电气专业术语中英对照

Aabort 中断,停止abnormal 异常abrader 研磨,磨石,研磨工具absence 失去Absence of brush 无(碳)刷Absolute ABS 绝对的Absolute atmosphere A TA 绝对大气压AC Lub oil pump 交流润滑油泵absorptance 吸收比,吸收率acceleration 加速accelerator 加速器accept 接受access 存取accomplish 完成,达到accumulator 蓄电池,累加器Accumulator battery 蓄电池组accuracy 准确,精确acid 酸性,酸的Acid washing 酸洗acknowledge 确认,响应acquisition 发现,取得action 动作Active power 有功功率actuator 执行机构address 地址adequate 适当的，充分的adjust 调整，校正Admission mode 进汽方式Aerial line 天线after 以后air 风，空气Air compressor 空压机Air duct pressure 风管压力Air ejector 抽气器Air exhaust fan 排气扇Air heater 空气加热器Air preheater 空气预热器Air receiver 空气罐Alarm 报警algorithm 算法alphanumeric 字母数字Alternating current 交流电Altitude 高度，海拔Ambient 周围的，环境的Ambient temp 环境温度ammeter 电流表，安培计Ammonia tank 氨水箱Ampere 安培amplifier 放大器Analog 模拟Analog input 模拟输入Analog-to-digital A/D 模拟转换Analysis 分析Angle 角度Angle valve 角伐Angle of lag 滞后角Angle of lead 超前角anthracite 无烟煤Anion 阴离子Anionic exchanger 阴离子交换器Anode 阳极，正极announce 通知，宣布Annual 年的，年报Annual energy output 年发电量anticipate 预期，期望Aph slow motion motor 空预器低速马达Application program 应用程序approach 近似值，接近Arc 电弧，弧光architecture 建筑物结构Area 面积，区域armature 电枢，转子衔铁Arrester 避雷器Ash 灰烬，废墟Ash handling 除灰Ash settling pond 沉渣池Ash slurry pump 灰浆泵assemble 安装，组装Assume 假定,采取,担任Asynchronous motor 异步马达atmosphere 大气，大气压Atomizing 雾化Attempt 企图Attemperater 减温器，调温器Attention 注意Attenuation 衰減,减少,降低Auto reclose 自动重合闸Auto transfer 自动转移Autoformer 自耦变压器Automatic AUTO 自动Automatic voltage regulator 自动调压器Auxiliary AUX 辅助的Auxiliary power 厂用电Available 有效的,可用的Avoid 避免,回避Avometer 万用表,安伏欧表计Axial 轴向的Axis 轴,轴线Axis disp protection 轴向位移，保护Axle 轴，车轴，心捧BBack 背后，反向的Back pressure 背压Back wash 反冲洗Back up 支持，备用Back ward 向后Baffle 隔板Bag filter 除尘布袋Balance 平衡Ball 球Ball valve 球阀Bar 巴，条杆Bar screen material classifier 栅形滤网base 基础、根据Base load 基本负荷Base mode 基本方式Batch processing unit 批处理单元Battery 电池Bearing BRG 轴承before 在…之前bell 铃Belt 带，皮带Bend 挠度，弯曲Besel 监视孔BLAS 偏置，偏压Binary 二进制，双Black 黑色Black out 大停电，全厂停电blade 叶片Bleed 放气，放水Blocking signal 闭锁信号Blow down 排污Blowlamp 喷灯blue 蓝色Bms watchdog Bms看门狗，bms监视器boiler BLR 锅炉Boiler feedwater pump BFP 锅炉给水泵Boil-off 蒸发汽化bolt 螺栓bore 孔，腔boost BST 增压，提高Boost centrifugal pump BST CEP 凝升泵Boost pump BP 升压泵Boot strap 模拟线路，辅助程序bottom 底部Bowl mill 碗式磨brash 脆性，易脆的bracket 支架，托架，括号breadth 宽度break 断开，断路breaker 断路器，隔离开关Breaker coil 跳闸线路breeze 微风，煤粉Brens-chluss 熄火，燃烧终结bridge 电桥，跨接，桥形网络brigade 班，组，队，大队broadcast 广播brownout 节约用电brush 电刷，刷子Brush rocker 电刷摇环Brown coal 褐煤Buchholtz protecter 瓦斯保护bucket 斗，吊斗Buffer tank 缓冲箱built 建立bulletin 公告，公报bump 碰，撞击bunker 煤仓burner 燃烧器Burner management system 燃烧器管理系统Bus section 母线段busbar 母线Busbar frame 母线支架buscouple 母联Bypass/by pass BYP 旁路Bypass valve 旁路阀Ccabinet 柜cable 电缆calculator 计算器caliber 管径、尺寸、大小calorie 卡caloric 热的、热量Caloric value 发热量、热值calorific 发热的、热量的Calorific efficiency 热效率cancel 取消、省略capacitance CAPAC 电容Capacitive reactance 容抗capacity 容量、出力、能量card （电子）板、卡carrier 搬运机、载波、带电粒子Carrier protection 高频保护cascade CAS 串级Case pipe 套管casine 壳、箱casual 偶然的、临时、不规则的Casual inspection 不定期检查、临时检查casualty 人身事故、伤亡、故障catastrophe 灾祸、事故Catastrophe failure 重大事故Cat-pad 猫爪cathode 阴板、负极Cathode ray tube CRT 显示器Cation exchanger 阳离子交换器caution 注意Center 中心centigrade 摄氏温标Central control room 中控室Central processing unit CPU 中央处理器Centrifugal 离心的Certificate 证明书、执照Centrifugal fan 离心风机Certification of fitness 合格证书、质量证书Chamber 办公室、会议室Change 改变Channel 通道、频道Character 字符Characteristics 特性、特性曲线Charge 负荷、充电、加注Charge indicator 验电器、带电指示器Chart 图、图线图chassis 底座、机壳Chassis earth 机壳接地Check 检查Check valve CK VLV 截止线、止回线Chemical 化学Chemical dosing 化学加药Chest 室Chief 主要的、首长、首领Chief engineer 总工程师Chief operator 值班长Chimney 烟囱、烟道Chlorine 氯Circuit 电路Circuit breaker 电路断路器Circuit diagram 电路图Circular current 环流Circulating 循环Circulating water pump 循环水泵Circulating cooling water 循环冷却水Clamp 夹具、钳Clarification 澄清Class 类、等级、程度Class of insulation 绝缘等级Clean 清洁的、纯净的Cleanse 净化、洗净、消毒Clear 清除CLEARING OF FAULT 故障清除Clock interface unit CIU 时钟接口单元Clockwise 顺时针、右旋的Close 关闭Closed cooling water 闭式冷却水Closed-loop 闭环Cluster 电池组、组、群Coal 煤Coal ash 煤灰Coal breaker 碎煤机Coal consumption 耗煤量、煤耗Coal crusher 碎煤机Coal handling 输煤设备、输煤装置Coal dust 煤粉Coal-fired power plant 燃煤发电厂Coal hopper 煤斗Coal yard 煤场Coarse 粗的、不精确的Coaxial cable 同轴电缆Code 代号、密码Coil 线圈Coil pipe 蛇形管Cold 冷Cold air 冷风Cold reheater CRH 再热器冷段Cold reserve 冷备用（锅炉）Cold start 冷态启动Cold test 冷态试验Collect 收集Collecting pipe 集水管Collector 收集器Colour 颜色Colour library 颜色库Combin 合并、联合Combustion 燃烧Command 命令、指挥Commission 使投入、使投产Common 共同的、普通的Communication 联系、通讯Commutator 换向器Compensation 补偿Company CO 公司Company limited CO LTD 有限公司Complexity 复杂Complete 完成Component 元件Compress 压缩Compress air 压缩空气Compresser 压缩机Computer 计算机Concrete 混凝土制的Concurrent 同时发生的、一致的Concurrent boiler 直流锅炉Cond press 凝结器压力Condensate 冷凝、使凝结Condensate extraction pump CEP 凝结水泵Condenser COND/CNDER 凝结器Condensive reactance 容抗Condition 条件、状况Conduct 传导Conductivity 导电率Conference 会议、商讨、谈判Congealer 冷却器、冷冻器Configure 组态Connection 联接Connector 联接器、接线盒Console 控制台Consult 商量、咨询、参考Consumption 消费、消耗Consumption steam 汽耗Constant 恒定的Contact 触点Contactor 接触器、触头Contact to earth 接地、触地、碰地Content 目录Contin blwdwn 连排Continuous 连续的Contract 合同Control CNTR/CNTPL 控制Control & instrument 仪控Control loop 控制环Control oil 控制油Control panel 控制盘Controller 控制器Control stage 调节级、控制级Control valve 调节阀Conve cton sh 低温过热器Convection 对流Convertor 运输机、传输机Cool 冷的Cooler 冷却器Cooling 冷却Cooling fan 冷却风机Cooling water pump 冷却水泵Cooling tower 冷却塔Coordinate COORD 协调Coordinate boiler follow mode 协调的锅炉跟随方式Coordinate control system 协调控制系统Coordinate turbine follow mode 协调的汽机跟随方式Copy 拷贝Core 铁心、核心、磁心Core loss 铁（芯损）耗Corner 角落Correction 修正、改正Corrosion 腐蚀Cost 价格、成本、费用Cost of fuel 燃料费用Cost of upkeep 日常费用、维护费用Coupler 联轴器Coupling 耦合、联轴Couple CPL 联轴器Crane 起重机Critical 临界的Critical speed 临界速度Crusher 碎渣机Current transformer CT 电流互感器Cube 立方（体）Cubicle illumination 箱内照明Curdle 凝固Current 电流、当前Cursor 光标Curve 曲线Custom 习惯、海关Custom keys 用户键Cutter 切削工具Cyanic 青色、深蓝色Cycle 循环、周期、周波Cymometer 频率表Cyclome classifier 旋风分离器Cylinder CYL 汽缸DDaily load curve 日负荷曲线Daily load 日负荷Damage 损坏、破坏Damper DMPR 阻尼器、挡板Danger 危险、危险物Dank 潮湿Danger zone 危险区Data 数据Data base 数据库Data acquisition system DAS 数据采集系统Data highway 数据高速公路Date 日期Data pool 数据库Dc lub oil pump 直流润滑油泵Dead band 死区Deaerator DEA/DEAE/DEAER 除氧器Decimeter 分米Decrease DEC 减少Deep 深度、深的、深Default 默认、缺席Degree 度、等级Demand 要求、查问Delay 延迟Delay time 延时Delete 删除Demineralized water 除盐水Demineralizer 除盐装置Deposit 沉积结垢Desalt 除盐设备Description 说明、描述Destination 目标、目的地Desuperheater 减温器Desuperheater water DSH WTE 减温水Detail 细节Detect 发现、检定Deviate 偏离、偏差Device 设备、仪器Diagnosis 诊断Diagram 图形、图表Diagram directory 图目录Diagram number 图形号Diameter 直径Diaphragm 膜片、隔板Dielectric 介质、绝缘的Diesel generator 柴油发电机Difference 差异、差别、差额Differential protection 差动保护Diff press 差压Diff expansion DIFF EXP 胀差Differential pressure DP/DSP 差压Digital 数字的Digital electric hydraulic 电调Digital input/output 数字量输入／输出Digital-to-analog D/A 数／模转换Dioxde 二氧化碳Direct current DC 直流（电）Direct digital control DDC 直接数字控制Disassembly 拆卸Disaster 事故、故障Disc 叶轮Disaster shutdown 事故停机Discharge 排除、放电、卸载Discharge current 放电电流、泄漏电流Disconnector 隔离器、隔离开关Disconnect switch 隔离开关Discrete input/output 离散输入／输出Disk 磁盘Disk manage commands 磁盘管理命令Dispatch 调度、发送派遣Dispatcher 调度员Dispatching station 调度站（局）Disconnector 隔离器、隔离开关Discrete input/output 离散输入／输出Disk 磁盘Displacement 位移Displacement pump 活塞泵Display 显示、列屏Distance 距离Distilled water DISTL WTR 蒸馏水Distributed 分布\分配\配电（水、汽）Distributed control system DCS 集散控制系统Distributed processing unit DPU 分布处理单元Distributing board 配电盘Distribution network 配电网络Distribution substation 二次变电站Disturbance 扰动Diverter vlv 切换线Divided by 除以Design 设计、发明Division 分界、部门Division wall 分割屏Documentation 文件Door 门Dosing pump 加药泵Dowel pin 定位销Down pipe 下降管Download 下载Downtime 停机时间Dozer 推土机Draft 通风、草图Drain DRN 疏水、排放Drain pump 疏水泵Drain tank 疏水箱Drawing 图样、牵引Drill 钻孔、钻头、钻床Drive 驱动、强迫Drn collector 疏水收集器Drop 站Drowned pump 潜水泵Drum 汽包Drum-type boiled 汽包式锅炉Dry 干、干燥Dual 双重的Duct 风道、管道Dust 灰尘Dust helmet 防尘罩Dust catcher 除尘器、吸尘器Duty 责任Dynamic 动态的Dynamometer 功率表EEarth 大地Earth fault 接地故障Earth connector 接地线、接地Earth lead 接地线、接地Eccentricity 偏心、扰度Econ recirc vlv 省煤器再循环线Economizer ECON 省煤器Edit 编辑Efficiency 效率Eject pump 射水泵Ejection 射出Ejector 抽气器Electric 电的Elbow 弯管、弯头Electric-hydraulic control 电／液控制Electrical 电的、电气的Electrical lockout solenoid vlv 电磁阀锁阀Electrical machine 电机Electrical service 供电Electric power industry 电力工业Electrode 电极Electric power company 电力公司Electric power system 电力系统Electronic 电子的、电子学的Electrotechnics 电工学、电工技术Electrostaic precipitator 静电除尘器Electrostatic 静电的Element 元件、零件、单元Elevation ELEV 标高Elevator 升降机Ellipse 椭圆Emergency decree 安规Emerg lub oil 事故润滑油Emerg off 事故停／关闭Emerg seal oil 事故密封油Emergency EMERG 紧急事故Emergency drain 事故疏水Emergency governet／intercepter 危急遮断器Employee 雇员Empty 排空Enclosure 外壳、包围End 末端、终结End cover 端盖Energize 激励、加电Energy 能、能量Energy meter 电度表Energy source 能源Engineer keyboard 工程师键盘Engineer station 工程师站Engineer's console 工程师操作站Engineering 工程Enter 开始、使进入Entry 输入Equalizer valve 平衡线Equipment 设备Erase 删除Error 错误Escape valve 安全线Evaporate 蒸发、冷化Evaporating 蒸发量Event 事件Excess 超过、过度Excess combustion air 过剩燃烧空气Excitation 励磁Exciter 励磁机Exhaust EXH 排汽Exhaust portion 排汽段Exit 出口Expansion EXP 膨胀Expansion tank 扩容箱Expenditure 费用Expert 专家、能手Explosion 爆炸Exponent 指数幂External 外部的、表面的Extinguisher 灭火器Extinguishing medium 灭弧介质Extraction check valve EXTR CHK VLV 抽汽逆止阀Extra-high voltage 超高压Extend 扩展、延伸Exteral 外部的、表面的Extr press 抽汽压力Extr temp 抽汽温度Extraction EXTR 抽汽FFactor 因素、因数Fahrenheit 华式温标Failure FAIL 失败FALSE 假的、错误的Fan 风扇、风机Fan duty 风机负荷Fast cut back FCB 快速切回Fault 故障Faulty operation 误操作Features 特点Feed 馈、供给Feedback 反馈Feed forward 前馈Feed water 给水Feed-water makeup 补给水Fiber optic 光纤Field 磁场、现场Field operator 现场运行人员Figure 数字、图案File 文件Filter 滤网、过滤器Filter differential pressure FILTR DP 滤网压差Final 最后的Final super-heater FSH 末级过热器、高过Fine ash silo 细灰库Fire 燃烧、火焰Fire-proof 耐火的、防火的Fire-extinguisher 灭火器Fire-hose 消防水带Fire hydrant 消防栓Fire-fight 灭火Fireproof 防火的、阻燃的Fire pump 消防水泵First stage 第一级、首级First stage guide vane 第一级导叶Flame 火焰Flame check 火检Flame detect cable FLM DET CAB 火检电缆Flange 法兰Flange joint 法兰结合面Flank 侧翼、侧面Flash 闪光、闪烁、闪蒸Flash lamp 闪光灯Flash light 闪光Flasher 闪光装置Flexible 灵活的、柔性的Flexible joint 弹性联接器Flip-flop 触发器、双稳态电路Float-charge 浮充电Floppy disk 软磁盘Floppy driver 磁盘机Flow 流量、流动Flowmeter 流量计Flue 烟道Format 形式、格式Flue gas 烟气Fluid 液体Fly ash 飞灰Follow 跟随Forbid 禁止Force 强制Force circulation 强制循环Force draft fan 送风机Forney 福尼（公司）Forward 向前Free end 自由端Frequency 频率From 从、来自Front 前面的Fuel 燃料Fuel safety 燃料保护Full speed 额定频率Fully 充分的、完全的Function 功能Function group 功能组Furnace 炉膛Fuse 保险丝、熔断器Fuse holder 保险盒Fusible cutout 熔断开关Fw bypass 给水旁路GGAIN 增益Gang 班、组Gas 气体、烟气Gate 闸门Gate damper 闸门式挡板Gateway 入口、途径Gauge 仪表、标准Gauge float 水位、指示、浮标Gear 齿轮Gear pump 齿轮泵Gear shift housing 变速箱Gen main breaker 发电机出口总开关General control panel 总控制屏General vlv 总阀Generate 引起、产生Generator 发电机、发生器Gland 密封套Gland heater GLAND HTR 轴封加热器Gland seal 轴封Glass-paper 砂纸Goal 目的、目标Go on 继续Govern vlv GV 调速器、调节器Graphics 调节阀Grease 图形Green 绿色Grid 高压输电网、铅板Grid system 电网系统Gross rating 总出力、总额定值Ground/earth 地、大地Group 组、群Group library 组库HHalt instruction 停机指令Hangers 悬吊管Hardware 硬件Hardness 硬度、困难的Hazardous 危险的、冒险的Header 联箱Heat 热、加热Heater 加热器Heating 加热Heat rate 热效率Heat soak 暖机Hertz HZ 赫兹Hesitate HESI 暂停、犹豫High 高的、高等的、高大的High pressure HP 高压High pressure heater HPH 高压加热器History 历史Historical date reporter HDR 历史数据报告Historical storage & retrieval unit HSR 历史数据报告存储与检索单元Hold 保持Home 家、处所Hopper 漏斗、料斗Hori vib(vibration) 水平振动Horizontal 水平的、横式Horse power 马力Hose 软管、水龙带Hot 热的Hot air 热风Hot rh 再热（器）热段Hot start 热态启动Hot well 热水井Hour 小时Hp cyl cross pipe 高压缸短管Hp turb exh press 高压缸排汽压力Hybrid 混合物Hydraulic 液压Hydrogen 氢（H）Hydrogen purity 氢气纯度Hydrobin/ dewatering bin 脱水仓IIdiostaic 同电位的Idle 空载的、无效的Ignition light oil 轻油点火Ignition 引燃、电火Ignitor 电火器Ignore 忽视Illustrate 说明Impeller 推进器、叶轮Impedance 阻抗Import 进口、引入Impulse 脉冲、冲击、冲量Inch IN 英寸Inching 缓动、点动Income 进线Increase INC 增加Index 索引、指示Indicator 指示器Individual 单个的、独立的Inductive reactance 感抗Input/output I/O 输入／输出Induced draft fan IDF 引风机Inductance 电感Induction motor 异步电动机Industrial water 工业水Industry 工业Inflatable seal 充气密封Inhibit 禁止Initial 最初的Inlet 入口Input group 输入组Insert 插入Inside 内侧、内部Inspection 观察、检查Install 安装Inspection hole 检查孔、人孔Installed capacity 装机容量Instantaneous 即时的、瞬时的Instantaneous power 瞬时功率Instruction 说明书、指南、指导Instrument 仪器Instrument panel 仪表盘Insulate 绝缘、绝热、隔离Insulator 绝缘子Intake 输入端、进线Integer 整数Integral 积分Intensity 强度Interpole 换向板Inter-stage extraction 中间抽头Interface 接口Interference 干扰、干涉Interlock 联锁Intermediate 中间的Internal 内部的Interrogation 质问、问号Interrupt 中断Interval 间隔Interlock auto on 联锁投自动Inverter 逆变器、反向器、非门Invoice INV 发票、发货单、托运Intermediate pressure IP 中压Intermediate relay 中间继电器Invalid 无效的、有病的Investment 投资Ion-exchange 离子交换器IP.cyl 中压缸Isolation 隔离Isolator 隔离、刀闸JJacking oil 顶轴油Jacking pump 顶轴泵Job 工作Jumper 跳线、跨接Junction box 接线盒KKey 键销、钥匙、键槽Keyboard 键盘Key library 键库Key switch 键开关Kilovolt-ampere KV A 千伏安Kink 弯曲、缠绕Knack 技巧、窍门、诀窍Knife-switch 闸刀开关LLabel 标号、标签Laboratory 实验室Labyrinth seal 迷宫密封Ladder 梯子、阶梯Ladder diagram 梯形图Lamp 灯、光源Large platen LARGE PLT 大屏Last 最后的Latch 止动销、挂闸、插锁Leak 泄漏（动词）Leakage 泄漏（名词）Left 左Length 长度Level 液位、水平Lifebelt 安全带、保险带Lift 提、升Light 光亮、点、点燃、照亮Lightning 雷电Light run 空转Lightning arrestor 避雷器Limit LMT 极限、限制Limiter 限制器、限位开关Line 线、直线Line impedance 线路阻抗Lining 衬层、内衬Linkage 连杆List 列表Liter 公升Ljungstrom trisector air preheaters 容克式空预器Load 负荷Load demand compute LDC 负荷指令计算Load impedance 负荷阻抗Load limit 负荷限制Load rejection 甩负荷Load shedding 甩负荷Loading 加负荷Load thrown on 带负荷Local 局部Local attendant 现场值班员Local repair 现场检修Local start 就地启动Local stop 就地停止Location 处所、位置Lock 闭锁、密封舱、固定Logger 记录器、拖车Logic 逻辑Long 长Loop 环、回路Loss 损失、减少Loss of excitation 励磁损失Loss of phase 失相Low 低Low press LP 低压Low press heater LPH 低压加热器Low-half 下半Lower 较低的、降低Lower heating value 低位发热量Low pressure cylinder LPC/LP CYL 低压缸Low temperature superheater LT SH 低温过热器Lub oil 润滑油Lub oil pump 润滑油泵Lubricate LUB 润滑MMagenta 品红色Magnet 磁Main 主要的/主蒸汽的/电力网Main oil tank 主油箱Main screen 主屏Main steam 主蒸汽Main transformer 主变压器Maintenance 维护、检修、小修Maintenance manual 检修手册Major overhaul 大修Make up 补充（补给）Makers works 制造厂Malfunction 出错、误动、失灵Management 管理、控制、处理Manhole 人孔、检查孔、出入孔Manifold 各式各样的联箱、集气管Manometer 压力表Man-machine interaction 人机对话Manual 手动、手册Manual reject MRE 手动切换Manual/Auto station M/A STATION 手动／自动切换站Mark 型号、刻度、标志、特征Mass memory 大容量存储器Master 主要、控制者Master control room 主控室、中央控制室Master fuel trip MFT 主燃料跳闸Maximum 最高的、最大Maximum continue rate MCR 最大连续率Mechanocaloric 热机的Mean 平均值、中间的Mean water level 平均水位Measure 