DATASHEETOverview Formality ® is an equivalence-checking (EC) solution that uses formal, static techniques to determine if two versions of a design are functionally equivalent.Formality delivers capabilities for ECO assistance and advanced debugging to help guide the user in implementing and verifying ECOs. These capabilities significantly shorten the ECO implementation cycle.The size and complexity of today’s designs, coupled with the challenges of meeting timing, area, power and schedule, requires that the newest, most advanced synthesis optimizations be fully verifiable.Formality supports all of the out-of- the-box Design Compiler ® and Fusion Compiler™ optimizations and so provides the highest quality of results that are fully verifiable.Formality supports verification of power-up and power-down states, multi-voltage, multi- supply and clock gated designs.Formality’s easy-to-use, flow-based graphical user interface and auto-setup mode helps even new users successfully complete verification in the shortest possible time.Figure 1: Formality equivalence checking solutionIndependent formalverification of DesignCompiler and FusionCompiler synthesisresults, with built-in intelligencedelivering the highestverifiable QoRFormality Equivalence Checking and Interactive ECOKey Benefits• Perfect companion to Design Compiler and Fusion Compiler—supports all default optimizations• Intuitive flow-based graphical user interface• Verifies low-power designs including power-up and power-down states• ECO implementation assistance, fast verification of the ECO, and advanced debugging• Auto setup mode reduces “false failures” caused by incorrect or missing setup information• Multicore verification boosts performance• Automated guidance boosts completion with Design Compiler and Fusion Compiler• Verifies full-custom and memory designs when including ESP technologyFormalityThe Most Comprehensive Equivalence Checking SolutionFormality delivers superior completion on designs compiled with Design Compiler or Fusion Compiler. Design Compiler is the industry leading family of RTL Synthesis solutions. Fusion Compiler is the next generation RTL-to-GDSII implementation system architected to address the complexities of advanced process node design. Designers no longer need to disable the powerful optimizations available with Design Compiler or Fusion Compiler to get equivalence checking to pass. Design Compiler/Fusion Compiler combined with Formality delivers maximum quality of results (QoR) that are fully verifiable.Easy to Use with Auto-setup modeFormality’s auto-setup mode simplifies verification by reducing false failures caused by incorrect or missing setup information. Auto-setup applies setup information in Formality to match the assumptions made by Design Compiler or Fusion Compiler, including naming styles, unused pins, test inputs and clock gating.Critical files such as RTL, netlists and libraries are automatically located. All auto-setup information is listed in a summary report.Guided SetupFormality can account for synthesis optimizations using a guided setup file automatically generated by Design Compiler or Fusion Compiler. Guided setup includes information about name changes, register optimizations, multiplier architectures and many other transformations that may occur during synthesis. This correct-by-construction information improves performance and first-pass completion by utilizing the most efficient algorithms during matching and verification.Formality-guided setup is a standard, documented format that removes unpredictability found in tools relying on log file parsing.Independent VerificationEvery aspect of a guided setup flow is either implicitly or explicitly verified, and all content is available for inspection in an ASCII file.Figure 2: Automatic cone pruning improves schematic readability when debuggingHier-IQ TechnologyPatented Hier-IQ technology provides the performance benefits of hierarchical verification with flat verification’s out-of- the-box usability.Error-ID TechnologyError-ID identifies the exact logic causing real functional differences between two design representations. Error-ID can isolate and report several logic differences when multiple discrepancies exist. Error-ID will also present alternative logic that can be changed to correct a given functional difference; this flexibility allows the designer to select the change that is easiest to implement.Failing Pattern Display WindowAll failing input patterns can be viewed in a familiar spreadsheet-like format. The failing pattern window is an ideal way to quickly identify trends indicating the cause of a failing verification or improper setup.Figure 3: Problem areas can be easy identified by visual inspection of the Failing Pattern WindowPower-aware VerificationFormality is fully compatible with Power Compiler™ and verifies power-up and power-down states, multi-voltage, multi-supply and clock gated designs.When a reference design block is powered up, Formality verifies functionality. If the implementation design powers up differently, failing points will occur.Formality functionally verifies that the implementation powers down when the reference powers down and will detectfunctional states where the implementation does not power down as expected. The valid power states are defined in the power state table (PST).Power intent is supplied to Formality through IEEE 1801 Unified Power Format (UPF).Figure 4: Power connectivity is easy to see and debug from the schematic viewAccelerated Time to ResultsFormality’s