AL-LT08LED日光灯规格书

Address: 3F Building 3, Landwind Industrial Zone, Shiyan Town,ModelPictureDiscriptionSize (LxW)mmLED Q'ty (pcs)Power (W)Voltage&FrequencyColor&KelvinLuminousFlux(lm)Unit price (100-1000pcs)(USD) Unit price>1000pcs)(USD)XH-LPR120-5WAl frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter120mm Cut diameter 105mm 25PCSSMD2835 LEDs5WAC85-265V 50-60Hz warm white/white 2800-7000K400-450 4.44 4.23XH-LPR145-8W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter145mm Cut diameter 130mm 40PCSSMD2835 LEDs8WAC85-265V 50-60Hz warm white/white 2800-7000K650-700 6.89 6.56XH-LPR160-9W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter160mm Cut diameter 145mm 45PCSSMD2835 LEDs9WAC85-265V 50-60Hz warm white/white 2800-7000K750-8007.447.09XH-LPR180-12W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter180mm Cut diameter 160mm 60PCSSMD2835 LEDs12WAC85-265V 50-60Hz warm white/white2800-7000K950-10008.117.72XH-LPR200-14W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter200mm Cut diameter 180mm 70PCSSMD2835 LEDs14WAC85-265V 50-60Hz warm white/white2800-7000K1100-11509.118.68XH-LPR220-16W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter220mm Cut diameter 200mm 80PCSSMD2835 LEDs16WAC85-265V 50-60Hz warm white/white2800-7000K1250-130010.449.95XH-LPR225-18W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter250mm Cut diameter 205mm 90PCSSMD2835 LEDs18WAC85-265V 50-60Hz warm white/white2800-7000K1450-140010.6710.16XH-LPR240-20W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter240mm Cut diameter 220mm 100PCSSMD2835 LEDs20WAC85-265V 50-60Hz warm white/white2800-7000K1650-170012.3311.75XH-LPR300-24W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter300mm Cut diameter 280mm120PCSSMD2835 LEDs24WAC85-265V 50-60Hz warm white/white2800-7000K1950-200015.6714.92ModelPictureDiscriptionSize(LxW)mmLED Q'ty (pcs)Power (W)Voltage&FrequencyColor&KelvinLuminousFlux(lm)Unit price (100-1000pcs)(USD) Unit price>1000pcs)(USD)XH-LPS110-5WAl frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter110x110mm Cut diameter 90x90mm 20PCSSMD2835 LEDs5WAC85-265V 50-60Hz warm white/white 2800-7000K400-450 4.67 4.44XH-LPS160-12W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter160x160mm Cut diameter 140x140mm 60PCSSMD2835 LEDs12WAC85-265V 50-60Hz warm white/white2800-7000K950-10008.337.94XH-LPS180-12W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter180x180mm Cut diameter 160x160mm 60PCSSMD2835 LEDs12WAC85-265V 50-60Hz warm white/white2800-7000K950-10008.568.15XH-LPS200-14W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter200x200mm Cut diameter 180x180mm 72PCSSMD2835 LEDs14WAC85-265V 50-60Hz warm white/white2800-7000K1100-11509.679.21XH-LPS220-16W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter220x220mm Cut diameter 200x200mm 80PCSSMD2835 LEDs16WAC85-265V 50-60Hz warm white/white2800-7000K1250-130010.8910.37XH-LPS240-16W Al frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter240x240mm Cut diameter 180x180mm80PCSSMD2835 LEDs16WAC85-265V 50-60Hz warm white/white2800-7000K1250-130012.3311.75Square Ultra thin LED Downlight seriesRound Ultra thin LED Downlight seriesXINGHUO LED TECH LIMITEDTel : 0086-0755-********-805 Fax: 0086-0755-********Web:Email:**************MSN:**************************:johnzuo88Bao'an District, Shenzhen, China 518108Ultra thin LED Downlight catalogue with pricelistXH-LPS300-20WAl frame+arylic coverTaiwan Original Chi Mei light panelguide,transparent rate 90%Diameter300x300mmCut diameter280x280mm100PCSSMD2835 LEDs20WAC85-265V50-60Hzwarm white/white2800-7000K1650-170015.6714.92Note: 1.LED light source:LumenMax SMD2835 LEDs, 20-22lm/pc LEDs CRI>802.Warranty: 3years3. Price Term: EXW Shenzhen5.Lead time: 3-5 working days for samples, 12-15days for large quantity6.Validity: 30days, the final price should be confirmed with Xinghuo LED7.The MOQ is 100pcs ( No requirements for new customers)Company Name:Account No.:Bank Code: SWIFT Code: Bank address: 004HSBCHKHHHKHHSBC, No. 1 Queen’s Road Central, Central, Hong Kong4. Certification: CE, ROHS, Erp approvedBy T/T payment in advance, kindly write the company name correctly.XINGHUO LED TECH LIMITED561-718396-838。

