教育一体机TL182-V2.0 板卡规格书
- 格式:pdf
- 大小:475.88 KB
- 文档页数:16
M185V2.0安卓主板_液晶驱动一体板技术规格书文档修改历史备注日期1创建2016-12-252修改2017-5-1M185是一款基于全志A83T主芯片开发的多媒体液晶驱动一体板。
本款主板搭载1G DDR3+8G eMMC,可以支持LVDS点屏和HDMI高清输出。
其主控IC采用台积电28nm HPC制造工艺,基于ARM Cortex-A7架构,八个核心,主频最高可达2GHz。
采用全志新一代SmartColor技术,有助于在高分辨率下显示出色的图像质量,为您的整机提供赏心悦目的视觉效果。
基本硬件规格:CPU全志A83T,八核ARM Cortex A72.0GHzGPU PowerVR SGX544内存DDR31G(Up to2G)内置存储容量EMMC8GB/16G/32G可选(标贴8GB)显示屏接口LVDS接口(单路,6位双路,8位双路)。
支持最大分辨率1920×1080,支持7"-100"显示屏屏电压选择支持3.3V/5V/12V可选网络RJ45标准接口,百兆以太网接口。
具备蓝牙+wifi模块,支持Wi-Fi802.11b/g/n协议。
支持蓝牙4.0协议。
可外挂3G\4G小板,支持3G数据/4G数据功能,支持WCDMA、EVDO、CDMA、GSM,2G/3G全频段支持850/900/1800/1900MHz/2100MHz(3G\4G小板请联系我司采购)屏幕旋转支持0度,90度,180度,270度手动旋转实时时钟内置实时时钟供电电池、支持定时开关机接口设备支持USB摄像头支持HDMI1.4输出1080P6个USB HOST、2个板载、4个外接扩展3个TTL,其中2个可兼容RS232接口。
支持外接串口设备模块(扩展传感器或一维码,二维码扫描,打印机,刷卡器模块等等)TF卡扩展,最大支持64GB1路标准I2C接口支持耳机输出,内置功放,支持2W*28欧喇叭音频输入支持MIC,1个麦克风接口锂电池接口支持单节锂电池充放电,系统掉电保护,防止重要数据丢失(在V1.2版本基础上增加了该功能)触摸屏支持红外、电阻、电容触摸屏电源输入:DC12V或DC12V5VSTB(开关电源)基本软件规格:操作系统Google Android4.4.4系统语言支持多国语言视频格式Support Video playback up to1080P@60fpsSupport Multi-Format video playback,including Mpeg1、Mpeg2、Mpeg4SP/ASP GMC、H.263including sorenson spark、H.264BP/MP/HP、VP8、WMV9/VC1、JPEG/MJPEG、etcHEVC/H.2651080P@30fps音频格式支持MP3,WMA,MP2,OGG,AAC,M4A,MA4,FLAC,APE,3GP,WAV格式音频播放,支持歌曲列表功能图片浏览支持JPG、BMP、PNG、GIF等各种图片格式浏览并支持旋转/幻灯片播放,最高支持到4096*4096分辨率文书处理WORD,EXCEL,POWERPOINT,PDF,TXT输入法标准Andriod键盘,可选第三方输入法(中文、韩文、日文等)扩展性Google市场多达2万多种优秀软件免费下载系统管理文件管理器原生态Android系统,开放root权限,可进行产品定制开发定时开关机支持OTA远程升级(需定制)3主要接口3.1接口分布图3.2主要接口介绍◆JP9(4PIN/2.0)电源输入扩展口◆◆JP4(6PIN/2.0)背光逆变器控制序号定义属性描述112V 电源输出背光电源输出,+12V 序号定义属性描述112V 电源输入+12V 电源输入212V 电源输入+12V 电源输入3GND 地线地线4GND 地线地线55VSB 输入待机电源,+5V 6STB 输出待机电源控制23BL_EN输出背光板开关控制脚4BL_ADJ输出背光板亮度控制脚5GND地线地线6◆JP21(6PIN/2.0)按键接口◆JP13(6PIN/2.0)CTP/I2C电容触摸屏接口◆JP1(2X15PIN/2.0)LVDS信号输出◆JP6(2X3PIN/2.0)液晶屏屏压选择接口◆JP12(4PIN/2.0)扬声器输出11RXO2-输出Pixel2Negative Data (Odd)12RXO2+输出Pixel2Positive Data (Odd)13GND 地线电源地1415RXOC-输出Negative Sampling Clock (Odd)16RXOC+输出Positive Sampling Clock (Odd)17RXO3-输出Pixel3Negative Data (Odd)18RXO3+输出Pixel3Positive Data (Odd)19RXE0-输出Pixel0Negative Data (Even )20RXE0+输出Pixel0Positive Data (Even )21RXE1-输出Pixel1Negative Data (Even )21RXE1+输出Pixel1Positive Data (Even )23RXE2-输出Pixel2Negative Data (Even )24RXE2+输出Pixel2Positive Data(Even )25GND 地线电源地2627RXEC-输出Negative Sampling Clock (Even )28RXEC+输出Positive Sampling Clock (Even )29RXE3-输出Pixel3Negative Data (Even )30RXE3+输出Pixel3Positive Data (Even )◆JP18(4PIN/2.0)UART4串口◆J23(4PIN/2.0)UART2串口◆J17(4PIN/2.0)UART1串口◆J9(4PIN/2.0)USB3扩展接口◆J11(4PIN/2.0)USB4扩展接口◆J7(4PIN/2.0)USB6扩展接口◆J8(4PIN/2.0)USB7扩展接口◆JP22(5PIN/2.0)遥控接收、工作指示灯◆JP3(2PIN/2.0)MIC麦克风接口◆J4 3.5mm耳机孔,音频输出◆J5Micro SD卡座◆HCON1HDMI信号输出,最高支持1080P◆U210RJ45,100M网口◆SW3UBOOT按键,配合系统升级使用◆JD14USB0_OTG接口,可用于系统升级或者调试◆JD13USB2-HOST接口,可接外部USB设备ANT1WIFI天线外接座子2.4G BT4.04寸4.1板卡尺寸PCB长:123.9mm PCB宽:87.8mm板总体高度约16mm,详细结构图请咨询业务员。
Products SolutionsServicesTechnical Information iTEMP HART ® TMT182Universal temperature Head transmitter for RTD, TC, resistance and voltage transmitters, HART ® -protocol, for installation in a sensor head Form BApplication•Temperature head transmitter with HART ® -protocol for con-verting various input signals into an scalable 4 to 20 mA analog output signal •Input:•Resistance thermometer (RTD)•Thermocouple (TC)•Resistance transmitter ( )•Voltage transmitter (mV)•HART ® -protocol for front end unit or panel unit operation using the hand operating module (DXR275, DXR375) or PC (e. g. ReadWin ® 2000 or FieldCare)Your benefits•Universal settings with HART ® -protocol for various input sig-nals•Operation, visualisation and maintenance via PC, e. g. FieldCare operating software •2 wire technology, 4 to 20 mA analog output•High accuracy in total ambient temperature range•Fault signal on sensor break or short circuit, presettable to NAMUR NE 43•EMC to NAMUR NE 21, CE•UL