CNAIS 2006 Symposium文题（不超过20字）*作者11，作者22，作者31……(1. 学校 系名，城市 邮编；2. 单位名称2，城市 邮编)文 摘： 包括目的、方法、结果、结论4部分，200-220字，信息具体。
关键词：关键词1（与分类号对应）；关键词2；关键词3；… 中图分类号： 分类号1；分类号2*基金项目：基金项目类别(项目编号) 作者简介：第一作者的姓名（出生年-），性别（民族），籍贯，职称。
通讯联系人：姓名，职称，E-mail ：……第一作者为研究生、博士后时，应当以作者中的导师为通讯联系人； 其他情况时，在作者简介后直接加E-mail ，不写通讯联系人。
当前，提高板料成形性能的新工艺的研发，成为全球板料冲压领域中处在前沿的一个热点课题，国内外的众多学者主要沿两个方向正在开展这项研究[1]。
这两个方向是：①控制和优化压边力曲线。
②多点位控制压边技术。
要提高板料在加工成覆盖件时的成形性能，必须对覆盖件拉深过程中的力学特征进行较为深刻的理论分析。
一般说来，任何一个非回转面的形状复杂的覆盖件，都是由多个直壁面或斜壁面与1/4左右的过渡圆柱面或圆锥面以及外凸曲面的底面组合而成的。
以图1所示的长方形盒形件的拉深工艺作为分析模型，用上限法来探讨一般的覆盖件拉深过程中的力学特征。
为此，将板坯的凸缘面分成两类区域：圆角区域与直边区域，前者如图1中的ABCD 区域，后者如图1中的ABHE 区域，且每个区域又可以分为凸缘部分与凹模的圆角部分。
文中用上限法对覆盖件拉深过程中的力学特征进行理论探讨，同时给出几点假设：①板厚δ在拉深过程中保持不变。
②等效应变速率按厚向异性的材料模型进行计算。
③计算动可容速度场时忽略接触面上的摩擦阻力。
事实上，假设①在主应力法中同样也被采用了[2]。
假如在拉深过程中，板坯上的圆角区域与直边区域的运动与变形是相互独立的，二者之间没有质点系的转移，即圆角区域中的质点按圆筒件的拉深模式进行运动与变形，而直边区域中的质点按平面应变拉深的模式进行运动与变形，则由上限法可导出如下结果。
