产品说明书英文版V HEN system office room 【HEN16H-HENS2AHENS8Q8-HENH1688】
X-Link PRODUCT MANUALS FOR MULTIVIEW CONTROLER
This manual applies to the following models:
3UA Multiview CONTROLER ( Optional Front Panal,LCD Console )
3UB Multiview CONTROLER ( Optional Front Panal,LCD Console )
8U Multiview CONTROLER ( Optional Front Panal )
8U-S Multiview CONTROLER( Optional Front Panal )
12U Multiview CONTROLER
LED Very-large Dot Matrix Screen Multiview CONTROLER ( K Series ) Monitoring Multiview CONTROLER ( N Series )
3D Multiview CONTROLER ( 3D Series )
4K Multiview CONTROLER (4k Series )
IMPORTANT NOTICE
The company reserves the right to update the manual according to improvement of products without any prior notice.
In the process of using, if any content in this manual is inconsistent with actual products or there is any further question during use,
please contact document information department of our company.
Please read this manual carefully before using the CONTROLER and properly file it after reading for future reference. Pictures are for reference only, subject to our available products.
Please pay close attention to those with the Icon of in the article.
Contents
1
1
2
I Safety guidelines
Danger High Voltage. There is a hazard of high
pressure inside this product, non-professional
maintenance personnel are forbidden to open the
device! Beware of electric shock!
Use the power correctly. Working voltage of this
product is 220V, please ensure using the power
correctly.
Ground and use the fuse correctly. This product
connects to the ground plane with earth conductors
of power line, please don't connect earth wires to
the high pressure.
Keep ventilation. Maintain adequate ventilation for
the device, the gap between front& rear panels and
the side should be at least 20cm.
Moisture proof. Please make sure the device is
placed in a dry environment.
Handle with care. There are precision components
inside the product, please handle with care.
Waterproof &foreign body proof. Any liquid, metal
fragments, or other irrelevant substances are
prohibited to enter the device.
Put it away from the inflammable and explosive
dangerous goods.
II Introduction of Multiview CONTROLER
This chapter includes:
Introduction of Multiview CONTROLER
Exclusive Features of Multiview CONTROLRE
1. Introduction of Multiview CONTROLER
Multiview CONTROLER is also called big screen processor and display wall CONTROLER etc. The main function is to splice multiple display
units together into a logic displayer of ultrahigh resolution, and to realize multiple screens and scenarios of optional position and size through opening windows on the basis of this ultrahigh-resolution displayer, which can also ensure that image quality in each screen is excellent. It can show the entire electronic map, geographical information system, industrial flow chart and industrial monitoring information and other data of ultrahigh resolution.
Base Type(A Series )3U、8U、12U Product Figure,as shown in the following picture:
Base Type Product Figure I（3U、8U、12U）
High-end type(U Series )3U LCD Controller Product Figure,as shown in the following picture:
3U LCD Controller Product Figure II
Mid-Range(K Series )3U Front Panal Product Figure,as shown in the following picture:
3U LCD Front Panal Figure III
Mid-Range(K Series )8U Front Panal Product Figure,as shown in the following picture:
8U LCD Front Panal Figure IV
2. Exclusive Features of Multiview CONTROLER
The company's multi-screen processor has the following exclusive features:
A. Pure hardware structure of FPGA, steady and reliability
With excellent image processing performance, completely avoid troubles caused by the slow starting speed of PC, hardware conflict and computer virus. Mean Time Between Failure（MTBF）>30000. It can work continuously for more than 1 years.
B. Support multiple video signals, on-demand distribution
It supports DVI, HDMI, VGA, AV, SDI, H264 and other video signal for accessing, users can find any collocation as required, meeting
individual requirements of different areas.
C. Flexible board design, random combinations; support hot plug, convenient maintenance
Removable board card matches with cases of different sizes, which can fully meet system requirements of different sizes. Cases make space for expanding and reducing capacity at any time. It is designed with exclusive card channel, system modules, such as input card, output card, control card, fan and power supply, are all independent plug-in design, truly achieving the real-time on-line replacement and convenient maintenance.
D. Multi-input videos roaming and overlaying, no regional and hierarchical constraints
Support multi-input videos to open multiple active windows in optional position in full screen, all windows are allowed to roam free, overlap, magnify and narrow down, no regional and hierarchical constraints, and no size and proportion limits.
E. Output synchronization and double-buffer technology
Realize seamless switching between scenario plans without limit to the number, truly achieving synchronous display of screens, ensure no tear, no flicker, no blue screen, no stationary state and other abnormal phenomena.
F. Arbitrary cutting function of input videos, support for cutting processing of any size
Arbitrary cutting function of any input video has been specially developed for this product according to different scenarios and requirements of users. Users can cut and shape any part of screen image
freely with convenient operation of the software according to display requirements, all the images are independently displayed.
G. Output mapping function makes construction more flexible
Realize the connection between devices and display units without
one-to-one correspondence between wires, which can be adjusted in the software freely.
H. Support special splicing. It can perfectly support various
display units, realize special display effect
In large-scale exhibitions, enterprise propaganda, stages, bars and other places, users can achieve effects shot by using the functions of special effect and special shape. This device support any splicing combination of display units, special-shaped splicing of LCD, DLP, PDP and LED display unit of any resolution.
I. Pane processing technology
For traditional splicing technology, when display units with gap . LCD \ DLP \ PDP, etc.) are used to present pictures, the picture at the gap between two display units will be divided because of imaging failure, resulting in picture’s breaking and deformation. X-LINK’s pane
proce ssing technology shields the picture’s part that is covered by gap between display units through precision adjustment for pixels, achieving smooth and intuitive display.
J. The unique advanced subtitle function makes the display more perfect
It can update and display dynamic text messages in real time
according to customer needs, such as the weather forecast and urgent message etc. The subtitle function helps users to mark video sources properly, which not only displays images but also increases the function of text information display.
K. Mask overlapping function supports the overlapping of customized shapes. Users can customize special effects freely
The use of mask of special effects can create a richer screen effect.
L. The preview and video echoed function greatly helps users to monitor the video
Video content displaying on the wall can be viewed in advance before playing by the software, and can be viewed remotely during playing.
M. Local-storage presupposition for unlimited scenarios facilitates to read and call at any time
Support the uncapped scene storage, with optional digital control panel, which can facilitate the application of "on-duty automatic
inspection" on the areas of manual switch, auto rotation and convenient monitoring etc.
N. Digital control panel is helpful to the?scene switching
Exclusively developed processor with digital control panel, using the experience of the buttons' superior characteristics of matrix equipment, is specially for splicing in LED screen of super large dot matrix, realizing the fast and convenient scene switching.