recognized component to UL 3111-1 •Marine approval •CSA General Purpose •Ex-Certification- ATEX Ex ia and dust zone 22 in compliance with EN 50281-1- FM IS - CSA IS•SIL2 compliant •Galvanic isolation •Output simulation•Min./max. process value indicator function •Customer specific linearization •Linearization curve matchTI00078R/09/EN/14.1871404916TMT1822Endress+HauserFunction and system designMeasuring principle Electronic monitoring and conversion of input signals in industrial temperature measurement.Measuring systemThe iTEMP HART ® TMT182 temperature head transmitter is a 2-wire transmitter with analog output. It has measurement input for resistance thermometers (RTD) in 2-, 3- or 4-wire connection,thermocouples and voltage transmitters. Setting up of the TMT182 is done using the HART ® -Protocol with hand operating module (DXR275, DXR375) or PC (e.g. configuration software ReadWin ® 2000 or FieldCare).InputMeasured variable Temperature (temperature linear transmission behaviour), resistance and voltageMeasuring rangeDepending upon the sensor connection and input signal. The transmitter evaluates a number of different measurement ranges.Type of inputResistance thermometer (RTD)TypeMeasurement rangesMin. measurement rangePt100Pt500Pt1000acc. to IEC 60751 (α = 0.00385)Pt100to JIS C1604-81 (α = 0.003916)-200 to 850 °C (-328 to1562 °F)-200 to 250 °C (-328 to 482 °F)-200 to 250 °C (-238 to 482 °F)-200 to 649 °C (-328 to 1200 °F)10 K (18 °F)10 K (18 °F)10 K (18 °F)10 K (18 °F)Ni100Ni500Ni1000acc. to DIN 43760 (α = 0.006180)-60 to 250 °C (-76 to 482 °F)-60 to 150 °C (-76 to 302 °F)-60 to 150 °C (-76 to 302 °F)10 K (18 °F)10 K (18 °F)10 K (18 °F)•Connection type: 2-, 3- or 4-wire connection•Software compensation of cable resistance possible in the 2 wire system (0 to 30 Ω)•Sensor cable resistance max. 20 Ω per cable in the 3 and 4 wire system •Sensor current: ≤ 0.2 mA•Corrosion detection as per NAMUR NE 89 for Pt100 4-wire connection (optional for 'A dvanced Diagnostic' version, see 'P roduct structure'). If corrosion detection is active, the response time is 2 s.Resistance transmitter Resistance Ω10 to 400 Ω10 to 2000 Ω10 Ω100 ΩThermocouple (TC)B (PtRh30-PtRh6)C (W5Re-W26Re)1)D (W3Re-W25Re)1E (NiCr-CuNi)J (Fe-CuNi)K (NiCr-Ni)L (Fe-CuNi)2)N (NiCrSi-NiSi)R (PtRh13-Pt)S (PtRh10-Pt)T (Cu-CuNi)U (Cu-CuNi)2acc. to IEC 584 Part 10 to +1820 °C (32 to 3308 °F)0 to +2320 °C (32 to 4208 °F)0 to +2495 °C (32 to 4523 °F)-270 to +1000 °C (-454 to 1832 °F)-210 to +1200 °C (-346 to 2192 °F)-270 to +1372 °C (-454 to 2501 °F)-200 to +900 °C (-328 to 1652 °F)-270 to +1300 °C (-454 to 2372 °F)-50 to +1768 °C (-58 to 3214 °F)-50 to +1768 °C (-58 to 3214 °F)-270 to +400 °C (-454 to 752 °F)-200 to +600 °C (-328 to 1112 °F)500 K (900 °F)500 K (900 °F)500 K (900 °F) 50 K (90 °F) 50 K (90 °F) 50 K (90 °F) 50 K (90 °F) 50 K (90 °F)500 K (900 °F)500 K (900 °F)50 K (90 °F)50 K (90 °F)•Cold junction: internal (Pt100)•Cold junction accuracy: ± 1 KVoltage transmitters Millivolt transmitter -10 to 75 mV 5 mV1) acc. to ASTM E9882) acc. to DIN 43710TMT182Endress+Hauser 3OutputOutput signal Analog 4 to 20 mA, 20 to 4 mASignal on alarm•Underranging: linear drop to 3.8 mA •Overranging: linear rise to 20.5 mA•Sensor break; sensor short-circuit (not for thermocouples TC): ≤ 3.6 mA or ≥ 21.0 mALoadmax. (V Power supply - 11.5 V) / 0.022 A (Current output)Linearization/transmission behaviour Temperature linear, resistance linear, voltage linearFilter1st order digital filter: 0 to 100 s Galvanic isolation U = 2 kV AC (input/output)Min. current consumption ≤ 3.5 mA Current limit ≤ 23 mASwitch on delay4 s (during power up I a = 3.8 mA)Power supplyElectrical connectionHead transmitter terminal connectionsFor the unit operation via HART ® protocol (terminals 1 and 2) a minimum load resistance of 250 Ω is necessary in the signal circuit!Supply voltage U b = 11.5 to 35 V, polarity protectionUndervoltage detectionOptional for 'A dvanced Diagnostic' version.If the supply voltage is not sufficient to output the output signal corresponding to the measuredtemperature, a signal on alarm ≤ 3.6 mA is generated. After approx. 