安桥tx-ds484和TX-SE570 说明书

調諧至一個無線電台自動調諧1.按主機上的 TUNER 幾次以選擇"AM"或"FM"。

2.按 TUNING MODE ，使顯示螢幕上的"AUTO"指示燈亮起。

3.按TUNING 開始自動調諧。

找到一個電台後搜尋即自動停止。

調諧至某個無線電台時，顯示幕上的"TUNED "指示燈亮起。

調到一個 FM 無線電台時，"FM STEREO"指示燈亮起。

"TUNED "指示燈熄滅時，無聲音輸出。

FM 無線電台的訊號微弱時：無線電波信號可能較弱，這取決於其構建結構與周圍環境情況。

在此種情況下，請按照下一節"手動調諧"說明的程序，手動選擇所需的電台。

手動調諧1.按主機上的TUNER 幾次以選擇"AM"或"FM"。

AM/FM 接收詳情2.按 TUNING MODE，使顯示螢幕上的"AUTO"指示燈熄滅。

3.按 TUNING 選擇所需的無線電台。

每按一下按鈕，頻率改變 1 個步長。

按住按鈕時頻率會持續改變，鬆開後停止。

調台時注意顯示幕。

若要返回自動調諧：按主機上的 TUNING MODE。

本機自動調諧至一個無線電台。

這時通常應顯示"AUTO"。

直接調諧頻率用於直接輸入您要收聽的無線電台的頻率。

1.按遙控器上的 TUNER 幾次以選擇"AM"或"FM"。

2.按 D.TUN。

3.使用數字按鈕，在 8 秒內輸入無線電台的頻率。

例如，要輸入 87.5 (FM)，請按 8、7、5 或 8、7、5、0。

如果輸入的數字錯誤，請按 D.TUN 並輸入正確值。

預設一個 AM/FM 無線電台可以記錄最多 40 個您最喜歡的 AM/FM 無線電台。

提前記錄無線電台讓您能夠直接調到喜歡的電台。

recommendations are for the will not diminish your listeningpleasure. All of the Studio™LSeries loudspeakers referredto in this guide are video-shielded and may safely beplaced near a television.MODEL:LC2Receiver’s Speaker OutputsWiring “out of phase” results in thin sound, weak bass and poor imaging.To use the binding-post speaker terminals, unscrew the colored collar until the pass-through hole in the cen-ter post is visible. Insert the bare end of the wire through this hole; then screw the collar down until the connection is tight.The hole in the center of each collar is intended for use with banana-type connectors. To comply with European CE certification, these holes are blocked with plastic inserts at the point of manufacture. To use banana-type connectors requires the removal of the inserts. Do not remove these inserts if you are using the product in an area covered by the European CE certification.sections using four conductors,one for each of the four terminals.For single-wire connection,leave the shorting bars in place and connect only a sin-gle set of speaker wires (two conductors) to the two upper terminals.Bi-Wire ConnectionsMODELS:L810,L820,LC2The supplied self-adhesive rubber feet may be attached to the bottom corners of your speakers to protect your furniture.WALL-MOUNTINGSPECIFICATIONSL810L820LC2Description3-Way, 5-1/4" Bookshelf/4-Way, 6" High-Performance, 4-Way, Dual 6"Wall-Mount Satellite Mirror-Image,Wall-Mount CenterWall-Mount SatelliteMaximum 150W150W150W RecommendedAmplifier Power*Power Handling 75W/300W75W/300W75W/300W (Continuous/Peak)Nominal Impedance8Ohms8 Ohms8 OhmsSensitivity (2.83V/1m)88dB90dB92dBFrequency 60Hz – 40kHz55Hz – 40kHz50Hz – 40kHz Response (±3dB)Crossover 3500Hz, 20kHz600Hz, 3500Hz, 20kHz700Hz, 4kHz, 20kHz FrequenciesUltrahigh-Frequency 3/4" Mylar®Dome With Cast-Aluminum ChassisHigh-Frequency 1" Pure-Titanium Dome With Cast-Aluminum Chassis in JBL EOS™Waveguide Midrange Transducer N/A4" PolyPlas™Cone 4" PolyPlas™ConeWith Rubber Surround With Rubber Surroundand Cast-Aluminum and Cast-AluminumChassis; HeatScape™Chassis; HeatScape™Motor Structure Motor StructureLow-Frequency 5-1/4" PolyPlas™Cone 6" PolyPlas™Cone Dual 6" PolyPlas™Cones Transducer(s)With Rubber Surround With Rubber Surround With Rubber Surrounds and Cast-Aluminum and Cast-Aluminum and Cast-AluminumChassis; HeatScape™Chassis; HeatScape™Chassis; HeatScape™Motor Structure; Motor Structure; Motor Structures;Symmetrical Field Symmetrical Field Symmetrical FieldGeometry™(SFG™); Geometry™(SFG™); Geometry™(SFG™);Oversized Kapton®Oversized Kapton®Oversized Kapton®Voice Coil; Magnetic Voice Coil; Magnetic Voice Coils; MagneticShorting Ring Shorting Ring Shorting Rings Magnetic Shielding Yes Yes YesBaffle Low Diffraction, IsoPower™Enclosure Bass-Reflex With Sealed SealedDual FreeFlow™Front-Firing PortsNetwork Straight-Line Signal Path™(SSP™)Terminals Gold-Plated 5-Way Binding Posts, Bi-WirableDimensions (H x W x D)14-1/4" x 12-1/4" x 5"12-1/4" x 15-1/2" x 5"12-1/4" x 22" x 5"(362mm x 311mm x 127mm) (311mm x 391mm x 127mm)(311mm x 559mm x 127mm) Weight per Speaker14 lb (6.4kg)19 lb (8.6kg)29 lb (13.2kg)*The maximum recommended amplifier power rating will ensure proper system headroom to allow for occasional peaks.We do not recommend sustained operation at these maximum power levels.All features and specifications are subject to change without notice.All dimensions include grilles and feet, but not spikes.JBL and Harman International are trademarks of HarmanInternational Industries, Incorporated, registered in the United States and/or other countries.Studio Series, Pro Sound Comes Home, EOS, PolyPlas, HeatScape, Symmetrical Field Geometry (SFG), IsoPower, FreeFlow and Straight-Line Signal Path (SSP) are trademarks of Harman International Industries, Incorporated.Dolby is a registered trademark of Dolby Laboratories.DTS is a registered trademark of DTS, Inc.Mylar and Kapton are registered trademarks of E.I. du Pont de Nemours and Company .Laurent RaultHarman Consumer Group InternationalTROUBLESHOOTINGIf there is no sound from any of the speakers:•Check that receiver/ampli-fier is on and that a source is playing.•Review proper operation of your receiver/amplifier.If there is no sound coming from one speaker:•Check the “Balance” control on your receiver/amplifier.•Check all wires and con-nections between receiver/amplifier and speakers.•Make sure no wires are touching other wires or terminals and creating a short circuit.•Make sure all wires are connected. Make sure none of the speaker wires are frayed, cut or punctured.•In Dolby ®Digital or DTS ®modes, make sure that the receiver/processor is config-ured so that the speaker in question is enabled.•Turn off all electronics and switch the speaker in ques-tion with one of the other speakers that is working cor-rectly. Turn everything back on, and determine whether the problem has followed the speakers, or has remained in the same channel. If the problem is in the same chan-nel, the source of the prob-lem is most likely with your receiver or amplifier, and you should consult the owner’s manual for that product for further information.If the problem has followed the speaker, consult your dealer for further assistance or, if that is not possible, visit for further information.If the system plays at low volumes but shuts off as volume is increased:•Check all wires and con-nections between receiver/amplifier and speakers.•Make sure all wires are connected. Make sure none of the speaker wires are frayed, cut or punctured.•If more than one pair of main speakers is being used,check the minimum imped-ance requirements of your receiver/amplifier.If there is no (or low)bass output:•Make sure the polarities (+ and –)of the left and right “Speaker Inputs” are connected properly.•Consider adding a powered subwoofer to your system for use with digital “.1” surround formats.If there is no sound from the surround speakers:•Check all wires and con-nections between receiver/amplifier and speakers.Make sure all wires are con-nected. Make sure none of the speaker wires are frayed, cut, punctured or touching each other.•Review proper operation of your receiver/amplifier and its surround sound features.•Make sure the movie or TV show you are watching is recorded in a surround sound mode. If it is not,check to see whether your receiver/amplifier has other surround modes you may use.•In Dolby Digital or DTS modes, make sure yourreceiver/processor is config-ured so that the surround speakers are enabled.•Review the operation of your DVD player and the jacket of your DVD to make sure that the DVD features the desired Dolby Digital or DTS mode, and that you have properly selected that mode using both the DVD player’s menu and the DVD’s menu.。

