clean fingered self-discipline norms," atotal of eight, collectively referred to as the "eight". "Four must" and "eight" of the content from the party constitution and Party's several generation of leaders, especially Xi Jinping, general secretary of the important discussion, refer to the "three discipline and eight points for attention" statements, and reference some embody the Chinese nation excellent traditional culture essence of epigrams. (2) the revised regulations, the main changes in the revised Regulations > to fully adapt to the strictly requirements, reflects the according to the regulations governing the law of recognition of deepening, the realization of the discipline construction and Jin Ju. < rule > is party a ruler, members of the basic line and follow. And the majority of Party members and cadres of Party organizations at all levels should adhere to the bottom line of thinking, fear discipline, hold the bottom line, as a preventive measure, to keep the party's advanced nature and purity. 1, respect for the constitution, refinement and discipline. Revised < rule > from comprehensive comb physical constitution began, the party constitution and other regulations of the Party of Party organizations and Party discipline requirements refinement, clearly defined in violation of the party constitution will be in accordance with regulations to give the corresponding disciplinary action. The original 10 categories of misconduct, integration specification for political discipline, discipline, honesty and discipline masses Ji Law and discipline and discipline and other six categories, the content of < rule >real return to Party discipline, for the majority of Party members and listed a "negative list. 7 2, highlighting the political discipline and political rules. > < Regulations according to the stage of the discipline of outstanding performance, emphasizing political discipline and political rules, organization and discipline, in opposition to the party's leadership and the party's basic theory, basic line, basic program and basic experience, the basic requirement of behavior made prescribed punishment, increase the cliques, against the organization such as violation of the provisions, to ensure that the central government decrees and the Party of centralized and unified. 3, adhere to strict discipline in the law and discipline In front, Ji separated. Revised < Regulations > adhere to the problem oriented, do Ji separated. Any national law existing content, will not repeat the provisions, the total removal of 79 and criminal law, repeat the content of the public security management punishment law, and other laws and regulations. In the general reiterated that party organizations and Party members must conscientiously accept the party's discipline, die van comply with national laws and regulations; at the same time, to investigate violations of Party members and even criminal behavior of Party discipline and responsibility, > < Regulations distinguish five different conditions, with special provisions were made provisions, so as to realize the connection of Party discipline and state law. 4, reflect Wind building and anti-corruption struggle of the latest achievements. < rule > the party's eighteen yearsimplement the spirit of the central provisions of the eight, against the requirements of the "four winds" and transformation for disciplinary provisions, reflecting the style construction is always on the road, not a gust of wind. In the fight against corruption out of new problems, increase the trading rights, the use of authority relatives profit and other disciplinary terms. Prominent discipline of the masses, the new against the interests of the masses and ignore the demands of the masses and other disciplinary terms and make provisions of the disposition and the destruction of the party's close ties with the masses.Discipline to protect the party's purpose. 8 of these regulations, a total of three series, Chapter 15, 178, more than 24000 words, after the revision of the regulations a total of 3 series, Chapter 11, 133, 17000 words, divided into "general" and "special provisions" and "Supplementary Provisions" Part 3. Among them, add, delete, modify the provisions of the proportion of up to nearly 90%. 1, the general general is divided into five chapters. The first chapter to the regulations of the guiding ideology, principles and scope of application of the provisions, highlight the strengthening of the party constitution consciousness, maintenance the authority of Party Constitution, increase the party organizations and Party members must abide by the party constitution, Y an Centralized centralized, would examine at all levels of the amended provisions implementing and maintaining Party discipline, and consciously accept the party discipline,exemplary compliance with national laws and regulations. The second chapter of discipline concept, disciplinary action types and effects of the regulations, will be a serious warning from the original a year for a year and a half; increase the Party Congress representative, by leaving the party above (including leave probation) punishment, the party organization should be terminated its representative qualification provisions. The third chapter of the disciplinary rules of use prescribed in the discipline rectifying process, non convergence, not close hand classified as severely or heavier punishment. "Discipline straighten "At least eighteen years of five years, these five years is to pay close attention to the provisions of the central eight implementation and anti -" four winds ". The fourth chapter on suspicion of illegal party disciplinary distinguish five different conditions, with special provisions were made provisions, to achieve effective convergence of Party and country 9 method. < rule > the provisions of Article 27, Party organizations in the disciplinary review found that party members have committed embezzlement, bribery, dereliction of duty dereliction of duty and other criminal law act is suspected of committing a crime shall give cancel party posts, probation or expelled from the party. The second is < Regulations > Article 28 the provisions of Party organizations in the disciplinary review But found that party members are stipulated in the criminal law, although not involved in a crime shall be investigated for Party discipline and responsibility shouldbe depending on the specific circumstances shall be given a warning until expelled punishment. This situation and a difference is that the former regulation behavior has been suspected of a crime, the feeling is quite strict, and the latter for the behavior not involving crime, only the objective performance of the provisions of the criminal code of behavior, but the plot is a crime to slightly. < Regulations > the 29 provisions, Party organizations in the discipline review found that party members and other illegal behavior, affect the party's image, the damage to the party, the state and the people's interests, we should depend on the situation Seriousness given disciplinary action. The loss of Party members, seriously damaging the party's image of behavior, should be given expelled from the party. At this article is party member is in violation of the criminal law outside the other illegal acts, such as violates the public security administration punishment law, customs