2 to 3 s, the system makes another attempt to output the signal corresponding to the temperature.Guaranteed values for setting "high alarm" (≥ 21 mA):•Standard model: > 21.5 mA•Advanced diagnostic model: ≥ 22.5 mATMT1824Endress+HauserResidual rippleAllowable ripple U ss ≤ 3 V at U b ≥ 13 V, f max. = 1 kHzPerformance characteristicsResponse time 1 s (TC), 1.5 s (RTD)Reference operating conditionsCalibration temperature: +25 °C (77 °F) ± 5 K (9 °F)Maximum measured errorInfluence of supply voltage≤ ± 0.01%/V deviation from 24 VPercentages refer to the full scale value.Influence of ambienttemperature (temperature drift)Total temperature drift = input temperature drift + output temperature driftThe accuracy data are typical values and correspond to a standard deviation of ± 3σ (normal distribution), i.e. 99.8% of all the measured values achieve the given values or better values.TypeMeasurement accuracy 1Resistancethermometer RTDPt100, Ni100Pt500, Ni500Pt1000, Ni10000.2 K or 0.08%0.5 K or 0.20%0.3 K or 0.12%Thermocouple TCK, J, T, E, L, U N, C, D R, S Btyp. 0.5 K or 0.08%typ. 1.0 K or 0.08%typ. 1.4 K or 0.08%typ. 2.0 K or 0.08%Measurement rangeMeasurement accuracy 1)1) % is related to the adjusted measurement range. The value to be applied is the greater.Resistance transmitter (Ω)10 to 400 Ω10 to 2000 Ω± 0.1 Ω or 0.08%± 1.5 Ω or 0.12%Voltage transmitters (mV)-10 to 75 mV± 20 μV or 0.08%Physical input range of the sensors 10 to 400 ΩPolynom RTD, Pt100, Ni10010 to 2000 ΩPt500, Pt1000, Ni1000-10 to 75 mV Thermocouple type: C, D, E, J, K, L, N, U -10 to 35 mVThermocouple type: B, R, S, TEffect on the accuracy when ambient temperature changes by 1 K (1.8 °F):Input 10 to 400 Ωtyp. 0.0015% of measured value, min. 4 m ΩInput 10 to 2000 Ωtyp. 0.0015% of measured value, min. 20 m ΩInput -10 to 75 mV typ. 0.005% of measured value, min. 1.2 μV Input -10 to 35 mV typ. 0.005% of measured value, min. 0.6 μV Output 4 to 20 mAtyp. 0.005% of spanTMT182Endress+Hauser 5Example for calculating measured error for ambient temperature drift:Input temperature drift ∆T = 10 K (18 °F), Pt100, measuring range 0 to 100 °C (32 to 212 °F)Maximum process temperature: 100 °C (212 °F)Measured resistance value: 138.5 Ω (IEC 60751) at maximum process temperature Typical temperature drift in Ω: (0.0015% of 138.5 Ω) * 10 = 0.02078 ΩConversion to Kelvin: 0.02078 Ω / 0.385 Ω/K = 0.05 K (0.09 °F)Influence of load± 0.02%/100 ΩValues refer to the full scale valueLong-term stability≤ 0.1 K/year or ≤ 0.05%/yearValues under reference operating conditions. % refer to the set span. The highest value is valid.Influence of cold junctionPt100 DIN IEC 60751 Cl. B (internal cold junction with thermocouples TC)Installation conditionsInstallation instructions•Installation angle:no limit•Installation area:Terminal head accord. to DIN 43 729 Form B; TAF10 field housingEnvironment conditionsAmbient temperature limits-40 to +85 °C (-40 to 185 °F) for Ex-area, see Ex-certificateStorage temperature -40 to +100 °C (-40 to 212 °F)Climate class According to IEC 60 654-1, class C Condensation PermittedDegree of protection IP 00, IP 66 installedShock and vibration resistance4g / 2 to 150 Hz as per IEC 60 068-2-6Typical sensitivity of resistance thermometers:Pt: 0.00385 * R nominal /KNi: 0.00617 * R nominal /KExample Pt100: 0.00385 x 100 Ω/K = 0.385 Ω/KTypical sensitivity of thermocouples:B: 10 μV/K C: 20 μV/K D: 20 μV/K E: 75 μV/K J: 55 μV/K K: 40 μV/K L: 55 μV/KN: 35 μV/KR: 12 μV/KS: 12 μV/KT: 50 μV/KU: 60 μV/KTMT1826Endress+HauserElectromagnetic compatibility (EMC)CE conformityEMC to all relevant requirements of the IEC/EN 61326 - series and NAMUR Recommendation EMC (NE21). For details, refer to the Declaration of Conformity.Maximum fluctuations during EMC- tests: < 1% of measuring span.Interference immunity to IEC/EN 61326 - series, requirements for industrial areas Interference emission to IEC/EN 61326 - series, electrical equipment Class BMechanical constructionDesign, dimensionsDimensions of the head transmitter in mm (in)Weight approx. 