Specifications Minimum RMS Power80 W per channel (8 ohms, 20 Hz–20 kHz, 0.09% THD 2-ch driven) Maximum Power115 W per channel (8 ohms, 1 kHz, 0.9% THD, 1-ch driven)Dynamic Power per Channel (8 / 6 / 4 / 2 ohms) 110 W / 130 W / 160 W / 180 W Bluetooth(Version) 2.1 + EDR, (Profile) A2DP , AVRCP (Audio codec) SBC, AAC (receiving only)InputsMini jack: 1, analog audio: 3, optical digital: 1, coaxial digital: 2, USB: 1, HDMI (audio input assignable, DCP2.2 compatible): 4, composite video (audio input assignable): 3OutputsHeadphone: 1, subwoofer: 2, speaker: 7-ch, monitor out (composite): 1, HDMI terminal (HDCP 2.2 compatible): 1TunerFM / AM0.3 W (HDMI control off)Standby Power Consumption 0.9 W (HDMI control on) Dimensions (W x H x D)17-1 / 8” x 6-3 / 8” x 12-7 / 8”(17-1 / 8” x 8-7 / 8” x 12-7 / 8” with antenna up)Weight17.9 lbs.Supplied AccessoriesRemote control, batteries (x 2), YPAO microphone, FM antenna, AM antennaHigh Sound Quality• 7.2-channel powerful surround sound80 W per channel (8 ohms, 20 Hz-20 kHz, 0.06% THD, 2-ch driven)115 W per channel (8 ohms, 1 kHz, 0.9% THD, 1-ch driven)145 W per channel (6 ohms, 1 kHz, 10% THD, 1-ch driven)• Streaming music compatible with Napster, SiriusXM Internet Radio, Pandora®, Spotify, TIDAL, Deezer and internet radio • CINEMA DSP 3D• Virtual front presence speaker• Height speaker configuration (presence, overhead or Dolby-enabled)• Dialogue Level Adjustment and Dialogue Lift • Burr-Brown PCM5102A • Dolby Atmos/DTS:X• Wi-Fi connectivity for wireless music playback (2GHz/5GHz)• Bi-amp (trade with surroundback/presence/Zone B)• YPAO with subwoofer EQ• High-resolution audio support (DSD, FLAC, WAV, AIFF, ALAC)• DSD (2.8/5.6/11.2 MHz)• SILENT CINEMA™ to enjoy surround sound with headphones • Direct Mode for high quality sound reproductionWide Variety of Enjoyment• HDMI input select in pass-through mode • Flexible audio/video input assignment• Audio delay for adjusting lip sync (0-500ms)• Bluetooth input• USB input for USB memory stick• Front panel mini-jack input for connecting portable audio player • Digital audio input for TV or Blu-ray Disc™ Player• AM/FM radio (40-station preset AM/FM tuning/auto preset tuning)• HDMI 2.1 with eARC (Enhanced Audio Return Channel) (via future firmware update)4 in/1 out• 4K Ultra HD support, HDR10, Dolby Vision, Hybrid Log-Gamma (HLG) and BT.2020• Video out feature (for tuner/USB/Bluetooth /AUDIO/AUX input)• 4K video upscaling from HDMI inputThis 7.2-channel AV receiver adds Dolby Atmos® and DTS:X™ support, combined with advanced streaming and video technologies. With built-in Wi-Fi® and Bluetooth ® for wireless music streaming, stunning 4K Ultra HD video with HDCP 2.2 (4 in/1 out), high dynamicrange (HDR10), Dolby Vision™ compatibility and a discrete 7.2-channel amplifier design with YPAO™ automatic calibration to ensure optimal performance, this 4K receiver is a trophy-worthy choice. The new MusicCast skills for Amazon Alexa also allow you to control your wirelessdevices with simple voice commands, including the ability to control volume, play favorites and link audio in other rooms with MusicCast wirelessspeakers. With MusicCast, you can now run wireless speakers as your rear surround speakers.Easy to Use, Elegant Appearance• MusicCast for multi-room listening• MusicCast Surround for wireless speakers and subwoofer • Works with Amazon Alexa devices • SCENE Mode• Setup Wizard (AV Setup Guide app)• Input Skip, DSP Skip and Remote Key • Zone B audio, bi-amp• Zone B volume trim and sync modeA Sound ChampionHDCP2.24K Ultra HD1Technical Data MusicCast AV ReceiverRX-V585MusicCast — Your Music EverywhereMusicCast is a revolution in network audio. Use all your MusicCast products together or separately — it’s completely up to you. Control it all from one app, intuitively, quickly and easily. Use a sound bar, a wireless speaker, an AV receiver, or Hi-Fi audio; whichever suits you best. Mix and match, then expand your MusicCast system as you want. What’s more, Amazon Alexa with MusicCast gives you the ability to control all MusicCast devices with simple voice commands.High Sound QualityEasy to Use, Elegant Appearance AmAmazon Alexa with MusicCastAmazon Alexa-enabled devices can now control key functions of any MusicCast product using voice commands. Using two types of Alexa skills, the MusicCast Smart Home skill and MusicCast skill, you can play music, control volume, play playlists and even link rooms together to play music all throughout the house. Discover a new, exciting way to control music and entertainment experiences in your home.CINEMA DSP 3DSound Field Reproduction TechnologyWide, high and dense sound. CINEMA DSP 3D provides a wide, high and dense sound field. HD Audio format decoding lets you enjoy HD Audio sources. Virtual Presence Speaker delivers three-dimensional sound without the actual use of presencespeakers.Dolby Atmos® and DTS:X ™Experience dimension. These sound technologies transport you from an ordinary moment into an extraordinary experience with captivating, multidimensional sound that fills your room with amazing richness and depth. These sound technologies allow for music, people and objects to come alive in breathtaking detail and flow in precise choreography all around you, making you feel like you are right in the middle of thestory.• AirPlay works with iPhone, iPad, and iPod touch with iOS 4.3.3 or later, Mac with OS X Mountain Lion or later, and Mac and PC with iTunes 10.2.2 or later. Supports iOS 7 or later for setup using Wireless Accessory Configuration. “Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless performance. AirPlay, iPad, iPhone, iPod, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. • The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Yamaha Corporation is under license. Other trademarks and trade names are those of their respective owners. • The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. The Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance. “Wi-Fi” and “Wi-Fi Protected Setup” are marks or registered marks of the Wi-Fi Alliance. • Spotify and Spotify logo are registered trademarks of the Spotify Group. • Pandora and Pandora Internet Radio logo are registered trademarks or trademarks of Pandora Media, Inc. in the United States and/or other countries. • TIDAL and TIDAL logo are registered trademark of Aspiro AB in the European Union and other countries. • Deezer and Deezer logo are international trademarks of Deezer S.A., registered in France and other countries. • Dolby, Dolby Atmos, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories. • For DTS patents, see . Manufactured under licence from DTS, Inc. DTS, the Symbol, DTS in combination with the Symbol, DTS:X, and the DTS:X logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. AllRights Reserved. • HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. • CINEMA DSP is a trademark of Yamaha Corporation.• SILENT CINEMA is a trademark of Yamaha Corporation. • Product designs and specifications are subject to change without notice.MusicCast SurroundWith wireless rear speakers, the fuss of hiding wires en route to the rear speakers is removed. You can also add a MusicCast wireless subwoofer, which can provide more options for subwoofer placement. All new from Yamaha, MusicCast Surround offers an easy way to enhance your home theater experience.plus MusicCast 20 x 2SUB 100Additional products required to utilize MusicCast Surround.SCENE for One-Touch StartOne-touch start. Pressing a SCENE button powers on the AV receiver and selects the input source and DSP mode. You can reset the buttons fordifferent sources by selecting a source and DSP mode, then pressing a SCENE button for more than three seconds.MusicCast AV ReceiverRX-V585RX-V585 NPB2Technical Data。