O. Optional embedded PC operating system
Design the embedded industrial PC motherboard into board card that can be inserted into the device, so as to integrate PC into the processor to reduce users' trouble to connect it to PC. Users can
install operating system and common software in the card, which can be used for playing video. perfectly combining functions of external
splicer of pure hardware architecture and splicer of software architecture.
P. Multi-screen interaction
Multi-screen interaction refers to the interaction of images, videos and all kinds of documentation resources among cellphone, tablet PC and large screen wall. It is a much "cool" function. It can bring users excellent experience, fun, convenience and it is simple, easy to use, playing the fun of touch to the limit.
Q. Support coordinated control among devices, such as startup & shutdown of splicing wall, matrix switching and PTZ control etc.
R. Support customized development.
III Hardware connection
This chapter includes:
Hardware connection diagram
Back panel interface signal diagram
Device supports video input,output and control port signals
1. Hardware connection diagram
The typical instance diagram of hardware connection is shown below, it can access various signal sources, such as cameras, DVDs, notebook computers, Blue-ray DVDs, PCs, Webcam etc., and then transmit them to the display wall.
Figure 1 Typical instance diagram of hardware connection The installation of this device is very simple; please install it according to the following instructions.
1. Disconnect main power of the system, and shut down powers of this device, each display unit and auxiliary devices;
2. Place the device into the cabinet or a steady worktable, direct
the back panel toward the operating personnel, and keep good ventilation.
3. According to figure 1, connect the video cable, network
cable(serial line) and power cord to the response interface of the device.
4. After checking and ensuring there is no problem, turn on the
power of each screen, each auxiliary device and the device to start running it with the combination of the control software on PC.
Note: please make sure that the power of each device is
disconnected and ensure all connections are correct and reliable during cable assembly.
2. Back panel interface signal diagram
3UA type multi-screen processor supports input card slots 4, output card slots 6.
Figure 2 3UA Back panel
3UB type multi-screen processor supports input card slots 6, output card slots 4.
Figure 3 3UB Back panel
8U type multi-screen processor supports 11-bit input slot, output card slots 9.
Figure 4 8U Back panel
12U-type multi-screen processor supports 22-bit input slot, output card slots 18.
Figure 5 12U Back panel
3. Instruction of port
(1) Video input signals
This device supports video signal inputs, as shown in the following table:
CVBS-2 input BNC interface, supported video format: PAL/NTSC/SECAM SDI input
Serial Digital Interface, support 1920*1080@60HZ YPbPr High-definition color component
interface,support 1920*1080@60HZ
(2) Video output signals
This device supports video signal outputs, as shown in the following table:
Output port
Description DVI output
Digital interface, support digital signal 1920*1080@60HZ VGA output
support analog signal, able to output VGA signals through the adapter HDMI output Digital interface, support HD signal, able to
output HDMI signals through the adapter
(3) Control port signals
This device supports the control, as shown in the following table:
Control port Description
Network interface Users can control the PC software via LAN or directly using a computer.
S232/ RS485 Users can connect the related equipment device s
through serial port for joint control.
IV Software operation
This chapter includes:
Multiview brief and decompression software installation operation
Variety of communication connectivity opitions
User logon operating software,check the device operation via
intelligent detection systemvice
PC operating processes,output resolution,mult-window display
layout and set a specific operation
1. Software brief introduction
MultiView software is a new generation of visual, WYSIWYG splicer
control software, the control software application features integrated splice products, combining the characteristics of the installation works on the development is completed. It adopts the forefront of software
design concepts, instead of the traditional splicing control software debugging complex requirements of the splicing process to achieve automatic operation of the window control process using a WYSIWYG interface, avoid the cumbersome and complex stitching software default process, use of personnel can quickly master the use of the software.
Simple software interface, easy to operate, easy to understand and easy to use, just three steps can be done by setting splicing processors. Specific operational procedures, as follows:
2. Uncompressed installation
(1) Unzip software installation package and we
get the following file: .
(2) Click it to start the installation. After the installation is completed, the program will create a shortcut icon on the desktop,
namely MultiView, and users can also see the installed in the start menu:
[ desktop shortcut] [start menu]
Figure 6 Software schematic diagram
Note: Some security defense software will hinder the process of the installation, please exit the security defense software temporarily for smooth installation.
3. Communication connection
There are two modes of configuration: network and serial mode.
(1)Serial mode:
Direct-connect method: Directly connect the device to PC via the serial port line. The software will automatically recognize the serial port (Figure 7).
Figure 7 Login page I (Serial) Figure 8 Login page 2 (Ethernet)
(2)Network mode (two methods): LAN connection method and
direct-connect method.
① LAN connection method
Connect via a local area network (automatic assignment of IP). It needs a server to support automatic assignment of IP, the software will automatically recognize the device IP(Figure 8).
② Direct-connect method
tware, namely the device IP(Figure 10). If it fails to detect this IP, please restart the computer.
Figure 9 the attribute interface Figure 10 Login page 3
4. User Login
Default user name is Admin, the password is blank.
Figure 11 PC Login page
A. Administrator User Login
MultiView login interface system default initial user name is Admin, password is blank. Click on the "Login" button, the software began to communicate with the device, complete with the device to synchronize information. Admin privileges can be adjusted by user rights management, different permissions, different level of response equipment operation. Notes:
(1) Under the Win7 environment, sometimes users need to set the software to "run as administrator", to let the software obtain the highest authority operation.
(2) The checked "device info" stands for information of displaying device and then manually enter the main page, the unchecked "device info" stands for information of devices that don't display and then automatically enter the main page.
Users can clearly know the operation of entire device by printed device information, including device temperature and cable’s connection state, etc.
Figure 12 Select device information
Figure 13 printing equipment information page
B. Operator User Login
The user selects the "operator" login page, shown in Figure 14. Users can switch keyboard shortcuts for quick scene change with the scene, relatively complex configuration eliminates the need for other operations, very easy to ordinary users.
Figure 14 Scene switch interface
5. Operation process of Multiview
Software operating procedures, including output resolution setting, the display layout setting, multi-window operation process, basic multi-window operation, scene auto player.
(1) Output resolution setting
Output resolution settings include increasing, deleting, editing parameters of the resolution and the test and calibration of them, the main operation flow diagram is as follow:
Display current resolution parameters, the output resolution can be achieved on testing and verification.
Figure 15 Output resolution setting
Select the right resolution, if there is no right one in the list, users can add the needed resolution. In general, users should select the best resolution.
Figure 16 current output resolution Settings
If the resolution of the display device resolution parameters and parameters of the current selection are inconsistent, you can click Edit to modify it.
View the current output resolution, check the "test" and color bar of seven colors will exist in the large screen if the setting is successful, as shown below.
Figure 17 Striped test
(2) Displayer layout settings
The displayer layout settings include array settings, corresponding relation settings and array test. The main operation flow diagram is as follows:
The number and distribution of equipment, the layout of the logical screen to be set according to the physical display.