常规LED日光灯参数客户名称：品名：LED日光灯T8 18W产品型号：T8 18W一，产品外型与普通T8荧光日光灯规格一样。

L=1178mm二，电气参数1、产品型号：TDC-TL8-10022、LED光源：3014 LED3、宽电压：AC180-260V4、整灯功率:18W±1W5、光通量：≥1620LM6、光效：≥90LM/W7、色温范围：2700-7000K8、发光角度：120度9、工作温度：-20-50°C10、外壳：铝型材+光扩散罩三，产品特点：1、高效：使用新型节能环保的LED作为光源，独特的电路控制设计，真正达到高效节能，LED灯管的亮度是普通日光灯亮度的2-3倍，相比传统日光灯可节能65%以上。

2、省电：相同亮度下，传统45W日光灯,每20小时就耗市电1度，18W LED日光灯管55小时耗市电1度。

3、稳定的电性：宽范围电压变化，幅度变化亮度保持恒定不变；启动响应迅速（无需预热时间）；频繁开关无损坏现象；非常适合开启次数频繁，电压波动范围大的场合（如声控过道频繁启动场合，大功率设备大幅度波及照明电网场合）。

4、颜色一致性：批量LED日光灯颜色一致性好，适合豪华型高标准大空间照明设计选用。

5、高寿命：LED日光灯寿命为普通日光管的10倍以上，不存在经常更换灯管，整流器，启辉器的问题，色调不变，永久光新，节免了管理维护费用6、环保，LED日光灯除了节能以外，更具有无频闪无红外辐射，显色性能优越之功能。

对人的视力有较好的保护作用。

（一般白炽灯的频闪为60-100Hz/秒），它的能源消耗少，可以减小很多煤矿等其他资源的消耗，能很大程度减小环境污染。

7、线性发光面，无黑影、无光斑，发光均匀，环保、高效、节能8、低光衰：1000H光衰为3%，如下为光衰曲线图图2 老化测试曲线图四，经济效益比1，省电对比：用18W LED 日光灯与40W 普通日光灯与比较，以工此同时业用电1.2元/度，每天10小时，一年使用期统计。