40 g (1.4 oz)Material•Housing: PC •Potting: PURTerminals•Cable up to max. 1.75 mm 2 (secure screws)•or 1.5 mm 2 with wire end ferrules•eyelets for easy connection of a HART ®-handheld terminal with alligator clipsHuman interfaceDisplay elementsNo display elements are present directly on the temperature transmitter.The measured value display can be called up using the ReadWin ® 2000 or FieldCare PC software.Operating elementsAt the temperature transmitter no operating elements are available directly. The temperaturetransmitter will be configured by remote operation with the PC software ReadWin ® 2000 or FieldCare.Remote operationConfigurationHand operating module DXR275, DXR375 or PC with Commubox FXA191/FXA195 and operating software (ReadWin ® 2000 or FieldCare).InterfacePC interface Commubox FXA191 (RS232) or FXA195 (USB)Configurable parametersSensor type and connection type, engineering units (°C/°F), measurement range, internal/external cold junction, compensation of wire resistance with 2-wire connection, failure mode, output signal (4 to 20/20 to 4 mA), digital filter (damping), offset, TAG + descriptor (8 + 16 characters), output simulation, customer specific linearization, min./max. process value indicator functionTMT182Endress+Hauser 7Certificates and approvalsCE-MarkThe device meets the legal requirements of the EC directives. Endress+Hauser confirms that the device has been successfully tested by applying the CE mark.Hazardous area approvalsFor further details on the available Ex versions (ATEX, CSA, FM, etc.), please contact your nearest Endress+Hauser sales organisation. All relevant data for hazardous areas can be found in separate Ex documentation. If required, please request copies from us or your Endress+Hauser sales organisation.Marine approvalFor further details on the available "Type Approval Certificiates" (DNVGL, BV, etc.), please contact your nearest Endress+Hauser sales organisation. All relevant data for marine approval can be found in separate "Type Approval Certificiates". If required, please request copies from us or your Endress+Hauser sales organisation.Other standards and guidelines•IEC 60529:Degree of protection provided by housing (IP-Code)•IEC 61010:Safety requirements for electrical measurement, control and laboratory use.•IEC 61326:Electromagnetic compatibility (EMC requirements)•NAMURStandards working group for measurement and control technology in the chemical industry. (www.namur.de)UL approval UL recognized component (see /database, search for Keyword "E225237")CSA GPCSA General PurposeExamination certificateIn compliance with WELMEC 8.8, valid only for the SIL-Mode: "Guide on the General andAdministrative Aspects of the Voluntary System of Modular Evaluation of Measuring Instruments.Ordering informationDetailed ordering information is available from the following sources:•In the Product Configurator on the Endress+Hauser website: -> Click "Corporate" -> Select your country -> Click "Products" -> Select the product using the filters and search field -> Open product page -> The "Configure" button to the right of the product image opens the Product Configurator.