边缘数据中心管理系统CloudOpera NetEcoCloudOpera NetEco 是华为开发的新一代边缘数据中心管理系统，致力于为客户提供多网点SaaS 管理服务。

实现边缘数据中心的统一智能管理。

产品简介特性价值FusionModule800华为云应用场景极简多网点集中监控，快速交付，平滑扩容，TCO 节省7-15%。

智能网点无人值守，远程故障分析，减小业务影响，节省运维成本75%安全依托华为云，云门户账号分级授权，保障客户业务安全。

企业分支政府学校医院酒店银行网点NetEco APPFusionModule800FusionModule800版权所有©华为技术有限公司2020。

保留一切权利。

非经华为技术有限公司书面同意，任何单位和个人不得擅自摘抄、复制本手册内容的部分或全部，并不得以任何形式传播。

产品特性功能模块特性描述GIS 地图•GIS 地图，支持地图风格变换•基于在线地图实时监控全网运行黄台，异常网点位置一目了然网点监控•提供环境监测，如温湿度、水浸、烟感、防雷器等•可统计IT 负载率、PUE 等信息•支持温控设备、UPS 、PDU 等设备的监测告警管理•支持当前告和历史警的浏览和查询功能•支持告警屏蔽设置，减少无效告警•支持专家经验库，可记录告警处理经验与建议安防管理•支持实时视频浏览•门禁支持指纹、密码、刷卡，支持非法开门告警、远程开门移动访问•支持APP 告警推送•支持查看当前告警、配电、制冷参数、门禁状态与现场实时视频画面。

维保管理•可生成网点报告，查看各个网点的维保过期提醒•可统计网点数量增长趋势、网点连接数量、维保过期数量和即将过期数量用户管理•可按照操作权限和管理区域分配账号权限•支持用户自行注册云服务账号。

目录1．运行ROCLINK800 (1)2．启动DL8000程序 (5)3. Copy 显示文件到安装路径 (6)4．显示屏 (8)5. 基本组态 (9)5．1 时钟设置 (9)5．2. 流量计算机信息 (10)5．3 标志位信息 (13)5．4 I/O配置 (14)5．5 MODBUS通讯配置 (16)5．6 查看报警和事件记录 (19)5．7 保存配置文件及下载配置文件 (19)5．8 FST下载 (22)5．9 升级固件（Firmware） (24)6．批控器具体各项组态 (26)ROCLINK800使用说明1．运行ROCLINK800在与ROC809在线连接时需注意以下事项：需要更改电脑的语言及区域设置，具体步骤如下：1．从电脑左下角的开始菜单中选择设置—>控制面板；2．在控制面板里选择“区域及语言选项”后出现如下画面：3．在“高级”选项卡中，将语言设置从中文（中国）改为英文（美国），如下图所示。

4．点击“应用”按钮，弹出需要重新启动电脑的对话框，点击Yes，重启电脑之后设置修改成功。

5．连接ROC809到电脑。

6．双击ROCLINK800图标，打开组态软件，显示如下登陆界面：7．鼠标放在“User ID”字母上，单击左键；8．如果使用LOI编程口组态，则点击直接连接后，等ROCLINK800软件右下角的红色“OFF-LINE”标记变为绿色“ON-LINE”后，连接成功。

点击此图标，建立电脑和ROC809的连接9．如果使用以太网口，需要使用交叉网线（即电脑与电脑连接所用网线），建立连接步骤如下：新的DL8000默认IP地址为：IP: 10.0.0.2子网掩码：255.255.255.0网关：10.0.0.1连接前首先确认将电脑IP配置到同一网段，Ping是否能通，然后点击Ethernet Device的属性，如图：检查IP是否为10.0.0.2如果是，可以点击上方的Connect按钮，或者双击Ethernet Device图标，等待连接。