PRODUCT SUMMARYSKY77807 Quad-Band Power Amplifier Module for FDD/TDD LTE (Tx Bands 7, 38, 40, 41)Applications•Multi-band 4G handsets •Long Term Evolution (LTE)-Up to 20 MHz bandwidth/ 100resource blocks Features•Envelope Tracking(ET)FDD band•Average Power Tracking (APT) for TDD/FDD bands•50 ohm input/output impedance with internal DC-blocking •Fully programmable Mobile Industry Processor Interface digital control •Continuous bias control for3G/4G PA High Power Mode via MIPI/RFFE interface•Low Supply voltage•Low voltage support (0.6 V) for APT/SMPS applications •Low Leakage current in power-down mode •Temperature Sensor •Integrated TDD TX-Rx switch for single SAW architecture •Low voltage support forAPT/SMPS applications •Small, low profile package-4.0x 3.0x 1.0 (Max.) mm-24-pad configurationDescriptionThe SKY77807Quad-Band Power Amplifier Module (PAM) is a fully matched, 24-pad surface mount module developed for 4G LTE applications. The PAM consists of PA blocks, input and output matching, and a MIPI standard logic control block for multiple power control levels, output input switch control in a single 4.0mm x 3.0mm x 1.0 (Max.)mm package.The SKY77807uses an enhanced architecture to cover multiple bands and meet the spectral linearity requirements of LTE QPSK and 16QAM modulations with up to 20 MHz bandwidth and up to 100 resource block allocations. Output power is controlled by varying the input power and VCC is adjusted using an ET modulator or DCDC converter to maximize efficiency for each power level. Extremely low leakage current maximizes handset standby time.Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100•*********************•203049C• Skyworks Proprietary Information. • Products and product information are subject to change without notice. • January 13, 20141Ordering InformationProduct Name Order Number Evaluation Board Part NumberSKY77807SKY77807© 2013,Skyworks Solutions, Inc. All Rights Reserved.Information in this document is provided in connection with Skyworks Solutions, Inc. (“Skyworks”) products or services. These materials, including the information contained herein, are provided by Skyworks as a service to its customers and may be used for informational purposes only by the customer. Skyworks assumes no responsibility for errors or omissions in these materials or the information contained herein. Skyworks may change its documentation, products, services, specifications or product descriptions at any time, without notice. Skyworks makes no commitment to update the materials or information and shall have no responsibility whatsoever for conflicts, incompatibilities, or other difficulties arising from any future changes.No license, whether express, implied, by estoppel or otherwise, is granted to any intellectual property rights by this document. Skyworks assumes no liability for any materials, products or information provided hereunder, including the sale, distribution, reproduction or use of Skyworks products, information or materials, except as may be provided in Skyworks Terms and Conditions of Sale.THE MATERIALS, PRODUCTS AND INFORMATION ARE PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, WHETHER EXPRESS, IMPLIED, STATUTORY, OR OTHERWISE, INCLUDING FITNESS FOR A PARTICULAR PURPOSE OR USE, MERCHANTABILITY, PERFORMANCE, QUALITY OR NON-INFRINGEMENT OF ANY INTELLECTUAL PROPERTY RIGHT; ALL SUCH WARRANTIES ARE HEREBY EXPRESSLY DISCLAIMED. SKYWORKS DOES NOT WARRANT THE ACCURACY OR COMPLETENESS OF THE INFORMATION, TEXT, GRAPHICS OR OTHER ITEMS CONTAINED WITHIN THESE MATERIALS. SKYWORKS SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING BUT NOT LIMITED TO ANY SPECIAL, INDIRECT, INCIDENTAL, STATUTORY, OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR LOST PROFITS THAT MAY RESULT FROM THE USE OF THE MATERIALS OR INFORMATION, WHETHER OR NOT THE RECIPIENT OF MATERIALS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.Skyworks products are not intended for use in medical, lifesaving or life-sustaining applications, or other equipment in which the failure of the Skyworks products could lead to personal injury, death, physical or environmental damage. Skyworks customers using or selling Skyworks products for use in such applications do so at their own risk and agree to fully indemnify Skyworks for any damages resulting from such improper use or sale.Customers are responsible for their products and applications using Skyworks products, which may deviate from published specifications as a result of design defects,errors, or operation of products outside of published parameters or design specifications. Customers should include design and operating safeguards to minimize these and other risks. Skyworks assumes no liability for applications assistance, customer product design, or damage to any equipment resulting from the use of Skyworks products outside of stated published specifications or parameters. Skyworks, the Skyworks symbol, and “Breakthrough Simplicity” are trademarks or registered trademarks of Skyworks Solutions, Inc., in the United States and other countries. Third-party brands and names are for identification purposes only, and are the property of their respective owners. Additional information, including relevant terms and conditions, posted at , are incorporated by reference.。

