Action points dry bulk system
After First quick inspection already a lot of points快速的检查下已经很多点:
- deck-connections:甲板连接
o PS-Aft : direction of piping : now going to mid ships should go to aft ship
左前:管子方向:现在是朝向中间,应该朝向船后
o PS-Aft : blocking part of hand valve damaged
o 左前:手动阀门锁定部分损坏
o PS Mid : handles ball valves are bended
o 左中:球阀手柄弯曲
o PS select AFT : blocking part of hand valve is bended
o 左边挑选的后面:手动阀门锁定部分弯曲
o PS select AFT : blocking part of hand valve is stocked
o 左边挑选的后面:手动阀门锁定部分损坏
o STB-Aft : blocking part of hand valve damaged
o 右后:手动阀门锁定部分损坏
o STB-Aft : handle ball valves are bended
o 右后:球阀手柄弯曲
o STB-Mid: handles of ball valves are bended
o 右中:球阀手柄弯曲
o STB select AFT : not possible to close the hand valve
o 右挑选的后面:阀不能关闭
o STB vent : blocking part of hand valve is bended
o 右透气:手动阀门锁定部分弯曲
o STB vent : handle ball valve is bended
o 右透气:球阀手柄弯曲
- Tank 1: below valves : missing 2 solenoids and 2 cables to the solenoid (T5 jumper)
- 1#柜:下部阀:缺失两个电磁阀和接阀的线(T5跨接线)
- Tank 2: missing Sensor T5 connection
- 2#柜:缺失传感器T5连接件
- Tank 2: Top, solenoid broken
- 2#柜:顶部,电磁阀坏
- Tank 2: missing 4 bolds for manhole
- 2#柜:人孔少4个螺栓
- Tank 3: Wrong solenoid placed and 2 cables to the solenoid are missing
- 3#柜:电磁阀放错了并且两个电磁阀线缺失
- Tank 3: Top, 2 solenoids are broken
- 3#柜:顶部,两个电磁阀坏
- Tank 4: missing solenoid and 2 cables to solenoid
- 4#柜:缺少电磁阀和两个电磁阀线
- Tank 4: Top, connection to valve is not good have to check for repair
- 4#柜:顶部,阀连接不好,必须检查纠正
- Tank 5:
- 5#柜子:
- Tank 6: broken solenoid
- 6#柜:坏电磁阀
- Tank 6: 0.5 Bar PRESSURE IS INSIDE THE TANK
- 6#柜:柜子里有0.5bar的压力(怎么会有压力的)
- Tank 6: Top, solenoid damaged connection have to check for repair
- 6#柜:顶部,电磁阀连接坏,必须检查维修
- Tank 7: missing solenoid and 1 cable to the solenoid
- 7#柜:缺失电磁阀和一根连接电磁阀线。
- Tank 8:
- 8#柜子:
- Filtertank 1 : discharge valve not connected (yellow cable)
- 滤器柜1#:排除阀没有连接(黄色线)
- Filtertank 1 : Actuator and solenoid set is missing for the dirty air inlet valve
- 滤器柜1#:脏空气进口阀执行机构和电磁阀装置缺失
- Filtertank 1 : high level switch not tightened
- 滤器柜1#:高位开关没有紧固
- Filtertank 1 : Top, broken solenoid selection discharge
- 滤器柜1#:顶部,选择排放电磁阀坏
- Filtertank 2 : Actuator and solenoid set is missing for the dirty air inlet valve
- 2#滤器柜:脏空气进口阀执行机构和电磁阀装置缺失
- Filtertank 2 : pressure sensor is missing
- 2#滤器柜:压力传感器缺失
- Filtertank 2 : motor valve is not connected
- 2#滤器柜:电动阀没有连接
- Filtertank 2 : bended support for climbing inside filtertank
- 2#滤器柜:滤器里面攀爬支撑弯曲
- Filtertank 2 : cable to high level switch is not tightened properly
- 2#滤器柜:高位开关线没有合适的紧固
- Motor valve on deck connection is missing for system 1 sealing’s are now painted
- 系统1#的连接到甲板的电动阀缺失,垫片现在被刷了漆
- Broken solenoid selection system 2 to STB
- 系统2#右挑选坏的电磁阀
- Hand valve cross over valve between two compressors is damaged
- 两台空压机间的手动转换阀坏
- Air vessel : missing pressure gauge
- 空气瓶:缺失压力表
- Air vessel : connection of automatic drain, other end again inside tank?
- 空气瓶:自动泄放的连接,另一头又在柜子里?
- Dryer PS: missing controller
- 左干燥器:缺失控制器
- Dryer PS: damaged cross over valve
- 干燥器左:手动转换阀坏
- Position of the Humidity sensor is different for system 1 and 2
- 系统1#和2#的湿度传感器位置不一样(服务商说右边是对的)
- Control cabinet : screen is placed upside down, connection to PC and screen is not
finished. Screen is not a touchscreen!!!
- 控制柜:屏幕颠倒,连接电脑和屏幕没有完成。屏幕不是触摸屏。
Not all could already be checked.不是所有的都已经检查了
Tank 5 – 8 top valves are covered with protection clothing
5#--8#柜顶部的阀被保护的布盖住了
Not checked inside tank没有检查柜子内部
Filtertanks not checked on position because it is difficult to get in position to see
everything.
滤器柜没有检查位置,分困难取得位置检查一切东西
Compressor is covered with protection clothing
空压机被保护的布盖着
