TVSI单电机制砂机
【进料粒度】：30-50mm
【生产能力】：60-520T/h
TVSI single sand making
[Feeder size 】:30-50mm
[Production capacity 】:60-520T/h _
产品介绍:Product introduction:
TVSI系列高效立轴冲击式破碎机，又称制砂机、整形机，是我公司引进德国权威专家最新 研制成果，并结合中国的矿山条件经过改进设计， 是目前国内最具有世界先进水平的第四代
高性能制砂设备。本产品广泛用于金属和非金属矿石、水泥、耐火材料、铝矶土、金刚砂、 玻璃原料、建筑材料、人工造砂以及各种冶金矿渣的细碎，特别对中硬、特硬物料比其它类 型的破碎机更具有优越性。
TVSI high-efficiency vertical shaft impact crusher is also known as sand making machine, sand shaping machine. We
introduced the German authoritative experts latest research results, combined with China's mining conditions and
improved design; this is the most advanced fourth generation high performance sand making equipment. Widely used in
the quarry, mixing plant, dry mortar, quartz sand, construction waste crushing and other industries, providing quality sand
and gravel aggregate for highway, railway, construction, municipal, hydroelectric dam construction and concrete mixing
station.
产品特点：Product features:
1. 结构简单 运行平稳
该机经过不断的改进优化，在保证机器的性能提高的同时，机器结构也得以简化，整个机器更容易操作。
其转子部件整体热处理，SKF进口轴承，增加副抛料头，稀油润滑自动控制系统，整机结构牢固，运行稳定 〔.Largest
throughput of single machine model is up to 450 t/h, compared with the same power of traditional equipment, production
increased by 30%, and very stable.
2. 高效节能破碎效率高
该机分料器安装在破碎腔的上部， 分料器可使物料经由中心入料管直接进入转子被逐渐加速到较高速度抛
射出去，在不增加功率消耗的前提下，增大生产能力，提高破碎效率。
2. Less friction between the materials and the wear parts, directly reduce the use cost.
3. 操作简单维修方便
液压调整进料口，操作简单，液压升降装置，维修更方便、快捷。
3. Cubic shape output, good grain shape, reasonable grading and fineness modulus is adjustable, especially suitable for
artificial sand making and stone shaping process.
4. 使用寿命长粉尘污染少
该机在整个破碎过程中，物料相互自行冲击破碎，不与金属元件直接接触，而是与物料衬层发生冲击、磨 擦而粉碎，从而延长机械磨损时间。并且该机涡动腔内部巧妙的气流自循环，消除了粉尘污染。
4. Adopting international brand bearing of high-precision level, ensure the system low failure rate.
5. 自动化操作安全更可靠
该机主轴轴承用稀油站进行循环润滑，设备工作时可保证向主机连续供油。并且可实现自动控制和事故报 警。
5. Equipped with the German original thin oil lubrication station, completely solved the bearing generate heat and other
problems.
技术参数：technical parameters:
型号
Model 最大进料
Max.feeding
size(mm) 转子工作圆直径
Rotor
diameter(mm) 转子速度
重量
Weight(t) 外型尺寸
Dimension(mm) Rotor
speed
(r/mim) 处理能力
Capacity(t/h) 电机功率
Power
(kw)
TVSI-600 40 713 1600 120 160 6.5 3670x1821x2100
TVSI-800 40 800 1200-1600 180 200 7.9 4037x2070x2375
TVSI-1000 40 1000 1200-1400 240 315 12 4890x2386x2678
TVSI-85G 50 840 1200-1400 350 315 14 4100X2150X2700
TVSI-95G 60 840 1200-1400 500 500 18 6000X2300X2850
工作原理:Working principle
物料由给料斗进入破碎机， 一部分物料经破碎腔上部的分料器进入高速旋转的转子， 在转子内被迅速加速，
其加速可达数百倍重力加速度，然后以 60 75米/秒的速度从转子周围的流道内抛射出去，首先同由给 料斗四周溢流口自由落下的一部分物料冲击破碎，然后一起冲击到破碎腔内衬层上，被物料衬层反弹，斜 向上冲击到破碎腔的顶部，又改变其运动方向，偏转向下运动，和从转子流道发射出来的物料形成连续的 物料幕。这样，一块物料在涡流破碎腔内受到多次撞击、摩擦和研磨破碎作用。被破碎的物料由下部排料 口排出。经循环筛分系统形成闭路，一般循环三次即可将物料破碎成为 4.75mm以下。破碎腔内部巧妙的
气流自循环，消除了粉尘污染。
VSI sand making machine selects the advanced selective crushing and comprehensive crushing principle, it directly send
the kinetic energy to material, and convert it to crushing energy, which can crush the material, via impacting energy.
Material will broke along the natural texture, comprehensive face, and good particle shape, lower cost. It can reach the two
kinds of working principle of stone to stone and
stone to iron. Central feeding material: The material is thrown by impeller with high speed, which gets from impeller and
ten times than acceleration of gravity, after feeding into hoper. Firstly rebound material crushes with falling material, then
impact to material lining(stone to stone) or (stone to iron), or being rebounded to the chamber top of impeller . Then
change material running direction to downward direction.
Then it crushes with material, which came from the trail plate of impeller to form the constant material curtain. So one
material discharge from bottom discharge opening after crushing, grinding, polishing many times in chamber.