Technical Data Sheet Top View LEDs67-21/X2C-BXXXXXXXXX/2TCarrier Tape Dimensions: Loaded Quantity 2000 pcs Per Reel.Note: Tolerance unless mentioned is ±0.1mm; Unit = mmMoisture Resistant PackagingLabelAluminum moisture-proof bagDesiccantLabelEverlight Electronics Co., Ltd. Device No. : DSE-0002584 Prepared date: 12-Oct.-2009Rev. 1Page: 11 of 16Prepared by: Ryan ChenTechnical Data Sheet Top View LEDs67-21/X2C-BXXXXXXXXX/2TReliability Test Items and ConditionsThe reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% Test Hours/Cycles 6 Min. Sample Size 22 PCS.No. 1Items Reflow SolderingTest Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RHAc/Re 0/12Temperature Cycle300 Cycles22 PCS.0/13Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs.22 PCS.0/14 5 6 722 PCS. 22 PCS. 22 PCS. 22 PCS.0/1 0/1 0/1 0/1Everlight Electronics Co., Ltd. Device No. : DSE-0002584 Prepared date: 12-Oct.-2009Rev. 1Page: 12 of 16Prepared by: Ryan ChenTechnical Data Sheet Top View LEDs67-21/X2C-BXXXXXXXXX/2TPrecautions for Use1. Over-current-proof Customer must apply resistors for protection; otherwise slight voltage shift will cause big current change (Burn out will happen). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life are 168 hours under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment: 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile1~5 °C / Sec. 260°C. Max. 10 Sec. Max. 1~5 °C / Sec. Pre-heating 180~200°C 60 Sec. Max. Above 220°C120 Sec. Max.3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board.Everlight Electronics Co., Ltd. Device No. : DSE-0002584 Prepared date: 12-Oct.-2009Rev. 1Page: 13 of 16Prepared by: Ryan ChenTechnical Data Sheet Top View LEDs67-21/X2C-BXXXXXXXXX/2T4. Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5. Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing.EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.CTel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 Everlight Electronics Co., Ltd. Device No. : DSE-0002584 Prepared date: 12-Oct.-2009Rev. 1Page: 14 of 16Prepared by: Ryan Chen。

LED 投光灯规格书客户代码:品名: LED 150W投光灯规格: L425 * W325 * H190mm送样日期: 2014年6月30日本厂型号: HTG06150档案号:送样数量:承认书份数: 1份客户承认核准制作一.产品材质：高纯度铝制反射器，灯壳及散热体；高强度钢化玻璃罩；大功率LED 光源；搭配高效率恒流电源.二.适用场所：主要用于户外投光照明、建筑物外墙、港口码头等，户外广告。

厂区、体育馆、停车场、广场、码头、工地、广告牌、桥梁、江河堤岸、园林、景观、庭院、草坪、池塘以及其他夜景亮化、照明的场所。

三、特点：1.采用集成大功率LED（50W）作为光源。

运用独特的多颗芯片集成式单模组光源设计，选用进口高亮度半导体晶片。

2.散热器与灯壳一体化设计，LED 直接与外壳紧密相接，通过外壳散热翼与空气对流散热，充分保证了LED灯的使用寿命。

3.灯壳采用铝合金压铸成型，可以有效的散热和防水、防尘。

灯具表面进行了耐紫外线抗腐蚀处理，整体灯具达到P65 标准。

4.采用单体椭圆反射腔配合球状弧面来设计，针对性地将LED 发出的光控制在需要的范围内，提高了灯具出光效果的均匀性和光能的利用率，更能凸显LED泛光灯节能优点。

与传统的纳灯相比，可节电70%以上.5.无不良眩光、无频闪。

消除了普通灯不良眩光引起的刺眼、视觉疲劳与视线干扰。

6.启动无延时，通电即亮，无需等待，消除了传统灯具长时间的启动过程。

7.绿色环保无污染，不含铅、汞等污染元素，对环境没有任何污染。

四、投光灯技术参数产品图和配光图：产品功率150W总功率功率168WLED 初始光通量15000lm整灯维持光通量13500lm相关色温暖白3200K 正白6500K显色指数暧白:＞70正白＞80配光曲线矩形光斑发光角度140度理论光衰＜10%（20000小时）输入电压AC85V-265V（50~60Hz）工作电压DC 30V结点温度50-70度整灯光郊＞88%功率因素＞0.95防护等级IP65尺寸L425*W325*H190mm净重8.5公斤材质优质压铸铝+钢化玻璃工作环境温度：-40℃—50℃湿度：10%—90%电源连接线棕色L火线蓝色 N零线黄色或黄绿G地线五、使用说明1.产品使用工作电压：AC 85V～265V 50/60Hz。