量度、测量Mechanical 机械的、力学的Mechanical trip vlv 机械跳闸阀Mechanism 机械、力学、方法Medial 中间的、平均的Mediate 间接的、调解Medium 装置、介质、工质Megawatt 兆瓦Memory 存储Metal 金属Meter 集量器、仪表、米Meter switch 仪表开关Method 方法、规律、程序Method of operation 运行方式Mica 云母Mica dielectric 云母电介质Microcallipers 千分尺Microphone 麦克风、话筒Middle MID 中间的Middle-temperature rh MT RH 中温再热器Mill 磨、磨煤机、铣刀Minimum 最小的Minor overhaul 小修Minus 减、负号Minus phase 负相位Minute 分钟Miss operation 误动作、误操作Miss trip 拒跳闸Mistake 错误、事故Mixed bed 混床Mixture 混合物Man-machine interface MMI 人机接口Modem 调制解调器Modify 修改Modulating control 调节控制Modulating valve 调节阀Module 模件Moisture 湿度、湿汽Monitor 监视器、监视Monoxide 一氧化物Month 目Motor MTR 马达Motor control center MCC 马达控制中心Motor winding 电动机组绕组Mouldproof 防霉的Mount 安装、固定Mountain cork 石棉Mouse 鼠标Move 移动Multidrop 多站Multispeed 多速Mult-multi 多、多倍Multimeter 万用表Multiplication 乘Multivibrator 多谐振荡器NName 名、名字Natural 自然的Naught line 零线Needlepoint vlv 针阀Negative 负的Negative pressure NEG PRESS 负压Neon tester 试电表Net ratine/net output 净出力Network 网络Neutral line 中性线Neutral 中性的Neutral point 中性点Next 其次的Night shift 夜班Nipper 钳子、镊子Noise 噪音No-loading 空载Nominal 标称的、额定的Nominal power 额定功率Nominal rating 标称出力、额定出力Non-return vlv 逆止线Non-work 非工作的Normal 正常的、常规的Normal closed contact 常闭触点Normal makeup wtr 正常补水Not available 无效、不能用No touch relay 无触点继电器Non-work pad / n-work pad 非工作瓦Nozzle 喷嘴Number 数字、号码、数目Number of turns 匝数Nut 螺母、螺帽OOccur 发生Odd 奇数Office 办公室Oil 油Oil breaker 油开关Oiler 注油器Oil fuel trip OFT 油燃料跳闸Oil gun 油枪Oil immersed natural cooling 油浸自然冷却Oil purifier 油净化装置On-line 在线、联机的On-load test 带负荷试验On/off 开／关Onset 开始、发作Open 开、打开Open-air 露天的、开启的Open-loop 开环Open work 户外作业Operating panel 操作盘Operation 操作、运行Operational log 运行记录Operator 操作员Operator keyboard 操作员键盘Operator station 操作员站Operator's alarm console 操作员报警台Optimal 最优的、最佳的Optimal value 最佳值Optional 可选的Option switch 选择开关Orifice plate 孔板Original 初始的、原始的Oscillator 振荡器Oscilloscope 示波器Out 出、出口Outage 停用Out-of-service 为投入运行的Outlet 出口Output 产量、产品、输出Output group 输出组Outside 外边、外面Over current 过流Over load 过负荷Overload protection 过载保护Overall design 总体设计Over voltage 过压Overflow 溢流Overflow vlv station 溢流阀门站Overhaul 大修Overhaul life 大修间隙Overhead 顶部Overhead line 架空线Override 超越Overspeed 超速Overspeed trip 超速跳闸Overview 概述、总述Own demand 厂用电量Oxide film 氧化膜、氧化层Oxygen 氧PPackage 组件、包Packed group 组合组Pad 瓦、衬垫Page 页Panel 屏、盘Parameter 参数Part 部分、部件Part per million PPM 百万分率Password 口令Path 路线Peak 峰值Peak load 峰值负荷Pendant 悬吊Pendant pull switch 拉线开关Penthouse 顶棚Penumatics 汽动装置Percent PCT 百分数Percentage 百分比Perfect 完全的、理想的Perfect combustion 完全燃烧Performance 完成、执行、性能Performance calculation 性能计算Performance curve 性能曲线Periodic 周期的、循环的Periodic inspection 定期检查Peripheral 周围的Peripheral equipment 外围设备Permanent 永久的、持久的Permanent magnetic generator 永磁发电机Permit 允许Permit to work 允许开工Petrol 汽油Phase PH 阶段、状态、方面、相Phase angle 相角Phase-failure protection 断相保护Phase not together 缺相、失相Phase sequence 相序Phase-in 同步Piezometer 压力计Pitch coal 烟煤Pid drawing 流程图Pilot 导向、辅助的、控制的Pilot bearing 导向轴承Pipe 管、管道Pitch 投、掷、节距、螺距Plan 计划Plant 工场、车间Plant load factor 电厂负荷因数Plastics 塑料Platen 台板、屏式Platen superheater PLT SH 屏式过热器Plug 塞子、栓、插头Plug socket 插座Plunger 柱塞、滑阀Plunger pump 柱塞泵Plus 加Plyers 钳子、老虎钳Pneumatic 气动的Point 点Point database 测点数据库Point directory 测点目录Point name 测点名Point record 测点记录Point field 泡克区Phase voltage 相电压Pole 机、柱Policher 除盐装置Pollution 污染Pop valve 安全阀、突开阀Portion 一部分Position POS 位置Positive 确定的、正的、阳性的Potable water 饮用水Potential transformer PT 电压互感器Pound LB 磅Power PWR 功率、电源Power factor 功率因子Power plant 电厂Pre-alarm 预报警Precipitator PRECI/PRECIP 除尘器Preheat 预热Pre light 预点火Preliminary 准备工作Present 出现Preset 预设、预置Pressure PRES 压力Primary 初级的、一次的Primary air 一次风Primary air fan PAF 一次风机Primary superheater 低温过热器Primary grid substation 主网变电站Prime 首要的Printer 打印机Principle 原理、原则Priority 优先级、优点Probe 探头Process 过程、方法Processing time 处理时间Program 程序Programmable 可编程的Programmable logical controller PLC 可编程逻辑控制器Prohibit 禁止Proportional / integral / derivative PID 比例／积分／微分Protection PROT 保护Protection bolt 危急遮断器飞锤Protection ring 危急遮断器飞环Protocol 规约（数据通信）Potential transformer PT 电压互感器Psig 磅／平方英寸（表压力）Psia 磅/平方英寸(绝对压力)Puffer breaker 压力式断路器Pulse 脉冲、脉动Pulverizer PULV 磨煤机Pump 泵Punch 冲床、冲压机Purge 净化、吹扫Purifier 净化器Purify 纯度Purpose 目的、用途Push and pull switch 推拉开关Push button 按钮Put into operation 投入运行Pyod 热电偶Pyrology 热工学QQ-line Q线Quad 回芯组线Quality 质量Quartz 石英、水晶Query 询问、查询Quick 快Quicksilver 水银、汞Quick open 快开Quit 停止、离开、推出RRack earth 机壳接地Radial 径向的、半径的Radication 开方Radiator wall rh 壁式再热器Radiator 散热（辐射）器Radiation fin 散热片Raise 升高Range 范围、量程Rap 敲打Rap device （除尘器）振打装置Rapid charge 快速充电Rated 额定的、比率的Rated conditions 额定条件Rated power 额定功率Ratio 比率Raw material 原材料Ray 光线、射线Reactance 电抗、反作用Reactive capacity 无功容量Reactive power 无功功率Read out 读出、结果传达Ready 准备好Real power 有效功率Real time 实时的Rear 后面Recall 重新调用、重查Receive tank 回收箱、接收箱Recipe 处方、配方Recire/Recycle damper 再循环挡板Recirculate 再循环Reclaim 再生回收Reclosing 重合闸Recommend 介绍、建议Recording 记录、录音、唱片Recovery 恢复、再生Recovery time 恢复时间Rectification 整流、检波、调整Rectifier 整流器Red 红色Reduction 还原、缩小、降低Redundancy 冗余、多余Reference REF 参考、参照、证明书Reflux 倒流、回流Region 地域、领域Register 寄存器Regulate 调节、控制Regulating stage 调节级Regulating valve 调节阀Reheater RH 再热器Relative REL 相对的Relative expansion 相对膨胀Relay 继电器Relay panel 继电器屏Release 释放Reliability 可*的、安全的Relief 去载、卸载、释放、解除Relieve valve 安全阀、减压阀Remote 遥远的、远方的Remote select 遥控选择Remote technical center RTC 遥控技术中心Renewal 更新、更换Repair 修理Repairer 修理工、检修工Repeat 重复、反复Replacement parts 备件、替换零件Request REO 请求Require 要求Reserve parts 备件Reserved 备用的Reset 复位Resistance 阻力、电阻Resonate 谐振、调谐Response 响应Responsibility 责任Retract 可伸缩的、缩回Retractable thermoprobe 可伸缩的温度探头Retrieval 可检索的、可追忆的Return 返回Return oil 回油Reverse power 逆功率Reverse rotation 反转Review 检查Rig 安装、装配、调整Right 右Right-of-way 公用线路Ring 环Roller 辊子Roof 顶、炉顶Root 跟Rotary switch 转换开关Rotating 旋转Rotating joint 液压联轴器Rotor 转子Routine 例行的、日常的Routing inspection 日常检查、日常检测Routing maintenance 日常维护Run 运行Run back 返回Rundown 迫降Running conditions 运行情况Running current 工作电流Running in 试运行、试转Running/operation overhaul 临时检修SSafe 安全的、可*的、稳定的Safe potential 安全电压Safety 安全Safety cap 安全帽Safety measure 安全措施Safety rules 安全规程Safety valve 安全线Sample 取样、举例Sampler 取样器Saturate 饱和Saturate condition 饱和条件、饱和状态Saturated steam SAT STM 饱和蒸汽Scale 铁锈水垢Scan 扫描Schedule 时间表、计划表Schematic 图解的、简图Scoop 勺管Scr controller 屏幕控制器Screen 屏幕Screw 螺杆、螺丝Screwdriver 螺丝刀Scroll 滚屏Sea 海Seal 密封Seal air 密封风Sealing gland 密封盖Seal oil 密封油Seal steam SEAL STM 密封蒸汽Search 寻找、查找Seawater 海水Second 秒、第二Second air SEC AIR 二次风Secondary 二次的Seep 渗出、渗漏Seepage 渗漏现象Select 选择Self 自己、自我、本人Self-hold 自保持Self-running 自启动Sensor 传感器Sensitive 灵敏器Sensitiveness 灵敏性Separator 分离器Sequence 顺序、序列Sequence of emergence SOE 事故追忆Sequential control system SCS 顺序控制系统Series-longitudinal layout 串联纵向布置Service 服务、伺服Service power 厂用电Servomotor 伺服电机Set 设定Setpoint 设定点Set up 安装、调整、建立Severity 刚度、硬度、严重Sewage treatment 废水处理Shadow 影子、屏蔽Shaft 轴、烟囱Shaft seal 轴封Shake 摇动、振动Shakeproof 防振Shaft 轴、手柄、矿井Shaped 形状Share 共享、分配Share memory 共享存储器Sheet 表格、纸张Shell 壳Shield 屏蔽层Shift 值、替换Shift charge engineer 值班工程师Shoe 推力瓦Shortage of water 缺水Short circuit 短路Shot 发射、冲击、钢粒Shunt reactor 并联电抗器Shut off 关闭Shutdown 停止、停机Siccative 干燥剂Side 侧边Sidewall 侧墙Sifter 筛子、滤波器Signal 信号Signal lamp 信号等Sign 标记、注册Significance 意义、有效Silence 消音、沉寂Silicon SI 硅Silicon stack 硅堆Silo 灰库Single 单个的、个体的Station interface module SLM 站接口模件Simple 单纯的、简单的Similar 同样的、类似的Simulator 仿真机Single blade switch 单刀开关Sinusoid 正弦曲线Site 现场Site commissioning test 现场投运方式Size 尺寸、大小Size of memory 存储量Sketch 图纸、草图Skin effect 集肤效应Skip 空指令、跳跃Slag 结垢Sliding key 滑销Sliding press mode 消压方式Sluiceway 水沟Slurry 灰浆Smoke 烟、冒烟Smokes-stack 烟囱Smooth 平滑的、光滑的Socket 插座Soft 软的、柔软的Software 软件Solenoid SOLN 螺线圈Solid 固体Sootblower 吹灰、吹灰器Sound detection 声音探测Source 源、电源Spanner 扳手Spare 备用的、空余的Spare parts 备件、备品Specification 技术说明Specific weight 比重Speed 速度Speed protection 超速保护Spray 喷射Spray nozzle 喷嘴Spray water 喷水Spring 弹簧、春天Spring clutch 弹簧离合器Square 广场、方的Squirrel-cage armature 鼠笼式电枢Stabiliser 稳定器Stability 稳定（性）Stack 烟囱Staff 职工Stage 级、台Stall 停车、阻止Standard 标准Standby 备用、待机Standby heat 热备用Star 星、星形连接Star connected system 星形连接制"Y" Start 启动、开始Starting conditions 启动条件Start up 启动Start-up sequence 启动程序State 状态Statement 说明、语句Static 静电Static storage 静态存储器Station 站、发电厂、地点Station capacity 发电厂容量Station interface unit SLU 站接口单元Stator 静子Stator coil 定子线圈Stator core 定子铁芯Status 状态Status display 状态显示Steadiness 稳定性Steam STM 蒸汽Steam cylinder 汽缸Steam exhaust 乏气、废气Steam feed pump 汽动给水泵Steam-turbine generator 汽轮发电机Step 步Step-by-step motor 步进电动机Step ladder 阶梯Step-down transformer 降压变压器Step-up transformer 升压变压器Stere 立方米Stockyard 储煤场Stop 停止Stop vlv 主汽线Storage 储存Storage battery 蓄电池Storage tank 储存箱Straight 直的、直线Strainer 滤网Stress 应力、强调Styrofoam 泡沫塑料。

电气工程常用名词中英文对照表Part1：缩写全称中文AC alternating current 交流电AC automatic control 自动控制ACA accident consequence assessment 事故后果评价ACB air circuit breaker 空气断路器ACC accident 故障、事故ACCUM accumulate accumulate 累计、蓄电池ACDS acourtic crack detection system 声裂纹检测系统ACT/S active side 带电部件、有功部件ACW anti-clockwise 反时针方向ACW anti-clockwise 反时针方向AD analog-digital 模拟-数字AEOD analysis and evaluation of operational data 运行数据分析和管理AFC automatic frequency control automatic following control 自动频率控制：自动跟踪控制AI artificial intelligence 人工智能ALT alternate 交变的、交替的ALTNTR alternator 同步发电机AM ammeter 电流表AMP ampere 安培AN air natural cooled 空气自然冷却AOC automatic overload control 自动过载控制APC automatic plant coordinate control automatic power control 机组自动协调控制：自动功率控制APP appendix auxiliary power plant 附录：辅助电源设备APS acessory power supply 辅助电源APU auxiliary power unit 辅助动力装置：辅助电源设备ARM armature 电枢、衔铁ASR automatic speed run up 自动升速ASU automatic synchronizing unit 自动同步系统AT auxiliary transformer 辅助变压器AUS auxiliary switch 辅助开关AUX auxiliany 辅助、备用A VL automatic voltage control 自动电压控制A VR automatic voltage regulator 自动调压器BAT battery 电池BD block decrease 闭锁减BDUC bus duct 母线导管、母线沟BDV blowdown voltage 击穿电压BF back feed 反馈BHP brake horse power 制动马力BI block increase 闭锁增BKR breaker 断路器BOS back-out system 补偿系统BOT build-operate-tranfer 建造-运行-移交BR brush 电刷、刷子BRKG breaking 断开BYC battery charger 电池充电器CA compressed air 压缩空气CAOS completely automatic operate system 全自动操作系统CAP capactty 电容、出力、容量CAP capacity 容量、功率CATS computer-aided trouble-shooting 计算机辅助故障查寻CB control buton circuit breaker circuit board 控制钮：线路断路器：电路板CBL line circuit breaker 线路断路器CC charactevistic curve 特性曲线CCW counter-clockwise 反时针CD control desk 控制台CEMF cownta electromotive force 反电动势CG center of gravity 重心CHGR charger 充电器CKT circuit 电路、线路CKW clockwise 顺时针方向CL center line 中心线CLSG closing 关闭、合闸CMR continuous maxinum rating 连续最大功率CNDN condition 工况、参数CO con-out 关闭、切断COEF coefficient 系数CONST constans construction 常数：构造、结构CONT contact control 接点：调节、控制CP control panel 控制板CPD capacitor potential device 电容器分压器CRT cathode-ray tube 阴极射线管CRT circuit 回路CS controlled switch controll signal 控制开关：控制信号CT current transformer 电流互感器CW clockwise 顺时针方向CY cycle 循环、周期DB distribution box 配电箱DBMS data base management system 数据库管理系统DC direct current 直流电DCAS data collection and analysis system 数据收集分析系统DE digital equipment display equipment 数字元件：显示设备DELIV deliver 供给、供电/输出DG diesel generator 柴油发电机DG diesel generator 柴油发电机DHP delivered horse power 输出功率DI data input 数据输入DISC disconnect 断开DISC SW disconnect swtich 隔离开关DISTR diatribution 分散、分配、配电DL data line 数据传输线DMM digital multimeter 数字万用表DMS data management system 数据管理系统DO diesel oil 柴油DO digital output 数字输入DOS dosing 量DPDT double-pole double-throw 双刀双掷开关DPST double-pole sigle-throw 双刀单掷开关DSCH discharge 放电DSL diesel 柴油机DSL line desconnect switch 隔离开关DT dawn time 故障停机时间DTS data transimission 数据传输系统DYNA dynamic analysis 动态分析E.U engineering units 工程单位E/P electrical to pneumatic converter 电动气动转换器EAF equivalent available factor 等效可运系数ECR economical continuous rating 经济连续出力EE electrical engineer 电气工程师EFF efficiency 效率EFFT effective 有效的EHV extra-high voltage 超高压ELEC electric 电气的EMER emergency 紧急、事故EMER emergency 事故保安EMF inductive electromotive force 感应电动势EMLON emergency condition 事故状态EMP eletromechanical power 机电功率EMS emergency switch 紧急开关、事故按钮ENCL enclose 封闭、包围ENER energize 励磁、使带电ENERD energized 已励磁的、已带电的ENG engage 发动机EP extreme power 极限功率ESD emergency shutdown 事故停机ESS essential service system 主要厂用系统ETS electrical trip solenoid 电气跳闸线圈EXC exciter 励磁机、励磁EXD external device 外部设备EY voltage transducer 电压变送器FB fuse block 保险盒FC fast closing 快关F-F flip-flop 触发器FL full load 满负荷FLF flip-flop 触发器FME frequency measuring equipment 频率计FP full power 满功率FREQ frequency 频率FU fuse 保险丝、熔断器FWR full-wave rectifier 全波整流器Part2：缩写全称中文GEN generator 发电机GIS gas-insulated metal-enclosed switch gear 全封闭组合电器GPT generator potential transformer 发电机电压互感器GRD ground 接地GRD FLT ground fault 接地故障GT grounding transformer 接地变压器HC holding coil 保持线圈HF high frequency 高频HG harmonic generator 谐波发生器HIPOT high potential test 高电压实验HLDG holding 保持HP horse power 马力HS hand switch 手动开关HT high tension 高压HTN high tension 高电压HV high voltage 高电压HV high voltage high velocity 高压：高速HVDC high voltage direct current transmission system 高压直流输电系统HVPC high voltage power supply 高电压源I/O input/output 输入/输出IC integrated circuit input circuit 集成电路：输入电路ICL incoming line 引入线IMP impedance 阻抗IMPLS impulse 脉冲、冲动INDN induction 感应INIT initial 启动、励磁INITD initiated 已励磁的、已启动的INSUL insulate 绝缘、隔热INTMT intermediate 间断的、间歇的INVR inverter 逆变器、反相器ISLN isolation 隔离开关ISOL isolation 隔离的、绝缘的JY watt transduce 有功变送器K kilo 千KW kilowatt 千瓦KWH kilowatt-hour 度L electrical power line 电线LA lightening arrester 避雷器LC load centre 负荷中心LC load center 负荷中心LDS line disconnecting switch 线路隔离开关、线路断路器LN line 线路LOC local 就地LPC linear power controller 线性功率放大器LR line relay 线性继电器LSIC large scale integrated circuit 大规模集成电路LV low voltage 低电压MAG magnet 磁铁/磁场的MAN manual 手动的MC manual control magnet contactor 人工控制：磁铁开关MCB molded case circuit breaker 模板式断路器MCC motor control centre 马达控制中心MCC motor control center 马达控制中心MCR main control room maxium capacity rating maxium continuous rating 主控室：最大额定出力：最大连续出力MDS motor disconnect switch 马达隔离开关MG motor generator 电动发电机ML mechanical loss 机械损失MNXFMR main transformor 主变压器MO motor 马达MOD motor operated disconnect 电动断开MPR motor protrelay 电机保护继电器MSTR motor starter 马达启动器MWE megawatt electric 兆瓦电MWH megawatt-hour 兆瓦小时NADVD not advanced 滞后NEG negative 阴极的、负的NET network 网络NEUT neutral 中性的NGT neutral groundong transformer 中性点接地变压器NL noload 空载、无负荷NOM nominal 额定的NRP normal rated power 额定功率O&R overhaul and repair 大小修OA operator auto mode 运行人员监控下的自动控制运行方式OL motor overload device 电机过负荷装置OP output power operating procedure 输出功率：运行规程OPER operating 操作OR operating record 停运记录OVHL overhaul 大修P.O. power