安桥功放中文说明书安桥功放中文说明书---1. 引言安桥功放是一款高性能音频功放器，采用先进的技术和设计，为用户提供出色的音频体验。

本说明书旨在向用户介绍安桥功放的操作方法、功能特点以及注意事项，以帮助用户正确使用该产品。

---2. 产品概述安桥功放是一款多功能的家用音频功放器，适用于多种音频设备，如电视、音响系统、蓝牙音箱等。

该功放器具有以下主要特点：- 高保真音质：采用先进的音频处理技术，确保音质清晰、细腻，还原原音效果。

- 多种音频接口：支持多种音频输入接口，包括HDMI、AUX、蓝牙等，方便用户连接各种音频设备。

- 多种场景模式：内置多种音效模式和音场调节选项，提供不同音频场景的选择，满足用户对音效的不同需求。

- 简便的操作：设备配备直观的按键和显示屏，用户可以轻松地进行操作和调节音量。

---3. 使用方法3.1 连接音频设备将您需要连接的音频设备通过相应的音频接口连接到安桥功放，可以根据需要选择HDMI、AUX或蓝牙等接口。

3.2 开机与关闭按下电源按钮，可以将安桥功放器开启。

长按电源按钮可进行关闭操作。

在使用过程中，请注意正确使用电源线，以免发生电气故障。

3.3 调节音量通过旋转音量按钮或遥控器上的音量键可以调节音量大小，根据需要进行调节。

3.4 选择音效模式安桥功放器内置多种音效模式，用户可以根据不同的需求选择合适的模式。

通过按下模式按钮或遥控器上的模式键，可以切换不同的音效模式。

3.5 音场调节安桥功放器提供多种音场调节选项，用户可以根据自己的喜好进行调节。

通过按下音场按钮或遥控器上的音场键，可以选择不同的音场效果。

---4. 注意事项- 请将安桥功放器放置在通风良好的位置，避免过热。

- 请勿将任何容器中的液体倒入设备内部，以免发生电路短路或损坏。

- 请勿在潮湿或多尘的环境中使用安桥功放器，以免影响设备的正常运作。

- 请勿将安桥功放器放置在易受震动的环境中，以免影响音质和寿命。

- 请勿自行拆卸或修理设备，以免发生电击或其他安全事故。

Make sure you have the following accessories:a Indoor FM antennab AM loop antennac Speaker cable labelsd Remote controller and two batteries(AA/R6)e Power cord(European and Taiwanese models)(Plug type varies from country to country.)f Speaker setup microphoneThe AV receiver can automatically perform speaker and surround settings, so that you can easily enjoy a surround sound tailored to your listening environment. Connect the supplied microphone to the AV receiver andfollow the on-screen instructions.When performing automatic speaker setup, connect your TV to the AV receiver and make the room as quiet as possible.Using the Remote ControllerBefore connecting the power cord, connect all of your speakers and AV components.Front speakersCenter speakerSurround speakersSubwoofer(s)Surround back speakersFront high speakersSpeaker Configuration5.1-channel:7.1-channel:+7.1-channel:+Y1302-1Connecting Components without HDMIConnecting to the Network (Optional)The following diagram shows how you can connect the AV receiver to your home network. In this example, it’s connected to a LAN port on a router, which has a 4-port 100Base-TX switch built-in.media serverThe AV receiver supports Wi-Fi, and you can connect the AV receiver to your home network by wireless LAN. For wireless LAN connection, see “4. Performing Wireless LAN Setup” (→Page 5).3. Turning On & Initial SetupInitial Setup is automatically started upon first-time use, and you can make an initial setup by watching guidance displayed on the TV screen. If you make this setup later, select No and press ENTER on the remote controller on the next screen after selecting the language.• Connect the AV receiver to your TV with HDMI to make an Initial Setup on the TV screen.• If you set your home network to “Wireless”, see “4. Performing Wireless LAN Setup”.Connecting Components with HDMIThe components connected to each terminal (BD/DVD , GAME , etc.) can be selected with the input selector buttons of the same name on the front panel. Note that these default assignments can be changed. For details, please refer to the instruction manual.Listening to TV audio (Optional)■Video upconversion to HDMI■AV receiverIf you’ve connected your TV to the AV receiver with an HDMI cable, composite video and component video sources can be upconverted and output by the HDMI OUT MAIN.(*) In order for the AV receiver to upconvert component input to HDMI output, the source output must be set to 480i/576i. When signal is input at resolution of 480p/576p and more, error message will be displayed.For further information, see “Playback ” in the Instruction Manual.Y ou can enjoy listening to Internet radio or files on a server (DLNA) through Wi-Fi (Wireless LAN) network. Y ou need to perform the wireless LAN setup to connect the AV receiver to a wireless device such as a wireless router.Previous check for wireless LAN routerThere are two types of setting, “Automatic” and “Manual”. If your wireless LAN router has a “WPS button” (*), automatic setup is available. If not, make the setting manually. If the router does not support WPS, take a note of a SSID and b Password (secret key) on the label of the router. Manual setting is available regardless of the “WPS button” on the router.(*) The “WPS button” is a standard of Wi-Fi Alliance. The name of the button may differ depending on the router maker.■Setup procedureConnect the AV receiver to your TV with HDMI and display the setup screen on the TV . Use a supplied remote controller for the setting. Press RECEIVER before using the remote controller. Use e /r or q /w in the center to select items on the screen, and press ENTER to confirm. Press RETURN to return to the previous screen. For further information, see “Remote Controller”. (→Page 8)1Display “Wireless setup” menu on your TV ● Setup using Initial SetupInitial Setup function is launched upon first-time use. To perform Initial Setup, move your cursor and click on “Wireless ” in “Network Connection ”, press ENTER , select “Yes ” on the next screen, and press ENTER . (*2)● Setup not using Initial SetupThis is a setting using Setup Menu (Home Menu). Display “Wireless setup ” menu by performing the following procedure which contains five steps.1. Press Receiver followed by Home on the remote controller.2. Select “Setup ” on the screen, and press ENTER .3. Select “Hardware Setup ”, and press ENTER .4. Select “Network (*1)”, and press ENTER .5. Select “Network Connection ”, move your cursor and click on “Wireless ”, and press ENTER . (*2)(*1) When “Network ” is grayed out, please wait until it becomes operable after the communication is completed.(*2) The reaction may be slow. Please wait for a short while.2Select the setting method, Automatic or Manual.● Automatic settingSelect “Push Button Configuration (Linksys E/EA Router)” (Connection to Linksys E/EA Router) or “Push Button Configuration (Other Routers)”, and press ENTER for North American models.Select “Push Button Configuration (Select from Router)” , and press ENTER for excluding North American models.● Manual settingSelect “Search Wireless Network ”, and press ENTER .3Automatic settingManual settingSelect “Push Button ” (*) and press ENTER . Press “WPS button” on thewireless LAN router, select “OK ” on the TV screen, and press ENTER .(*) If you select “PIN Code ”, PIN code setting isavailable. Use this setting in case WPS button is in the hard location to press, etc. In PIN code setting, register the displayed eight-digit PIN code with the wireless LAN router. For registration, see the instruction manual provided with the wireless LAN router.Select SSID of your wireless LAN router from the list of SSID displayed on the screen, and press ENTER . Either of the following options is automatically displayed in conjunction with the wireless router setting.WEP method1. Select “Default key ID ”, and press ENTER .2. Select “1” on the next screen. (If you change WEP key on the router side, select that number.)3. Select “Password ” on the next screen, and press ENTER .4. Enter the Password (*) by using a key board displayed on the screen, select “OK ”, and press ENTER .5. Select “OK ” on the next screen, and press ENTER .(*) Pressing Shift switches betweenuppercase and lowercase.WPA/WPA2 method1. Select “Password ”, and press ENTER .2. Enter the Password (*) by using a key board displayed on the screen, select “OK ”, and press ENTER .3. Select “OK ” on the next screen, and press ENTER .(*) Pressing Shift switches betweenuppercase and lowercase.No encryptionY ou do not need to set the default key ID nor Password. Select “OK ” on the screen, and press ENTER . Select “OK ” on the next screen again, and press ENTER .4ConnectionConnection is started, and Wi-Fi indicator flashes on the left of the AV receiver display. When connected successfully, Wi-Fi indicator lights. If the indicator does not light, the connection was not made successfully. Make settings above again. Try the manual setting if the automatic setting does not work.5Enjoying Internet radioPress HOME on the remote controller, select “Network Service ” on the next screen. Y ou can enjoy various types of Internet functions. For further information, see “Playback” in the Instruction Manual.If the settings or operations of Wi-Fi or Bluetooth do not work, see separate volume, “Wi-Fi & Bluetooth Troubleshooting”.■Remote Controller6. compressed music files.c Selects Zone 2/3.d Connection to your Access Point starts and Wi-Fi indicator flashes.e The remote control sensor receives signals from the remote controller.f Displays various information.g Selects listening modes.h (North American and Taiwanese models) DIMMER : Adjusts the display brightness.i Stores or deletes radio presets.j Selects the Auto or Manual tuning mode.k Accesses the HOME menu.l When the AM or FM input source is selected, w TUNING q are used to tune the tuner, and e PRESET r are used to select radio presets.When used with onscreen menus, they work as cursor buttons to select and set items. ENTER is also used with onscreen menus.pairing mode.p Connects a standard pair of stereo headphones.q Connects a camcorder or similar for audio/video playback.r Adjusts the tone.s Selects the input sources.t Displays various information about the currently selected input source.u Connects a USB storage or portable player for playback of music files.v Connects the speaker setup microphone.w Lights depending on the AV receiver’s setting status.x (European, Australian and Asian models)RT/PTY/TP : Used for RDS (Radio Data System).RDS works only in areas where RDS broadcasts are available.y (European, Australian and Asian models) Selects the Pure Audio listening mode.The indicator lights when this mode is selected.。