Figure 18 Displayer layout settings
Set the layout of the logical screen according to the actual screen quantity and distribution of display units.
Figure 19 corresponding relations settings
The actual display units of logical screens can be matched based on the connectivity condition of the actual output interface as follows: Select the output channel and drag it to the corresponding display unit. Directly click the output channel in the display unit to cancel it as necessary.
Notes:
No. 1& 2 board cards of 3UA slot support to open four windows, others support to open two windows.
All board cards of 3UB and 8U support to open four windows.
(3) Multi-window Settings
Multi-window settings include settings of open windows and parameters and scene saving etc. according to input video sources. The main operating flow diagram is as follows:
Open multiple windows to display multiple screens can be realized on the big screen, multiple input sources simultaneously display, picture
in picture, the picture of any size, quickly switch the input source,
and a series of partial zoom display function. When multiple windows are superimposed, superimposed on top of the window display section information. Multiple windows can be the same input source may also be a different input source.
Figure 20 Multi-window Settings
Select the input sources to be displayed, open a window in the
logical screen, and then adjust the window size and other parameters. Note:
please refer to (4) basic operation for details.
(4) Basic operation
A. Open a window
① Choose the input sources in the video source list;
② Drag out a rectangular window from the upper left to the lower right corner directly in edit area of logical screen with the mouse.
B. Edit the window attribute
There are two methods to edit the basic attributes of the window:
Method I: adjust the settings of the size and coordinate of the window by dragging the mouse directly in the edit area of logical screen;
Method II: edit the window attribute directly in window attributes column.
C. Switch input sources of a window
There are two methods to switch input sources of a window when it is necessary:
Method I: Select the window that needs switch input sources,
directly double click the input slot and channel to be switched in " Video Source " for change settings;
Method II: Select the window that needs switch input sources, and then complete the switching by clicking the input slot and channel directly in window attribute column.
D. Windows shortcuts
There are two methods to delete, cut, resize the window and change levels etc.
Method I: Select the target window and complete the operation by context menu;
Method II: Select the target window and complete the operation through the shortcut key in " Win Prop ".
E. Window lock
When the window attribute setting is completed, users can lock it to prevent any incorrect operation or unnecessary change by moving the cursor. Windows will be transparent and irremovable when it is locked.
: Select the target window and click the button to lock it.
: double click the locked window at any position to select it and
then click the button to unlock it.
F. The window covers all over the logical screen
There are two methods to extend a window to the range covered by the grids of its four vertices, namely the window covers all over the
logical screen:
Method I: double click the mouse to move the cursor to the target window and then double click left mouse button to complete the operation.
Method II: get a fast implementation through toolbar shortcuts of
cover all over logical screen button .
G. Open PIP(picture in picture) function
① Select the target input source in the Video Source;
② Drag out a rectangular window from the upper left to the lower right corner directly in edit area of logical screen with the mouse.
③ Select the target window and click the button to lock it.
④ After the window becomes transparent, drag out a rectangular window from the upper left to the lower right corner on top of it with the mouse.
H. Arbitrary cutting function of input video sources
Cut any part of the video source to display independently and get a fast implementation of video clips and window refinement so as to make the focal points stand out. The specific operation is as follows:
① Drag out a rectangular window from the upper left to the lower right corner directly in edit area of logical screen with the mouse.
② Select the target window and click the button to cut it.
I. Delete the window:
①Partial delete: select the target window and click the delete button in the upper right corner of the window to delete part of it.
② Delete all: complete the operation by using the clear screen button .
J. Save the information to the device:
By pressing the button , users can save the configured settings into the device or save them as default scenes to directly restore to the latest related settings when users startup the device next time, as shown below.
Device saving can be divided into three functions, respectively are:
① Scene saving: click "add" to select the added scene in the left list and set the relevant information on the right and then click "save" to complete the operation.
②Scene covering: select the target scene to be covered and set the relevant information on the right and then click "save" to complete the operation.
③Scene deleting: select the target scene to be deleted and then click "del" to complete the operation.
Figure 21 scenes save
(5) Scene player (scene auto switching)
It is similar to scene management tools of music players, users can customize different scenes as needed, realizing the management to the play order and time among different scenes and can change the information freely. The main operation flow diagram is as follows:
Scene player
①Tick the "start"
②Right click the mouse to choose new list in
the left list
③Right click the mouse to insert the scene on
the right playlist
④Choose the target scene to be playing in the
"scene list"
⑤Click the "play" button
list".playlist
Scene player interface is shown below:
Figure 22 Scene player
Key features include scene play, pause, increase switching and scene lists, delete, and switching.
Figure 23 Scene player–scene settings
Right click and choose the new list in the left list, and then right click to choose the insert scene in the right scene playlist.
Figure 24 Scene player–scene show
Click the button to play the video.
Note: click the button to stop the video if you need to modify or edit it.
V Front panel button operation
This chapter includes:
Schematic view of the front panel buttons
Key operating instruction
The main operating of keys
1.Front panel button diagram
Control panel with LCD display, status lights, operating buttons.
Figure 25 Control panel with buttons
2. Instruction of buttons
The front panel is provided with 20 keys and a Chinese / English LCD module. 20 keys are divided into 2 functional areas, the clear
functional partitioning is convenient for users to operate the device, while the LCD module provides rich display information.
(1)Control button
The main control buttons are used to do some fast operation, features a clear, easy to operate, the specific key functions in the following table:
(2)Numeric keys
After being saved in upper computer, the scene is defined as a number and then is switched by using numeric keys.
(3)Key operation
1. Easy scene switching
Press any key to lighten LCD screen, select the scene switching by pressing "up" and "down" keys , press "OK" to enter the next page, then select "easy switch" and press "ok" button to switch the scenes by corresponding numeric keys according to the order to saved scenes.
Scene switching includes easy switching, list switching and number switching.
2. Device detection
Press any key to lighten LCD screen, select the "device detection" by pressing "up" and "down" keys to view the current working condition of the device.