output 功率输出P.U. per unit 标幺值PA power amplifier 功率放大器PAMS post-accident montoring instrumentation 事故后监测仪表PB push button 按钮开关PC power center 动力中心PCB power circuit breaker 功率继电器PCC power conditioning and control 电力调节与控制PCM pulse-code modulation 脉冲编码调制PD potenial difference power driven 电位差：电动的PE power equipment 发电综合控制PF power factor indicator 功率因数PFI power factor indicator 功率因数表PGCC power generation control complex 相位PH phase 功率输入PI power input 峰值负荷PK peak 峰值PL plate 板、极板PL peak load 峰值负荷PLD payload 有效负载PM phase midulation 调相PO power operator 电动操作POH planned outage hours 计划停运小时POOH planned overhaul outage hours 计划大修停运小时POS positive 正的、正极的POS position 位置POT potential transformer 电势、电位计PP peak power 峰值功率PPS plant protective system primary protection system 电厂保护系统：一次保护系统PS power station power supply power system 电站：电源：电力系统PSS power support stabilizer 电力系统稳定器PT potential transformer 电压互感器PT potential transformer 电压互感器PT pressure transducer 压力变送器PWR power 功率Q transistor 晶体管QA quick acting 快速动作QMQB quick-make quick-break 快通快断R rate rotor ratio 速率：转子：比率系数RA remote auto 远程自动RAM repair and maintenance 检修与维护RB run back 甩负荷RD run down 降负荷RF reserve free 备用ROT rate of turn reserve oil tank 转动速度：备用油箱RP rated power 额定功率RPM revolution per minute 转/分RPS revolution per second 转/秒RS resistor 电阻器RSV reserve 备用RTD resistance temperature device 电阻测量计RU run up 升负荷RU run up 升负荷Part3：缩写全称中文S/C short circuit 短路SC short circuit 短路SC semi-conductor 半导体SCR silicon-controlled rectifier 可控硅整流器SECT sectional 等级、分级SEN sensor 传感元件、传感器SERV service 工作、厂用SG standby generator 备用发电机SO shut-off 停机、遮断SOE sequence of events 事故顺序记录SOH scheduled outage hours 计划停机时间SOV solenoid -operated valve 电磁阀SP single pole spare 单极：备用SPC system power control 系统电源控制SPDT single-pole double-throw 单刀双掷SR speed reguletor standard rating silicon rectifier 调速器：额定容量：硅整流器SS station service 厂用SS stopping switch 停机开关SST station service transformer 厂用变压器ST starter startup transformer 启动器：启动变压器STA stationary 固定的STAT stator 定子STBY standby 备用STBY stand by 备用STR reserve station service transformer 厂用备用变压器SUBSTA substation 变点站SUPL supervisory 供电、电源SUR surge 冲击、波动SV solenoid valve 电磁阀、滑阀SW switch 开关SW switch 开关、手把SW short wave switch 短波：开关SWBD switchboard 配电SWBD switchboard 开关板、配电盘SWC surge withstand capability 冲击电压承受能力SWGR switchyard 配电装置SWYD switchyard 开关场SY synchroscope 同步指示器SYM symmetrical system 对称系统SYNC synchronize 使---同步SYNCG synchronizing 同步SYNSCP synchroscope 同步指示器SYS system 系统SYST system 系统T&D transimission and distribution 输电与配电T&M testing and maintenance electrical trip and monitoring 实验与维修：电电气跳闸与监视系统TACH tachometer 转速表TASS technique assembly 装配工艺TB therminal board 端子板、终端板TBO time between overhaul 大修间隔TC thermocouple 热电偶TD time delay 延时TD technique data time delay 技术数据：时滞、延时TDC time delay closing 延时闭合TDD time delay on deenerization 延时失励TDE time delay energization 延时激励TDO time delay opening 延时打开TE thermoelectric test equipment 热电的：测试设备TH thermal element 热电偶、热偶元件TIS test instrumentation system thermal insulation system 测试仪表系统：绝缘系统TL total loss total load time limit 总损失：总负荷：时间限制TM time monitor 时间监视器TOT total 总共TP test point time pulse 实验点、测试点：时间脉冲TPDT triple-pole double-throw 三刀双掷开关TR test run transducer 试运行：变送器TRANS transport 运输TRC transmission and reception controller 传输及接收控制器TRIAC triode altermating current switch 三极管交流开关TRU transmit-receive unit 发送接收装置TSI turbine supervisory instrument 汽轮机监视仪表TVM transistor voltmeter 晶体管电压表U unit 机组UAT unit auxiliary transformer 厂用变压器UDF unit derating factor 机组降低出力系数UDG unit derating generation 机组降低出力少发电量UDH unit derating hours 机组降低出力小时UERS unusual event recording system 异常事故记录系统UNDH unit derating hours 机组降低出力小时UNIV universal 通用UNLD unloading 无载的、空载的UO unit operator 机组操作员UOF unplanned outage factor 非计划停运系数UOH unplanned outage hour 非计划停运小时UOR unplanned outage rate 非计划停运率UPS uninterrupted power supply 不停电电源URT unit run time 设备运行时间UST unit station service transformer 厂用变压器UV under voltage 电压不足、低电压UV 电压监察V AR variable 变量V ARHM garhour meter 无功电度表VC variable capacitor voltage comparator 可变电容:电压比较器VCB vacuum circuit breaker 真空断路器VCT voltage current transformer 电压电流互感器VENT ventilator 通风VF vriable frequency 可变频率VOLTREG voltage regularor 电压调节器VR variable resistor voltage regulator 可变电阻：稳压器VT vibration testing 振动实验VT voltage time to breakdown 击穿电压时间VTVM vacuum-tube voltmeter 真空管电压表W/O without 没有WDG winding 绕组、线圈WH watt-hour 瓦特小时WHM watthour meter 有功电度表WTR water 水WV working voltage 工作电压WZJ 绝缘监察XDCR transducer 变送器XFER transfer 转换XFMR transfoormer 变压器XMSN transmission 输电XMTR transmitter 变送器XS transfer switch 转换开关YD yard 工作场。

本文由mo_tse01贡献pdf文档可能在WAP端浏览体验不佳。

建议您优先选择TXT，或下载源文件到本机查看。

电气术语中英文对照表 - 电路的基本概念及定律电源 source 电压源 voltage source 电流源 current source 理想电压源 ideal voltage source 理想电流源 ideal current source 伏安特性 volt-ampere characteristic 电动势electromotive force 电压voltage 电流current 电位potential 电位差potential difference 欧姆 Ohm 伏特 Volt 安培 Ampere 瓦特 Watt 焦耳 Joule 电路circuit 电路元件 circuit element 电阻 resistance 电阻器 resistor 电感 inductance 电感器 inductor 电容 capacitance 电容器 capacitor 电路模型 circuit model 参考方向 reference direction 参考电位 reference potential 欧姆定律 Ohm’s law 基尔霍夫定律 Kirchhoff’s law 基尔霍夫电压定律 Kirchhoff’s voltage law（KVL）基尔霍夫电流定律 Kirchhoff’s current law（KCL）结点 node 支路 branch 回路 loop 网孔 mesh 支路电流法 branch current analysis 网孔电流法 mesh current analysis 结点电位法 node voltage analysis 电源变换 source transformations 叠加原理 superposition theorem 网络 network无源二端网络 passive two-terminal network 有源二端网络 active two-terminal network 戴维宁定理 Thevenin’s theorem 诺顿定理 Norton’s theorem 开路（断路）open circuit 短路 short circuit 开路电压 open-circuit voltage 短路电流 short-circuit current电气术语中英文对照表 - 交流电路直流电路 direct current circuit (dc) 交流电路 alternating current circuit (ac) 正弦交流电路 sinusoidal a-c circuit 平均值 average value 有效值 effective value 均方根值 root-mean-squire value (rms) 瞬时值 instantaneous value 电抗 reactance 感抗inductive reactance 容抗capacitive reactance 法拉Farad 亨利Henry 阻抗impedance 复数阻抗 complex impedance 相位 phase 初相位 initial phase 相位差 phase difference 相位领先 phase lead 相位落后 phase lag 倒相，反相 phase inversion 频率frequency 角频率 angular frequency 赫兹 Hertz 相量 phasor 相量图 phasor diagram 有功功率 active power 无功功率 reactive power 视在功率 apparent power 功率因数power factor 功率因数补偿 power-factor compensation串联谐振 series resonance 并联谐振 parallel resonance 谐振频率 resonance frequency 频率特性 frequency characteristic 幅频特性 amplitude-frequency response characteristic 相频特性 phase-frequency response characteristic 截止频率 cutoff frequency 品质因数 quality factor 通频带 pass-band 带宽 bandwidth (BW) 滤波器filter 一阶滤波器 first-order filter 二阶滤波器 second-order filter 低通滤波器low-pass filter 高通滤波器 high-pass filter 带通滤波器 band-pass filter 带阻滤波器 band-stop filter 转移函数 transfer function 波特图 Bode diagram 傅立叶级数Fourier series电气术语中英文对照表 - 三相电路三相电路three-phase circuit 三相电源three-phase source 对称三相电源symmetrical three-phase source 对称三相负载 symmetrical three-phase load 相电压phase voltage 相电流 phase current 线电压 line voltage 线电流 line current 三相三线制 three-phase three-wire system 三相四线制 three-phase four-wire system 三相功率 three-phase power 星形连接 star connection(Y-connection) 三角形连接 triangular connection(- connection ,delta connection) 中线 neutral line 电路的暂态过程分析编辑本段回目录暂态 transient state 稳态 steady state 暂态过程，暂态响应 transient response 换路定理 low of switch 一阶电路 first-order circuit三要素法 three-factor method 时间常数 time constant 积分电路 integrating circuit 微分电路differentiating circuit 磁路与变压器编辑本段回目录磁场magnetic field 磁通 flux 磁路 magnetic circuit 磁感应强度 flux density 磁通势magnetomotive force 磁阻 reluctance 电动机编辑本段回目录直流电动机 dc motor 交流电动机 ac motor 异步电动机 asynchronous motor 同步电动机 synchronous motor 三相异步电动机 three-phase asynchronous motor 单相异步电动机 single-phase asynchronous motor 旋转磁场 rotating magnetic field 定子 stator 转子 rotor 转差率 slip 起动电流 starting current 起动转矩 starting torque 额定电压 rated voltage 额定电流rated current 额定功率 rated power 机械特性 mechanical characteristic 继电器电气术语中英文对照表 - 继电器-接触器控制按钮 button 熔断器 fuse 开关 switch 行程开关 travel switch 继电器 relay 接触器 contactor 常开(动合)触点 normally open contact 常闭(动断)触点 normally closed contact 时间继电器 time relay热继电器 thermal overload relay 中间继电器 intermediate relay 可编程控制器（PLC）可编程控制器 programmable logic controller 语句表 statement list 梯形图ladder diagram电气术语中英文对照表 - 半导体器件本征半导体 intrinsic semiconductor 掺杂半导体 doped semiconductor P 型半导体P-type semiconductor N 型半导体 N--type semiconductor 自由电子 free electron 空穴hole 载流子 carriers PN 结 PN junction 扩散 diffusion 漂移 drift 二极管 diode 硅二极管 silicon diode 锗二极管 germanium diode 阳极 anode 阴极 cathode 发光二极管light-emitting diode (LED) 光电二极管 photodiode 稳压二极管 Zener diode 晶体管（三极管） transistor PNP 型晶体管 PNP transistor NPN 型晶体管 NPN transistor 发射极emitter 集电极 collector 基极 base 电流放大系数 current amplification coefficient 场效应管 field-effect transistor (FET) P 沟道 p-channel N 沟道 n-channel 结型场效应管 junction FET（JFET）金属氧化物半导体 metal-oxide semiconductor (MOS) 耗尽型MOS 场效应管 depletion mode MOSFET（D-MOSFET）增强型 MOS 场效应管 enhancement mode MOSFET（E-MOSFET）源极 source 栅极 grid 漏极 drain 跨导 transconductance 夹断电压 pinch-off voltage 热敏电阻 thermistor 开路 open 短路 shorted 基本放大器放大器 amplifier 正向偏置 forward bias 反向偏置 backward bias 静态工作点 quiescent point (Q-point) 等效电路 equivalent circuit 电压放大倍数 voltage gain 总的电压放大倍数 overall voltage gain 饱和saturation 截止cut-off 放大区amplifier region 饱和区saturation region 截止区cut-off region 失真distortion 饱和失真saturation distortion 截止失真cut-off distortion 零点漂移zero drift 正反馈positive feedback 负反馈 negative feedback 串联负反馈 series negative feedback 并联负反馈parallel negative feedback 共射极放大器common-emitter amplifier 射极跟随器emitter-follower 共源极放大器 common-source amplifier 共漏极放大器 common-drain amplifier 多级放大器 multistage amplifier 阻容耦合放大器 resistance-capacitance coupled amplifier 直接耦合放大器direct- coupled amplifier 输入电阻input resistance 输出电阻 output resistance 负载电阻 load resistance 动态电阻 dynamic resistance 负载电流 load current 旁路电容 bypass capacitor 耦合电容 coupledcapacitor 直流通路 direct current path交流通路 alternating current path 直流分量 direct current component 交流分量alternating current component 变阻器（电位器）rheostat 电阻（器）resistor 电阻（值）resistance 电容（器）capacitor 电容（量）capacitance 电感（器，线圈）inductor 电感（量），感应系数 inductance 正弦电压 sinusoidal voltage 集成运算放大器及应用差动放大器 differential amplifier 运算放大器 operational amplifier(op-amp) 失调电压offset voltage 失调电流offset current 共模信号common-mode signal 差模信号different-mode signal 共模抑制比common-mode rejection ratio (CMRR) 积分电路integrator（circuit）微分电路 differentiator（circuit）有源滤波器 active filter 低通滤波器 low-pass filter 高通滤波器 high-pass filter 带通滤波器 band-pass filter 带阻滤波器 band-stop filter 波特沃斯滤波器 Butterworth filter 切比雪夫滤波器 Chebyshev filter 贝塞尔滤波器 Bessel filter 截止频率 cut-off frequency 上限截止频率 upper cut-off frequency 下限截止频率 lower cut-off frequency 中心频率center frequency 带宽 Bandwidth 开环增益 open-loop gain 闭环增益 closed-loop gain 共模增益 common-mode gain 输入阻抗 input impedance 电压跟随器 voltage-follower 电压源 voltage source 电流源 current source 单位增益带宽 unity-gain bandwidth 频率响应 frequency response 频响特性（曲线）response characteristic波特图 the Bode plot 稳定性 stability 补偿 compensation 比较器 comparator 迟滞比较器hysteresis comparator 阶跃输入电压step input voltage 仪表放大器instrumentation amplifier 隔离放大器 isolation amplifier 对数放大器 log amplifier 反对数放大器 antilog amplifier 反馈通道 feedback path 反向漏电流 reverse leakage current 相位 phase 相移 phase shift 锁相环 phase-locked loop(PLL) 锁相环相位监测器 PLL phase detector 和频 sum frequency 差频 difference frequency 波形发生电路振荡器 oscillator RC 振荡器 RC oscillator LC 振荡器 LC oscillator 正弦波振荡器sinusoidal oscillator 三角波发生器 triangular wave generator 方波发生器 square wave generator 幅度 magnitude 电平 level 饱和输出电平（电压） saturated output level电气术语中英文对照表 - 功率放大器功率放大器 power amplifier 交越失真 cross-over distortion 甲类功率放大器class A power amplifier 乙类推挽功率放大器 class B push-pull power amplifier OTL 功率放大器output transformerless power amplifier OCL 功率放大器output capacitorless power amplifier电气术语中英文对照表 - 直流稳压电源半波整流 full-wave rectifier全波整流 half-wave rectifier 电感滤波器 inductor filter 电容滤波器 capacitor filter 串联型稳压电源series (voltage) regulator 开关型稳压电源switching (voltage) regulator 集成稳压器 IC (voltage) regulator电气术语中英文对照表 - 晶闸管及可控整流电路晶闸管 thyristor 单结晶体管 unijunction transistor（UJT）可控整流 controlled rectifier 可控硅 silicon-controlled rectifier 峰点 peak point 谷点 valley point 控制角 controlling angle 导通角 turn-on angle电气术语中英文对照表 - 门电路与逻辑代数二进制 binary 二进制数 binary number 十进制 decimal 十六进制 hexadecimal 二-十进制 binary coded decimal （BCD）门电路 gate 三态门 tri-state gate 与门 AND gate或门 OR gate 非门 NOT gate 与非门 NAND gate 或非门 NOR gate 异或门 exclusive-OR gate 反相器 inverter 布尔代数 Boolean algebra 真值表 truth table 卡诺图 the Karnaugh map 逻辑函数 logic function 逻辑表达式 logic expression 电气术语中英文对照表 - 组合逻辑电路组合逻辑电路 combination logic circuit 译码器 decoder 编码器 coder 比较器comparator 半加器 half-adder 全加器 full-adder 七段显示器 seven-segment display 电气术语中英文对照表电气术语中英文对照表 - 时序逻辑电路时序逻辑电路 sequential logic circuit R-S 触发器 R-S flip-flop D 触发器 D flip-flop J-K 触发器 J-K flip-flop 主从型触发器 master-slave flip-flop 置位 set 复位 reset 直接置位端 direct-set terminal 直接复位端 direct-reset terminal 寄存器register 移位寄存器 shift register 双向移位寄存器 bidirectional shift register 计数器 counter 同步计数器 synchronous counter 异步计数器 asynchronous counter 加法计数器 adding counter 减法计数器 subtracting counter 定时器 timer 清除（清 0）clear 载入 load 时钟脉冲 clock pulse 触发脉冲 trigger pulse 上升沿 positive edge 下降沿negative edge 时序图 timing diagram 波形图 waveform电气术语中英文对照表 - 脉冲波形的产生与整形稳态触发器 monostable flip-flop双稳态触发器 bistable flip-flop 无稳态振荡器 astable oscillator 晶体 crystal 555 定时器 555 timer电气术语中英文对照表 - 模拟信号与数字信号的相互转换模拟信号 analog signal 数字信号 digital signal AD 转换器 analog -digital converter (ADC) DA 转换器 digital-analog converter (DAC)电气术语中英文对照表 - 半导体存储器只读存储器 read-only memory（ROM）随机存取存储器 random-access memory（RAM）可编程 ROM programmable ROM（PROM）1。