影音安桥OnkyoTX近几年影音规格变更很快，虽然声画效果同样不断推陈出新，愈来愈好，不过有时就需要新器材才能兼容到。

这次就借来这部新机试一下音效表现，会配合反射喇叭，看一下效果如何。

近几年影音规格变更很快，虽然声画效果同样不断推陈出新，愈来愈好，不过有时就需要新器材才能兼容到。

这次就借来这部新机试一下音效表现，会配合反射喇叭，看一下效果如何。

支持 Dolby Surround 和 DTS Neural:X 向上转换及AccuReflex 功能TX-NR676E 属于Onkyo 中端偏入门的功放，7.2 声道设计可以支持Dolby Atmos 和DTS:X 的5.2.2 喇叭。

自己就更偏向Dolby Atmos 的安装方式，因为新机内置AccuReflex 技术，即使用反射式喇叭依然会有比较好的音效定位。

所以即使不方便装天花喇叭，用反射喇叭应该都有不错的效果，况且一半家居要水平摆齐7 个喇叭都有难度，不如用来玩天空声道更有效果。

前面板右边是音量旋钮，新机继续采用了Onkyo 的Dynamic Audio Amplification 技术，可以提供更佳的驱动力。

机身设有实体讯源、选单等按钮，可以通过前面的显示屏操作，不过当然用 HDMI 接电视、投影机后再设定会方便很多。

继承了中高端 RZ 系列的设计，机身左边有聆听模式、高低音调节的旋钮，方便实时转换音效，比起用遥控操作更加直接。

每声道 165W 的输出，实测我们试音室约 200 呎的空间都相当够用，普通家居客厅相信都足够应付。

除了本身支持Dolby Atmos 和DTS:X 音效输出之外，即使播放一些普通5.1 声效的影碟，都可以通过 Dolby Surround 和 DTS Neural:X 的 up-mixing 功能，变做有天空声道效果，对于手头上有不少 Dolby TrueHD 或者 DTS-HD 音效的Blu-ray 影碟玩家，就相当实用。