•From your Endress+Hauser Sales Center: Product Configurator - the tool for individual product configuration •Up-to-the configuration•Depending on the device: Direct input of measuring point-specific information such as measuring range or operating language •Automatic verification of exclusion criteria•Automatic creation of the order code and its breakdown in PDF or Excel output format •Ability to order directly in the Endress+Hauser Online ShopTMT182Accessories•Commubox FXA191 (RS232) or FXA195 (USB)Order code: FXA191-... or FXA195-...•PC-operating software: ReadWin ® 2000 or FieldCareReadWin ® 2000 can be downloaded free of charge from the internet from the following address: /readwin•Hand operating module ’HART ® Communicator DXR375’Order code: DXR375-...•DIN rail clip according to IEC 60715 (TH35) for head transmitter mounting Order code: 51000856•Field housing TAF10 for Endress+Hauser head transmitter, aluminum, IP 66,dimensions W x H x D: 100 x 100 x 60 mm (3.94" x 3.94" x 2.36")Order code: TAF10-...Documentation•Operating short manual iTEMP HART ® TMT182 (KA142R/09/a3)•Additional documentation for use in explosion-hazardous areas:ATEX II1G: XA006R/09/a3ATEX II3G: XA011R/09/a3ATEX II3D: XA027R/09/a3•Operating short manual TAF10 Field housing (KA093R/09/a2)•SIL: Functional safety manual TMT182 (SD006R/09/en)。
E18系列产品规格书CC25302.4GHz ZigBee3.0无线模块目录第一章产品概述 (3)1.1产品简介 (3)1.2特点功能 (4)1.3应用场景 (5)第二章规格参数 (6)2.1射频参数 (6)2.2电气参数 (6)2.3硬件参数 (6)2.4网络系统参数 (7)第三章机械尺寸与引脚定义 (8)第四章硬件设计 (11)第五章软件设计 (11)第六章常见问题 (13)6.1传输距离不理想 (13)6.2模块易损坏 (13)6.3误码率太高 (13)第七章焊接作业指导 (7)7.1回流焊温度 (7)7.2回流焊曲线图 (7)第八章相关型号 (8)第九章天线指南 (8)第十章产品包装图 (8)修订历史 (9)关于我们 (9)第一章产品概述1.1产品简介E18系列是亿佰特设计生产的2.4GHz频段的ZigBee通信协议转串口无线模块,贴片型,PCB板载天线或IPEX-1接口,引脚间距1.27mm,出厂自带自组网固件,到手即用,适用于多种应用场景(尤其智能家居)。
E18系列模块采用美国德州仪器公司原装进口CC2530射频芯片,芯片内部集成了8051单片机及无线收发器,部分模块型号内置PA功率放大器增加通信距离。
出厂自带固件基于ZigBee3.0协议实现的串口数据透传,支持ZigBee3.0协议下各种指令命令。
经实测,对市面上大多数ZigBee3.0产品有着非常良好的兼容性。
1.2ZigBee 3.0优势E18系列模块固件基于Z-Stack3.0.2协议栈(ZigBee 3.0),该版本为CC2530/CC2538系列芯片最优协议栈,因此我司也此基础上做了许多优化,确保系统长期稳定运行。
ZigBee3.0与早前版本的应用方式区别:1.组网方式发生变化:ZigBee 3.0取缔了一上电就组网的方式,而是根据实际需要进行组网。
任何设备在出厂状态下是无网络状态,协调器需要运行“formation”(调用bdb_StartCommissioning(BDB_COMMISSIONING_MODE_NWK_FORMATION))来新建网络,然后再运行"Steering"(调用bdb_StartCommissioning(BDB_COMMISSIONING_MODE_NWK_STEERING))打开网络,打开网络默认时间180秒,可通过广播"ZDP_MgmtPermitJoinReq"的方式将打开网络提前关闭。
Dimensions: [mm]Scale - 2:1Scale - 1,5:176********768748018276874801827687480182T e m p e r a t u r eT T T 7687480182Cautions and Warnings:The following conditions apply to all goods within the product series of WE-TI-HV ofWürth Elektronik eiSos GmbH & Co. KG:General:•This electronic component is designed and manufactured for use in general electronic equipment.•Würth Elektronik must be asked for written approval (following the PPAP procedure) before incorporating the components into any equipment in fields such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network, etc. where higher safety and reliability are especially required and/or if there is the possibility of direct damage or human injury.•Electronic components that will be used in safety-critical or high-reliability applications, should be pre-evaluated by the customer. •The component is designed and manufactured to be used within the datasheet specified values. If the usage and operation conditions specified in the datasheet are not met, the wire insulation may be damaged or dissolved.•Do not drop or impact the components, the component may be damaged.•Würth Elektronik products are qualified according to international standards, which are listed in each product reliability report. Würth Elektronik does not warrant any customer qualified product characteristics beyond Würth Elektroniks’ specifications, for its validity and sustainability over time.•The responsibility for the applicability of the customer specific products and use in a particular customer design is always within the authority of the customer. All technical specifications for standard products also apply to customer specific products.Product specific:Soldering:•The solder profile must comply with the technical product specifications. All other profiles will void the warranty.