AAbnormal异常Accuracy精度ACSR = aluminum conductor steel reinforced钢芯钻铰线adjustment 调整adjustable range可调范围fine adjustment细调rough adjustment粗调air gap气隙alarm 报警alarm bell警铃alarming window报警窗口ampacity载流量ampere安培kilovolt ampere千伏安amperemeter安培表，电流表amplifier放大器announciator报警器anode阳极anti-corrosion防腐蚀anti-pumping device防跳装置AOL = aircraft obstruction lamp航空障碍灯low intensity AOL低光强航空障碍灯high intensity AOL高光强航空障碍灯AQR = automatic reactive power regulator自动无功功率调整器arcing chamber灭弧室armature电枢ASS = automatic synchronizing system 自动同期系统asynchronous 非同期non-asynchronous capability非同期能力Bballast镇流器ballast-factor镇流器系数ball eyes 球头挂环battery蓄电池Cd-Ni battery镉-镍蓄电池lead-acid battery铅-酸蓄电池maintenance free battery 免维护蓄电池battery capacity蓄电池容量battery rack电池架battery room蓄电池室end battery端电池BIL = basic insulation level绝缘基本冲击耐压水平blocking diode闭锁二极管box 盒，箱cast aluminum junction box铸铅接线盒cast Ferro alloy junction box铸铁合金接线盒junction box接线盒lead box出线箱maintenance box检修箱marshalling box(总配线箱)power supply box动力箱terminal box端子箱test box试验盒normal lighting box 工作照明箱breaker 断路器close the breaker 合断路器open the breaker打开断路器breaker compartment 断路小室PT circuit broken PT回路断线brush 刷graphite brush石墨碳刷brush holder刷握brush supporter刷架brushless excitation system无刷励磁系统bus 母线branch bus分支母线by-pass bus 旁母main bus 主母线bus tie母联flexible busbar 软母线hard busbar硬母线miniature busbar 小母线tubular busbar管型母线changeover busbars倒母线bushing 套管oil filled bushing充油套管seal-off bushing密封套管wall bushing穿墙套管bushing lead terminal套管端子button 钮子push button 按钮self-holding push-button 自保持按钮turn button旋钮buzzer蜂鸣器Ccabinet 柜control cabinet控制柜distribution cabinet 配电柜cable 电缆3 cores cable三芯电缆armoured cable铠装电缆coaxial cable同轴电缆control cable控制电缆copper wire braid shield cable铜编织线屏蔽电缆fiber-optical cable光纤电缆fire resistant cable耐火电缆flame retardant cable阻燃（难燃）电缆heat tracing cable伴热电缆heating cable加热电缆heating sensitive cable热敏电缆high voltage oil-filled cable高压充油电缆impregnated paper insulated cable油浸纸绝缘电缆lead covered cable铅皮电缆mineral insulated cable无机绝缘电缆overhead cable架空电缆power cable动力电缆signal cable信号电缆stranded copper cable铜铰线电缆telephone cable电话电缆triple-core cable 三芯电缆twin-core cable 两芯电缆unarmoured cable 非铠装电缆communication cable 通讯电缆single-core cable单芯电缆tag of cable 电缆标牌cable clip 电缆夹flexible cable conduit 电缆软管cable conduit 电缆管cable head 电缆头cable laying 电缆敷设cable laying & list 电缆敷设及清册cable mezzanine 电缆夹层cable raceway system 电缆通道系统cable rack 电缆支架cable shaft 电缆竖井cable support 电缆支架cable suspender 电缆吊架cable terminal 电缆终端头cable tray 电缆桥架cable trench 电缆沟cable tunnel电缆隧道cable vault 电缆夹层control cable with copper tape shield 铜带屏蔽的控制电缆call 呼叫call back 回叫call signal呼叫信号external calling 外部呼叫internal calling 内部呼叫calling 主叫detail calling record 呼叫详细记录candle power distribution curve 配光曲线capability 能力out-of-phase breaking capability 失步开断能力pressure relief capability 压力释放能力rated closing capability 额定关合能力short-line fault breaking capability近区故障开断能力transient overvoltage capability 暂态过电压能力capability of switching long no-load line 分合长空载线路能力capability of switching no-load transformer 分合空载变压器能力capacitance 电容adjustable capacitor 可变电容器shunt capacitor 并联电容器voltage sharing capacitor 均压电容器capacitor 电容器capacitor divider 电容分压器capacity 能量,容量current carrying capacity 载流能量spare capacity 备用容量cavity ratio 室腔比cell jar 电瓶chain link 挂环changeover 切换automatic changeover 自动切换star-delta changing device 星角切换装置charge 充电equalizing charge 均衡冲电float charge 浮充电fully charged 全充charger 充电器boost charging voltage 大充电压initial charging voltage 起始充电电压check phase order核对相序circuit 电路，回路auxiliary circuit 辅助回路follow-up circuit 跟踪回路main circuit 主电路short circuit plate 短路板spare circuit(feeder)备用回路series circuit 串联电路circuit breaker 断路器air circuit breaker 空气断路器bus tie circuit breaker 母联断路器by-pass bus circuit breaker 旁路断路器current-limiting circuit breaker 限流断路器earth leakage circuit breaker 漏电开关field circuit breaker 磁场开关oil circuit breaker 油断路器residual current circuit breaker 漏电开关sectionalized circuit breaker 分段断路器SF6 gas insulated circuit breaker 六氟化硫断路器frame-type circuit breaker 框架式断路器clamp 线夹strain clamp耐张线夹suspension clamp 悬垂线夹clearance 带电距离clip 线夹quick clip 快速线夹closing 合闸open phase closing of breaker 非全相合闸closing pulse 合闸脉冲coil 绕组arc-suppression coil 消弧线圈armature coil 电枢绕组holding coil 保持线圈redundant trip coil 双跳闸线圈reset coil 复归线圈shunt excitation coil 分励线圈trip coil 跳闸线圈combined 综合combined filter 综合滤波器combined starter 综合起动器commission 调试communication 通信communication building 通信楼communication line 通信线communication monitoring 通信监听dispatching communication system 调度通信系统intra-plant communication system 厂内通信系统wireline communication system 有线通信系统component 分量fundamental component 基波分量harmonic component 谐波分量conductor 导体high conductivity 高导电率composite conductor 组合导线flexible conductor 伸缩节flexible conductor 软导线conductor cross-section 导体截面conform to 符合connection 连接，接线double bus connection 双母线接线open-delta connection 开口三角形连接star connection 星形连接zigzag connection 曲折形连接1 and 1/2 circuit breaker connection 1个半断路器接线connection pin 连接端子connection plate 联接片double bus connection with bypass 双母线带旁路接线end connector 终端接头power connector 电源接头removable connector 可拆接头oil conservator 油枕contact 触头arcing contact 弧触头arcing-extinguishing contact 灭弧触头common alarm contact 公用报警接点electrical independent contact 无源接点main contact 主触头moving contact 动触头normally closed contact 常闭接点normally opened contact 常开接点stationary contact 静触头auxiliary contact 辅助触头contactor 接触器electromagnetic pneumatic contactor 电磁气动接触器vacuum contactor真空接触器electromagnetic contactor 电磁接触器between open contacts 断口间continuous duty (service) 连续运行continuous rating 连续额定值control 控制automatic control 自动控制centralized control 集中控制local control 就地控制one-to-one control 一对一控制photoelectric control 光电控制器remote control 远方控制control circuit 控制回路electrical auxiliary control panel 电气辅助控制屏mosaic surface control panel马赛克控制屏network control room 网控室cool 使冷却hydrogen inner cooled 氢内冷water cooled 水冷却natural cooling 自冷式forced air cooling system 强迫风冷系统copper bus-bar 铜母线core limb 铁芯柱corona 电晕corona-proof cover防晕罩correcting circuit 校正电路correction factor 校正系数COS = change-over switch 切换开关CP = candle power 烛光creepage distance 爬距crest 峰，峰值crest voltage 峰值电压CS = control switch 控制开关CT = current transformer 电流互感器burden of CT CT的二次容量zero sequence CT 零序CTCU = coefficient of utilization 利用系数current电流capacitive current 电容电流dynamic stable current 动稳定电流field current 磁场电流impressed current 外加电流inductive current 电感电流interrupting current 开断电流leakage current 泄漏电流line-charging current 线路充电电流making current 关合电流momentary current 瞬时电流negative sequence current 负序电流no-load current 空载电流nominal discharge current 标称放电电流peak withstand current 峰值耐受电流rated breaking current 额定开断电流rated short time current 额定短时耐受电流reactive current 感性电流short circuit current 短路电流starting current 起动电流stray current 泄漏电流rated continuous current 额定持续电流zero sequence current 零序电流current amplification 电流放大current collector 集电器current converter 变流器current intensity 电流强度secondary current of CT CT的二次电流current shunt 分流器phase current 相电流DDC system 直流系统de-energized equipment 不带电设备definite time lag 定时限deformation 变形dehydrating breather 吸湿器delay 延时long time delay 长延时short time delay 短延时delta connection 三角形连接depth of embedded grounding wire 接地线埋深derating factor 降容系数diagram 图图纸CWD =control wiring diagram 控制接线图EWD =elementary wiring diagram 原理接线图mimic diagram 模拟图one-line diagram 单线图dial 拔号diameter 直径direct dialling 直拨directly burying 直埋敷设discharge 放电deep discharge 过放电intercept lightning discharge 截取雷电流self discharge 自放电discharge counter 放电计数器discharge final voltage 放电未期电压disconnection 解列busbar disconnection 母线解列system disconnection 系统解列system disconnection and field extinction 解列灭磁dispatcher 调度员distortion factor 畸变系数diversity factor 分散系数document 文件double column 双柱DP = drip-proof 防滴型draw-out carriage 抽出式小车dust proof type 防尘型Eearthing 接地earthing rod 接地极earthing terminal 接地端子efficiency 效率electric 电气electric braking 电气制动electric welding machine 电焊机electrical life 电气寿命electricity engineering 电气工程electrode pole 电极electrolyte 电解液electromagnet 电磁铁electromagnetic induction 电磁感应electromotance 电动势electronic element 电子元件emergency bell 事故铃energy 能，能量forced line energization 线路强送电successful forced line energization 线路强送电成功trial line energization 线路试送电enter the cubic from the top 柜顶进线enter the cubicle from the bottom 柜底进线excitation 励磁reducing excitation 减励磁force excitation 强励low excitation 低励磁over excitation 过励磁excitation cubicle 励磁柜excitation current 励磁电流force excitation factor 强励系数excitation initiating equipment 起励设备static excitation system 静态励磁系统excitation system response ratio励磁系统响应比excitation transformer 励磁变压器excitation voltage 励磁电压exciter 励磁机main exciter 主励磁机pilot exciter 副励磁机standby exciter 备用励磁机expansion join 伸缩节expected life 期望寿命explosion-proof type 防爆型Ffailure alarming signal 事故报警信号fault 故障grounding fault 接地故障fault recollecting and recording device 事故追忆记录装置fault recorder 故障记录F-C = high-voltage current limiting fuse and vacuum contactor 高压限流熔断器及真空接触器feeder 馈线incoming feeder 进线outgoing feeder 出线feeder bay馈线间隔field 磁场field extinction 灭磁field flashing equipment起励设备field voltage 磁场电压fire 火fire proof blockage 防火堵料fire proof limit耐火极限fire proof partition 耐火隔板fire protection pillows 阻火包fire retardant coating 阻燃涂料single face exit sign fixture 单面出口标志灯flexible joint 挠性接头FOA = forced oil air cooled 强油风冷foot candle ( F.C ) 英尺-烛光forced outage 强迫停机frequency频率frequency converter station 变频站fuse 熔断器no powder-filled cartridge fuse无填料封闭管式熔断器plug-in type fuse 插入式熔断器powder-filled cartridge fuse 有填料封闭管式熔断器screw-type fuse螺旋式熔断器self-mending fuse 自复熔断器fast acting fuse 快速熔断器fuse blow熔断器熔断Ggalvanic protection system 牺牲阳极保护系统galvanized steel镀锌钢gap 间隙protective gap 保护间隙gapless metaloxide type 无间隙金属氧化型generator 发电机direct current generator 直流发电机dual inner water cooled generator 双水内冷发电机signal generator 信号发生器water-hydrogen-hydrogen cooling generator 水-氢-氢冷发电机generator hydrogen cooling system 发电机氢冷却系统generator load curve发电机负荷曲线generator pedestal发电机基座generator rotor发电机转子generator sealing oil system 发电机密封油系统generator stator 发电机定子generator terminal 发电机端子generator terminal lead 发电机引出线generator termination room 发电机出线小室generator water cooling system 发电机水冷却系统generator-transformer extension unit 发变组扩大单元generator-transformer unit 发电机变压器组GIS = gas insulated switchgear 全封闭组合电器Glare眩光glass cloth tape 波纤带grading ring 均压环、屏蔽环ground pad 接地端子groundbed 接地床anode groundbed 阳极接地床distributed-type groundbed 分散型接地床impressed current groundbed 泄漏电流接地床directly (solid) grounded 直接接地effectively grounded 有效接地un- grounded 不接地grounded through resistor 通过电阻接地grounding 接地single-phase grounding 单相接地grounding conductor 接地导体grounding megger 接地电阻测试仪main grounding network (grid)主接地网grounding system 接地系统grounding terminal 接地端子grounding wire 接地线guarantee 保证Hharmonics 谐波even harmonic 偶次谐波odd harmonic 奇次谐波heater 加热器self limiting parallel heater 自限制式并联加热器heating element 加热元件hertz (Hz) 赫兹high 高high pressure sodium ( HPS ) 高压钠灯high voltage transmission line 高压线路high-frequency amplification 高频放大high-frequency filter 高频滤波器hot-dipped galvanized 热镀锌Iidentification 识别igniter触发器illuminance 照度impedance 阻抗asymmetrical impedance 不对称阻抗negative-sequence impedance 负序阻抗positive-sequence impedance 正序阻抗zero sequence impedance 零序阻抗impressed current cathodic protection 外加电流阴极保护indicator 指示器indoor type 户内式initial 首次initial power transmission 首次送电initial synchronization 首次并网input 输入instrumentation测量仪表insulation 绝缘epoxy resin insulation 环氧树脂绝缘insulating strength绝缘强度layer insulation 层间绝缘4 - 8 电气专业mica insulation 云母绝缘plastic insulation 塑料绝缘section insulation 段间绝缘turn insulation 匝绝缘insulation between phase 相间绝缘insulation class 绝缘等级insulation level 绝缘水平porcelain insulator 瓷质绝缘子post insulator 柱式绝缘子supporting insulator支撑绝缘子suspending insulator 悬挂式绝缘子tension insulator 耐张绝缘子insulator绝缘子interlock 联锁inverse time lag反时限inverter 逆变器IPB = isolated phase bus duct 离相封闭母线Jtesting jack 试验端子Kkilovar (kVAR) 千乏kilovolt 千伏kilowatt (kW) 千瓦kilowatt-hour 千瓦时Llagging phase 滞后相lamp 灯left（right）arrow lamp 单面出口标志灯portable lamp 行灯mercury lamp 水银灯metal halide lamp 金属卤化物灯high intensity discharge lamp 高强气体放电灯fluorescent lamp荧光灯incandescent lamp 白炽灯self-ballasted lamp自镇流灯tungsten halogen lamp碘钨灯projection lamp 投光灯lamp socket 灯座layer-to-layer 层间LDD = luminaire dirt depreciation 照明器污秽减光系数leading phase 超前相down- light 筒灯light source (illuminant)光源flood lighting泛光照明local lighting 局步照明emergency lighting 应急灯lighting box 照明箱emergency lighting box 事故照明箱double-faced plate lighting fixture 双块板灯flush mounted fluorescent lighting fixture嵌入式荧光灯tube fluorescent lighting fixture 简式荧光灯anticorrosive, dust-proof and water-resistant lighting fixture三防灯具wrap-around fluorescent lighting fixture 全密封荧光灯garden lighting fixture 庭院灯waterproof fluorescent lighting fixture 防水荧光灯flameproof fluorescent lighting fixture 防爆耐火荧光灯road lighting fixture路灯lighting fixture 灯具lightning 雷电tube type lightning arrester 管形避雷器valve type lightning arrester 阀型避雷器lightning arrester避雷器lightning current 雷电流lightning protection 防雷lightning recorder 雷电记录器lightning rod避雷针4 - 9 电气专业lightning strike 雷击lightning wave front shape雷电波头形状lightning wire避雷线live line connection带电接线live line disconnection 带电拆线LLD = lamp lumen depreciation 光通量衰减系数Load 负荷target load 目标负荷load characteristic curve负载特性曲线load rejection甩负荷locked rotor current 转子堵转电流locked rotor torque 转子锁定转矩looping-off 解环loss 损耗copper loss 铜损iron loss 铁损load loss 负载损耗no-load loss空载损耗supplementary load loss附加损耗loss-ratio 损耗比louver 格栅louver all ceiling 大面积发光天棚lug 接线片ring lug 环型接线片spade lug 铲型接线片terminal lug 接线端子lumen 流明background luminance 背景亮度luminaries 照明器effective luminous intensity 有效光强LX = lux 勒克司Mmagnetic lock 电磁锁maintenance 维护malfunction 误动作manhole 人孔marking strip 标识条MCB = miniature circuit breaker 微型断路器MCCB = moulded case circuit breaker 塑壳式断路器mechanical life 机械寿命megawatt (MW) 兆瓦metal clad 金属铠装meter 表计gravity meter 比重计insulation supervision meter 绝缘监察表kVAR-hour meter 无功电度表kW-hour meter 有功电度表phase meter 相位表plier-type current meter钳型表power factor meter 功率因数表secondary meter 二次表计single-phase kilowatt-hour meter 单相电能表three-phase kilowatt-hour meter 三相电能表voltage meter 电压表watt-hour meter 电度表MF = maintenance factor维护系数MHF = mounting height above the floor 距地面安装高度MHWP = mounting height above the work-place 距工作面安装高度milliammeter 毫安表millivoltmeter 毫伏表mimic bus 模拟母线mis-operation 误操作MOC = mechanism operated cell switch 机构操作式开关motor 电动机adjustable speed motor调速电动机commutator motor整流子电动机governor motor 调速电动机horizontal type motor卧式电动机induction motor 诱导电动机synchronous motor同步电动机variable speed motor 可变速电动机vertical type motor 立式电动机motor maximum torque 电动机最大转矩mounted 镶嵌，安装standing pole mounted 立杆安装4 - 10 电气专业ceiling mounted嵌入顶棚handrail mounted 扶手安装open mounted 明装wall mounted 吸壁flush mounted 暗装pendant mounted 悬挂stanchion mounted 柱上安装surface mounted 吸顶安装mounting type 安装方式movable type 移动式Nnameplate 铭牌negative pole 负极neutral point 中性点normal 正常NPB = non-segregated phase bus duct 共箱母线Oohm 欧姆OHM = ohmmeter 欧姆表oil level indicator 油位指示器OLTC = on-load tap-changer 有载分接开关open circuit characteristic curve 开路特牲曲线operate 操作operated in single phase 分相操作operated in three phase 三相操作operating duty cycle 操作顺序hydraulic operating mechanism 液压操作机构pneumatic operating mechanism 气动操作机构spring stored-energy operating mechanism 弹簧贮能操作机构operating mechanism 操作机构operation 运行load limit operation 限负荷运行open phase operation 非全相运行trial operation 试运行pole slip operation 滑差运行operation mode 运行方式oscilloscope 示波器outdoor type 