The Pioneer VSX-932 brings out the full excitement from everything you see and hear, with DTS:X™ and Dolby Atmos® featuring the Reflex Optimizer for Atmos-enabled speakers, Ultra HD video, HDR10, HLG (Hybrid Log-Gamma), and Dolby Vision. Stream music to any room with FireConnect™, Chromecast built-in, and DTS Play-Fi®. Listen to a multitude of songs via internet radio and network streaming services, with smooth control on the Pioneer Remote App. You can even connect a turntable via the phono input.FRONT TERMINALS›USB 1 In for USB Drive›MCACC Setup MIC In›Audio 1 In (Mini Stereo Jack)›Phones 1 OutREAR TERMINALS›HDMI 4 In (4 Assignable)›HDMI 1 Out›Ethernet 1 In›USB 1 In for USB Drive›AV (Composite) 2 In (Assignable) ›Digital Coaxial 1 In (Assignable)›Digital Optical 1 In (Assignable)›Subwoofer 2 Pre Out›Speaker 7 ch Out(FRONT, CENTER, SURROUND,SURROUND BACK/HEIGHT/Bi-AMP)›FM/AM AntennaSPECIFICATIONS›Power Requirements: AC 120V, 60 Hz›Power Consumption/Standby: 480W/0.15 W›Product Dimensions (W x H x D):17-1/8" x 6-13/16" x 12-5/8"(435 x 173 x 320.5 mm)›Product Weight: 19.4 lbs. (8.8 kg)›Carton Dimensions (W x H x D):20-5/8" x 9-3/4" x 17"(435 x 173 x 320.5 mm)›CartonWeight: 22.9 lbs. (10.4 kg)›UPC: 889951000188WHAT'S IN THE BOX›Main unit›Setup microphone›Remote Control›AAA size batteries x2›AM loop antenna›FM wire antenna›Quick start guide›Safety Brochure*1 Available with future firmware update *2 Compatible apps required *3 Availability of services may vary by region. *4 Available for free download from the App Store/Google Play™© 2017 Onkyo & Pioneer Corporation. All rights reserved.Note: Specifications and design subject to change without notice.Multi-Dimensional Excitement with Dolby Atmos ®The VSX-932 is compatible with5.2.2ch configuration of the latest theater sound platform, Dolby Atmos ®. You can reproduce object-oriented sound in smooth, curvingmovements, or the realistic three-dimensional movement overhead by the top speakers.DTS:X™DTS:X is the next-generation audio codec from DTS that leverages object-based audioto enable new immersive and interactive audio experiences. Since DTS:X can automatically adapt the audio to the existing channels and speaker system, no specific speaker layout is required. Experience an immersive soundscape with incredibly rich and life-like audio.Next Generation Video Standard ReadyThe VSX-932 supports pass-through for Dolby Vision, HLG (Hybrid Log-Gamma), andHDR10 signals. By connectinga compatible source device, you can enjoy these latest video standards on a compatible display. What’s more, all HDMI terminals support 4K (60p/4:4:4/24-bit), Wide Color Gamut (BT.2020), and HDCP 2.2, so you will have no problem when upgrading to new devices, and can also enjoy premium content such as 4K videos with digital copy protection.Chromecast built-inThe VSX-932 comes with Chromecast built-in, so you can use your mobile device tostream your favorite music, radio, or podcasts to your speaker. You can control the audiofrom anywhere in the house using Chromecast-enabled apps running on your personal device—iPhone, iPad, Android phone and tablet, Mac and Windows laptop, and Chromebook™. Discover Chromecast-enabled apps at /cast/apps.DTS Play-Fi ®DTS Play-Fi* wirelessly streams any audio content from any compatible mobile device to theVSX-932 and DTS Play-Ficompatible audio systems, creating a multi-room system in your home. You can stream different sources to different speakers at the same time from the DTS Play-Fi app.* DTS Play-Fi will be available with future firmware update.Dolby Atmos 5.2.2ch Speaker SystemHDR Dynamic Range Expansion ImageNo HDRWith HDR* For illustration purpose onlyMCACC Auto Room TuningCreate the optimum acousticenvironment with Pioneer’s MCACC (Multi-Channel Acoustic Calibration System), developed with theexpertise of professional recording studios. With the custom microphone, the system automatically compensates for differences in speaker size, level and distance, and equalzes response.Synchronized Sound with Phase ControlAs an innovative solution for the phase lag between the subwoofer and the mainchannel speakers caused by the bass management filter, Phase Control compensates for the delayed bass to improve sound synchronization.Reflex OptimizerWhen using Dolby Atmos-enabled speakers, high Before After directivity sound from the unit reflects off thesound directly reaches the ears. The different pathways cause a phase shift, making the soundfeel uncomfortable. The Reflex Optimizer which uses the Phase Control technology adjusts this shift, and improves the localization of the sound image by aligning the frequencies with those of the floor speakers, creating the ideal reproduction environment.Multi-room Audio Offers a Variety of Ways to Enjoy MusicFireConnect™ mirrors network audio andexternal analog sources connected to the master component—from streaming services to vinylrecords—on FireConnect™-compatible speakers in other rooms. Music selection, speaker grouping, and playback management across the home are built into Pioneer Remote App for iOS and Android.* Sharing of audio from external inputs depends on the model and is enabled with a future firmware update. Sampling rates of 44.1 kHz and 48 kHz are supported. FireConnect is atechnology based on Blackfire provided by Blackfire Research Corp., USA.•PIONEER, MCACC, Phase Control, Advanced Sound Retriever , and the logos are registered trademarks of Pioneer Corporation, and are used under license. •The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. •Dolby, Dolby Atmos, Dolby Surround, Dolby Vision, and the double-D symbol are registered trademarks of Dolby Laboratories. •For DTS patents, see . Manufactured under license from DTS, Inc. DTS, the Symbol, DTS and the Symbol together , DTS:X, the DTS:X logo, Play-Fi, and the Play-Fi logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved. •AirPlay, iPad, and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries. •AirPlay works with iPhone, iPad, and iPod touch with iOS 4.3.3 or later , Mac with OS X Mountain Lion, and Mac and PC with iTunes 10.2.2 or later. The AirPlay logo is a trade-mark of Apple Inc. App Store is a service mark of Apple Inc. •IOS is a trademark on which Cisco holds the trademark right in the US and certain other countries. •Wi-Fi is a registered trademark of the Wi-Fi Alliance. The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. •The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. •”x.v.Color” is a trademark of Sony Corporation. •Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc. used with permission. •Spotify and the Spotify logo are trademarks of the Spotify Group, registered in the U.S. and other countries. •The product with the Hi-Res Audio logo is conformed to Hi-Res Audio standard defined by Japan Audio Society. The logo is used under license from Japan Audio Society. •Android, Google Play, Chromebook, and the Chromecast built-in badge are trademarks of Google Inc. •Blu-ray Disc™, Blu-ray™, Ultra HD Blu-ray™ and the logos are trademarks of the Blu-ray Disc Association. •FireConnect is a technology of Blackfire Research Corp, USA.VSX-932All other trademarks and registered trademarks are the property of their respective holders.Integrated Technologies。