3. View the IP address of this device
系统简介与操作说明书 系统的基本构成 该系统由弱电控制强电的方式配合相应传感器和软件实现智能化控制系统，系统结构由输出模组、输入模组、控制软件、云端服务、四部分为一体的智能化控制系统。 输出模组： 输出模组是控制各类设备的电源，控制了设备的电源就控制了设备的工作状态，通过设备的信号输入端接受传感器和相关软件的数据就改变了设备的运行模式，完成智能运行，该模组可支持工业智能化控制、农业智能化控制、建筑智能化控制、家居智能化控制等领域。如：工业电机和设备、农业浇灌和设备、家居设备的的空调、热水器、地暖、新风机、洗衣机、灯光照明、环境调光、家电集成、窗帘电机、车库电机等其他设备，模组提供了共计32路接口输出。 1、8路30A大电流输出口，可支持220V/6kw以下的设备负载，如空调、热水器、功率电机等。 2、8路16A可控硅调压输出，可支持220V/3kw以下的调压调速设备负载，如车库电机、推窗电机、窗帘电机、灯具、等及其他设备。 3、16路16A+16A双触点并联输出口，可支持220V/5kw以下的设备负载，如室内灯光、环境灯光、家用电器、等及其他设备。 4、提供12/24V清洁电源接口，系统支持直流供电、如：常规照明、视频监控、安全报警、门禁对讲、网络供电、可实现持续供电，断电不断网。 5、提供3+1供电接口为模组供电（主电源+辅助电源+直流电源），保证设备长期可靠待机。 6、提供16路过流保护，为设备安全提供保障。
输入模组： 输入模组是系统的心脏，包含控制输出、手动控制输入、自动控制输入、传感器输入、工业控制信号输入、视频监控信号输入、报警信号输入、门禁信号输入、红外线信号输入、射频信号输入、网络输入、总线控制输入等。 1、控制输出接口：连接输出模组，将系统的工作状态传递给输出模组，驱动继电器完成动作。 手动输入接口：提供32进32出的手动控制接口，输入输出对应控制输出，自适应传统的各类型控制面板（翘板开关、轻触开关），可操作系统的开、关、调光、调速等的模式转换等功能，与系统控制APP全兼容，控制状态同步显示，即使系统的核心芯片因某种原因出现故障，也不影响系统的基本功能使用。 2、自动控制输入：自动控制是通过传感器接收到控制信号或事先预定的任务去自动完成控制，如：红外报警、火警、煤气泄漏、甲醛超标、PM2.5、温度、湿度、门禁、车辆进出、定时等。 3、传感器输入接口：输入模组提供了8个模拟传感器兼容接口，输入端接到传感器的控制信号后，将模拟信号转换成数字信号、去执行远端APP或本地报警、同时根据需要打开输出模组对应的端口，完成智能控制。如：智能恒温、智能除湿、智能除甲醛、智能灭火、智能断气、智能断水、智能新风、智能报警、智能开门、定时控制等。 4、工业控制信号输入接口：输入模组提供了两组RS232接口和一组RS485控制接口，两组RS232接口可扩展32路独立控制端口，可同时控制32台不同型号的工业设备，控制代码通过学习或手动输入即可控制，如：舞台灯光设备、多功能会议设备、音视频矩阵转换设备、专用功放、等。RS485控制接口兼容常规的RS485协议设备，在系统中默认DMX512控制协议，支持效果灯光控制台，为室内/室外环境提供专业的效果灯光。如影音室效果灯光、卡拉OK效果灯光、环境效果灯光等。 5、视频监控信号输入：视频监控信号是通过网络接口进入主机芯片处理，可实现远端APP监视、移动侦测报警、查询、录像、对讲、控制、支持本地录像、查询、对讲等。 报警信号输入接口：报警信号是接8个I/O信号接口，主机自带8个传感器输入接口，最多
超说明书用药规定 1 2020年4月19日
临沭县中医医院 超说明书用药管理规定及程序 一、为加强药事管理工作，促进临床合理用药，保障临床用药的安全性、有效性、合理性及药师自身安全，避免不必要的纠纷，依据《中华人民共和国药品管理法》、《处方管理办法》、《医疗机构药事管理规定》等药政法规，特制定本规定。 二、超说明书用药是指临床实际使用药品的适应证、给药方法或剂量不在具有法律效力的说明书之内的用法，包括年龄、给药剂量、适应人群、适应证、用药方法或给药途径等与药品说明书中的用法不同的情况，又称超范围用药、药品未注册用药或药品说明书之外的用法。 三、虽然超药品说明书用药现象的存在具有一定的合理性和必要性，可是超说明书用药有可能没有大量临床研究数据支持，也没有获得药品监管部门批准，因此就必然存在一定的风险，且药品说明书具有法律效力，超药品说明书用药不受法律保护，超说明书用药导致不良后果的，医生和药师要承担相应法律责任。 四、当临床医生因医疗创新确需要超药品说明书用药时，应提供权威的文献依据，并经药事委员会审核同意，报医务科备案，使用时与患者签署《超说明书用药知情同意书》。药师在审核和调剂超药品说明书用药处方或医嘱时，严格依据《超说明书用药知情同意书》和医务科备案方能调剂药品。
五、药师应按照药品说明书或者处方用法，进行用药交代与指导。药师应当对处方用药适宜性进行审核，审核内容包括处方用药与临床诊断的相符性、剂量用法的正确性、其它用药不适宜情况等。药师经处方审核后，认为存在用药不适宜时，应当告之处方医师，请其确认或者重新开具处方，药师发现严重不合理用药或者用药错误，应当拒绝调剂。 六、药师在审核处方或医嘱时，应以药品说明书为依据，严格按药品说明书规范调剂药品，规 避用药风险，确保调剂行为的安全及患者的用药安全。 七、药师对超说明书用药存在严重违反“用法、用量和注意事项”之规定，即便是已签署《超说明书用药知情同意书》和医务科备案外，药师也应当依法拒绝调配，或及时与医师沟通进行合理用药干预，详细指明处方中存在的问题，请开方医师重新开具合理处方，认真把好合理用药关。 八、临床药师要对超说明书用药疗效进行认真分析、评价，对超说明书用药导致的药物不良反应及时分析原因，并上报医务科和通知相关病区，减少和防止因超说明书用药导致不良反应的重复发 生。
附件4：产品说明的提交要求 说明：红字条款可根据软件产品实际情况进行剪裁，黑字条款为标准要求必须说明的项目。斜体字是对国家标准条款的解读或举例，仅供使用者参考。 一、产品说明： 【定义】 陈述软件各种性质的文档，目的是帮助潜在的需方在采购前对该软件进行适用性评价。 解读：产品说明为供方在进行产品销售时对产品性质的宣传资料，目的是让采购方获得产品概况，判断该产品是否能够满足自己的需求，进而决定是否采购该产品。 【要求】 产品说明对于需求方是可用的，包含潜在需方所需的信息，信息内容应排除内部的不一致，且与用户文档集和软件实际情况一致，产品说明的内容应该是可以验证或测试的，产品说明应有唯一性标识，当产品说明内容超出一页文档时，要有封面和目录，方便使用者进行内容查找。 【内容】 1、软件产品应以其名称、版本和日期指称； 解读：软件产品要用名称+版本或名称+日期命名。 例如：城市水资源管理系统软件V1.0或城市水资源管理系统软件2011。 2、产品说明应显示唯一的标识； 解读：产品说明在封面或卡片的显著位置显示唯一的产品标识。 例如：城市水资源管理系统软件V1.0产品说明。 3、产品说明应包含供方和至少一家销售商（当适用时）电子商务销售商或分销商的名称和地址（邮政的或网络的）。 解读：产品说明在封面或卡片的显著位置显示供方和销售商信息一般包括名称和地址，且供方和销售商可以为同一企业或个人。 4、产品说明应标识该软件能够完成的预期的工作任务和服务； 解读：此项描述软件的销售方向，适用的行业，潜在的客户群，概要介绍软件的用途。