户外式outgoing feeder gantry structure 出线门型架构outgoing line 出线direction of outgoing line 出线方向output 输出shaft output轴功率output increment 增负荷output reduction降负荷overhead line 架空线over-flux 过激磁over-voltage times 过电压倍数oxygen index 氧指数PP.U. value = per unit value标幺值packing instruction 包装说明paging dispatching unit 扩音调度机panel 盘control panel 控制盘side panel 边屏parallel 并联parallel branch 并联支路parameter 参数partial discharge 局部放电periodic duty service定期运行phase 相in-phase 同相phase angle 相角phase sequence 相序phase shifter 移相器phase to ground 相对地phase-angle difference 相角差plug-in unit 插件pole and tower 杆塔pole plate 极板pole-mounting type 柱上式positive pole 正极potential 电位,电势protective potential 保护电位step potential 跨步电压touch potential 接触电压transferred potential 传递电位zero potential 零电位potentio meter 电位计power 功率,能量active power 有功功率apparent power 视载功率electric power 电功率loss of power 失电reactive power 无功功率stand by power 备用电源power factor 功率因数line power flow线路潮流power grid电网auxiliary power ratio 厂用电率AC power source 交流电源DC power source 直流电源power system swing 系统振荡auxiliary power system 厂用电系统power system 电力系统printed wiring board 印刷电路板protection 保护back-up protection 后备保护branch overcurrent protection 分支过流保护busbar protection 母线保护cathodic protection 阴极保护differential protection 差动保护distance protection 距离保护freeze protection 防冻generator main protection 发电机主保护grounding protection 接地保护high-frequency protection 高频保护impedance protection 阻抗保护instantaneous overcurrent protection 速断保护longitudinal differential protection 纵差保护loss-of field protection 失磁保护low frequency protection 低频保护negative-sequence current protection负序电流保护out-of step protection 失步保护over current protection 过流保护over excitation protection 过励磁保护reverse power protection 逆功率保护start-up protection 起动保护thermo-magnetic protection 热磁保护transverse differential protection 横差保护under voltage protection 低电压保护zero-sequence current protection 零序电流保护PT (=potential transformer) balance protection PT断线保护protection level at steep current 陡波冲击保护水平protective zone 保护范围PVC(polyvinyl chloride) insulated cable 聚氯乙烯绝缘电缆Qquality assurance 质量保证quality control 质量控制Rradio 无线电rated 额定rated input 额定输入rated output 额定输出rated value 额定值reactance 电抗capacitive reactance 容抗inductance reactance 感抗subtransient reactance 次暂态电抗synchronous reactance 同步电抗transient reactance 暂态电抗reactive power compensation device 无功补偿装置reactor 电抗器current-limiting reactor 限流电抗器disruptive reactor 分裂电抗器grounding reactor 接地电抗器shunt reactor 并联电抗器receiver 接收机receptacle (socket) 插座receptacle plug 插头re-close 重合闸recording 记录recording duration 记录时间recording instrument 记录仪表rectifier 整流器rectify 整流redial 重拨reflectance factor 反射系数reignite 重燃relative 有关的relay 继电器auxiliary relay 辅助（中间）继电器blocking relay 闭锁继电器Buchholtz relay 瓦斯/压力断电器closing relay 合闸继电器control relay 控制继电器current relay 电流继电器current-limiting relay 限流继电器delayed relay 延时继电器digital type protection relay 数字式继电保护directional relay 方向继电器distance relay 距离继电器flicker relay 闪光继电器lockout relay 出口继电器micro-processor based protective relay 微机继电保护pilot relay 辅助继电器plugging relay 防逆转继电器position relay 位置继电器reclosing relay 重合闸继电器reed relay 舌簧继电器self-starting relay 自启动继电器SIC protection relay 半导体继电保护thermal relay 热继电器time relay 时间继电器tripping relay 跳闸继电器two zone distance relay 两段距离继电器voltage relay 电压继电器voltage-controlled overcurrent relay 电压控制过电流继电器relay 继电器combined protection relay 综合保护继电器protection relay panel 继电保护屏relay protection 继电保护relay station 中继站relevant 相关的repeater 中继器repeater circuit 中继电路repeater group 中继组resistance 电阻high resistance 高阻low resistance 低阻arc suppression resistor 灭弧电阻dynamic braking resistor 制动电阻non-liner resistor 非线性电阻standard resistor 标准电阻starting resistor 起动电阻resistor 电阻器resolution 分辨率rheostat 变阻器slider-type rheostat 滑线式变阻器start rheostat 起动变阻器ripple contain factor 波纹系数RMS = root-mean-square 有效值rotor 转子squirrel-cage type rotor 鼠笼型转子wound type rotor 绕线式转子rotor conductor slot 转子线槽rotor retaining ring 转子护环rotor slip ring 转子滑环rotor winding 转子线圈rubber cushion 橡皮绝缘垫SS/MH = spacing-to-mounting height ratio 距高比sampling frequency 采样频率saturation 饱和saturation factor 饱和系数scanner 扫描器scope 范围scope of supply 供货范围scope of work 工作范围seismic 地震self-holding 自保持sensitivity 灵敏度series 串联serial capacitor compensation device 串联电容补偿装置service level 服务级别setting range 整定范围setting value 整定值SF6 gas leakage detector SF6气体泄漏检测器SF6 gas moisture analyzer SF6气体湿度分析仪SF6 gas reclaiming equipment SF6气体回收设备shade and railing 遮栏sheath 护套inner sheath 内护套outer sheath 外护套shield 屏蔽short circuit 短路three-phase short circuit 三相短路two-phase short circuit 两相短路system short circuit capacity 系统短路容量short circuit characteristic curve 短路特牲曲线short circuit ratio 短路比short time parallel 短期并列signal 信号failure signal 事故信号flash signal 闪光信号status signal 状态信号signal indicator 信号指示器SIL = switching impulse level 操作冲击水平silicon-steel sheet 硅钢片single-phase 单相sinusoid 正弦波slight pressure device 微正压装置soil resistivity 土壤电阻率solid state rectifier 固态整流器solver plated 镀银spacer 间隔棒spare parts 备品备件special tool 专用工具splice 接头factory splice 工厂接头field splice 现场接头SS = select switch 选择开关stabilized power supply device 稳压电源装置starter 起动器full-voltage starter 全电压启动器reduced-voltage starter 降压启动器rotor resistance starter 转子电阻启动器star-delta starter星-三角起动器magnetic starter 磁力起动器stator 定子stator core 定子铁芯stator end cover 定子端盖stator housing 定子外壳stator winding 定子线圈storage 贮存storage battery 蓄电池substation 变电站sub-synchronous resonance 低频共振surge 冲击浪涌surge absorber 过电压吸收装置zinc- oxide surge arrester 氧化锌避雷器surge arrester 避雷器magnetic blow surge arrester 磁吹避雷器SVC = static VAR compensator 静态无功补偿装置switch 开关disconnecting switch 隔离开关double earthing switch 双接地刀electronic switch 电子开关fuse- switch 熔断器式开关grounding (earthing) switch 接地开关iron clad switch 铁壳开关proximity switch 极近开关single earthing switch 单接地刀static transfer switch 静态转换开关voltmeter change-over switch 电压表切换开关switch 开关dimmer switch 调光开关knife switch 刀开关pull switch 拉线开关single pole switch 单极开关switch off 断开switch on 合上switch-fuse 负荷开关switchgear 配电装置in-door switchgear 屋内配电装置out-door type switchgear 户外配电装置day-night switching unit 昼夜开关step-up switchyard 升压站switchyard 开关站symmetrical 对称的synchronization 同期single phase synchro-control 单相同期控制synchronization checking 同期鉴定automatic quasi-synchronization 自动准同期manual quasi-synchronization 手动准同期synchronizing device 同期装置synchronous condenser 调相器synchroscope 同期表system 系统system oscillation 系统振荡Ttap lead 抽头tap position indicator 分接头位置指示器tapping 分接tapping range 分接范围tapping step 分接级全封闭风冷型telecontrol 遥控telemetering 遥测telephon 电话telephon set 电话机automatic exchange telephone 自动交换机dispatching telephone 调度电话机extension telephone 电话分机noise-reducing telephone 抗噪音电话机talking on the telephone 通话video telephone 可视电话telephone booth 电话亭telephone handset 电话听筒teleregulation 遥调telesignalisation 遥信terminal 端子compression terminal 压缩端子compression type terminal 压接型端子terminal block 端子排terminal screw 端子螺钉test 试验AC withstand voltage test 交流耐压试验continuous breaking capability test 连续开断能力试验DC withstand voltage test 直流耐压试验evolving fault breaking test 开断发展性故障试验insulation withstanding test 绝缘耐受试验mechanical performance test 机械性能试验out-of-phase breaking test 失步开断试验parallel breaking test 并联开断试验partial discharge test 局部放电试验performance test 性能试验rain proof test 防雨试验routine test 例行试验routine test 常规试验sealing test 密封试验seismic test 抗震试验short circuit test 短路试验short circuit making and breaking test 短路关合和开断性能试验short-line fault test近区故障试验site test 现场试验standard type test 标准型式试验static test 静态试验switching no-load long line test 分合空载长线试验switching no-load transformer test 分合空载变压器试验switching shunt reactor test 分合并联电抗器试验temperature rise test 温升试验test report 试验报告test voltage 试验电压pen tester 试电笔TEWAC = totally enclosed with water cooled air cooler 全封闭水空冷型thermo-couple 热电偶thermometer 温度计thyristor element 硅整流元件auto-reclosing dead time 自动重合闸无电流时间time 时间breaking time 分闸时间inherent closing time 固有合闸时间inherent opening time 固有分闸时间reclosing time 重合闸时间Max.breaking time 最大全分闸时间time delay de-engergizing 延时释放time delay energizing 延时带电time lead 导前时间tin galvanized 镀锡TOC = truck operated cell switch 小车操作式开关torque 转矩breakdown torque 破坏转矩starting torque 起动转矩torsional stress 扭应力transducer 变送器transformer 变压器auto- transformer 自耦变压器booster transformer 增压变压器busbar straight-through current transformer 母线式电流互感器bushing current transformer 套管式电流互感器core type transformer 芯式变压器coupling-capacitor voltage transformer 耦合电容式电压互感器current transformer 电流互感器dry type transformer 干式变压器isolated transformer隔离变压器lighting transformer 照明变压器low voltage auxiliary transformer 低压厂用变压器low voltage common transformer 低压公用变压器main transformer 主变压器maintenance transformer 检修变压器measuring transformer 测量用互感器oil-immersed type transformer 油浸变压器protecting transformer 保护用互感器PT = potential transformer 电压互感器shell type transformer壳式变压器single-phase transformer 单相变压器split winding type transformer 分裂变压器start-up/stand by transformer 起动/备用变压器step-down transformer 降压变压器step-up transformer 升压变压器three-phase transformer 三相变压器tie transformer 联络变压器transformer 变压器auxiliary building transformer辅助厂房变压器transformer angular displacement 变压器联接组别current transformer calibrating device 电流互感器校验装置transformer cooling system 变压器冷却系统transformer fitted with O.L.T.C (on-load tap-changer)有载调压变压。

电气规范-术语-中英对照.doc备用电源standby electrical source应急电源electric source for safety services导体conductor中性导体neutral conductor(N)保护导体protective conductor(PE)保护接地中性导体protective and neutral conductor(PEN)剩余电流residual current特低电压extra-low voltage(ELV)安全特低电压系统safety extra-low voltage(SELV)system保护特低电压系统protective extra-low voltage(PELV)system外露可导电部分exposed-conductive-part外界可导电部分extraneous-conductive-part 保护接地protective earthing；protective grounding功能接地functional earthing；functional grounding接地故障earth fault；ground fault接地配置earthing arrangement；grounding arrange—ment接地系统(earthing system)接地极earth electrode；ground electrode接地导体earth conductor；earthing conductor；grounding conductor接地网earth—electrode network；ground—electrode network等电位联结equipotendal bonding防雷装置lightning protection system雷电波侵入lightning surge on incoming services雷击电磁脉冲lightning electromagnetic impulse雷电防护区lightning protection zone防护区protection area禁区restricted area盲区blind zone纵深防护longitudinal-depth protection最大声压级maximum sound pressure level 传输频率特性transmission frequency characteristic 传声增益sound transmission gain声场不均匀度sound field nonuniformity建筑设备监控系统building automation system分布计算机系统distributed computer system现场总线fieldbus综合布线系统generic cabling system电磁环境electromagnetic environment电磁兼容性electromagnetic compatibility电磁干扰electromagnetic interference电磁辐射electromagnetic radiation电磁屏蔽electromagnetic shielding电子信息系统electronic information system 阻塞流choked flow流量系数K v flow coefficient管件形状修正系数F p piping correction factor雷诺数修正系数Re v reynokls number factor 舞台监督指挥系统Stage manager control system舞台监视系统stage monitoring (disp1ay) System面光桥fore stage lighting gallery耳光室fore stage side 1ighting台口柱光架lighting tower灯光吊笼lighting (cable) basket天桥侧光fly gallery lighting流动灯光movable lighting灯控室lighting control room声控室sound control room出入口控制系统accesscontrol system(ACS) 目标object目标信息object information钥匙key人员编码识别human coding identification物品编码识别article coding identification人体生物特征信息human body biologic characteristic人体生物特征信息识别human body biologic character-istic identification物品特征信息article characteristic物品特征信息识别article characteristicidentification密钥、密钥量与密钥差异key-code，amount of key-code，difference of key-code钥匙的授权key authorization误识false identification拒认refuse identification识读现场identification locale识读现场设备locale identify equipment防护面protection surface防技术开启能力anti technical opened ability复合识别combination identification防目标重入anti pass-back多重识别控制multi-identification control异地核准控制remote approve control受控区、同级别受控区、高级别受控区controlled area，the same level controlled area，high level controlled area集中式供电centralized power supply mode 分散式供电distributed power supply mode 混合式供电combined power supply mode主变电所high voltage substation牵引降压混合变电所combined substation 杂散电流stray current同步数字传输系统synchronous digital hierarchy transmission system(SDH)全球定位系统global position system(GPS) 列车自动控制automatic train control(ATC) 列车自动监控automatic train supervision(ATS)列车自动防护automatic train protection(ATP)列车自动运行automatic train operation(ATO)调度集中centralized traffic control(CTC)自动人行道moving pavement自动售检票设备automatic fare collection火灾自动报警系统fire alarm system(FAS) 区域报警系统local alarm system集中报警系统remote alarm system环境与设备监控系统building automatic system(BAS)系统集成system integration(SI)运营控制中心operation control center(0CC) 集中监控和管理concentration supervisory control and management净距net distance常用给水泵operation feed water pump工作备用给水泵standby feed water pump事故备用给水泵emergency feed water pump火灾疏散照明lighting for fire evacuation火灾疏散照明灯light for fire evacuation火灾疏散标志灯marking lamp for fire evacuation火灾备用照明reserve lighting for fire risk初始照度initial illuminance使用照度service illuminance维护系数maintenance factor主摄像机main camera辅摄像机auxiliary camera照度均匀度uniformity of illuminance均匀度梯度uniformity gradient色温(度) colour temperature相关色温(度) correlated colour temperature 显色指数ceolour rendering index一般显色指数general colour rendering index 眩光glare眩光指数(眩光值) glare rating应急照明emergency lighting疏散照明escape lighting安全照明safety lighting备用照明stand-by lightingTV应急照明TV emergency lighting障碍照明obstacle lighting。

电气术语中英文对照表 电气术语中英文对照表 — 电路的基本概念及定律 电源 source 电压源 voltage source 电流源 current source 理想电压源 ideal voltage source 理想电流源 ideal current source 伏安特性 volt-ampere characteristic 电动势 electromotive force 电压 voltage 电流 current 电位 potential 电位差 potential difference 欧姆 Ohm 伏特 Volt 安培 Ampere 瓦特 Watt 焦耳 Joule 电路 circuit 电路元件 circuit element 电阻 resistance 电阻器 resistor 电感 inductance 电感器 inductor 电容 capacitance 电容器 capacitor 电路模型 circuit model 参考方向 reference direction 参考电位 reference potential 欧姆定律 Ohm&rsquo；s law 基尔霍夫定律 Kirchhoff＆rsquo;s law 基尔霍夫电压定律 Kirchhoff＆rsquo；s voltage law（KVL) 基尔霍夫电流定律 Kirchhoff＆rsquo；s current law(KCL） 结点 node 支路 branch 回路 loop 网孔 mesh 支路电流法 branch current analysis 网孔电流法 mesh current analysis 结点电位法 node voltage analysis 电源变换 source transformations 叠加原理 superposition theorem 网络 network 无源二端网络 passive two—terminal network 有源二端网络 active two—terminal network 戴维宁定理 Thevenin＆rsquo；s theorem 诺顿定理 Norton＆rsquo;s theorem 开路(断路）open circuit 短路 short circuit 开路电压 open—circuit voltage 短路电流 short-circuit current

