扩展板说明书
为更好满足客户需求，我公司对控制卡的外围设备做进一步改进，增加扩展板设备，以下是扩展板的简要介绍：
一、扩展板的作用：
扩展板和HUB板结合，是对控制卡进行转接的一套设备，通过扩展板可接入两张HUB板，为客户接入大量模组提供方便。

二、扩展板示意图如下图1
图1
三、扩展板各接口说明，及注意事项，如下图2所示
图2
扩展板与HUB板连接，将HUB板50pin脚对应扩展板50pin插孔，确认方向正
确，如下图3所示
图3
四、添加扩展板的HUB板与控制卡的连接：如下图4
注意：通过扩展板的连接，一张控制卡上可连接两张HUB板，如上图的连接。