•All other soldering methods are at the customers’ own risk.Cleaning and Washing:•Washing agents used during the production to clean the customer application might damage or change the characteristics of the wire insulation, marking or plating. Washing agents may have a negative effect on the long-term functionality of the product. Potting:•If the product is potted in the customer application, the potting material might shrink or expand during and after hardening. Shrinking could lead to an incomplete seal, allowing contaminants into the core. Expansion could damage the component. We recommend a manual inspection after potting to avoid these effects.Storage Conditions:• A storage of Würth Elektronik products for longer than 12 months is not recommended. Within other effects, the terminals may suffer degradation, resulting in bad solderability. Therefore, all products shall be used within the period of 12 months based on the day of shipment.•Do not expose the components to direct sunlight.•The storage conditions in the original packaging are defined according to DIN EN 61760-2.•The storage conditions stated in the original packaging apply to the storage time and not to the transportation time of the components. Packaging:•The packaging specifications apply only to purchase orders comprising whole packaging units. If the ordered quantity exceeds or is lower than the specified packaging unit, packaging in accordance with the packaging specifications cannot be ensured. Handling:•Violation of the technical product specifications such as exceeding the nominal rated current will void the warranty.•Applying currents with audio-frequency signals may result in audible noise due to the magnetostrictive material properties.•Due to heavy weight of the components, strong forces and high accelerations may have the effect to damage the electrical connection or to harm the circuit board and will void the warranty.•Please be aware that products provided in bulk packaging may get bent and might lead to derivations from the mechanical manufacturing tolerances mentioned in our datasheet, which is not considered to be a material defect.•The temperature rise of the component must be taken into consideration. The operating temperature is comprised of ambient temperature and temperature rise of the component.The operating temperature of the component shall not exceed the maximum temperature specified.These cautions and warnings comply with the state of the scientific and technical knowledge and are believed to be accurate and reliable.However, no responsibility is assumed for inaccuracies or incompleteness.Würth Elektronik eiSos GmbH & Co. KGEMC & Inductive SolutionsMax-Eyth-Str. 174638 WaldenburgGermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODTRi001.0002021-03-02DIN ISO 2768-1mDESCRIPTIONWE-TI HV Radial Leaded WireWound Inductor (High Voltage)ORDER CODE7687480182SIZE/TYPE BUSINESS UNIT STATUS PAGEImportant NotesThe following conditions apply to all goods within the product range of Würth Elektronik eiSos GmbH & Co. KG:1. General Customer ResponsibilitySome goods within the product range of Würth Elektronik eiSos GmbH & Co. KG contain statements regarding general suitability for certain application areas. These statements about suitability are based on our knowledge and experience of typical requirements concerning the areas, serve as general guidance and cannot be estimated as binding statements about the suitability for a customer application. The responsibility for the applicability and use in a particular customer design is always solely within the authority of the customer. Due to this fact it is up to the customer to evaluate, where