电力电子-专业词汇中英文对照〔一〕Absorber Circuit吸收电路AC/AC Frequency Converter交交变频电路AC power control 交流电力控制AC Power Controller 交流调功电路AC Power Electronic Switch 交流电力电子开关Ac Voltage Controller 交流调压电路Asynchronous Modulation 异步伐制Baker Clamping Circuit 贝克箝位电路Bi-directional Triode Thyristor 双向晶闸管Bipolar Junction Transistor-- BJT 双极结型晶体管Boost-Buck Chopper 升降压斩波电路Boost Chopper 升压斩波电路Boost Converter 升压变换器Bridge Reversible Chopper 桥式可逆斩波电路Buck Chopper 降压斩波电路Buck Converter 降压变换器Commutation换流Conduction Angle导通角Constant Voltage Constant Frequency --CVCF恒压恒频Continuous Conduction--CCM〔电流〕持续模式Control Circuit控制电路Cuk Circuit CUK 斩波电路Current Reversible Chopper电流可逆斩波电路Current Source Type Inverter--CSTI电流〔源〕型逆变电路Cyclo convertor周波变流器DC-AC-DC Converter直交直电路DC Chopping直流斩波DC Chopping Circuit直流斩波电路DC-DC Converter直流－直流变换器Device Commutation器件换流Direct Current Control直接电流控制Discontinuous Conduction mode〔电流〕断续模式displacement factor位移因数distortion power畸变功率double end converter双端电路driving circuit驱动电路electrical isolation电气隔离fast acting fuse快速熔断器fast recovery diode快恢复二极管fast revcovery epitaxial diodes快恢复外延二极管fast switching thyristor快速晶闸管field controlled thyristor场控晶闸管flyback converter反激电流forced commutation强迫换流forward converter正激电路frequency converter变频器full bridge converter全桥电路full bridge rectifier全桥整流电路full wave rectifier全波整流电路fundamental factor基波因数gate turn-off thyristor——GTO可关断晶闸管general purpose diode普通二极管giant transistor——GTR电力晶体管half bridge converter半桥电路hard switching硬开关high voltage IC高压集成电路hysteresis comparison带环比较方式indirect current control间接电流控制indirect DC-DC converter直接电流变换电路insulated-gate bipolar transistor---IGBT绝缘栅双极晶体管intelligent power module---IPM智能功率模块integrated gate-commutated thyristor---IGCT集成门极换流晶闸管inversion逆变latching effect擎住效应leakage inductance漏感light triggered thyristor---LTT光控晶闸管line commutation电网换流load commutation负载换流loop current环流电力电子-专业词汇中英文对照〔二〕1 backplane 背板2 Band gap voltage reference 带隙电压参考3 bench top supply 工作台电源4 Block Diagram 方块图5 Bode Plot 波特图6 Bootstrap 自举7 Bottom FET Bottom FET8 bucket capacitor 桶形电容9 chassis 机架11 constant current source 恒流源12 Core Saturation 铁芯饱和13 crossover frequency 交叉频率14 current ripple 纹波电流15 Cycle by Cycle 逐周期16 cycle skipping 周期跳步17 Dead Time 死区时间18 DIE Temperature 核心温度19 Disable 非使能，无效，禁用，关断20 dominant pole 主顶点21 Enable 使能，有效，启用22 ESD Rating ESD额定值23 Evaluation Board 评估板24 Exceeding the specifications below may result in permanent damage to the device, or device malfun ction. Operation outside of the parameters specifiedin the Electrical Characteristics section is not implie d. 超过下面的规格使用可能引起永久的设备损害或设备故障。

SYMBOLS Cj ……Junction Capacitance 结电容ηv ……Rectification Efficiency 整流效率I(AV) ……Average Forward Rectified Current 正向平均整流电流IBO ……Breakover Current 转折电流ID ……Stand-off Reverse Leakage Current 关态反向漏电流IF ……DC Forward Current 正向直流电流IFM ……Maximum DC Forward Current 最大正向直流电流IFSM ……Peak Forward Surge Current 正向浪涌峰值电流IFRM ……Repetitive Peak Forward Current 正向重复峰值电流IH ……Holding Current 维持电流IO ……Mean Forward Current 正向平均电流IPPM ……Maximum Peak Impulse Current 最大脉冲峰值电流Irr ……Reverse Recovery Current 反向恢复电流IR ……Reverse Leakage Current 反向漏电流IRM ……Maximum Reverse Leakage Current 最大反向漏电流IRRM ……Repetitive Peak Reverse Current 重复峰值反向电流IRSM ……Maximum Non-repetitive Reverse Peak Current 最大反向不重复峰值电流ITRM ……Repetitive Peak On-state Current 重复峰值开态电流ITSM ……Non Repetitive Surge Peak on-state Current 不重复浪涌峰值开态电流IT ……Test Current 测试电流I2T ……Rating for Fusing 正向浪涌电流的平方对电流IRRM ……Peak Repetitive Reverse Current 反向重复峰值电流IZ ……Zener Current 齐纳电流IZM ……Maximum Zener Current 最大齐纳电流PM(AV) ……Maximum Steady State Power Dissipation 最大稳态功耗PPPM ……Peak Pulse Power Dissipation 峰值脉冲功耗Ptot ……Total Power Dissipation 总功耗Qrr ……Recovered Charge 恢复电荷R θJA ……Thermal Resistance(Junction to Ambient) 热阻（结到环境）RθJC ……Thermal Resistance(Junction to Case) 热阻（结到管壳）RθJL ……Thermal Resistance(Junction to Lead) 热阻（结到引线）TA ……Ambient Temperature 环境温度TC ……Case T emperature 管壳温度Td ……Time Duration 持续时间Tf ……Fall Time 下降时间tfr ……Forward Recovery Time 正向恢复时间Tj ……Junction Temperature 结温TL ……Lead T emperature 引线温度tr ……Rise Time 上升时间trr ……Reverse Recovery Time 反向恢复时间TP ……Pulse Duration 脉冲持续时间TSTG ……Storage Temperature 存储温度TT ……Temperature of the terminals (SMD) 引线端的温度（SMD）V(BR) ……Reverse Breakdown Voltage 反向击穿电压VBO ……Breakover Voltage 转折电压VC ……Clamping Voltage 箝位电压VDC、VR ……DC Reverse Voltage 反向直流电压VF ……Forward Voltage 正向电压VFM ……Maximum Forward Voltage 最大正向电压VFR ……Forward Recovery Voltage 正向恢复电压VISO ……Isolation Voltage 绝缘电压VO ……Output Voltage 输出电压VRM ……Maximum Recurrent Peak Reverse Voltage 最大重复峰值反向电压VRMS ……RMS Input Voltage 均方根输入电压VRRM ……Peak Repetitive Reverse Voltage 反向重复峰值电压VRSM ……Maximum Non-Repetitive Peak Reverse Voltage 最大反向不重复峰值电压VTM ……Peak On-state Voltage 峰值开态电压VWM ……Working Stand-off Voltage 关态工作电压VZ ……Zener Voltage 齐纳电压ZZ ……Dynamic Zener Impedance 动态齐纳阻抗︱+VBO︱- ︱VBO︱……Breakover Voltage Symmetry 转折电压的对称性︱±△V ︱……Dynamic Breakover Voltage 弹回电压(负阻) αV(BR) ……Maximum Reverse Voltage Temperature Coefficient 最大反向电压温度系数αVZ ……Temperature Coefficient of Zener Voltage 齐纳电压的温度系数Duty Cycle (Ratio of pulse duration of full cycle) 占空因数(由脉冲比率持续时间制成的完整周期)（此文档部分内容来源于网络，如有侵权请告知删除，文档可自行编辑修改内容，供参考，感谢您的支持）。

电流current电压voltage母线bus电力系统power system绝缘insulation发电机generator变压器transformer过电流overcurrent短路电流short-circuit current电流零点current zero电流截断（截流）current chopping畸变电流distortion current弧后电流post-arc current电弧电压arc voltage电弧长度arc length电气名词Electric items线路（母线、回路）Lines (Bus , circuits)设备Equipments保护、继电器Protection , relays电气仪表Electric instruments防雷Lightning protection接地Grounding , earthing室、所Room , Substation电修车间设备Equipments of electric repair材料Material图名Drawings , diagrams表头Tables标准图词汇Terms from standard DWG电气名词Electric items交（直）流Alternating (direct) current短路电流Short-circuit current起始次暂态短路电流Initial subtransient short-circuit current冲击电流Impulse current稳态短路电流Steady state short-circuit current 临界电流Critical current 切断电流Rupturing current熔断电流Blow-out current故障电流Fault current计算电流Calculating current极限有限电流Limit effective current过电流Over current逆电流Inverse current整定电流Setting current额定电流Rated current电流密度Current density短路电流最大有效值Maximum effective value of short-circuit current高压High-voltage , High-tension低压Low-voltage , Low-tension计算电压Calculating voltage激磁电压Exciting voltage冲击电压Impulse voltage临界电压Critical voltage残留电压Residual voltage击穿电压Puncture voltage脉动电压Pulsating voltage供电电压Supply voltage电力电压Power voltage照明电压Lighting voltage灯丝电压Filament voltage额定电压Rated voltage电压损失Voltage loss过(欠)电压Over (under) voltage线路电压Line voltage电压降Voltage drop工作电压Working voltage一次电压Primary voltage二次电压Secondary voltage电源Electric source (power supply)自控电压Power supply for process control6kV控制闪光电源Flashing supply for 6kV control工作电源Working power supply (electric source)保安电源Emergency power supply (electric source)直流稳压电源Stabilized D.C. source控制电源Control supply直流电源D.C. source交流电源A.C. source负荷计算Load calculation设备容量Installed capacity需要容量Electric demand功率因数Power factor安装高度Mounting height耐电压Breakdown voltage工频耐压High-voltage test with working frequency表面闪络Surface flash-over直流泄漏D.C. leakage体电阻率Volume resistivity介质损失角Dielectric loss angle击穿强度Puncture intensity电压等级Voltage grade比重Specific gravity性能Feature相序Phase sequence瞬时Instantaneous倾角Angle of inclination跨度Span正极Positive pole负极Negative pole截面(积) Cross section area辅助电源Auxiliary source遮断容量Interrupting capacity载流量Current-carrying capacity 校正系数Correction factor连续负荷Continuous load长期载流量Continuous capacity长时间额定值Longtime rating电动机堵转电流Locked-rotor motor current限定负荷Limited load电感负荷Inductive load感应电流Induced current二．线路（母线、回路）Lines (Bus , circuits)母线Bus-bar合闸电源母线Closing power source bus闪光母线Flashing-bus备用母线Spare bus装在支柱上的插接式母线Post-supported plug-in bus way装在吊钩上的插接式母线Hook-supported plug-in bus way装在支架上的插接式母线Bracket-supported plug-in bus way小母线Miniature bus电源小母线Power supply miniature bus操作小母线Operating miniature bus事故信号小母线Miniature bus for fault signal闪光小母线Flashing miniature bus主母线Main bus直流主母线D.C. main bus预告母线Prewarning bus干线Main line照明干线Lighting main line接地干线Grounding main line插座干线Receptacle main line电压干线Voltage main line端子出线Terminal outgoing中性线Neutral支线Branch-line引入线Lead-in电气线路Electric circuit交流配电线路A.C. distribution circuit直流配电线路D.C. distribution circuit事故照明线路Emergency lighting circuit控制线路Control circuit接地或接零线路Grounding or neutralizing circuit信号线路Signal circuit有接地极的接地线路网Grounding with grounding electrodes定子绕组测温回路Temperature measuring circuit for stator winding接地信号回路Grounding signal circuit闪光信号回路Flashing-signal circuit开阀回路Circuit for opening valve关（闭）阀回路Circuit for closing valve开度计回路Circuit for opening meter电流测量回路Current-measuring circuit差动保护回路Differental protective circuit过流保护回路Over-current protective circuit合闸回路Closing circuit停车延时回路Delayed shutdown circuit掉闸回路Trip circuit激磁回路Exciting circuit备用回路Spare circuit主回路Main circuit馈路Feeder circuit现有回路Existing circuit单线回路Single-wire circuit接地回路Earthed circuit有电压的电路Live circuit设备Equipments高压开关柜H.V. switchgear动力配电箱Power distribution cabinet电源配电箱Source distribution cabinet 直流配电屏 D.C. switchboard (distribution panel)交流低压配电屏 A.C.L.V. switchboard (distribution panel)静电电容器柜Static capacitor cabinet多种电源插销箱Receptacle box for miscellaneous power supplies控制箱Control cabinet照明配电箱Lighting (distribution panel)连接箱Junction box出线盒Outlet box开关箱Switch box控制台Console分段屏Sectionalizing panel进线屏Incoming line panel电控箱Electric control panel边屏Side board端子箱Terminal box供电盘Power supply box瓶车箱Synchronizing cabinet感应调压器专用变压器高压柜Special transformer H.V. cabinet for induction voltage regulator电压互感器柜Potential transformer cabinet信号屏Signal panel浮充屏Floating panel蓄电池屏Battery panel充电屏Charging panel母线联络柜Bus tie cabinet转换开关Transfer switch电压表转换开关Voltmeter change-over switch 铁壳开关Metal-clad switch (Iron-clad switch)管式熔断器Cartridge fuse真空断路器Vacuum circuit breaker (V.C.B.)自动开关Automatic switch高压负荷开关H.V. load break switch三极高压断路器3-pole HV circuit-breaker刀开关Knife switch转换开关Transfer switch双极铁壳开关2-pole iron-clad switch风扇变速开关Fan speed regulator switch密闭照明灯开关Hermetic lighting switch防爆照明灯开关Explosion-proof lighting switch 行程开关Limit switch高压隔离开关H.V. disconnecting switch明装单极板钮开关Surface-mounted single-pole toggle switch暗装单极板钮开关Flush-mounted single-pole toggle switch三路开关Three-way switch气密式组合开关Hermetic packet type switch防护式开关Guard type switch联锁开关Interlock switch操作方式选择开关Selecting switch for types of operation控制电源开关Switch for control supply主令开关Master switch (controller)多切点切换开关Multi-point change-over switch 按钮Push-button控制按钮Control push-button防爆控制按钮Explosion-proof control push-button事故紧急按钮Emergency stopping push-button 起动按钮Starting push-button停止按钮Stopping push-button现场按钮Push-button in field挡板damper音响解除按钮Push-button for sound release起动器Starter磁力起动器Magnetic starter综合起动器Combination starter (Magnetic starter combination)电力变压器Power transformer调压变压器Voltage regulating transformer 电压互感器Potential transformer电流互感器Current transformer照明变压器Lighting transformer三相三绕组变压器3-phase tertiary winding transformer高压试验变压器H.V. testing transformer局部照明变压器Local lighting transformer多量程仪用电流互感器Multi-range current transformer for measurement降压变压器Step-down transformer伺服电动机Servo-motor双电压电动机Dual-voltage motor感应电动机Induction motor交流异步电动机A.C. asynchronous motor同步电动机synchronous motor三相滑环感应电动机3-phase slip-ring induction motor三相鼠笼感应电动机3-phase squirrel-cage induction motor绕线式电动机Wound-rotor induction motor反应式电动机Reaction motor柴油发电机Diesel generator励磁发电机Excitation generator明装双极插座Surface-mounted 2-pole receptacle暗装双极插座Flush-mounted 2-pole receptacle 双极带接地插座2-pole receptacle with grounding contact单相三孔明插座Surface-mounted single phase 3-pole receptacle防护式明装三相四孔插座Guard type surface-mounted 3-phase 4-pole receptacle配照型灯Standard dome lighting fitting搪瓷深照型灯Enameled high bay lighting fitting 防水防尘灯Water and dust proof lighting fitting 安全灯Safety lighting fitting隔爆灯Explosion-proof lighting fitting弯灯Goose-neck light壁灯Wall light高压水银灯High pressure mercury vapor lighting fitting投光灯Flood-light (projection light)信号灯Signal lamp天棚灯Ceiling-mounted lighting fitting局部照明灯Local lighting fitting灯座Lamp holder事故照明灯Emergency lighting fitting高压水银荧光灯H.P. mercury fluorescent lighting fitting广照型工厂灯Wide lit type industrial fitting深照型灯具High bay lighting fitting白炽灯具Incandescent lamp (bulb)圆球型灯Globe lamp嵌入式荧光灯flush type fluorescent lighting fitting红色障碍灯Red obstruction lamp for aviation厂区道路照明灯Street lighting in plant area路灯Street lamp视孔灯Inspection hole lamp立杆弯灯goose-neck post lamp , pole lamp模拟报警信号Semigraph and alarm signal自整角机Selsyn励磁机Exciter显示器Display电位器Potentiometer内电阻Internal resistance固定电阻（器）Fixed resistance脱扣Release , trip分励Shunt trip特殊失压脱扣器Special no-voltage release “或”开关放大器“Or” switch amplifier制动器Brake电容Capacitor 整流器Rectifier镇流器Chock分流器Shunt油变阻器Oil immersed rheostat频敏电阻器Frequency sensitive rheostat滑线变阻器Sliding rheostat蜂鸣器Buzzer电机加热器Space heater (for motor)空气断路器电机操作机构Motor operating mechanism for air circuit-breaker可控硅励磁装置Silicon controlled rectifier excitation device保护装置Protective device (element)闪光装置Flashing device接闪装置（避雷器）Lightning arrester断相保护Phase failure protection保护、继电器Protection , relays信号继电器Signal relay过电流继电器Over-current relay电压继电器Voltage relay时间继电器Time relay中间继电器Auxiliary relay热继电器Thermal relay温度继电器Temperature relay瓦斯继电器Gas relay控制电源中间继电器Auxiliary relay for control supply自动操作继电器Relay for auto-operation低电压继电器Under-voltage relay过电压继电器Over-voltage relay联锁继电器Interlock relay冲击继电器Impact relay合闸位置继电器Close position relay逆流继电器Reverse-current relay差流继电器Differential current relay差动继电器Differential relay电流继电器Current relay功率继电器Power relay接地继电器Earthing relay重合闸继电器Reclosing relay同步继电器Synchronous relay速动继电器Quick acting relay定时限继电器Definite time relay光电继电器Photoelectric relay电子继电器Electronic relay电磁式继电器Electromagnetic relay电动式继电器Electrodynamic relay气压继电器Gas-pressure relay继电器常开触点Relay N.O. contact继电器常闭触点Relay N.C. contact继电器保护触点（常开）Relay holding contact (N.O.)