178Series MAC 500The MAC 500 series is designed to interface with the Ford/Chrysler standard base. This series is available in the following configurations:• single or double solenoid• 2 or 3 position• single or dual pressure• with or without indicator lights• various electrical connections and manual operationsValves and bases must be ordered separately. These may be assembled prior to shipping by adding the suffix -9 after the valve code. EXAMPLE: MAC 500A-V1B1-PM-111DA-9MAC 500A-B21A-9SPECIAL APPLICATION INSTRUCTIONS The 'A' cylinder port is normally open. On a spring return valve, the spring is the 'A' operator, the solenoid the 'B' operator. Energizing the 'B' operator pressurizes the 'B' port; energizing the 'A' operator pressurizes the 'A' port.EXTERNAL PILOT APPLICATIONSAn external pilot supply is only required when the main valve pressure is less than 25 psi on single solenoid or 3 position valves and less than 10 psi on double solenoid 2 position valves. Pipe the external pilot supply to the External Pilot Port supplied in the valve base or manifold.VACUUM APPLICATIONS(2-Pos. Valves Only) - Use an External Pilot model as described above and also connect the vacuum source to the Exhaust Port and leave the Inlet Port open to atmosphere. The Inlet port may be connected to a pressure source to provide a selector application (vacuum/pressure).SELECTOR APPLICATIONSUse an External Pilot Model as described above if both pressures are below the minimum, otherwise use an Internal Pilot Model and connect the higher pressure to the Inlet Port and the lower to Port EA or EB depending on which cylinder port is to be active.REDREDSOLBSOLA15432GREENGREENRED/WHITEFORDCHRYSLERRED/WHITERED/YELLOWRED/YELLOWRED/BLACKRED/BLACK15432SOLBSOLA
Current feedback actuator driverBA5954FP/FMDescriptionDimension (Units : mm)FeaturesApplications Absolute Maximum Ratings (Ta=25˚C)∗ PCB (70mmx70mm, t=1.6mm) glass epoxy mounting. ∗1 Derating : 13.6mW/˚C for operation above Ta=25˚C ∗2 Derating : 17.6mW/˚C for operation above Ta=25˚C HSOP28 / HSOP-M2818.5 ± 0.27.5 ± 0.29.9 ± 0.328151142.2 ± 0.10.35 ± 0.15.15 ± 0.10.5 ± 0.20.80.25 ± 0.116.0 ± 0.20.110.1 S0.08 MCD/CD-ROMSupply voltagePower dissipationOperating temperature rangeStorage temperature rangeParameterSymbolLimitsUnitVcc, PVcc1/2PdToprTstg18(BA5954FP) 1.7(BA5954FM) 2.2+85+150–35–55~~W˚C˚CV∗1∗2BA5954FP/FM is an actuator driver IC for CD-ROMand DVD players. This actuator driver adopts current feedback system. This IC incorporates 2 channel actuator drivers and 2 channel motor drivers. Current phase lag influenced load inductance is little, because this type is current feedback. 1) Wide dynamic range VOM4.0V(typ.) at PreVcc=12V,PVcc=5V,RL=8Ω2) Level shift circuit built in.3) Thermal-shut-down circuit built in.4) Stand-by mode built in.
300 Myles Standish Blvd., Taunton, MA 02780Ph: 1-800-823-8082 Fax: 5W Medical Grade Ultraminiature Switching Power SuppliesMMA-5 series
Single / Dual / Triple OutputsUniversal 85VAC to 265VAC Input3.3VDC to 24VDC Outputs4,000VAC Input to Output IsolationPCB and Chassis Mount PackagesFull Safety Approvals
Model Number Output Voltage Output Amps Output Watts
SINGLE OUTPUT - PCB Mount
MSMA-5000 3.3 VDC 1.25 4W
MSMA-5001 5 VDC 1 5W
MSMA-5002 12 VDC 0.42 5W
MSMA-5003 15 VDC 0.33 5W
MSMA-5005 24 VDC 0.23 5W
SINGLE OUTPUT - Chassis Mount
MSMC-5000 3.3 VDC 1.25 4W
MSMC-5001 5 VDC 1 5W
MSMC-5002 12 VDC 0.42 5W
MSMC-5003 15 VDC 0.33 5W
MSMC-5005 24 VDC 0.23 5W
SINGLE OUTPUT - DIN Rail Mount
MSMC-5000/DRL 3.3 VDC 1.25 4W
MSMC-5001/DRL 5 VDC 1 5W
MSMC-5002/DRL 12 VDC 0.42 5W
MSMC-5003/DRL 15 VDC 0.33 5W
Epec 5050 控制单元
技术文档
文档版本历史 日期 注 07.01.2013 文档更新 (增加 8 MByte 硬件版本) 04.12.2012 文档更新 19.10.2012 第一版发布
Technical Manual 5050 / MAN000539 在解释争议的情况下，以英文为准。英文版文档可从EPEC网站或中国办事处获取。
Epec Oy reserves all rights for improvements without prior notice Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland 目录
1 前言 ....................................................................................................................................... 5 1.1 使用的符号 ................................................................................................................ 5 1.2 所需的基本技能 ......................................................................................................... 5 1.3 安全准则 .................................................................................................................... 6 1.4 Warranty .................................................................................................................... 6 1.4.1 Limited Liability ............................................................................................... 7 1.5 Environmental Statement .......................................................................................... 7 1.5.1 WEEE ............................................................................................................. 7 1.5.2 RoHS .............................................................................................................. 7 2 产品概述................................................................................................................................ 8