appropriate to investigate and decide whether the device with the specific product characteristics described in the product specification is valid and suitable for the respective customer application or not.2. Customer Responsibility related to Specific, in particular Safety-Relevant ApplicationsIt has to be clearly pointed out that the possibility of a malfunction of electronic components or failure before the end of the usual lifetime cannot be completely eliminated in the current state of the art, even if the products are operated within the range of the specifications.In certain customer applications requiring a very high level of safety and especially in customer applications in which the malfunction or failure of an electronic component could endanger human life or health it must be ensured by most advanced technological aid of suitable design of the customer application that no injury or damage is caused to third parties in the event of malfunction or failure of an electronic component. Therefore, customer is cautioned to verify that data sheets are current before placing orders. The current data sheets can be downloaded at .3. Best Care and AttentionAny product-specific notes, cautions and warnings must be strictly observed. Any disregard will result in the loss of warranty.4. Customer Support for Product SpecificationsSome products within the product range may contain substances which are subject to restrictions in certain jurisdictions in order to serve specific technical requirements. Necessary information is available on request. In this case the field sales engineer or the internal sales person in charge should be contacted who will be happy to support in this matter.5. Product R&DDue to constant product improvement product specifications may change from time to time. As a standard reporting procedure of the Product Change Notification (PCN) according to the JEDEC-Standard inform about minor and major changes. In case of further queries regarding the PCN, the field sales engineer or the internal sales person in charge should be contacted. The basic responsibility of the customer as per Section 1 and 2 remains unaffected.6. Product Life CycleDue to technical progress and economical evaluation we also reserve the right to discontinue production and delivery of products. As a standard reporting procedure of the Product Termination Notification (PTN) according to the JEDEC-Standard we will inform at an early stage about inevitable product discontinuance. According to this we cannot guarantee that all products within our product range will always be available. Therefore it needs to be verified with the field sales engineer or the internal sales person in charge about the current product availability expectancy before or when the product for application design-in disposal is considered. The approach named above does not apply in the case of individual agreements deviating from the foregoing for customer-specific products.7. Property RightsAll the rights for contractual products produced by Würth Elektronik eiSos GmbH & Co. KG on the basis of ideas, development contracts as well as models or templates that are subject to copyright, patent or commercial protection supplied to the customer will remain with Würth Elektronik eiSos GmbH & Co. KG. Würth Elektronik eiSos GmbH & Co. KG does not warrant or represent that any license, either expressed or implied, is granted under any patent right, copyright, mask work right, or other intellectual property right relating to any combination, application, or process in which Würth Elektronik eiSos GmbH & Co. KG components or services are used.8. General Terms and ConditionsUnless otherwise agreed in individual contracts, all orders are subject to the current version of the “General Terms and Conditions of Würth Elektronik eiSos Group”, last version available at .Würth Elektronik eiSos GmbH & Co. KGEMC & Inductive SolutionsMax-Eyth-Str. 174638 WaldenburgGermanyCHECKED REVISION DATE (YYYY-MM-DD)GENERAL TOLERANCE PROJECTIONMETHODTRi001.0002021-03-02DIN ISO 2768-1mDESCRIPTIONWE-TI HV Radial Leaded WireWound Inductor (High Voltage)ORDER CODE7687480182SIZE/TYPE BUSINESS UNIT STATUS PAGE。