能自动返回的常闭按钮触点Self-return button with N.C. contact模拟信号触点Contact for semigraph signal强励磁接点Shock excitation contact电感线圈Induction coil电流线圈Current coil脱扣线圈Trip coil合闸线圈Close coil释放线圈Releasing coil掉闸线圈Tripping coil予告信号Prewarning signal掉闸回路断线信号Breakage signal of trip circuit 断路器事故掉闸信号Fault trip signal of breaker 掉闸音响信号Tripping audible signal重瓦斯预告信号Heavy gas prewarning signal 温度预告信号Temperature prewarning signal 手动、自动操作时事故信号Fault signal in manual/automatic operation保护掉闸Protective trip控制掉闸Control trip 手动跳闸Manual trip变电所紧急停车Emergency shutdown at substation工艺故障Fault in process励磁故障Fault in excitation工作电源失电报警No-voltage alarm of working electric source工作电源分合闸On and off of working electric source工作电源投入Throw-in of working electric source保安电源送电supply of emergency electric source运转指示Indicating of operation投入指示Indicating of throw-in同步指示Indicating of synchronism延时停车Delayed shutdown电源切除Switch off the power supply速断及过流断通Instantaneous trip and over-current off/on自保持Self-holding自锁Self-lock联锁Interlocking绝缘监视Insulation supervision电压监视Voltage supervision联锁解除Release of interlock工作、保安电源切换Transfer of working and emergency power supply发电机与工作母线并车Synchronization of generator to working bus重瓦斯保护Heavy gas protection开或闭超扭矩保护Over-torque protection during opening and closing valve电机起动顺序Sequence of motor starting铭牌框注字Name plate denotation (inscription) 电气仪表Electric instruments电流表Ammeter电压表Voltmeter三相三线有功电度表Three-phase three-wire kilowatt-hour meter , kWh meter单相电度表Single-phase kilowatt-hour meter三相无功电度表Three-phase kilovar-hour meter有功功率表Active power meter , kilowatt meter 无功功率表Reactive power meter , kilovar meter三相瓦特表(功率表) Three-phase watt meter功率因数表Power factor meter频率表Frequency meter验电流器Galvanoscope欧姆表Ohmmeter相位表Phase meter转速表Tachometer波长表Wave-length meter三相四线制标准电度表3-phase 4-wire standard watthour-meter过载电流表Overload ammeter低功率因数瓦特表Low power-factor wattmeter 交直流两用钳型电流表A.C./D.C. multi-purpose tongtester兆欧表Megger , Megohmmeter万用表Avometer微安表Microammeter毫安表Milliammeter各种测量仪表Various kind of measuring instruments接地电阻测量仪Earthing resistance tester真空管电压表Vacuum tube voltmeter电动秒表Electric second-meter防雷Lightning protection避雷装置Lightning protector避雷针Lightning rod避雷带Strap type lightning protector避雷网Network of lightning protector 避雷针支架Lightning rod support避雷针尖Tip of lightning rod避雷针拉铁Brace for lightning rod避雷器Lightning arrester , surge discharger球型避雷器Spherical arrester管形避雷器Tubular arrester阀形避雷器Auto-valve arrester低压避雷器Low voltage arrester角形避雷器Horn arrester多隙避雷器Multigap arrester铝避雷器Aluminum cell arrester氧化膜避雷器Oxide film arrester击穿保险器Puncture lightning arrester雷击Lightning stroke直接雷击Direct lightning stroke感应雷击Induction lightning stroke雷电日Thunderbolt days雷电或然率Lightning and thunder probability 触电Electric shock静电感应Electrostatic induction接地Grounding , earthing接地保护Ground protection , earth protection 防雷接地Grounding for lightning保护接地Protective earthing人工接地Artificial grounding工作接地Working grounding , working earthing 重复接地Multiple earthing屏蔽接地Screen earthing , shielding ground中性点接地Neutral point grounded接地系统Grounding system , earthing system 接地故障Ground fault , earth fault单相接地Single phase earthing母线接地Bus ground接地装置Grounding device , earthing device 引下线Down-lead , down conductor引下线固定Clamping plate of support for fixing支架夹板Down lead引下线固定支脚Support for fixing down lead接地线Ground connector接地干线Ground(ing) main , (bus)接地网Grounding network , earthing network 接地极Earth electrode (pole)接地电阻Earth resistance接地电路Earth (ground) circuit连接条Connecting strip断接卡Connecting clamp室、所Room , Substation贮藏室Storage套间Compartment蓄电池室Battery room控制室Control room配电室Distribution room维修间Repair room变电所Substation高压配电室H.V. distribution room休息室Rest room电修车间设备Equipments of electric repair砂轮机Emery wheel grinder台钻Bench drilling machine交流电焊机A.C. welding machine移动式空气压缩机Portable air compressor手电钻Electric hand drill单速手摇绕线机Single speed hand winding machine导线钳压器Wire jointing press-clamp油压千斤顶Hydraulic jack电吹尘器Electric dust cleaner存放柜Store chest高压试验变压器H.V. testing transformer泄漏试验变压器Leakage testing set大电流发生器Strong current generator 油浸自冷感应调压器Oil-immersed self-cooled induction voltage regulator多量程仪用电流互感器Multi-range current transformer for measurement仪用电感互感器Instrumental voltage transformer单相自耦变压器Single-phase auto-transformer 三相自耦变压器3-phase auto-transformer硅整流器Silicon rectifier仪表试验台Testing stand for instrument接触器，继电器试验台Relay and contactor testing stand慢扫描示波器Slow scanning oscillograph交流电子稳压器 A.C. electronic voltage stabilizer携带式交流电桥Portable A.C. electric bridge接地电阻测量仪Earthing resistance tester电缆故障探伤仪Cable fault detector直流单臂电桥D.C. single-arm electric bridge , Wheatstone bridge材料Material绝缘包布Insulating tape填料Filler , packing绝缘膏Insulating compound电缆膏Cable compound防腐油Anti-corrosive oil沥青漆Bituminous varnish绝缘漆Insulating varnish瓷漆Enamel varnish有色金属Non-ferrous metal黑色金属ferrous metal白金属White metal云母Mica环氧树脂Epoxy resin聚氯乙烯Polyvinyl chloride , PVC蜡Wax滑石粉Talc powder电胶木Bakelite聚丙烯外壳Polyacrylic cover耐油橡胶管Oil-proof rubber tubes接地铜线Grounding copper wire垫圈Pad塑料绝缘线Plastics insulated wire橡套电缆Rubber sheathed cable中间接头Splice填充剂Filling agent绝缘电线Insulated wire移动软电缆Movable flexible cable补偿导线Extension wire套管Bushing母线槽Busway悬索Cable suspension滑触线Trolley conductor镀锌煤气管Galvanized gas pipe镀锌角钢Galvanized steel angle镀锌扁钢Galvanized steel strap钢丝绳Steel wire rope电笛Siren电磁阀Electromagnetic valve连接片Connecting link切换片Transfering link端子排Terminal board半导体二极管Semiconductor diode开度计Opening meter逻辑元件Logical element接线盒Junction box仪表槽板Instrument trunking电缆吊架Cable hanger出线套Outgoing line sleeve图名Drawings , diagrams电气图纸目录Contents of electric drawings 电力系统图Electric power system diagram 照明系统图Lighting system diagram 电力平面布置图Electric power layout plan照明平面布置图Lighting layout plan单线图One line diagram控制箱面部布置图Surface arrangement of control box背部接线图Back wiring (diagram)外部接线图External (outside) wiring diagram内部接线图Internal (inside) wiring diagram控制原理图Principle control diagram原理图Schematic diagram展开图Developed diagram电气标准图Electric standard drawing电气施工图Electric working drawing复用图Reproducibles (drawing)电缆联系图Cable hook-up diagram转换开关接点图Contact diagram of transfer switch箱侧视图Side view of box正视图Front view , facade背视图Back view剖面图Section参考图Reference drawing电缆敷设图Cable laying diagram箱内框架布置图Arrangement of frames inside the cabinet控制箱台面展开图Surface developed diagram of console出线端子示意图Schematic diagram of terminal outgoing lines端子接线图Diagram of terminal connections电气管线表List of wire , cable and conduits设备材料表List of equipment and materials表头Tables电力系统图Power system diagram引入线Lead in保护设备Protective device型号Type额定值Rating整定值Setting主启动设备回路Circuit to starting device导线型号、芯数、截面及管径Conductor type , cores , section & diameter of conduit线长Wire length管长Conduit length启动设备Starting device型号规格Type , specification保护元件Protective element计量装置Calculating device用电设备主回路Main circuit of electric equipment控制回路Control circuit控制装置Control device用电设备Electric equipment设备容量Consumer capacity生产设备Production equipment位号No. of location名称Name备注Remarks引入线Feed in配电箱Distribution cabinet型号及编号Type and No.开关型号Switch type保护装置Protective device回路编号Circuit No.相别Phase灯数Number of lamps插座数Number of receptacles电缆编号No. of line起点Starting终点Ending母线截面Section of bus零母线Neutral bus屏编号Panel No. 型号及方案号Type and variant No.控制原理图号Principle control diagram工艺位号Process item No.标准图词汇Terms from standard DWG电工系统图图形符号Graphic symbols for electric system交流电的相别A.C. phase sequence直流电的正负极 D.C. positive and negative poles有中性点引出线的星形连接的三相绕组Star-connected three phase windings with neutral outlet开口三角形连接的三相绕组3-phase winding with open delta connection互相连接的导线Cross connection of wires不连接的跨越导线Crossing wires not in contact with each other可拆卸的电气连接Removable connection电缆终端头Pothead of cable or cable end自耦变压器Auto-transformer感应调压器Induction voltage regulator凸极同步电动机Salient pole synchronous motor带接换装置的蓄电池组Accumulator battery with tap-changers空气断路器Air circuit-breaker保持触点Holding contact热元件Thermal element自动复位的操作开关Spring-return operating switch插接器Plug-in connector电喇叭Horn电炉Electric furnace分流器Shunt可控硅整流箱屏Silicon controlled rectifier box panel直流配电屏D.C. distributing panel磁力起动器组Magnetic starter group自动开关箱Automatic switch box行程开关Limit switch局部灯Local lighting fitting荧光灯列Series fluorescent lighting fitting防护式灯开关Protective switch导线引上Conductors turning up导线引下Conductors turning down导线由上引来Conductors turning from above 导线由下引来Conductors turning from below电缆沟Cable trench调压器Voltage regulator隔离变压器Isolating transformer击穿保护器Puncturing safety device晶体管Transisorized diode地坪Grade level电缆与水管平行Cable running parallel to a water supply pipe电缆与热力管道交叉敷设Cable running across heat pipeline车道Drive way电缆穿管与管道交叉Cable protective pipe across a pipeline双(单)侧支架电缆沟Trench with rack on both sides (one side)室外地坪Outdoor grade跨接线Jumper金属软管Flexible metal tube过渡接头Adapter功角power angle有功（功率）active power无功（功率）reactive power功率因数power factor无功电流reactive current下降特性droop characteristics斜率slope 额定rating变比ratio参考值reference value电压互感器PT分接头tap下降率droop rate仿真分析simulation analysis传递函数transfer function框图block diagram受端receive-side裕度margin同步synchronization失去同步loss of synchronization阻尼damping摇摆swing保护断路器circuit breaker电阻：resistance电抗：reactance阻抗：impedance电导：conductance电纳：susceptance导纳：admittance电感：inductance电容: capacitanceAbsorber Circuit 吸收电路AC/AC Frequency Converter 交交变频电路AC power control交流电力控制AC Power Controller交流调功电路AC Power Electronic Switch交流电力电子开关Ac Voltage Controller交流调压电路Asynchronous Modulation 异步调制Baker Clamping Circuit贝克箝位电路Bi-directional Triode Thyristor双向晶闸管Bipolar Junction Transistor-- BJT双极结型晶体管Boost-Buck Chopper升降压斩波电路Boost Chopper升压斩波电路Boost Converter升压变换器Bridge Reversible Chopper桥式可逆斩波电路Buck Chopper 降压斩波电路Buck Converter降压变换器Commutation 换流Conduction Angle 导通角Constant Voltage Constant Frequency --CVCF 恒压恒频Continuous Conduction--CCM （电流）连续模式Control Circuit 控制电路Cuk Circuit CUK 斩波电路Current Reversible Chopper 电流可逆斩波电路Current Source Type Inverter--CSTI 电流（源）型逆变电路Cycloconvertor 周波变流器DC-AC-DC Converter 直交直电路DC Chopping 直流斩波DC Chopping Circuit 直流斩波电路DC-DC Converter 直流－直流变换器Device Commutation 器件换流Direct Current Control 直接电流控制Discontinuous Conduction mode （电流）断续模式displacement factor 位移因数distortion power 畸变功率double end converter 双端电路driving circuit 驱动电路electrical isolation 电气隔离fast acting fuse 快速熔断器fast recovery diode 快恢复二极管fast revcovery epitaxial diodes 快恢复外延二极管fast switching thyristor 快速晶闸管field controlled thyristor 场控晶闸管flyback converter 反激电流forced commutation 强迫换流forward converter 正激电路frequency converter 变频器full bridge converter 全桥电路full bridge rectifier 全桥整流电路full wave rectifier 全波整流电路fundamental factor 基波因数gate turn-off thyristor——GTO 可关断晶闸管general purpose diode 普通二极管giant transistor——GTR 电力晶体管half bridge converter 半桥电路hard switching 硬开关high voltage IC 高压集成电路hysteresis comparison 带环比较方式indirect current control 间接电流控制indirect DC-DC converter 直接电流变换电路insulated-gate bipolar transistor---IGBT 绝缘栅双极晶体管intelligent power module---IPM 智能功率模块integrated gate-commutated thyristor---IGCT 集成门极换流晶闸管inversion 逆变latching effect 擎住效应leakage inductance 漏感light triggered thyristo---LTT 光控晶闸管line commutation 电网换流load commutation 负载换流三绕组变压器：three-column transformer ThrClnTrans双绕组变压器：double-column transformer DblClmnTrans电容器：Capacitor并联电容器：shunt capacitor电抗器：Reactor母线：Busbar输电线：TransmissionLine发电厂：power plant断路器：Breaker刀闸(隔离开关)：Isolator分接头：tap电动机：motor状态参数有功：active power无功：reactive power电流：current容量：capacity电压：voltage档位：tap position有功损耗：reactive loss无功损耗：active loss功率因数：power-factor功率：power功角：power-angle电压等级：voltage grade空载损耗：no-load loss铁损：iron loss铜损：copper loss空载电流：no-load current阻抗：impedance正序阻抗：positive sequence impedance负序阻抗：negative sequence impedance零序阻抗：zero sequence impedance电阻：resistor 电抗：reactance电导：conductance电纳：susceptance无功负载：reactive load 或者QLoad有功负载: active load PLoad遥测：YC(telemetering)遥信：YX励磁电流(转子电流)：magnetizing current定子：stator功角：power-angle上限:upper limit下限：lower limit并列的：apposable高压: high voltage低压：low voltage中压：middle voltage电力系统power system发电机generator励磁excitation励磁器excitor电压voltage电流current母线bus变压器transformer升压变压器step-up transformer高压侧high side输电系统power transmission system输电线transmission line固定串联电容补偿fixed series capacitor compensation稳定stability电压稳定voltage stability功角稳定angle stability暂态稳定transient stability电厂power plant能量输送power transfer交流AC装机容量installed capacity电网power system落点drop point开关站switch station双回同杆并架double-circuit lines on the same tower变电站transformer substation补偿度degree of compensation高抗high voltage shunt reactor无功补偿reactive power compensation故障fault调节regulation裕度magin三相故障three phase fault故障切除时间fault clearing time极限切除时间critical clearing time切机generator triping高顶值high limited value强行励磁reinforced excitation线路补偿器LDC(line drop compensation)机端generator terminal静态static (state)动态dynamic (state)单机无穷大系统one machine - infinity bus system机端电压控制AVR电抗reactance电阻resistanceAccuracy 精度ACSR = aluminum conductor steel reinforced 钢芯钻铰线adjustment 调整adjustable range 可调范围Lines (Bus , circuits) 线路（母线、回路）able [`eibl] adj.能够abnormal [ b`n :m l] adj.异常abort [ `b :t]中断,停止absent [` bs nt] adj. 不在的，缺少的acceleration [ k.sel `rei n] n. 加速，加速度access [` kses] vt. 存取,进入，接近action [` k n]. 动作actuator [` ktjueit ]n.操作(执行)机构,执行器address [ `dres] 地址adjust [ `d st] 调整，校正adjustable wrench 活扳手adjustable [ `d st bl] 可调整的adjusting screw 调整螺钉adjustment [ `d stment] 调节、调节装置air compressor空压机[k m`pres ] 压缩机air exhaust fan排气扇[ig`z :st] 排气，抽完air [e ]风，空气alarm [ `lam] 报警align [ `lain] 定位，对准，调整alternating current AC 交流电[ :l`t :n t] 轮流，交替ambient temp 环境温度ambient [` mbi t] 周围的，环境的ammeter [` mit ] n. 电流表，安培计amp [ mp] n. 安培ampere [` mp ] n. 安培amplifier [` mplifai ] n. 放大器，扩音器analog input [` n l g] 模拟量输入analog output 模拟量输出analog signal 模拟信号[` n l g] [`signl]analog [` n l g] 模拟analog-to-digital A/D 模数转换[`did it l] angle valve 角伐angle [` gl] 角度application program 应用程序[. pli`kei n] 请求,应用arc [a:k] 电弧，弧光area [`e ri ] 面积，区域arrester [e`rest ] 避雷器assemble line装配线，生产线[ `sembl] assemble [ `sembl] 安装，组装asynchronous motor 异步马达[ei`si n s] atomizing [` tm s.fi ] 雾化attention [ `ten n] 注意auto reclose 自动重合闸autoformer 自耦变压器automatic [. :t ` tik] AUTO 自动automatic voltage regulator 自动调压器[`regjuleit ]auxiliary [ :g`zilj i] AUX 辅助的avoid [ `v id] 避免,回避avometer [ `v mit ]万用表,安伏欧表计axis [` ksis] 轴,轴线back pressure 背压back up 支持，备用back wash 反冲洗baffle [`b fl] 隔板bag filter 除尘布袋balance [`b l ns] 平衡,称，天平ball [bc:l] 球bar [ba:] 巴，条杆base [beis] 基础、根据battery [`b t ri] n. 电池bearing [`b ri ] BRG 轴承bell [bel] 铃,钟(ring 铃声，环) belt tension 皮带张力[`ten n]belt [belt]带，皮带bi rate [bai reit] n.比特率binary [`bain ri] 二进制，双bit [bit] 比特（二进制）black [bl k] 黑色blade [bleid] 叶片bleed [bli:d] 放气，放水blow [bl u] 吹blown [`bl un] 熔断的blue [blu:] 蓝色boiler BLR [`b il ] 锅炉bolt [b ult] 螺栓、拧螺丝boolean [`bu:li n] n. 逻辑boost [bu:st] BST增压，提高boost pump BP 升压泵bore 孔，腔both 双方，两者都bottom底部bracket支架，托架，括号brake [breik] 刹车，制动器，闸break [breik] 断开，断路、破裂、折断breaker coil 跳闸线路breaker [`breik ]断路器，隔离开关brown [braun] 棕色brush [br ] 电刷，刷子bucket [`b kit] 斗，吊斗buffer n. [`b f 缓冲器bump [b mp] 碰，撞击burner [`b :n ] 燃烧器button [`b tn] 按钮bypass/by pass BYP 旁路byte [bait] 字节（八位）cabinet [`k binit] 厨柜，机箱、柜cable [`keibl] 电缆calculator [`k lkjuleit ] 计算器caliber [`k lib ] 管径、尺寸、大小cam [k m] 凸轮cancel [`k ns l] 取消、省略capacitance [k `p sit ns] n. 容量，电容capacitor [k `p sit ] n. 电容器＝capacitator card [ka:d]（电子）板、卡carton [`ka:t n] 纸板箱casualty [`k ju lti] 人身事故、伤亡、故障center [`sent ] 中心central control room 中控室central processing unit CPU 中央处理器centrifugal fan 离心风机centrifugal [sen`trifjug ] 离心的change [t 改变character [`k rikt ] 字符charge indicator 验电器、带电指示器chassis earth 机壳接地chassis [` si] 底座、机壳check [t ek] 检查chimney [`t mni] 烟囱、烟道circuit [`s :kit] n. 电路circuit breaker 电路断路器circuit diagram 电路图circuitry [`s :kitri] n.