www.vishay.com12CCF07Vishay Dale
For Technical Questions, contact ff3dresistors@vishay.comDocument Number: 31013Revision 08-Dec-05Metal Film Resistors, Industrial, ± 2 % and ± 5 % ToleranceFEATURES•0.25 watt at + 70 °C power ratingDual rated for 0.5 watt•± 2 % and ± 5 % tolerance•± 100 ppm/°C and ± 200 ppm/°C temperaturecoefficient•Tape and reel packaging for automatic insertion(52.4 mm inside tape spacing per EIA-296-E)•Flame retardant epoxy conformal coating•Standard 4 band color code marking for ease ofidentification after mounting•Lead-(Pb)-free version is RoHS compliantGLOBALHISTORICALPOWER RATINGLIMITING ELEMENTTEMPERATURETOLERANCERESISTANCEE-SERIESMODELMODEL P70 ˚CVOLTAGE MAX.COEFFICIENTRANGEWVƆppm/°C%ΩCCF07CCF-070.25 / 0.5250± 100± 2, ± 510R - 1M24CCF07CCF-070.25 / 0.5250± 200± 51.1M - 2M24STANDARD ELECTRICAL SPECIFICATIONS
PARAMETERUNITCCF07Rated Dissipation at 70 °CW0.25 / 0.5Maximum Working VoltageVƆ≤ 250Insulation Voltage (1 min)Veff500Dielectric StrengthVAC450Insulation ResistanceΩ ≥ 1011Operating Temperature Range°C- 65 / + 150Terminal Strength (pull test)lb2Weightg0.35 maxTECHNICAL SPECIFICATIONS
GLOBAL MODELRESISTANCE VALUETOLERANCE TEMPER
ATUR
E PACKAGINGSPECIAL CODECOEFFICIENTCCF07R = DecimalG = ± 2 %K = 100 ppmR36 = Tin/Lead, T/R (5000 pcs)K = ThousandJ = ± 5 %N = 200 ppmE36 = Lead free, T/R (5000 pcs)(Dash Number)M = Million(up to 3 digits)10R0 = 10 Ω from1 - 999 680K = 680K Ωas applicable2M00 = 2.0M ΩGLOBAL PART NUMBER INFORMATIONNew Global Part Numbering: CCF07240RGKR36 (preferred part numbering format)
CCF07240RGKR36
Historical Part Number example: CCF-07241G (will continue to be accepted)CCF-07241GR36HISTORICAL MODELRESISTANCE VALUETOLERANCE CODEPACKAGINGBlank = StandardAvailablePb-free
RoHS*COMPLIANTe3
* Pb containing terminations are not RoHS compliant, exemptions may apply元器件交易网www.cecb2b.comwww.vishay.com13CCF07Vishay Dale
Document Number: 31013Revision 08-Dec-05For Technical Questions, contact ff3dresistors@vishay.comDIMENSIONS in inches [millimeters]
PERFORMANCE
* Test Methods per MIL-STD-202G/IEC 60115/DIN EN 140000 (as applicable).** Life ∆R is ± 2.0 % for 1/2 watt rating.0.245 ± 0.020[6.22 ± 0.51]1.100 ± 0.040[27.94 ± 1.02]0.090 ± 0.008[2.29 ± 0.20]Refer to note forWire Dia.Metal Film Resistors, Industrial
RESISTANCE VALUESVishay Dale Model CCF07 is available in the standard 24 resistance values per decade. Values are obtained from the following decade tableby multiplying by powers of 10. As an example: 24 can represent 24 ohm, 240 ohm, 2.4 kohm, 24 kohm or 240 kohm.101112131516566268758291333639434751182022242730- Color bandMARKING
TEST*MAX. ∆R (Typical Test Lots)Thermal Shock± 1.0 %Short Time Overload± 0.5 %Low Temperature Operation± 0.5 %Moisture Resistance± 1.5 %Resistance to Soldering Heat± 0.5 %Shock / Bump± 0.5 %Vibration± 0.5 %Terminal Strength± 0.5 %Dielectric Withstanding Voltage± 0.5 %Life± 1.5 %**- 65 - 50 - 25 0 25 50 70 75 100 125 150175 200 AMBIENT TEMPERATURE IN ˚CDERATING120100806040200RATED POWER IN %
*Note: Wire Dia.CCF07 (Sn/Pb) = 0.025 ± 0.002 [0.64 ± 0.05]CCF07 (Sn) = 0.023 ± 0.002 [0.60 ± 0.05]元器件交易网www.cecb2b.com Document Number: 91000 www.vishay.comRevision: 18-Jul-081DisclaimerLegal Disclaimer NoticeVishay
