80Semiconductor Fuses150/250/500/600/700 VACsVery Fast-Actings1 – 1000 Amperes
Designed to protect today’s equipment and systems,Littelfuse semiconductor fuses are manufactured withLittelfuse-developed technology that sets tomorrow’s stan-dards for accuracy, consistent quality, reliability, and predict-able performance.By using advanced metallurgical, polymer,and materials research;mathematical modeling, and comput-erized statistical analysis;Littelfuse engineers have redefined“State-of-the-Art.”APPLICATIONSDesigned specifically for supplementary protection of semiconducting devices such as silicon controlled rectifiers(SCR’s), diodes, thyristors, triacs, transistors, and similarsolid-state devices.These devices are used in power equipment including variable speed drives, power rectifiers,UPS systems, DC power supplies, and in a wide range ofelectronic equipment.May be used wherever extremely fast-acting, current-limitingfuses with no time delay are required.SPECIFICATIONSVoltage Ratings:L15S:150 V AC/DC (1 – 60A)150 VAC (70 – 1000A)100 VDC (70 – 1000A)L25S:250 V AC/DC (1 – 200A)250 VAC (225 – 800A)200 VDC (225 – 800A)L50S:500 VAC/450VDCL60S:600 VACKLC:600 VACL70S:700VAC/650VDCInterrupting Rating:AC:200,000 rms amperes (L15S series 100,000 amperes)DC:20,000 amperesAmpere Range:1 – 1000 amperesSee Rating Table for ratings available in each series.Approvals:UL Recognized under the Components Programand CSA Recognized under the ComponentAcceptance Program.UL File No:E71611CSA File No:LR29862L15S and L25S series fuses are LittelfuseCertified for DC ratings shown in Rating Table.AMPERE RATINGSSee Rating Table.RECOMMENDED FUSE BLOCKSLSCR series:Refer to Fuse Block section of this catalog foradditional information.SAFETYs200,000 A.I.R.— Reliable interruption of all overcurrents upto 200,000 amperes ...meets present and future systemrequirements.(Note:L15S series has 100,000 A.I.R.)sExtremely Current Limiting — Low I2t and peak let-throughcurrents meet most semiconductor requirements.sUL Recognized — Littelfuse semiconductor fuses are recognized under the components program of UnderwritersLaboratories, Inc., and carry the mark.UL Recognizedsemiconductor fuses may be used to provide supplemen-tary protection in UL listed equipment.LONGER EQUIPMENT LIFEsLow Watt Losses — Means less heating and power consumption in circuit.sControlled Transient Overvoltages — All circuits are subjectto transient overvoltages during fault current interruption.These transient overvoltages (arc voltages) start when fuselinks melt or circuit breaker contacts part, and subsidewhen circuit is interrupted.Semiconductors are very sensitive to overvoltages.Littelfuse semiconductor fusedesigns keep transient overvoltages to low levels and helpreduce semiconductor failure.元器件交易网www.cecb2b.com
81‡ KLC series fuses are recommended for replacement use only.Semiconductor Fuses150/250/500/600/700 VACsVery Fast-Actings1 – 1000 Amperes Series & VoltageL15SL25SL50SL60SKLC‡L70S150V AC250V AC150V DC (1 – 60A)250V DC (1 – 200A)500V AC600V AC600V AC700V AC100V DC (70 – 1000A)200V DC (225 – 800A)450V DC650V DC1L15S 1L25S 1L60S 1KLC 12L15S 2L25S 2L60S 2KLC 23L15S 3L25S 3L60S 3KLC 34L15S 4L25S 4L60S 4KLC 45L15S 5L25S 5L60S 5KLC 56L15S 6L25S 6L60S 6KLC 67L15S 7KLC 78L15S 8L25S 8L60S 8KLC 89L15S 910L15S 10L25S 10L50S 10L60S 10KLC 10L70S 1012L15S 12L25S 12L50S 12L60S 12KLC 1215L15S 15L25S 15L50S 15L60S 15KLC 15L70S 15171⁄2L60S 171⁄2KLC 171⁄220L15S 20L25S 20L50S 20L60S 20KLC 20L70S 2025L15S 25L25S 25L50S 25L60S 25KLC 25L70S 2530L15S 30L25S 30L50S 30L60S 30KLC 30L70S 3035L15S 35L25S 35L50S 35L60S 35KLC 35L70S 3540L15S 40L25S 40L50S 40L60S 40KLC 40L70S 4045L15S 45L25S 45L60S 45KLC 4550L15S 50L25S 50L50S 50L60S 50KLC 50L70S 5060L15S 60L25S 60L50S 60L60S 60KLC 60L70S 6070L15S 70L25S 70L50S 70L60S 70KLC 70L70S 7080L15S 80L25S 80L50S 80L60S 80KLC 80L70S 8090L15S 90L25S 90L50S 90L60S 90KLC 90L70S 90100L15S 100L25S 100L50S 100L60S 100KLC 100L70S 100110KLC 110125L15S 125L25S 125L50S 125L60S 125KLC 125L70S 125150L15S 150L25S 150L50S 150L60S 150KLC 150L70S 150175L25S 175L50S 175L60S 175KLC 175L70S 175200L15S 200L25S 200L50S 200L60S 200KLC 200L70S 200225L25S 225L50S 225L60S 225KLC 225L70S 225250L15S 250L25S 250L50S 250L60S 250KLC 250L70S 250275L25S 275L50S 275300L15S 300L25S 300L50S 300L60S 300KLC 300L70S 300350L15S 350L25S 350L50S 350L60S 350KLC 350L70S 350400L15S 400L25S 400L50S 400L60S 400KLC 400L70S 400450L15S 450L25S 450L50S 450L60S 450KLC 450L70S 450500L15S 500L25S 500L50S 500L60S 500KLC 500L70S 500550L50S 550600L15S 600L25S 600L50S 600L60S 600KLC 600L70S 600700L25S 700L50S 700L60S 700KLC 700L70S 700800L15S 800L25S 800L50S 800L60S 800KLC 800L70S 8009001000L15S 1000AmpereRatingsRATING TABLE元器件交易网www.cecb2b.com
