飞机外蒙皮上非受力结构有限元模型设计浅析摘要:飞机外蒙皮上的非受力结构具有这样的特性,既要向飞机传递本身的气动载荷,又不参与飞机整体受力。
所以为该类结构建立有限元模型时,要综合考虑上述两个因素,以免出现有限元局部模型失真的情况。
本文根据实际工作中所碰到的一些特殊问题,总结出该类结构的有限元模拟方法。
关键词:非受力结构RBE2 RBE3 MPC Independent node Dependent node1 引言为了保证更好的设计精度和安全性,现代飞机设计对细节的要求越来越高。
我们在Patran中建立飞机有限元模型时,经常会碰到一些用普通单元无法解决的问题,比如,民机的旅客观察窗、外蒙皮的非受力口盖等。
这些结构具有这样的特性,既要向飞机传递本身的气动载荷,又不参与飞机整体受力,即该结构需要设计为只向外传递气动载荷而不传递机身载荷。
2 理论依据为了解决这类问题,我们需要使用Patran中的MPC单元:RBE2和RBE3,下面先叙述这两种MPC单元的工作原理。
2.1 RBE2RBE2单元是一种刚性单元,它由一个主节点(independent node)和若干个从节点(dependent node)构成。
主节点和从节点之间被约束的自由度不能有相对位移,从节点之间被约束的自由度也不能有相对位移,即RBE2内所有的节点在被约束的自由度上是刚性的。
所以RBE2的从节点适用于连接在一个较为刚性的子结构上。
2.2 RBE3RBE3单元是一种柔性连接单元,由若干个主节点(independent node)和一个从节点(dependent node)构成。
它建立了不同节点的力与力矩的分配关系,也称之为插值单元。
其局部刚度为零,不会对系统刚度产生影响。
力和力矩在RBE3单元的作用下,通过相应的权值,被从节点分配到一系列主节点上。
3 建立模型由于民机的旅客观察窗、外蒙皮的非受力口盖等非承力结构仅仅承受气动载荷,其在总体有限元模型中所起的作用也仅仅是在不影响飞机总体传力的前提下,使飞机承受的气动载荷完整而精确。