例如：本软件为水务行业管理软件，适用于各供水公司、净水厂、水污染处理企业、政府水资源行业管理部门，可完成水资源相关业务的管理及实施对水资源处理装置的动态监控和实时处理。 5、供方想要声称软件产品符合由法律或行政机构界定的要求时，产品说明应标识出这些法律或行政机构界定的要求的需求文档； 解读：供方为加大产品的宣传力度，增强产品竞争力，更好的销售其软件产品，可表明其产品符合法律或行政机构界定的要求。但必须将符合的内容在产品说明中进行详细说明。 例如：本软件符合中华人民共和国水利行业标准SL475-2010水利信息公用数据元标准，该标准的详细信息参见附录一 6、产品说明应以适当的引用文档指名产品在何处依赖于特定软件和（或）硬件；解读：当产品在某些情况下需要依赖于特定的软件和（或）硬件才能实现其生成的产品性质时，要对这些特定的软件和（或）硬件进行描述，以便采购方在采购产品时能够合理评价采购成本。 例如：本软件在对水资源处理装置进行远程动态监控及实时处理时如传输距离超过50米需要信号放大器或无线信号发射器与无线信号接收器 7、产品说明引证已知的对其他软件的用户可调用的接口时，应标识出这些接口或软件； 解读：如果软件再使用过程中需要调用其他软件许可的接口时，应说明这些接口或软件从而使采购方在选择该产品时，明确还需购买其他接口许可或软件。 例如：本软件运行时需要调用水资源信息实时处理业务系统V1.0 8、产品说明应指明产品期望在单一系统上供多个并发最终用户使用或供一个最终用户使用，并且应说明在所要求的系统的所陈述的性能级别上可行的最大并发最终用户数； 例如：当软件支持并发时，此处可进行如下类似描述：本软件在单一系统上可供多个并发最终用户使用，在服务器主频大于3.0GHZ、内存大于2GB、响应时间小于5秒的情况下最大100并发最终用户。 当软件不支持并发时，此处可进行如下类似描述：本软件在单一系统上只供一个最终用户使用，不支持并发操作。
医院药品超说明书用药管理制度 (征求意见稿) 为进一步加强我院药事管理，保障病人用药安全，降低医疗风险，根据《中华人民共和国药品管理法》、《医疗机构药事管理规定》、《处方管理办法》、《药品说明书和标签管理规定》等法律法规，结合我院实际情况，特制定本管理规定。 一、超说明书用药的定义 超说明书用药是指临床实际使用药品的适应证、给药方法或者剂量不在具有法律效力的说明书之内的用法，包括年龄、给药剂量、适应人群、适应证、用药方法或给药途径等与药品说明书中的用法不同的情况，又称超范围用药。 二、临床超说明书用药的原则 （一）为保障病人安全，临床用药原则上不得超出药品说明书规定的范围，即不得超说明书用药。 （二）在临床工作中，特殊情况需超说明书用药时必须同时具备以下条件： 1、在影响病人生活质量或危及生命的情况下，无合理的可替代药品和疗法。但必须充分考虑药品不良反应、禁忌证、注意事项，权衡病人获得的利益大于可能出现的风险，保证该用法是最佳方案。 2、用药目的必须仅仅是为了病人的利益，而不是试验研究。 3、超说明书用药应当有必要的科学依据、会诊意见、充分的临床实践和相关文献、研究报道。 4、病人知情同意，并签署知情同意书。 三、超说明书用药的审批流程 1、临床确需超说明书用药时，对病人要实行告知并签署知情同意书。医师应充分告知病人用药方案、治疗步骤、预后情况及可能出现的风险，签署知情同意书后方可进入审批程序经批准后使用。签署的知情同意书留存使用科室。 2、超说明书用药时需由医师提出用药申请，并提供权威的文献依据（如治疗指南、专家共识、循证医学证据等），由临床科室主任签字，报院药事管理与药物治疗学委员会及伦理委员会审核同意后，报医务处备案。 四、超说明书用药的使用与调剂 1、药师在审核处方或医嘱时，应以药品说明书为依据，严格按药品说明书
设备名称 使 用 说 明 书 襄阳国铁机电有限责任公司
设备名称 一、概述： 二、主要结构及工作原理： 1.主要结构 2.工作原理 三、主要性能参数： 四、操作指南：
五、设备保养： 示例如下： 电茶炉试验台 使 用 说 明
书 襄阳国铁机电有限责任公司 电茶炉试验台 一、概述： 电茶炉试验台主要用于CRH2/3（兼容CRH5型）动车组用的电热开水器的电流、电压、功率、电热开水器的产开水温度、产开水量、缺水保护、满水保护以及绝缘电阻、泄漏电流等安全性能性能检测和校检。 二、主要结构及工作原理： 1.主要结构 电茶炉试验台主要由机体、不锈钢试验水箱、管路系统、连接装置等组成。
2.工作原理 该设备用于CRH2/3（兼容CRH5型）动车组用的电热开水器的试验。通过不锈钢试验水箱、管路系统、连接装置模拟出动车组上的电热开水器的工作环境，使电热开水器能够安装合理、简单、方便，通过温度、液位等感器将电热开水器的数据传送到工控机中进行分析，试验台能够自动控制，试验参数自动测试、实时显示、自动保存。 三、主要性能参数： 1、输入电源电压：三相AC 380V±10%,50 Hz； 2、输入电源容量： 6 kW （AC）； 3、电压测量范围：AC:0～380 V;DC:0～600 V,精度0.5级； 4、电流测量范围：AC:0～20 A;DC:0～20 A,精度0.5级； 5、功率测量范围：0～6 kW 精度0.5级； 6、绝缘电阻测量范围：0～1000 MΩ精度5%； 7、温度测量范围：0℃～+150℃精度0.5%。 四、操作指南：
1. 操作前，请仔细检测各管路系统有无泄露、各管路接口有无松动现象；电气元件有无短路现象。如果一切正常，方可进行试验。 2.设备通电，打开试验界面，如下所示： 3.确认电茶炉与设备连接好后，点击“试验/停止”按钮，出现如下对话框： 点击“试验”按钮，设备开始试验。
Product Manual - Operation and Maintenance Manual Product Name:API 6D Ball Valve January 2012
1Scope This manual covers manually/motor/pneumatic operated seat supported /trunnion supported ball valve having tow/three pieces body with nominal sizes DN 15mm-1200mm (1/2”-48”) and class ranges PN1.6MPa-10MPa(ANS1 class 150-2500). Valve ends may be threaded, flanged, butt-welded or socket 2 Applications 2.1 Ball valves are used to open/close the flow in pipeline. 2.2 The nature of applicable fluid depends on valve material: 2.2.1 Carbon steel valve applies to non-corrosive fluid, such as water, vapor or oil etc. 2.3 Temperature range depend on sent material: PTFE ≤130℃ RPTFE ≤160℃ PPL ≤300℃ NYLON ≤121℃ 3. standard： Basic design API 6D-2008 Inspe crlon tesring BS EN 12266.1-2003 End flange ASME B16.5-2009 TEMP. & PRESSURE ASME B16.34-2009 Face toface ASME B16.10-2009 Main parts and materials ASME materials, see Table 1 Figure 1:Trunnion Ball Valve 4 Structure 4.1 Ball Valve structure is shown in Fig. 1.
