Alpha Industries, Inc.[781] 935-5150 •Fax[617]824-4579•Emailsales@alphaind.com•www.alphaind.com
1
Specifications subject to change without notice.1/00A
PHEMT GaAs IC High Linearity 3 V
Control SPDT Switch 0.1–2 GHz
FeaturesI+2.5 to +5 V Linear Operation P-0.1 dB≥37 dbmIHarmonics H2, H3> 65 dBc @ PIN= 34.5 dBmILow Insertion Loss (0.5 dB @ 0.9 GHz)IUltra Miniature SOT-6 PackageIPHEMT ProcessSOT-6
AS190-73
0.074
(1.90 mm REF.)
0.071 (1.80 mm)
0.052 (1.30 mm)
0.037 (0.95 mm) REF.
0.122 (3.10 mm)
0.106 (2.70 mm)
0.006
(0.15 mm)
0.000
(0.00 mm)
0.057 (1.45 mm)
0.035 (0.90 mm)
0.020 (0.51 mm)
0.014 (0.350 mm)
0.126 (3.20 mm)
0.087 (2.20 mm)
PIN 6
PIN 1
PIN 1
INDICATOR
0.022 (0.61 mm)
0.004 (0.10 mm)
0.014
(0.26 mm)
0.004
(0.10 mm)
0.012
(0.30 mm)
TYP.
5.0˚ ± 1˚
5.0˚ ± 1˚
Description
The AS190-73 is a PHEMT GaAs FET IC high linearity
SPDT switch in a SOT-6 plastic package.This switch has
been designed for use where extremely high linearity, low
control voltage, low insertion loss and ultra miniature
package size are required.It can be controlled with positive,
negative or a combination of both voltages.Some standard
implementations include antenna changeover, T/R and
diversity switching over 3 W.The AS190-73 switch can be
used in many analog and digital wireless communication
systems including cellular, GSM and DECT applications.
Parameter1FrequencyMin.Typ.Max.Unit
Insertion Loss20.1–0.5 GHz0.250.40dB
0.5–1.0 GHz0.350.50dB
1.0–2.0 GHz0.750.90dB
Isolation0.1–0.5 GHz2224dB
0.5–1.0 GHz1517dB
1.0–2.0 GHz1012dB
VSWR30.1–1.0 GHz1.2:1dB
1.0–2.0 GHz1.3:1dB
Electrical Specifications at 25°C (0, +3 V)
Preliminary
ParameterConditionFrequencyMin.Typ.Max.Unit
Switching Characteristics4Rise, Fall (10/90% or 90/10% RF)60ns
On, Off (50% CTL to 90/10% RF)100ns
Video Feedthru50mV
Input Power for -0.1 dB Compression0/+3 V0.9 GHz+37dBm
Harmonics H2, H3PIN= 34.5 dBm0.9 GHz+70dBc
Control VoltagesVLow= 0 to 0.2 V @ 20 µA Max.
VHigh= +2.5 V @ 100 µA Max.to +5 V @ 200 µA Max.
Operating Characteristics at 25°C (0, +3 V)
1.All measurements made in a 50 Ωsystem, unless otherwise specified.
2.Insertion loss changes by 0.003 dB/°C.
3.Insertion loss state.
4.Video feedthru measured with 1 ns risetime pulse and 500 MHz bandwidth.
元器件交易网www.cecb2b.com
PHEMT GaAs IC High Linearity 3 V Control SPDT Switch 0.1–2 GHzAS190-73
2
Alpha Industries, Inc.[781] 935-5150 •Fax[617]824-4579•Emailsales@alphaind.com•www.alphaind.com
Specifications subject to change without notice.1/00A
C
BL
C
BL
V1J1V2J
2
GND
J
3
C
BL
1
2
3
6
5
4
Pin OutV1V2J1–J2J1–J30VHighIsolationInsertion LossVHigh0Insertion LossIsolationTruth Table
VHigh= +2.5 to +5 V.
DC blocking capacitors (CBL) must be supplied externally.
C
BL
= 100 pF for operating frequency >500 MHz.
I
n
s
e
r
t
i
o
n
L
o
s
s
(
d
B
)
Frequency (GHz)
Insertion Loss vs. Frequency
-1.0
-0.9
-0.8
-0.7
-0.6
-0.5
-0.4
-0.3
-0.2
-0.1
0
00.51.01.52.0
Frequency (GHz)
Isolation vs. Frequency
I
s
o
l
a
t
i
o
n
(
d
B
)
00.51.01.52.0
-40
-35
-30
-25
-20
-15
-10
-5
0
Frequency (GHz)VSWR vs. Frequency1.01.21.41.61.82.0VSWR00.51.01.52.0H2, H3 (dBc)VCTRL (V)
Harmonics vs. Control Voltage
34.5 dBm 900 MHz GSM Pulse
30
35
40
45
50
55
60
65
70
75
80
2.02.53.03.54.04.55.0
H
2
H
3
Typical Performance Data