安桥说明书安桥说明书1. 简介安桥是一种适用于计算机网络中的防火墙设备。

它能够对网络流量进行监控和过滤，以保护网络中的计算机系统免受未经授权的访问和恶意攻击。

本文档将介绍安桥的功能、配置和使用方法。

2. 功能安桥具备以下主要功能：- **包过滤**：安桥可以根据预设的规则对网络流量进行过滤，只允许特定的数据包通过，从而减少恶意流量对网络的影响。

- **访问控制**：通过配置安桥，管理员可以限制从内部网络到外部网络的访问，保护敏感数据不被未经授权的人员获得。

- **攻击防护**：安桥可以通过检测和阻断特定类型的攻击流量，如DDoS攻击、SQL 注入攻击等，保护网络免受恶意攻击。

- **日志记录**：安桥可以记录网络流量、连接和事件等信息，方便管理员进行审计和故障排查。

3. 配置3.1 硬件配置安桥的硬件配置取决于网络规模和性能需求。

通常包括以下组件：- **处理器**：用于处理和过滤网络流量的中央处理器。

- **内存**：存储安桥运行所需的配置和数据。

- **网络接口**：用于连接安桥与网络设备的接口。

3.2 软件配置安桥的软件配置包括以下方面：- **操作系统**：选择合适的操作系统，并进行安装和配置。

- **网络配置**：配置安桥的网络接口、IP地址、子网掩码等信息，以使其能够正常和其他设备进行通信。

- **规则配置**：根据需求，配置安桥的包过滤规则、访问控制规则和攻击防护规则等。

- **日志配置**：配置安桥的日志记录选项，包括日志的格式、存储位置等。

4. 使用方法4.1 登录与认证使用Web浏览器访问安桥的管理界面，并输入正确的用户名和密码进行登录认证。

4.2 配置管理在安桥的管理界面中，可以进行以下配置管理操作：- **规则配置**：设置包过滤规则、访问控制规则和攻击防护规则，以满足特定的安全需求。

- **网络配置**：配置网络接口、IP地址、子网掩码等信息，以使安桥能够与其他设备进行通信。

MELT AWAYRX-A4AR X-A4ACINEMA DSP HD3This unique Yamaha proprietary sound field playback technology was created by combining actual measured sound field data with cutting-edge digital signal processing technology. The revamped CINEMA DSP HD3 features new signal processing algorithms and maximizes sound effects, accurately reproducing a new dimension of realism.This AV Receiver is compatible with AirPlay 2. iOS 11.4 or later is required. Use of the Works with Apple badge means that an accessory has been designed to work specifically with the technology identified in the badge and has been certified by the developer to meet Apple performance standards. Apple, AirPlay, Apple TV, Apple Watch, iPad, iPad Air, iPad Pro, iPhone, and Lightning are trademarks of Apple Inc., registered in the U.S. and other countries. MusicCast CONTROLLER will turn your smart phone into a Wi-Fi enabled remote control for select Yamaha network products. This MusicCast CONTROLLER App can be downloaded from App Store or Google Play. App Store is a service mark of Apple Inc. Google Play is a trademark of Google LLC. Dolby, Dolby Atmos, Dolby Surround, Dolby Vision, and the double-D symbol are trademarks of Dolby Laboratories. For DTS patents, see . Manufactured under license from DTS, Inc. DTS, the Symbol, DTS in combination with the Symbol, DTS:X, and the DTS:X logo are registered trademarks or trademarks of DTS, Inc. in the United States and / or other countries. © DTS, Inc. All Rights Reserved. The terms HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. The Wi-Fi CERTIFIED™ Logo is a certification mark of Wi-Fi Alliance®. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Yamaha Corporation is under license. Other trademarks and trade names are those of their respective owners. Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc. Used with permission. Napster and the Napster logo are registered trademarks of Rhapsody International Inc registered in the United States and other countries. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc. All other marks, channel names and logos are the property of their respective owners. All rights reserved. Spotify and Spotify logo are registered trademarks of the Spotify Group. Qobuz and its logo are registered trademarks of Xandrie S.A. TIDAL and TIDAL logo are registered trademark of Aspiro AB in the European Union and other countries. Deezer and Deezer logo are international trademarks of Deezer S.A., registered in France and other countries. Amazon, Amazon Music and all related logos are trademarks of , Inc. or its affiliates. Music streaming services listed may not be available in your region. View Yamaha product website for details.R X -A 4ASurround:AI™This artificial intelligence analyzes the DSP parameters and optimizes the surround effect of distinct sound elements such as background music, dialogue and sound effects. It’s like having a professional sound engineer tune the sound according to the scene. 64-bit processing with Qualcomm® QCS407.8K60AB *, 4K120AB * and 4K60This receiver supports end-to-end 8K/4K resolutions and higher refresh rates, giving you a smoother and more realistic viewing experience.HDR10+* and Dolby Vision™The latest enhancement for HDR provides deeper contrast and more realistic images that stay true to the creators' intent. Support for Dolby Vision, Hybrid-Log Gamma and BT-2020 included.Enhanced Gaming Features (ALLM, VRR, QMS and QFT)*New enhanced gaming/media features offer seamless motion and transitions to enhance your performance.Future Support for Multiple HDMI Inputs*These HDMI inputs will equally support the latest HDMI technology to allow several next-gen gaming consoles to be connected at the same time.MusicCast AppExplore the power of multi-room audio, access your sources and streaming devices, and control your AV receiver, all through your smartphone.Voice ControlWorking with Alexa and Google Assistant, your AV receiver is always at your command. Through AirPlay 2, you can stream your music via voice control operation Siri from Apple iOS device.AV Setup Guide AppThis app offers expert guidancethrough installation, cable connections, and various other settings.Third Party ControlThis receiver includes integration with third party control partners, including Crestron, URC, RTI, Control4 and more.YPAO™-R.S.C. with Multipoint Measurement and Precision EQYPAO (Yamaha Room Acoustic Optimizer) analyzes your room acoustics and measures speaker characteristics to optimize every channel of your home theater. R.S.C. (Reflected Sound Control) also optimizes sound parameters for maximum performance from CINEMA DSP, Dolby Atmos ® and DTS:X™. This feature includes low frequency mode.Compatible with Wireless Surround SoundGo wire-free with MusicCast Surround, letting you create a 5.1-channel surround sound system without the need to run wires to the back of the room. Connect wirelessly byconnecting one MusicCast 50 or two MusicCast 20 wireless speakers to this AV receiver.Dynamic and CompellingDesignClassic Yamaha craftsmanship meets cutting-edge design. Every piece has been carefully crafted to ensure this AV receiver looks and sounds perfect in your home.High-Quality Digital ComponentsQualcomm® QCS407 takes your AV receiver’s surround sound to the next level with support for Dolby Atmos® and DTS:X®. With SABRE ES9007S Premier Audio DAC, you get extraordinary signal-to-noise ratioand up to 120 dB of dynamic range forprofessional quality audio.Crafted for ClarityThe newly designed Anti-ResonanceTechnology (A.R.T.), H-shaped Cross Frame and mechanical structure are a rock-solid defense against internal and external vibrations that affect the sound. Experience crystal clear sound that moves you, all while your AV receiver stays perfectly still.R X -A 4AMORE KEY SPECS*These functions are available via future update7ch / 110 WMulti-room AudioCINEMA DSP HD3Dolby Atmos®eARC High Slew Rate Amplifier HDMI 7 inputs / 3 outputsAirPlay 2Streaming ServicePhonoDTS:X ™Zone 2 including HDMI。