performance is enhanced with multicore verification. This Formality capability allows verification of the design using up to four cores simultaneously to reduce verification time.Other Time-Saving FeaturesFormality’s Hierarchical Scripting provides a method to investigate sub-blocks without additional setup and is ideal for isolating problems and verifying fixes.The Source Browser opens RTL and netlist source files to highlight occurrences of a selected instance. This can help users correlate between the RTL and gate-level design versions.Error Region Correlation provides a quick, visual identification of the logic from one design that correspond to the errors isolated by Error-ID within the other.Command Line Editing allows you to take advantage of history and common text editor commands when working from Formality’s command line.Interactive ECOKey BenefitsProvides GUI-driven ECO implementation assistance, fast ECO verification, and advanced debugging. Formality guides the user through the implementation of ECOs, and then quickly verifies only the changed logic.Formality Interactive ECO FlowFormality uses the ECO RTL and an unmodified netlist. Guided GUI driven changes are made to the netlist. Once the ECO has been implemented, a quick verification is run on only the affected logic cones, eliminating the need for a full verification run on the design to verify that the ECO was implemented correctly.Once all ECO’s are implemented and fully verified, a list of IC Compiler™ commands is generated to assist in implementing the physical changes to the design.ECO GuidanceFormality highlights equivalent nets between the reference and implementation designs, and nets that have lost their equivalence due to the ECO changes in the reference. This helps the designer quickly identify where the change should be made in the implementation.Implementing the ECOEditing commands in Formality are used to modify the netlist in-place using the GUI.Rapid ECO VerificationFormality can identify and verify just the portion of the design affected by the ECO. This ensures that the ECO was implemented correctly. If the ECO verification fails, the ECO can be interactively “undone” and new edits can be made again. Once the partial verification passes, the changes are committed. This partial verification eliminates having to verify the entire design to assure that the ECO was implemented correctly, dramatically reducing the total time required to implement and verify the ECO.Figure 5: Equivalent net is highlighted between Reference design (left) and Implementation design (right)Figure 6: On a completed ECO, the schematic shows the nets affected by ECO in yellow, and the new component and net in orangeFigure 7: Formality transcript shows a successful partial verification of the portion of the design that was affected by the ECOInterface with IC Compiler IIOnce the ECO’s are implemented and verified, a final complete verification run is performed to assure that the ECO RTL and the ECO netlist are functionally equivalent.Formality produces IC Compiler II compatible ECO command file, easing the implementation in the physical design.Advanced DebuggingFormality incorporates advanced debugging capabilities that help the designer identify and debug verifications that do not pass. The designer can find compare points, equivalences (and inverted-equivalences) between reference and implementation designs, perform “what if” analysis by interactively modifying the designs, and verify equivalence between two (or multiple) points.Transistor VerificationESP combines with Formality to offer fast verification of custom circuits, embedded memories and complex I/Os. ESP technology directly reads existing SPICE and behavioral RTL models and does not require restrictive mapping or translation.Input Formats• Synopsys DC, DDC, Milkyway™• IEEE 1800 SystemVerilog• Verilog-95, Verilog-2001• VHDL-87, VHDL-93• IEEE 1801 Unified Power Format (UPF)Guided Setup Formats• Synopsys V-SDC• Formality Guide Files (SVF)Platform Support• Linux Suse, Red Hat and Enterprise• SPARC SolarisFor more information about Synopsys products, support services or training, visit us on the web at: , contact your local sales representative or call 650.584.5000.©2019 Synopsys, Inc. All rights reserved. Synopsys is a trademark of Synopsys, Inc. in the United States and other countries. A list of Synopsys trademarks isavailable at /copyright.html . All other names mentioned herein are trademarks or registered trademarks of their respective owners.。
ieee1012-1998
IEEE 1012-1998 是IEEE(Institute of Electrical and Electronics Engineers,电气和电子工程师协会)制定的一项标准,关于软件验证和验证的指南。
IEEE 1012-1998 的全名是"IEEE Standard for Software Verification and Validation",即《软件验证和验证的标准》。
该标准提供了关于软件验证和验证过程的指南,旨在确保软件系统的质量和可靠性。
该标准涵盖了软件验证和验证的各个方面,包括定义、目标、原则、过程、活动和任务等。
它提供了一套规范化的方法和步骤,以帮助软件开发团队在软件生命周期的不同阶段进行验证和验证活动,从而发现和解决潜在的问题和错误。
IEEE 1012-1998 的目标是提供一种系统化的方法,以确保软件系统在设计、开发和交付过程中满足特定的需求和规范。
它强调了验证和验证过程的重要性,并提供了一些常用的技术和方法,如测试、检查、审查等,来支持软件质量的评估和验证。
需要注意的是,IEEE 1012-1998 是在 1998 年发布的标准,因此可能不再是最新版本。
在实际应用中,建议参考最新的相关标准或文档,以确保符合当前的行业标准和最佳实践。