教育一体机规格书(产品型号:HOHVI-7500)文件编号:NO.2018MI-01版本信息:Ver1.0编制:郭军强审核:张镇发布日期:2018-06-13*此文件中包含的所有信息内容最终解释权归本公司,所有未经授权和允许的复制都是不被认可和应被禁止的。
*此文件中包含所有的参数数据信息为此系列标准版机型的参数信息,不代表我司此系列产品所有的参数数据,实际参数数据要以与销售签订的具体型号为准。
版本变更记录目录封面 (1)版本变更记录 (3)目录 (4)产品概述 (5)产品参数说明 (6)实物效果预览 (16)配件 (17)1、产品概述1)铝合金外框,表面拉丝阳极氧化处理,铁壳后盖,主动散热;2)4mm物理钢化防暴高透玻璃;加强视觉效果,提升触摸体验;3)高速10点红外触控,更快的书写速度,最佳书写体验;4)超窄拉丝面框,超窄设计,整机面框单边仅22MM。
5)使用国际通用标准的OPS插槽,一体化插拔式设计,方便升级与维护,外部无可见电脑模块的连接线,机身美观。
6)正面前置式扩展端口:1路PC-USB 、1路TV-USB、1路HDMI、1路TOUCH-USB接口,方便用户拓展使用。
7)正面前置7键功能按钮分别为:通道/信号源、菜单、音量+、音量-、桌面、电源、节能;电源按键可实现三合一电视、电脑、节能一体开关功能;操作便捷。
8)前置遥控窗口,便于用户用遥控器操作,设置调试机器使用。
9)喇叭出音前置,防止因内嵌环境导致声音效果变质。
10)机器内的安卓主板和PC端分别内置WIFI模块,便于用户通过WIFI进行无线传输及网络操作。
11)支持侧拉触摸菜单,支持任何通道书写、批注、截图功能;童锁功能,通过设置可屏蔽按键功能等。
2、产品参数说明2.1显示参数2.2主板参数2.3外观参数75寸:3、实物效果预览4、案例展示会议室:教室:5、配件附件规格电源线国标三插2M * 1说明书X1保修卡X1合格证X1遥控器X1触摸笔X1壁挂壁挂架/移动支架x1(选配)。
深圳市嘉润源电子有限公司规格书- MST9UGX-V2 V1.0液晶显示器驱动主板规格书板卡型号:MST9UGX-V2板卡规格: DVI-I +2DP+2HDMI+AUDIO版本号:V2编制:ZXH审核:ZL批准:日期:2014.03.25深圳市嘉润源电子有限公司规格书- MST9UGX-V2目录页码内容1 目录2 产品概述2 产品特性3 产品外观图4 模式支持表5 产品结构图6 接口定义7 使用注意事项1.规格简介GENERAL DESCRIPTIONMST9U01V1 是一个 4K2K 的 LCD 显示器的单芯片解决方案,最高支持到 4096x2160@60Hz 的分辨率。
MST9U01V1 ,a total chip SOC that for LCD monitors with panel resolutions up to4096x2160@60Hz.主要特点:Key features include:>1. 集成 4个高质量图像缩放引擎,可同时处理 4个 4K2K@30Hz 视频输入流。
Integrated four High-quality scaling engine for processing up to 4 4K2K@30Hz AV Stream.>2. 集成 6 个复合数字接口,每一个都可支持 HDMI/DVI/DP/MHL 接口,另外集成 1 路模拟输入端口,支持 PC(VGA)输入。
Integrated 6 Combo Digital Ports (Supports HDMI/DVI/DP/MHL) and 1 Analog Input Ports (Supports深圳市嘉润源电子有限公司规格书- MST9UGX-V2 Analog RGB Compliant Input Ports);>3. 内建LVDS/eDP(可选),需要转接板支持)/VBY1接口,最高支持分辨率为4096x2160@60Hz的 LCD Panel。
教育信息化“三通两平台”工程1云数据中心核心设备清单及技术要求5、统一用户认证的同时支持权限的多级识别控制,如一个教师在本校是管理员权限,其可控制系统后台,但其访问区域内其他学校首页和资源时,只是普通用户的权限。
6、区域内各校管理员独立对本校内的资源进行分类、对教师信息、学校主页设置等进行管理和设置,之间互不干扰。
区域管理员对全区学校的资源有审核管理最高权限。
校内教研员可观看本校内教师直播、区域教研员具有观看全区直播课堂的权限。
7、对区域各校资源管理展示:1)对资源进行热门、最新排行。
2)资源按照学校、学科、年级导航。
3)按照教材结构导航,如按照学科、册、章、节四级目录导航,目录结构支持自定义。
4)文档资源的展示,并按照学校、学科、年级、教材结构分类导航;5)视频文档的关联。
课程视频可关联教学课件、题库、教案等文档资源。
6)文档下载。
支持文档下载功能并对此功能进行权限控制。
7)全局搜索。
分别按照学校、学科、年级、类型、标题、关键词、主讲人等关键字进行搜索。
8)自定义学科、年级等信息8、对全区域内视频和文档进行评论和评分,并按照评论数量进行排序。
全区域公开课直播。
支持自动生成包含教师隶属学校、姓名、学科、年级、课程信息等消息信息的直播列表,有权限的用户点击列表观看直播。
9、可根据实际的教学评估要求,设置多套评估标准,如语文课的评估标准、数学课的评估标准、英语课的评估标准、不同科目教学技能训练用评估标准,不同的需要使用不同的微格教学评估标准。
每套评估标准可设置不同的总分,可设置多项评估项目,每项评估项目可设置多项评估子项,可满足各种各样的评估要求。
并支持评估标准编辑功能。
10、微视频:教师从平台下所有视频资源中切割出一部分,生成新视频。
微视频编辑支持虚拟切割技术,在不损害源文件的基础上,支持同一视频多人同时在线同时编辑而互不影响。
截取过程支持填写标题、片段的教学反思记录等内容,截取的微视频可保存到教师个人空间,并支持微视频的搜索功能。
LCD TV controller board specification for KSTV29.A1
P r o d u c t S p e c i f i c a t i o n LC D TV Main boa rd
M o d e l:T L182-V 2.0
Author:谭柏华
Review:
Version:A1
LCD TV controller board specification for KSTV29.A1
CONTENTS
LCD TV controller board specification for KSTV29.A1
REVISION HISTORY
LCD TV controller board specification for KSTV29.A1 4、概述
▲支持最高分辨率为1920×1200@60Hz,主配机型为15’-84’
▲ RF制式:PAL-D/K/B/G/I;SECAM-D/K/B/G/L/L’;NTSC-M/N
▲支持HDMI1.4(HDCP1.1),DVI1.0
5、特点描述
LCD TV controller board specification for KSTV29.A1
6、 端子描述
7、板卡尺寸 请参考附件。
输出 A V 输入接口
IO 口1 TV 输入 S 端子 串口1
A V 输入接口
LVDS 输出接口
前置电脑/前置高清
12V 功放供电
按键接口
遥控/LED 接口
麦克风输入
LCD TV controller board specification for KSTV29.A1 8、注意事项
▲整机装配和运输过程注意防静电处理。
▲主板上电时一定要注意屏电压的选择。
▲主板正常工作时要避免金属物质掉落在板卡上。
▲请勿拆卸模块。
▲如果主板表面很脏,请用软(不湿)布。
▲整机装配时,不要使板子变形或扭曲,勿受重压。
9、操作要求
▲相对湿度:≤80%.
▲存储温度: -10~+60 °C.
▲工作温度: 0~+40 °C.
10、接口定义描述
CON12(4PIN/2.0)USB connector 2
CON4(2×18PIN/2.0): LVDS output。