Spiral chute 1、product description Spiral chute is integrated spiral separator, spiral chute, shaker, centrifugal concentration machine characteristics of the equipment, mining, mineral processing is the best equipment, especially the seaside, riverside, sand beach, the stream of placer mining is more ideal. The product has the advantages of reasonable structure, simple installation, covers an area of small, simple operation, stable ore beneficiation, clear, large processing capacity, high efficiency enrichment ratio high, high recovery rate, reliable operation characteristics. Have weight light, moisture-proof, rust-proof, corrosion resistance, of the feeding quantity and concentration, particle size, quality of volatility adaptability is strong, no noise. 2、Separation principle Spiral chute is a membrane flow gravity separation equipment, the selection principle is the use of useful minerals and gangue in proportion, particle size, shape differences, in rotating inclined flow by gravity, centrifugal force, hydrodynamic pressure and friction force with different groove face, realize the useful minerals and gangue stratification, branch tape sorting. Heavy, coarse granularity, fast sedimentation of particles gradually moved towards the spiral groove inner edge, the proportion of small, fine particle size, particle sedimentation slow gradually moved to the spiral groove edge, gradually banding, culminating in the spiral groove end by cutting ore tank is respectively connected out, to realize separation. 3、Application The sorting equipment for grain size mm fine iron ore, titanium ore, chromite,
药品超说明书用药管理制度 为进一步加强我院药事管理，保障病人用药安全，降低医疗风险根据《中华人民共和国药品管理法》、《医疗机构药事管理规定》、《处方管理办法》、《药品说明书和标签管理规定》等法律法规，结合我院实际情况，特制定本管理规定。 一、超说明书用药的定义 超说明书用药是指临床实际使用药品的适应证、给药方法或剂量不在具有法律效力的说明书之内的用法，包括年龄、给药剂量、适应人群、适应证、用药方法或给药途径等与药品说明书中的用法不同的情况，又称超范围用药。 二、临床超说明书用药的原则 （一）为保障病人安全，临床用药原则上不得超出药品说明书规定的范围，即不得超说明书用药。 （二）在临床工作中，特殊情况需超说明书用药时必须同时具备以下条件： 1、在影响病人生活质量或危及生命的情况下，无合理的可替代药品和疗法。但必须充分考虑药品不良反应、禁忌证、注意事项，权衡病人获得的利益大于可能出现的风险，保证该用法是最佳方案。 2、用药目的必须仅仅是为了病人的利益，而不是试验研究。 3、超说明书用药应当有必要的科学依据、会诊意见、充分的临床实践和相关文献、研究报道。 4、病人知情同意，并签署知情同意书。 三、超说明书用药的审批流程 1、临床确需超说明书用药时，对病人要实行告知并签署知情同意书。医师应充分告知病人用药方案、治疗步骤、预后情况及可能出现的风险，签署知情同意书后方可进入审批程序经批准后使用。签署的知情同意书留存使用科室。 2、超说明书用药时需由医师提出用药申请，并提供权威的文献依据（如治疗指南、专家共识、循证医学证据等），由临床科室主任签字，报院药事管理与药物治疗学委员会及伦理委员会审核同意后，报医务处备案。 四、超说明书用药的使用与调剂 1、药师在审核处方或医嘱时，应以药品说明书为依据，严格按药品说明书规范调剂药品，规避用药风险，确保调剂行为的安全及患者的用药安全。药师经
产品说明书 1.产品概述 插座，又称电源插座，开关插座，是指有一个或一个以上电路接线可插入的座，通过它可插入各种接线，便于与其他电路接通。电源插座是为家用电器提供电源接口的电气设备，也是住宅电气设计中使用较多的电气附件，它与人们生活有着十分密切的关系。居民搬进新居后，普遍反映电源插座数量太少，使用极不方便，造成住户私拉乱接电源线和加装插座接线板，常常引起人身电击和电气火灾事故，给人身财产安全带来重大隐患。所以，电源插座的设计也是评价住宅电气设计的重要依据。插座种类：电源插座、电脑插座、电话插座视频、音频插座、移动插座、usb插座等等。 本产品集电源插座、USB插座、移动插座与一体的多功能插座。 2.产品的性能和特点 本产品采用创新的外形设计，弧度优美，结构雅致，灵活的模块化结构，安装及拆卸都很便捷，丰富的面框组合，产品功能范围齐全。 3.产品的使用方法 1.所接电器功率总和不得超过额定功率 2.使用时严禁捆扎导线，以免异常过热。 3.请不要在潮湿的环境下使用。 4.请勿在插座和电线破损的情况下使用。 5.请勿使用金属坚硬物与各种坚硬物猛插插孔。 6.请勿擅自拆卸。 7.请勿用湿手插拔插头 8.请勿在儿童能接触的地方安放插板。 4.产品的保养和维修 1.插板的的安放。 （1）插板要放在室内通风良好的地方。 （2）切勿把插板放在发热物体旁边或阳光直射的地方。插板温度过高，使插板不能很好的散热，增加耗电量。 （3）插板放置要平稳,避免震动、碰撞。若把插板放在地毯上，应在插板下加垫木板。 (4) 远离室内潮湿点,环境潮湿易引起插板内部线路生锈和影响插板绝缘，易造
成电路短路。 （5）电源应用三芯安全插头和插座，并安装安全保护的接地线以确保安全。 2.插板的保养， 定期适当的保养可以延长插板的寿命，保养插板前务必拔下插头。 （1）经常清理插板正面或底部灰尘，可使用吸尘器或毛刷除尘。 （2）插板长期停用时，应先切断电源。 （3）经常检查插板的密封是否破损，如果破损应立即停用。 （4）注意检查电源线上是否有裂缝或划伤，防止漏电。 5.其他事项 （1）不可随意拆卸，否则后果自负。
产品说明书英文版V HEN system office room 【HEN16H-HENS2AHENS8Q8-HENH1688】
X-Link PRODUCT MANUALS FOR MULTIVIEW CONTROLER
This manual applies to the following models: 3UA Multiview CONTROLER ( Optional Front Panal,LCD Console ) 3UB Multiview CONTROLER ( Optional Front Panal,LCD Console ) 8U Multiview CONTROLER ( Optional Front Panal ) 8U-S Multiview CONTROLER( Optional Front Panal ) 12U Multiview CONTROLER LED Very-large Dot Matrix Screen Multiview CONTROLER ( K Series ) Monitoring Multiview CONTROLER ( N Series ) 3D Multiview CONTROLER ( 3D Series ) 4K Multiview CONTROLER (4k Series ) IMPORTANT NOTICE The company reserves the right to update the manual according to improvement of products without any prior notice. In the process of using, if any content in this manual is inconsistent with actual products or there is any further question during use, please contact document information department of our company. Please read this manual carefully before using the CONTROLER and properly file it after reading for future reference. Pictures are for reference only, subject to our available products. Please pay close attention to those with the Icon of in the article.
