产品规格书模版(总11页)
-CAL-FENGHAI.-(YICAI)-Company One1
-CAL-本页仅作为文档封面，使用请直接删除
Shenzhen leyond opto electronics co.,ltd
深圳市立洋光电子有限公司
SPECIFICATION
(产品规格书)
PART NO. : LY-WH61L0BLIJ05
(产品型号)
SPEC NO. : LY-LEYOND -052404
(规格书编号)
DESCRIPTION : 50瓦白光大功率LED
(产品描述)
DATE : 24/05/2012
(日期)
R&D DEPARTMENT
(技术部)
APPROVED
(核准) CHECKED
(审核) PREPARED
(制定)
刘春香
工厂地址：深圳市宝安区石岩镇水田村同富康工业区B栋5楼 深圳OFFICE：深圳市福田区华强北路华强广场一楼Q1A224号
电话：6 传真：5 电话：8 / 传真：8
邮箱： 网址：
香港立洋电子有限公司
地址：香港九龙旺角弥敦道555号九龙行11楼1102-1103室
电话：01 传真：00
Part NO.: LY-WH61L0BLIJ05 SPEC NO.:LY-LEYOND -052404 REV NO.:A1
■ Description
(描述)
◆ Part NO. (产品型号)：LY-WH61L0BLIJ05
◆ LED Chip：Material(材质) ，InGaN/GaN 、Emitted Color(发光颜色)，Blue(蓝色)
◆ LED Emitted Color(LED发光颜色)： White(白色)
◆ Lens Color(透镜颜色)：Clear(透明)
■ Feature
(特 性)
◆ 50W High Power LED (50W大功率LED)
◆ Package : SMT Package(贴片式外形)
◆Half Angle (2Θ1/2):120°(半光强角度：120°)
◆Lens Color : Water Clear(透镜颜色：无色透明)
■ Applications
(应 用)
◆ General Linghting(普通照明)
◆ Advertisement(广告灯)
◆Architectural Lighting(建筑照明)
◆ Street Lamps(路 灯)
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE DEVICES
Part NO.: LY-WH61L0BLIJ05 SPEC NO.:LY-LEYOND -052404 REV NO.:A1
Package Dimensions
(外观尺寸)
Equivalent circuit diagram
（等效电路圖）
Notes:
dimensions are in millimeters.
(所有尺寸以毫米为单位)
is ± unless otherwise noted
(未标注公差为：±
Part NO.: LY-WH61L0BLIJ05
SPEC NO.:LY-LEYOND-052404
REV NO.:A1
■ Electrical/Optical Characteristics (At TA=25°C)
(光 电 参 数)
Parameter
(参数) Symbol
(符号) Conditions
(测试条件) Min.
(最小值) Avg.
(平均值) Max.
(最大值) Units
(单位)
Luminous Flux
(发光强度) Φ IF=1750mA 5000 -- 5500 lm
Color Temperature/ Color
coordinates
(色温/色坐标) CCT IF=1750mA 4300 4500 4700 K
Forward Voltage
(正向压降) VF IF=1750mA 32 -- 34 V
Thermal Resistance
Junction
To Board (热 阻) RΘJ-B IF=1750mA − − − − °C/W
Reverse Current
(反向漏电流) IR VR=5V − − − − 2 μA
Viewing Angle [1]
(发光角度) 2Θ1/2 IF=1750mA − − 120 − − Deg
■ Absolute Maximum Rating(At TA=25°C)
(极 限 参 数)
Parameter
(参数) Symbol
(符号) Ratings
(数值) Units
(单位)
Power Dissipation
(功率) PD 50 W
Continuous Forward Current
(正向输入电流) IF 1750 mA
LED Junction Temperature
(结点温度) TJ 120 °C
Reverse Voltage
(反向电压) VR 30 V
Operating Temperature Range
(工作温度) TOPR -20°C To +60°C
Storage Temperature Range
(储存温度) TSTG -40°C To +100°C
Manual Solding Temperature
(手工焊接温度) TSOL 350°C± 20°C For 3~5 Seconds
ESD Sensitivity
(抗静电能力) ESD 2000V
BM
NOTE: (Tolerance: Iv ±10%, λd ±2nm, Vf ±
Part NO.: LY-WH61L0BLIJ05
SPEC NO.:LY-LEYOND -052404
REV NO.:A1
Reliability
(1)TEST ITEMS AND RESULTS
Type Test Item Test Conditions Note Number of
Damaged
Environmental
Sequence Temperature
Cycle -40℃ 30min
↑↓5min
100℃ 30min 100 cycle 0/100
Thermal Shock -40℃ 15min
↑↓
100℃ 15min 100 cycle 0/100
High
Temperature
Storage Ta=80℃ 1000 hrs 0/100
Temperature
Humidity
Storage Ta=60℃
RH=90% 1000 hrs 0/100
Low Temperature
Storage Ta=-30℃ 1000 hrs 0/100
Power on/off
Cycle Test
IF=1750mA On 2 hours
↑↓
Off 10min 100 cycle 0/100
Life Test Ta=25℃
IF=1750mA 1000 hrs 0/100
Operation
Sequence Low Temperature
Life Test Ta=-20℃
IF=1750mA 1000 hrs 0/100
/ / / /
Item Symbol Test Conditions Criteria for
Judgement Item
Min.
Forward Voltage VF IF=1750mA _ Forward Voltage
Reverse Current IR VR=30V _ Reverse Current
Luminous
Intensity Φ IF=1750mA Intensity
Upper Standard Level Lower Standard Level