Amplification›Channels: 9›Amplification Type: Class D3 (Direct Energy HD)›850 W Multi ch Simultaneous Drive (8 ohms, 1 kHz, THD 1.0 %)›255 W/ch (4 ohms, 1 kHz, THD 1.0 %, 2ch Driven)›200 W/ch (6 ohms, 1 kHz, THD 1.0 %, 2ch Driven FTC)›140 W/ch (8 ohms, 1 kHz, THD 0.08 %, 2ch Driven FTC) Construction Design›Advanced Direct Construction›Rigid Trans-Stabilizer›Insulated Dual Chassis›3D Space Frame Construction›Low Leakage Flux Power Transformer›Anti-Standing Wave InsulatorAudio Features›AIR Studios Monitor Certification›Dolby Atmos®/Dolby® TrueHD/Dolby Digital Plus/Dolby Surround›DTS:X/DTS Neural:X Ready*1›DTS-HD Master Audio/DTS-ES›USB-DAC 192 kHz/32-bit with DSD Native Playback›DSD Direct Playback via Network/USB (2.8 MHz, 5.6 MHz/2ch)›DSD Disc (SACD) Playback via HDMI (2.8 MHz/5.1ch, 2ch)›SABRE32 Ultra DAC (ES9016+ES9016) for 9.2ch›Audio Scaler 192 kHz/32-bit Enhancer›MCACC Pro Room Calibration• Full Band Phase Control• Auto Phase Control Plus/Phase Control Plus• Standing Wave Control• 3D Time Axis Measurement• Precision Distance• Subwoofer EQ (4 Band)• Bass Management System for Dolby Atmos Enabled Speakers ›Sound Enhancements• PQLS Bit-stream/Multi-Surround/2ch• Advanced Sound Retriever (Multi-ch)• Auto Sound Retriever/Auto Sound Retriever for ARC• Auto Level Control (Multi-ch)• Virtual Speakers (Wide/Height/Surround Back)• Rendering Mode›Advanced Surround Modes• Action, Drama, Advanced Game, Sports, Classical, Rock/Pop• Front Stage Surround• Sound Retriever Air, Phones Surround• ECO Mode 1, ECO Mode 2›Input Volume Absorber›Speaker System 15 Patterns Including 7 Patterns for Dolby Atmos Video Features›Ultra HD Pass-through with HDCP 2.2 (4K/60p/4:4:4/24-bit,4K/24p/4:4:4/36-bit, 4K/60p/4:2:2/36-bit)›Video Scaler (1080p to 4K) with Super Resolution›Triple HD Noise Reduction›Advanced Video Adjust›Stream Smoother/Stream Smoother LinkHome Network Features›Apple AirPlay® Certified›DLNA Certified™ (1.5)›HTC Connect™ Certified›Windows® 8 Compatible›Music File Playback/Seek via Network/USB: AIFF, Apple Lossless, WAV, FLAC, MP3, WMA, AAC, DSD• 192 kHz/24-Bit Audio playback (AIFF, Apple Lossless, WAV, FLAC)• Multi-Channel (5.1ch, 5.0ch) Audio Playback (WAV*2, FLAC*3)›Gapless Playback for AIFF, Apple Lossless, WAV, FLAC, AAC, MP3, DSD ›Pandora® Internet Radio*4›Spotify® Digital Music-Streaming Service Ready*5›Internet Radio with vTunerConvenience Features›iPod® Digital Transmission via Front USB Terminal›Android™ Audio/Video Playback with MHL™›Start-up Navi (Initial Setting App) Ready (iOS/Android)*6›AVNavigator (Wiring Navi/Interactive Operation Guide)›iControlAV5 Remote Control App Ready (iOS/Android)*6›HDMI ZONE Out (HDZONE)›Built-in Wi-Fi (Dual Band 5 GHz/2.4 GHz)›Built-in Bluetooth Wireless Technology (Version: 2.1 + EDR, Profile: A2DP/ AVRCP, Codec: SBC/AAC)›Power Save for HDMI Standby Through›Learning Remote Control (Luminous)9.2 Channel Elite AV Receiver featuring Class D3amplification, SABRE32Ultra DAC, Air Studios®Monitor Certification, Dolby Atmos®, MCACC®Pro Room Calibrations, HDCP 2.2 copy protection, Ultra HD Pass-though, USB DAC, DTS:X*1 with built in Bluetooth® and Wi-Fi® technologies*1 Firmware update required*2 Up to 192 kHz streams via USB, up to 96 kHz streams via wired LAN, up to 48 kHz via wireless LAN *3 Up to 96 kHz streams *4 Service only available in the U.S. *5 For service availability in your country, check *6 Available for free download from the App Store SM/the Google Play™ Bold denotes step-up features from SC-97© 2015 Pioneer & Onkyo USA Corporation. All rights reserved. Note: Specifications and design subject to change without notice.Pioneer, Elite, MCACC, Advanced Sound Retriever, and the corresponding logos are registered trademarks of Pioneer Corporation and are used by Pioneer & Onkyo U.S.A. Corporation under license. •AIR STUDIOS and the AIR STUDIOS logo are registered trademarks of Air Studios, Inc.•The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. •Dolby, Dolby Atmos and the double-D symbol are registered trademarks of Dolby Laboratories. •DTS, DTS:X, DTS-HD, the Symbol, & DTS or DTS-HD and the Symbol together are registered trademarks of DTS, Inc. ©DTS, Inc. All Rights Reserved. •Windows and the Windows logo are trademarks of the Microsoft group of companies. •AirPlay works with iPhone, iPad, and iPod touch with iOS 4.3.3 or later, Mac with OS X Mountain Lion, and Mac and PC with iTunes 10.2.2 or later. “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance. Apple, AirPlay, iPad, iPhone, iPod, iPod nano, iPod touch, iTunes and Mac are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. The AirPlay logo is a trademark of Apple Inc. •iOS is a trademark on which Cisco holds the trademark right in the US and certain other countries. •Wi-Fi is a registered trademark of the Wi-Fi Alliance. The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. •The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by PIONEER CORPORATION is under license. •DLNA™, the DLNA Logo and DLNA Certi-fied™ are trademarks, service marks, or certification marks of the Digital Living Network Alliance. •HTC, the HTC logo, and HTC Connect are trademarks of HTC Corporation. •SABRE™ is a trademark of ESS Technology, Inc. •Android and Google Play are trademarks of Google Inc. •MHL, the MHL Logo, and Mobile High-Definition Link are trademarks or registered trademarks of MHL LLC in the United States and other countries. •Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc. used with permission. •Spotify and the Spotify logo are trademarks of the Spotify Group, registered in the U.S. and other countries. •vTuner is a registered trademark of Nothing Else Matters Software, Ltd. •Phase Control is a trademark placed on a product with Pioneer’s Phase Control Technology concept. The technology enables high-grade sound reproduction environment by improving the phase matching for each of the components. •The product with the Hi-Res Audio logo is conformed to Hi-Res Audio standard defined by Japan Audio Society. The logo is used under license from Japan Audio Society.Control4 and the Control4 logo are registered trademarks of Control4 Corporation. Crestron and the Crestron logo are registered trademark of Crestron Electronics, Inc. AMX and the AMX logo are trademarks of AMX, LLC registered in the U.S. and other countries. Universal Remote Control logo is a registered trademark of Universal Remote Control, Inc. RTI logoIntegrated TechnologiesFront Terminals›HDMI 1 in›USB 1 in for iPod/iPhone ®, USB drive ›MCACC Setup MIC in›Phones 1 outRear Terminals›HDMI 7 in (7 assignable, 1 for HDMI/MHL) ›HDMI 3 out (2 for MAIN, 1 for MAIN/HDZONE) ›Ethernet 1 In›AV (Composite) 2 In/1 Out ›Audio 1 In (assignable) ›Phono (MM) 1 In›Digital Coaxial 2 In (assignable)›Digital Optical 2 In (assignable)/1 Out ›USB-DAC In (B-Type)›Component Video 2 In (assignable)›Monitor Component 1 Out/Monitor Composite 1 Out›Preout 11.2 ch (13.2 ch terminals) ›Speaker 11 ch Out›Independent Dual Subwoofer ›IR 2 In/1 Out›12 V Trigger x 2/RS-232CSpecifications›Power Requirements: AC 120 V 60 Hz ›Power Consumption/Standby: 370 W/0.1 W›Dimensions (W x H x D):17-1/8 x 7-5/16 x 17-3/8 inches (435 x 185 x 441 mm) ›Weight: 38 lbs. 12 oz. (17.6 kg)UPC›8-84938-29076-0Available with firmware update。
