1. 1. Introduction
Recently, the increase in the already large amount of acidic wastewater generated by semiconductor manufacturing plants during etching processes, which contains fluoride (FÀ), nitrate (NO3À), and phosphate (PO4nÀ) anions, has become a serious environmental concern [1]. Furthermore, phosphate and nitrate have been introduced into the environment through sewage treatment effluent, surface runoff carrying fertilizers, and many other human activities, which has deteriorated water quality, resulting in algal bloom and depletion of dissolved oxygen in water media [2]. Thus, the demand for treatment of these anions has been persistently increasing to maintain a clean environment and supply safe drinking water.
a Department of Chemical and Biomolecular Engineering (BK21 program), KAIST, 335 Gwahak-ro, Yuseong-gu, Daejeon 305-701, Republic of Korea b Advanced Biomass R&D Center, KAIST, 291 Daehakno, Yuseong-gu, Daejeon 305-701, Republic of Korea c Department of Chemical & Biochemical Engineering (BK21 program), Chosun University, Seosuk-dong, Dong-gu, Gwangju 501-759, Republic of Korea
