注塑产品模具可行性分析(DFM) PPT

客户确认所有安装孔 都是一个方向
Parting line
P/ LINE
蓝色为PL线 Blue line is PL line.
Notes: please advice any concern on propose parting line.
Cavity PL
Core
Parting line
确认是否能 更改（客户 不能理解此 处具体意思 ）；客户回 复分型线有 问题，都是 放在最下面 的，不会出 现插穿面， 乐新下来根 据客户意见 重新分析
Core side slider 1 ,2 and slider insert line (both side are the same) 后模行位1和2（左右两侧）
倒扣问题，PPT说 明不清楚，乐新重 新更新
Notes: please advice any concern on witness line form by lifter.
产品周圈无出模斜度 ，建议减胶拔模出后 模 This position around the Parts do not have demolding draft angle ，need to modify
客户下来检查数 据
Core side Cavity side
？ ？ ？
Gate layout
三点位置针阀式热嘴转搭底进胶 3 point valve gates turn to edge gate
Part Layout
Need to show part layout to avoid customer misunderstood our proposal Tool top
P/ LINE
参考 Cavity S301
PL Core
蓝色为PL线 Blue line is PL line.
目前没有插穿角度，为简化分型面， 此处做5°以上插穿（左右两侧） This position do not have shut off angle. For To simplify the parting line, we suggest make 5 degree shut off shutoff angle. (Both side are the same)
Thickness Analysis (shrinkage/strength/sink
mark)
产品整体胶厚均匀 Overall the part thickness even
Draft angle information Cavity Part Issue one
前模此处位置倒 扣，需修改 These position have undercut need to modify
Need your input and correction to below information:
ቤተ መጻሕፍቲ ባይዱ
Shrinkage
Y X
Notes: above shrinkage is estimated according to our understanding, pls correct it if there is any risk of getting right dimension
P/ LINE
前模镶件结构如示 Cavity side main inserts layout
此区域要做成整 块，要装配帘布 ，不能有分型线
Insert 1
Insert 2
Insert 3
软硬模前模镶件分型一样 Soft tool and Hard tool are the same
Notes: please advice any concern on propose parting line.
Notes: please advice any concern on propose parting line.
Parting line
P/ LINE
蓝色为PL线 PL line
Notes: please advice any concern on propose parting line.
Insert lines of Cavity side
S401 Rear Frame DFM CAD version number：95_23335_A01
Product information
产品尺寸 Product size：311.06*935.6*62.4
Cavity and core Impression
Core Cavity
Tool information
Core Lifter & Slider
乐新重新更 新PPT，需 要客户确认 的东西都要 提出来是否 需要客户确 认，确认何 种问题
后模行位3 Core side slider 3 position and slider insert lines
Notes: please advice any concern on witness line form by lifter.
Insert lines of Core side
P/ LINE
后模镶件结构如示 Cavity side main inserts layout
Insert 1
Insert 2
Insert 3
软硬模后模分3件
Soft tool and Hard tool are the same
Core Lifter & Slider
Notes: this is very rough layout, but it is a Useful guidance for our tool designer.
大家应该也有点累了，稍作休息
大家有疑问的，可以询问和交流
Benchmark Location
出模方向 Demolding direction
Notes: please advice any concern on propose parting line.
Parting line
P/ LINE
此处建议做3度左右减胶拔 模，模具上需插穿 We suggest reduce plastic to increase the draft angle to 3 degree.