抗菌药物超说明书用法专家共识 中国医药教育协会感染疾病专业委员会 中华结核和呼吸杂志编辑委员会 中国药学会药物临床评价研究专业委员会 中华结核和呼吸杂志, 2015,38(06): 410-444. DOI: 10.3760/cma.j.issn.1001-0939.2015.06.005 前言 药品说明书是临床医师处方的最重要依据，但因药物在临床应用中不断有新的发现与经验积累，再加上药物临床注册试验周期长、药品说明书更新相对滞后，因此，超说明书用药有其科学性与合理性，在临床中往往是不可避免的，甚至有时也会成为挽救生命的唯一手段。与其他类药物相比，抗菌药物用于敏感细菌的超适应证用法或用于不够敏感细菌的超剂量用法更普遍、更常见。文献报道，在25个研究共7亿2千余万处方中，成人重症患者抗菌药物超说明书用法处方占19%～43%，普通门诊也占23%@[1]。可见抗菌药物的超说明书用法是一种在临床业已存在的较普遍的现象。 超说明书用法也称未注册用法(off-label uses，unlabeled uses，out of label usage or outside of labeling)，其内容包括超适应证、超剂量、超疗程、超适应人群及改变说明书中规定的用药途径与用药间隔时间等。 2013版"赫尔辛基宣言"[2]在最后一节中强调指出："医生在治疗患者时，如无已证实的有效方法或其他已知方法均无效时，当医生判断有挽救生命、恢复健康、减轻痛苦的可能，在征得患者或监护人同意后，参考专家建议可采用未经证实的方法"。而本共识推荐的用法均是经过临床实践证明较为安全有效的用法。目前，我国有关超说明书用药的法规尚不完善，医师选择超说明书用药将承担更大的风险。本共识的主要宗旨是给读者提供有参考价值的、常用且重要的抗菌药物超说明书应用的科学信息，并不涉及超说明书用法的批准程序，也不涉及婴幼儿、孕妇及哺乳期妇女等特殊人群。 临床医师应自始至终时刻权衡治疗对象的获益和风险，在遵守国家、地方政府和所在医院有关法律规定的基础上，参照本专家共识提供的信息，针对不同的治疗对象制定具体治疗方案，同时本共识也强调，当遵照说明书就能达到安全有效的治疗目的时，应尽量避免选择超说明书用法。 本共识推荐的证据等级划分参照以下原则：A级：国外说明书已载入或国内外权威指南作为A级推荐；B级：本共识制定者认可的指南中作为B级推荐或有循证医学证据支持、发表在权威学术期刊上的研究结果；C级：学术刊物发表的有一定科学根据的研究结果。本共识不收录以个案报告及专家个人意见为依据的用法。 第一章β-内酰胺类 β-内酰胺类抗生素在结构上的共同特点是均具有一个典型或非典型的β-内酰胺环，该环如被破坏则失去抗菌活性。根据结构上的差异与抗菌特点，β-内酰胺类又分为青霉素类、头孢菌素类、头霉素类、碳青霉烯类、单环类及酶抑制剂等。该类抗生素在临床应用广泛，毒性相对较低，大多数属于典型的时间依赖性抗生素，也有些品种具有较长的抗生素后效应(postantibiotic effect，PAE)，在日剂量不变的前提下，增加用药次数、缩短间隔时间或延长静脉滴注时间，可增加疗效。本章只介绍比较常见的药物超说明书用法。 青霉素G
产品说明书范文英文版 电子产品说明书——媒体音响英文说明书范例(中英) 便携式多媒体音响 Portable Multimedia Acoustics 使用说明书User’s Manual 专注于完美音质的追求?? Concentrate on perfect sound pursuit? 感谢您使用本公司出品的数码产品，为了让您轻松体验 产品，我们随机配备了内容详尽的使用说明，您从中可以获 取有关产品的介绍，使用方法等方面的知识。在您开始使用 本机之前请先仔细阅读说明书，以便您能正确的使用本机， 如有任何印刷错误或翻译失误望广大用户谅解，当涉及内容 有所更改时，恕不另行通知。 Thank you for using this digital product of our company. In order to let you experience the product swimmingly, detailed instruction is provided which you can find the product’s introduction, usage and other information. Before using this product, please read the manual carefully, so that you can correctly use it. In case of any printing or translation error, we apologize for the inconvenience. As for the content change, we are sorry for no further notice. 一、产品概述 General Information 本机是一款外观小巧，设计精美、携带方便多媒体小音响， 适用于家居、户外旅游、办公室等场所，随时随地享受音乐
使用说明书 目录 概述：智方热能表性能介绍第一部分：工作原理及结构第二部分：使用方法 第三部分：安装、注意事项第四部分：选型 第五部分：维修说明
一、智方热能表技术说明： 1、热能表由三个组成部分：流量传感器、配对温度传感器、 智能计算器。 2、三个组成部分均需电池供电才能正常工作，电池寿命长 达5年以上。 3、芯片内容包括： a.流量传感器计量参数：如智能误差修正系数，温度修正， 流量传感器安装位置的修正等； b.配对温度传感器参数：如智能配对修正功能； c.计算器参数：如热量计算及修正公式，内部控制程序； d.各种参数测量设置与信息储存等； e.错误代码判断及显示功能。 4、芯片内容的设置与改写是在生产线及检验线上通过专 用设备及程序自动完成的。 5、断电保护，数据可以保存100年：当电源中断时，热能表保存所有有效数据，如累积流量，累积热量等。故障排除后，数据自动恢复。 二：智方热能表性能介绍： A、测量精度高 1、Pt1000测温更准。 2、超低功耗MCU，16位AD温度测量分辨率＜0.01oＣ。 3、热系数K动态校正，使热量计算更准确。
B.使用可靠： 1、全中文显示累积热量、累积冷值,累积流量、进水温度、出 水温度,瞬时流量,累积工作时间等,显示内容全面。 2. 防尘、防水、防凝露、防磁场攻击、防拆卸、防止人为破坏。 3. 采用先进的MCU，整表静态功耗＜5μA，有效延长电池使用 寿命。 C.安装方便： 水平安装，回水管安装 三、智方热能表技术指标
第一部分：工作原理及结构 一、原理公式 按热力学理论，一物体散发的热量值Q为： Q=∫qmΔhdt 式中：qm为流体质量流量 Δhdt为时间为热循环系统进出口比焓差 上式在实际应用中不被使用，因为热焓差不是可直接测量的量。实际上热焓值主要与介质的成分有关，因为液体的不可压缩性，所以压力影响可忽略不计，上式可转化为： 式中：Cp为进出口平均介质比热值 ΔΘ为进出口温差值 qv为介质体积流量 ρ(Θi)为介质密度 将值组合为新值，即为热量系数K。所以实际应用的热量计算公式为： 或： 式中： 热量系数；热介质（水）成分的参数，是热介质在实际温度的函数， 流量传感器测量热介质流过热循环统体积值； 热电阻对测量热循环系统进、出口温差值；
常见超说明书用药一览表，教你搞定超说明书用药！ 国内外药物治疗中超说明书用药是普遍现象，普通成人用药中有7.5%~40%。有关资料报道，在美国每一年约40%～60%的处方药被用于“未经FDA 批准的用途”。统计显示，住院儿科患者中超说明书用药占有50%~90%。2013年中国药理学会对全国45家医院进行“超说明书用药调查”，结果显示，24 家医院填报的1652 项超说明书用药涉及的998 个药品，超适应证用药的有90.4％，超用药剂量和频率有21.1％，超用药途径有9. 3％，超药品的使用人群的有3.9％。 超药品说明书用药的定义——是指临床实际使用药品的适 应证、给药方法或剂量不在具有法律效力的说明书之内的用法，包括年龄、给药剂量、适应人群、适应证、用药方法或给药途径等与药品说明书中的用法不同的情况，又称超范围用药、药品未注册用药或药品说明书之外的用法。点击链接查看→超说明书用药的侵权责任（药师必读！） 指导思想：依据《药品管理办法》、《医疗机构药事管理规定》、《侵权责任法》、《药品说明书和标签管理规定》，为加强药事管理工作，保证医院药学服务安全；促进临床合理用药，保障临床用药的安全性、有效性、合理性及药师自身安全，避免不必要的纠纷。