Contents3 Diverse Form Factors for Convenient Strong Authentication4 Hardware OTP Tokens4 Certificate-based Virtual Smart Card5 Certificate-based Smart Cards6 Certificate-Based USB Tokens6 FIDO Devices7 Smartphone and Software Tokens7 Tokenless Authentication Solutions8 Card Readers8 About SafeNet Identity and Access Management Solutions 8 About ThalesDiverse Form Factors for Convenient Strong AuthenticationOffering the broadest range of multi-factor authentication methods and form factors, Thales facilitates and empowers enterprise-wide security initiatives for maintaining and improving secure access to enterprise resources.Thales’s SafeNet authenticators include hardware and software OTP tokens, FIDO devices, X.509 certificate-based USB tokens , physical and virtual smart cards, OOB, hybrid tokens, and phone tokens for all mobile platforms. Many Thales SafeNet hardware tokens support physical access control to secure buildings and sites.Allowing you to address numerous use cases, assurance levels and threat vectors, Thales’s authenticators are supported by authentication platforms which offer uniform, centralized policy management—delivered in the cloud or on premises. Supporting software solutions include SafeNet Trusted Access (STA), an access management and authentication service, and SafeNet Authentication Client Middleware, for certificate-based authentication.Thales partners with 3rd-party CMS vendors to offer the most comprehensive identity access and authentication management solutions.To tailor strong authentication to your business and IT needs, choose from the authenticators shown below:Hardware OTP TokensThales’s SafeNet OTP hardware tokens provide a strong and scalable foundation for securing access to enterprise, web-based and cloud applications, and complying with privacy and security regulations.Thales’s SafeNet hardware tokens offer rich case-branding options, and are field-programmable by the customer, enabling organizations to maintain stringent control over their own critical OTP security data.Certificate-based Virtual Smart CardEnable your cloud transformation securely by building on your current PKI authentication framework for cloud access. Increase mobility by allowing users to access enterprise apps with PKI credentials, from any device via VDI.As convenient as another credit card in your wallet, Thales’s SafeNet credit card-size form factors enable enhanced security with PKI Certificate-Based-Authentication (CBA) and enable preboot authentication, disk encryption, file encryption, digital signatures, and secure certificate and key storage.All Thales smart card authenticators can easily double as physical access cards to secure buildings and sites, in addition to offering rich branding options and support for photo-badging. Depending on the configuration, Thales’s certificate-based authenticators are FIPS or CC certified. The dual interface versions of SafeNet IDPrime Smart Cards comply with the ISO 14443 standard which is also compatible with some NFC readers present in smartphones and tablets. SafeNet IDPrime Smart Cards are supported by SafeNet Authentication Client Middleware or SafeNet Minidriver.Thales’s portfolio of certificate-based USB tokens offers strong multi-factor authentication in a traditional USB form factor, enabling organizations to address their PKI security needs. SafeNet PKI USB tokens offer a single solution for strong authentication and applications access control, including remote access, network access, password management, network logon, as well as advanced applications including digital signature, data and email encryption.Depending on their configuration, the certificate-based USB tokens can be FIPS and CC certified.FIDO DevicesFIDO authenticators enable multi-factor authentication to cloud and web services as well as Windows 10 devices. Thales offers a range of FIDO devices, including a combined PKI-FIDO smart card and a FIDO USB token.Smartphone and Software TokensOffering the convenience of phone-as-a-token authentication, Thales offers PUSH OTP software authentication for tablets and mobile phones.Tokenless Authentication SolutionsThales’s tokenless technology enables any user to be authenticated anytime and anywhere. Thales’s context-based authentication offers convenient, frictionless strong authentication while maintaining the flexibility and agility to add protection with stronger methods of security in higher risk situations. Combined with “step-up” authentication, context-based authentication optimizes a layered approach to access security by assessing user login attributes and matching them against pre-defined security policies.Card ReadersInterface devices, or readers, are an essential component of any smart card deployment and ensure communication between smart cards and network services, but they must do so in a convenient yet secure manner. Thales’s full range of smart card readers provide the perfect balance of ease of use, backed by the highest level of security.About SafeNet Identity and Access Management SolutionsThales's industry-leading Access Management and Authentication solutions let enterprises centrally manage and secure access to enterprise IT, web and cloud-based applications. Utilizing policybased SSO and universal authentication methods, enterprises can effectively prevent breaches, migrate to the cloud securely and simplify regulatory compliance.To learn more, visit: /access-managementAbout ThalesThe people you rely on to protect your privacy rely on Thales to protect their data. When it comes to data security, organizations are faced with an increasing number of decisive moments. Whether the moment is building an encryption strategy, moving to the cloud, or meeting compliance mandates, you can rely on Thales to secure your digital transformation.Decisive technology for decisive moments.> <Contact usFor all office locations and contact information, please visit /contact-ush a l e s - N o v e m b e r 2020 • R M v 46。