law, financial laws and regulations behavior. The fourth is < cases > Article 32 stipulates, minor party members and the circumstances of the crime, the people's Procuratorate shall make a decision not to initiate a prosecution, or the people's court shall make a conviction and exempted from criminal punishment shall be given within the party is removed from his post, probation or expelled from the party. Party members and crime, sheets were fined in accordance with For acts; the principal Ordinance amended the provisions of the preceding paragraph. This is the new content, in order to achieve Ji method effectiveconvergence. Five is < > the thirty third article 10 of the provisions, the Party member due to an intentional crime is sentenced to criminal law (including probation) sheets or additional deprivation of political rights; due to negligence crime and was sentenced to three years or more (excluding three years) a penalty, shall give expelled punishment. Due to negligence crime is convicted and sentenced to three years (including three years) in prison or be sentenced to public surveillance, detention, shall in general be expelled from the party. For the individual may not be expelled from the party, should control Approval. This is followed and retained the original > < Regulations the provisions of punishment party authorization rules and report to a level party organizations. For is "party members with criminal acts, and by the criminal punishment, generally should be expelled from the party". The fifth chapter of probationary Party member of the discipline and discipline after missing members of the treatment and punishment decisions, such as the implementation of the provisions, clear the related party discipline and punishment decision made after, for duties, wages and other relevant alteration formalities for the longest time. 2, sub sub section will the original regulations of10 categories of acts of violation of discipline integration revised into 6 categories, respectively, in violation of the punishments for acts of political discipline "in violation of discipline behavior of punishment" in violation of integrity of disciplinary action points "of violation punishments for actsof mass discipline" "the violation of work discipline, punishment" in violation of discipline of life behavior punishment "6 chapters. 3, annex" Supplementary Provisions "clear authority making supplementary provisions of, cases of interpretative organ, as well as regulations implementation time and retroactivity etc.. 11 (3) learning understanding > < regulations needs to grasp several key problems The first problem -- about the violation of political discipline behavior > < new ordinance chapter 6 the political discipline column for the six disciplines, that is the main opposition to Party leadership and the opposition of the basic theory, basic line, basic program and basic experience, basic requirements of misconduct made provisions of the disposition, especially the eighteen since the CPC Central Committee put forward the Yan Mingzheng treatment of discipline and political rules requirements and practical achievements transformation for Discipline article, increase the false debate central policies, cliques, against the organization review, make no discipline of the principle of harmony terms. These are the party's eighteen years in comprehensive strictly Process combined with the practice of rich content. (1) false debate the central policies and undermine the Party of centralized and unified the problem is made in accordance with the provisions of the party constitution. Constitution in general programme requirements adhere to democratic centralism is one of the requirements of the construction of the party must adhere to the four cardinal. Applicationof this principle is not only the party the basic organization principle and is also the mass line in party life, it requires that we must fully develop inner-party democracy, respect for the dominant position of Party members, safeguarding the Party member democratic rights, give full play to the enthusiasm and creativity of the party organizations at all levels and Party members, at the same time, also must implement the right concentration, ensure the party's mission < the chaos in unity and concerted action to ensure that the party's decision to get quickly and effectively implementing. The Party Central Committee formulated the major principles and policies, through different channels and ways, fully listen to the party organizations and Party members of the opinions and suggestions, but 12 is some people face to face not to say back blather "" will not say, after the meeting said, "" Taiwan does not say, and nonsense ", in fact, not only disrupt the people thought, some causing serious consequences, the damage to the Party of the centralized and unified, hinder the central policy implementation, but also a serious violation of the democratic system of principles. There is no doubt that shall, in accordance with the Regulations > 4 Specified in Article 6 to give the appropriate punishment. For did not cause serious consequences, to give criticism and education or the corresponding tissue processing. (2) about the destruction of the party's unity < New Regulations > the forty eighth to fifty second article, to damage Party's unity unified and violation of political discipline, punishment situationmade explicit provisions. Article 52 of the new "in the party get round group, gangs seek private gain, cliques, cultivate private forces or through the exchange of interests, for their own to create momentum and other activities to gain political capital, given a serious warning or withdraw from their party posts disposition; if the circumstances are serious, to give Leave a party to observation or expelled from the party. (3) on against the organization review of the provisions of the constitution, party loyalty honesty is party members must comply with the obligations. Members must obey the organization decision, shall not violate the organization decided encounters by asking questions to find organization, rely on the organization, shall not deceive the organization, against the organization. For example, after the investigation does not take the initiative to explain the situation, but to engage in offensive and defensive alliance, hiding the stolen money is against survey organization, is a violation of the behavior of political discipline. Article 24 of the original > < Regulations, although the provisions of the interference, hinder group review the behavior of the fabric can be severely or 13 Aggravated punishment, but did not put this kind of behavior alone as a discipline for qualitative amount of discipline. > < new regulations increase the Article 57, "anti organization review, one of the following acts, given a warning or serious warning; if the circumstances are relatively serious, giving removed from or placed on probation within the party post; if the circumstances are serious, give。

JF21系列干式离合、压塌式保险开式固定台压力机
■ 钢板焊接高刚度机身；
■ 主电机采用西门子电机；
■ 组合式干式气动摩擦离合器、制动器；
■ 齿轮副浸油润滑；
■ 矩形六面加长导轨；
■ 刚性压塌式保险器；
■ JF21-25/25B/45手动调模，其中JF21-25/45刻度指示，JF21-25B数字显示；■ JF21-63以上电动调模，数码显示；
■ 其中JF21-45可选配电动调模，数码显示；
■ 滑块装设了上提式平衡缸装置（除JF21-25以外）；
■ 进口双联电磁阀；
■ JF21-160及以上采用电动浓油强制润滑系统；
■ 平衡缸采用手动稀油润滑系统；
■ 配一组吹件装置；
■ 国际品牌PLC控制；
■ 国际品牌接触器、按钮、指示灯；
■ 可选配气垫装置，自动送料轴装置，光电保护装置，可搭配各种自动化设备。