重要性：超药品说明书用药现象的存在具有一定的合理性和必要性，但是超说明书用药有可能没有大量临床研究数据支持，也没有获得药品监管部门批准，因此必然存在一定的风险，且药品说明书具有法律效力，超药品说明书用药不受法律保护，超说明书用药导致不良后果的，医生和药师要承担相应法律责任。 《处方管理办法》第五章规定：药师应按照药品说明书或者处方用法，进行用药交代与指导。药师应当对处方用药适宜性进行审核，审核内容包括处方用药与临床诊断的相符性、剂量用法的正确性、其他用药不适宜情况等。药师经处方审核后，认为存在用药不适宜时，应当告之处方医师，请其确认或者重新开具处方，药师发现严重不合理用药或者用药错误，应当拒绝调剂。 药师在审核处方或医嘱时，首先应对药品说明书有深入、细致、透彻地了解，并以药品说明书为依据，严格按药品说明书规范调剂药品，规避用药风险，确保调剂行为的安全及患者的用药安全。 当临床医生因医疗创新确需要超药品说明书用药时，应提供权威的文献依据，并经药事管理与药物治疗学委员会审核同意，报医务科备案，使用时与患者签署知情同意书。药师在审核和调剂超药品说明书用药处方或医嘱时，严格依据《知情同意书》和医务科备案方能调剂药品。
产品使用手册/说明文档 模板 目录 第1章第2章 2.1 2.2 2.3 2.4 2.5 2.6 2.7 文档历史 ............................................................................. ......................... 3 引言............................................................................ 错误！未定义书签。 文档约定 ............................................................................. ............ 错误！未定义书签。术语 ............................................................................. .................... 错误！未定义书签。背景 ............................................................................. .................... 错误！未定义书签。预期读者 ............................................................................. .............................................. 5 主要功能 ............................................................................. .............................................. 5 参考文档 ............................................................................. ............ 错误！未定义书签。风险总述 ............................................................................. ............ 错误！未定义书签。 第3章 3.1 功能模块1 .............................................................................. (7) 功能点1 .............................................................................. . (7) 3.1.1 3.1.2 3.1.3 3.1.4 3.1.5 3.2 功能描述 .................................... 错误！未定义书签。主要流程.................................... 错误！未定义书签。角色......................................................... 7 用户界面（ui）............................................... 7 待解决问题 .................................. 错误！未定义书签。 功能点2 .............................................................................. .............................................. 8 3.2.1 3.2.2 3.2.3 功能描述.................................... 错误！未定义书签。角色......................................................... 8 用户界面
深圳市慧拓鑫科技有限公司 Shenzhen Hui Tuo Xin Technology Co., Ltd. 产品资料 Product information 1、TOP电源防雷箱系列（TOP Power lightning protection box series） 产品介绍Product introduction TOP电源防雷箱系列依据IEC标准设计，8/20波形最大通流容量20KA-100KA，能对电源系统的浪涌电压进行有效的钳制，电源B、C、D级产品均具备。 TOP Power lightning protection box series is designed according to IEC
standard, 8/20 wave maximum flow capacity of 20KA-100KA, to power system voltage surge effectively clamped, power supply B, C, D products have. TOP电源防雷箱配系列具备测试指示灯功能，能有效的指示防雷箱工作电源、浪涌防护状态，并可选备雷击计数、远程遥信监测功能。 TOP Power lightning protection box series Have a test indicator function，Can effectively indicate the lightning protection box power supply、Surge protection status And optional lightning counting、Remote remote monitoring function ★电涌保护器失效报警功能/相零反接及接地不良报警 ★（Surge protection device failure alarm function / Phase zero reverse connection and grounding alarm） ★雷击计数显示、电源指示功能（可选） ★ Lightning counting display，Power indicator function（Optional） ★电浪保护器远程监测功能（失效） ★ Remote monitoring function（Failure） ★残压低、响应时间快 ★ Residual depression and Fast response time ★安装设计人性化、结构严谨 ★ Installation design of humanity and Strict structure ★工作环境温度适应性强 ★ Working environment temperature adaptability