电路，线路circulating water pump 循环水泵circulating 循环[`s :kjuleiti ]clamp [kl mp] 夹具、钳class of insulation 绝缘等级[.insju`lei n] class [kla:s] 类、等级、程度clean [kli:n] 清洁的、纯净的cleanse [kle 净化、洗净、消毒CLEARING OF FAULT 故障清除clockwise [`kl kwaiz] 顺时针、右旋的clog [kl g] 障碍，塞满，粘注close [kl uz] 关闭closed-loop 闭环[lu:p]coarse [k :s] 粗的、不精确的code [k ud] 代号、密码coder [`k ud ] 编码器coil [k il] n.线圈cold [k uld] 冷,冷的，感冒collect [k `lekt] 收集colour [`k l ] 颜色command [k `ma:nd] 命令、指挥communication [k .mju:ni`kei 通信、通讯compensation [k mpen`sei n]补偿，矫正component [k m`p un nt] 元件compress air 压缩空气[ ]compress [k m`pres] 压缩compressor [k m`pres ] 压缩机computer [k m`pju:t ] 计算机condensate [k n`denseit] 冷凝、使凝结condition [k n`di n] 条件、状况、环境conduct [`k nd kt] 传导conductivity [.k nd k`tiviti] 导电率conductor [k n`d kt ] n.导体，导线configure [k n`fig ] 组态congealer [k n`d i:l ] 冷却器、冷冻器connect [k `nekt] 连接connection [k `nek n] 联接connector [k `n kt ] 联接器、接线盒console [k n`s ul] 控制台constant [`k nst nt] 恒定的contact [`k nt kt] n.接触,触点,vt.接触,联系contact to earth 接地、触地、碰地[ : ]contact [`k nt kt] 触点contactor [`k nt kt ] （电流）接触器、触头continuous [k n`tinju s] 连续的control [k n`tr l] CNTR/CNTPL 控制control panel 控制盘[`p nl] 面板，仪表板，屏幕control valve 调节阀[v lv]controller [k n`tr ul ] 控制器convert [k n`v :t]n.转换vt.使转变，转换…. conveyor [k n`vei ] 传送带，输送机cooktop [`kukt p] n.炉灶cool [ku:l] 冷的cooler [`ku:l ] 冷却器cooling fan 冷却风机[f n]cooling tower 冷却塔[`tau ] 塔，城堡cooling water pump 冷却水泵cooling [`ku:li ] 冷却copy [`k pi] 拷贝core [k :] 铁心、核心、磁心correct [k `rekt] 正确的,改正correction [k `rek n] 修正、改正corrosion [k `r u n] 腐蚀counter [`kaunti ] n.计数器couple [`k pl] CPL 联轴器curdle [`k :dl] 凝固currency [`k r nsi] 流动、流通current [`k r nt] n. 电流，水流、当前、气流current transformer CT 电流互感器[tr ns`f :m ] cursor [`k :s ] 光标curve [k :v] 曲线cutter [`k t ] 切削工具,刀具ccycle 循环、周期、周波cylinder [`silind ] CYL 汽缸，圆柱体cymometer [sai`m mit ] 频率表，频率计damage [`d mid ] 损坏、破坏danger zone 危险区[z un]danger [`deind ] 危险、危险物dangerous [`deind r s] 危险的dank [d k] 潮湿data base 数据库[beis] 底部，基层，灯座data pool 数据库[pu:l]data [`deit ] 数据deactivate [di:` ktiveit] 使无效dead band 死区[ded] [b nd] 区，队debugging [di:`b gi ] n.调试deceleration [di:.sel `rei n] n. 减速，减速度decrease [di:`kri:s] DEC 减少deep [di:p] 深度、深的、深default [di`f :lt] n. 默认(值),缺省(值)degree [di`gri:] 度、等级delay time 延时[di`lei] 延迟，滞后relay [`ri:lei] 继电器delay [di`lei] 延迟，滞后delete [di`li:t] 删除，作废defective [di`fektiv] 有缺陷的，损坏，次品，不完全description [dis`krip n] 说明、描述detect [di`tekt] 发现、检定detector [di`tekt ] 检测器，探测器deviate [`di:vieit] 背离、偏差device [di`vais] 设备、仪器，装置diagnosis [.dai g`n usis] 诊断diagram [`dai gr m] 图形、图表diameter [dai` mit ] 直径dielectric [.daii`lektrik] 介质、绝缘的diesel generator 柴油发电机[`di:z l] [`d en reit ]发电机，振荡器differential [.dif `ren ] 差别的，差动的，微分differential pressure DP/DSP 差压[`pre ]。

AAbnormal 异常Accuracy 精度ACSR = aluminum conductor steel reinforced 钢芯钻铰线adjustment 调整adjustable range 可调范围fine adjustment 细调rough adjustment 粗调air gap 气隙alarm 报警alarm bell 警铃alarming window 报警窗口ampacity 载流量ampere 安培kilovolt ampere 千伏安amperemeter 安培表，电流表amplifier 放大器announciator报警器anode 阳极anti-corrosion 防腐蚀anti-pumping device 防跳装置AOL = aircraft obstruction lamp 航空障碍灯low intensity AOL 低光强航空障碍灯high intensity AOL 高光强航空障碍灯AQR = automatic reactive power regulator 自动无功功率调整器arcing chamber 灭弧室armature 电枢ASS = automatic synchronizing system 自动同期系统asynchronous 非同期non-asynchronous capability 非同期能力Bballast 镇流器ballast-factor 镇流器系数ball eyes 球头挂环battery蓄电池Cd-Ni battery 镉- 镍蓄电池lead-acid battery 铅- 酸蓄电池maintenance free battery 免维护蓄电池battery capacity 蓄电池容量battery rack 电池架battery room 蓄电池室end battery 端电池BIL = basic insulation level 绝缘基本冲击耐压水平blocking diode 闭锁二极管box 盒，箱cast aluminum junction box 铸铅接线盒cast Ferro alloy junction box 铸铁合金接线盒junction box 接线盒lead box 出线箱maintenance box 检修箱marshalling box ( 总配线箱 )power supply box 动力箱terminal box 端子箱test box 试验盒normal lighting box 工作照明箱breaker 断路器close the breaker 合断路器openthe breaker 打开断路器breaker compartment 断路小室PT circuit broken PT回路断线brush 刷graphite brush 石墨碳刷brush holder 刷握brush supporter 刷架brushless excitation system 无刷励磁系统bus 母线branch bus 分支母线by-pass b us 旁母mainbus 主母线bus tie 母联flexible busbar 软母线hardbusbar 硬母线miniature busbar 小母线tubular busbar 管型母线changeover busbars 倒母线bushing 套管oil filled bushing 充油套管seal-offbushing 密封套管wall bushing穿墙套管bushing lead terminal套管端子button 钮子push button 按钮self-holding push-button 自保持按钮turn button 旋钮buzzer 蜂鸣器Ccabinet 柜control cabinet 控制柜distribution cabinet 配电柜cable 电缆3 cores cable 三芯电缆armoured cable 铠装电缆coaxial cable 同轴电缆control cable 控制电缆copper wire braid shield cable 铜编织线屏蔽电缆fiber-optical cable 光纤电缆fire resistant cable 耐火电缆flame retardant cable 阻燃（难燃）电缆heat tracing cable 伴热电缆heating cable 加热电缆heatingsensitive cable 热敏电缆high voltage oil-filled cable 高压充油电缆impregnated paper insulated cable 油浸纸绝缘电缆lead covered cable 铅皮电缆mineralinsulated cable 无机绝缘电缆overhead cable 架空电缆power cable 动力电缆signal cable 信号电缆stranded copper cable 铜铰线电缆telephone cable 电话电缆triple-core cable 三芯电缆twin-core cable 两芯电缆unarmoured cable 非铠装电缆communication cable 通讯电缆single-core cable 单芯电缆tag ofcable 电缆标牌cable clip 电缆夹flexible cable conduit 电缆软管cable conduit 电缆管cable head 电缆头cablelaying 电缆敷设cable laying & list 电缆敷设及清册cable mezzanine 电缆夹层cable raceway system 电缆通道系统cable rack 电缆支架cable shaft 电缆竖井cablesupport 电缆支架cablesuspender 电缆吊架cableterminal 电缆终端头cable tray 电缆桥架cable trench 电缆沟cabletunnel 电缆隧道cable vault电缆夹层control cable with copper tape shield 铜带屏蔽的控制电缆call 呼叫call back 回叫call signal 呼叫信号externalcalling 外部呼叫internal calling 内部呼叫calling 主叫detail calling record 呼叫详细记录candle power distribution curve 配光曲线capability 能力out-of-phase breaking capability 失步开断能力pressure relief capability 压力释放能力rated closing capability 额定关合能力short-line fault breaking capability 近区故障开断能力transient overvoltage capability 暂态过电压能力capability of switching long no-load line 分合长空载线路能力capability of switching no-load transformer 分合空载变压器能力capacitance 电容adjustable capacitor 可变电容器shunt capacitor 并联电容器voltage sharing capacitor 均压电容器capacitor 电容器capacitor divider 电容分压器capacity 能量 , 容量current carrying capacity 载流能量spare capacity 备用容量cavity ratio 室腔比cell jar 电瓶chainlink 挂环changeover 切换automatic changeover 自动切换star-delta changing device 星角切换装置charge 充电equalizing charge 均衡冲电float charge 浮充电fully charged 全充charger 充电器boost charging voltage 大充电压initial charging voltage 起始充电电压check phase order 核对相序circuit 电路，回路auxiliary circuit 辅助回路follow-up circuit 跟踪回路main circuit 主电路shortcircuit plate 短路板spare circuit(feeder) 备用回路series circuit 串联电路circuitbreaker 断路器air circuit breaker 空气断路器bus tie circuit breaker 母联断路器by-pass bus circuit breaker 旁路断路器current-limiting circuit breaker 限流断路器earth leakage circuit breaker 漏电开关field circuit breaker 磁场开关oil circuit breaker 油断路器residual current circuit breaker 漏电开关sectionalized circuit breaker 分段断路器SF6 gas insulated circuit breaker 六氟化硫断路器frame-type circuit breaker 框架式断路器clamp 线夹strain clamp 耐张线夹suspension clamp 悬垂线夹clearance 带电距离clip 线夹quick clip 快速线夹closing 合闸open phase closing of breaker 非全相合闸closing pulse 合闸脉冲coil 绕组arc-suppression coil 消弧线圈armature coil 电枢绕组holdingcoil 保持线圈redundant trip coil双跳闸线圈resetcoil 复归线圈shunt excitation coil 分励线圈trip coil 跳闸线圈combined 综合combined filter 综合滤波器combined starter 综合起动器commission 调试communication 通信communication building 通信楼communication line 通信线communication monitoring 通信监听dispatching communication system 调度通信系统intra-plant communication system 厂内通信系统wireline communication system 有线通信系统component 分量fundamental component 基波分量harmonic component 谐波分量conductor 导体high conductivity 高导电率composite conductor 组合导线flexible conductor 伸缩节flexibleconductor 软导线conductor cross-section 导体截面conform to 符合connection 连接，接线double bus connection 双母线接线open-delta connection 开口三角形连接starconnection 星形连接zigzag connection 曲折形连接1 and 1/2 circuit breaker connection 1个半断路器接线connection pin 连接端子connection plate 联接片double bus connection with bypass 双母线带旁路接线end connector 终端接头powerconnector 电源接头removableconnector 可拆接头oil conservator 油枕contact 触头arcing contact 弧触头arcing-extinguishing contact 灭弧触头common alarm contact 公用报警接点electrical independent contact 无源接点main contact 主触头moving contact 动触头normally closed contact 常闭接点normally opened contact 常开接点stationary contact 静触头auxiliarycontact 辅助触头contactor 接触器electromagnetic pneumatic contactor 电磁气动接触器vacuum contactor 真空接触器electromagnetic contactor 电磁接触器between open contacts 断口间continuousduty (service) 连续运行continuous rating连续额定值control 控制automatic control 自动控制centralized control 集中控制local control 就地控制one-to-one control 一对一控制photoelectric control 光电控制器remote control 远方控制control circuit 控制回路electrical auxiliary control panel 电气辅助控制屏mosaic surface control panel 马赛克控制屏network control room 网控室cool 使冷却hydrogen inner cooled 氢内冷water cooled 水冷却natural cooling 自冷式forced air cooling system 强迫风冷系统copper bus-bar 铜母线core limb 铁芯柱corona 电晕corona-proof cover 防晕罩correcting circuit 校正电路correction factor 校正系数COS = change-over switch 切换开关CP = candle power 烛光creepage distance 爬距crest 峰，峰值crest voltage 峰值电压CS = control switch 控制开关CT = current transformer 电流互感器burden of CT CT的二次容量zero sequence CT 零序 CTCU = coefficient of utilization 利用系数current 电流capacitive current 电容电流dynamic stable current 动稳定电流field current 磁场电流impressed current 外加电流inductive current 电感电流interrupting current 开断电流leakage current 泄漏电流line-charging current 线路充电电流making current 关合电流momentary current 瞬时电流negative sequence current 负序电流no-load current 空载电流nominal discharge current 标称放电电流peak withstand current 峰值耐受电流rated breaking current 额定开断电流rated short time current 额定短时耐受电流reactive current 感性电流shortcircuit current 短路电流startingcurrent 起动电流straycurrent 泄漏电流rated continuous current 额定持续电流zero sequence current 零序电流current amplification 电流放大current collector 集电器current converter 变流器current intensity 电流强度secondary current of CT CT 的二次电流current shunt 分流器phase current 相电流DDC system 直流系统de-energized equipment 不带电设备definite time lag 定时限deformation变形dehydrating breather 吸湿器delay 延时long time delay 长延时shorttime delay 短延时deltaconnection 三角形连接depth of embedded grounding wire 接地线埋深derating factor 降容系数diagram 图图纸CWD =control wiring diagram 控制接线图EWD =elementary wiring diagram 原理接线图mimic diagram 模拟图one-line diagram 单线图dial 拔号diameter 直径direct dialling 直拨directly burying 直埋敷设discharge 放电deep discharge 过放电intercept lightning discharge 截取雷电流self discharge 自放电discharge counter 放电计数器discharge final voltage 放电未期电压disconnection 解列busbar disconnection 母线解列system disconnection 系统解列system disconnection and field extinction 解列灭磁dispatcher 调度员distortion factor 畸变系数diversity factor 分散系数document 文件double column 双柱DP = drip-proof 防滴型draw-out carriage 抽出式小车dust proof type 防尘型Eearthing 接地earthing rod 接地极earthing terminal 接地端子efficiency 效率electric 电气electric braking 电气制动electricwelding machine 电焊机electricallife 电气寿命electricity engineering 电气工程electrode pole 电极electrolyte 电解液electromagnet 电磁铁electromagnetic induction 电磁感应electromotance 电动势electronic element 电子元件emergency bell 事故铃energy能，能量forced line energization 线路强送电successful forced line e nergization 线路强送电成功trial line energization 线路试送电enter the cubic from the top 柜顶进线enter the cubicle from the bottom 柜底进线excitation 励磁reducing excitation 减励磁force excitation 强励low excitation 低励磁overexcitation 过励磁excitation cubicle 励磁柜excitation current 励磁电流force excitation factor 强励系数excitation initiating equipment 起励设备static excitation system 静态励磁系统excitation system response ratio 励磁系统响应比excitation transformer 励磁变压器excitation voltage 励磁电压exciter 励磁机main exciter 主励磁机pilot exciter 副励磁机standby exciter 备用励磁机expansion join 伸缩节expected life 期望寿命explosion-proof type 防爆型Ffailure alarming signal 事故报警信号fault 故障grounding fault 接地故障fault recollecting and recording device 事故追忆记录装置fault recorder 故障记录F-C = high-voltage current limiting fuse and vacuum contactor 高压限流熔断器及真空接触器feeder 馈线incoming feeder 进线outgoing feeder 出线feeder bay 馈线间隔field 磁场field extinction 灭磁field flashing equipment 起励设备field voltage 磁场电压fire 火fire proof blockage 防火堵料fire proof limit 耐火极限fire proof partition 耐火隔板fire protection pillows 阻火包fire retardant coating 阻燃涂料single face exit sign fixture 单面出口标志灯flexible joint 挠性接头FOA = forced oil air cooled 强油风冷foot candle ( F.C ) 英尺- 烛光forced outage 强迫停机frequency 频率frequency converter station 变频站fuse 熔断器no powder-filled cartridge fuse 无填料封闭管式熔断器plug-in type fuse 插入式熔断器powder-filled cartridge fuse 有填料封闭管式熔断器screw-type fuse 螺旋式熔断器self-mending fuse 自复熔断器fast acting fuse 快速熔断器fuseblow 熔断器熔断Ggalvanic protection system 牺牲阳极保护系统galvanized steel 镀锌钢gap 间隙protective gap 保护间隙gapless metaloxide type 无间隙金属氧化型generator 发电机direct current generator 直流发电机dual inner water cooled generator 双水内冷发电机signal generator 信号发生器water-hydrogen-hydrogen cooling generator 水- 氢- 氢冷发电机generator hydrogen cooling system 发电机氢冷却系统generator load curve 发电机负荷曲线generator pedestal 发电机基座generator rotor 发电机转子generator sealing oil system 发电机密封油系统generator stator 发电机定子generator terminal 发电机端子generator terminal lead 发电机引出线generator termination room 发电机出线小室generator water cooling system 发电机水冷却系统generator-transformer extension unit 发变组扩大单元generator-transformer unit 发电机变压器组GIS = gas insulated switchgear 全封闭组合电器Glare 眩光glass cloth tape 波纤带gradingring 均压环、屏蔽环ground pad 接地端子groundbed 接地床anode groundbed 阳极接地床distributed-type groundbed 分散型接地床impressed current groundbed 泄漏电流接地床directly (solid) grounded 直接接地effectively grounded 有效接地un- grounded 不接地grounded through resistor 通过电阻接地grounding 接地single-phase grounding 单相接地grounding conductor 接地导体grounding megger 接地电阻测试仪main grounding network (grid) 主接地网grounding system 接地系统grounding terminal 接地端子grounding wire 接地线guarantee 保证Hharmonics 谐波even harmonic 偶次谐波odd harmonic 奇次谐波heater 加热器self limiting parallel heater 自限制式并联加热器heating element 加热元件hertz (Hz) 赫兹high 高high pressure sodium ( HPS ) 高压钠灯high voltage transmission line 高压线路high-frequency amplification 高频放大high-frequency filter 高频滤波器hot-dipped galvanized 热镀锌Iidentification 识别igniter 触发器illuminance 照度impedance 阻抗asymmetrical impedance 不对称阻抗negative-sequence impedance 负序阻抗positive-sequence impedance 正序阻抗zero sequence impedance 零序阻抗impressed current cathodic protection 外加电流阴极保护indicator 指示器indoor type 户内式initial 首次initial power transmission 首次送电initial synchronization 首次并网input 输入instrumentation测量仪表insulation绝缘epoxy resin insulation 环氧树脂绝缘insulating strength 绝缘强度layer insulation 层间绝缘mica insulation 云母绝缘plastic insulation 塑料绝缘section insulation 段间绝缘turn insulation 匝绝缘insulation between phase 相间绝缘insulation class 绝缘等级insulationlevel 绝缘水平porcelain insulator 瓷质绝缘子post insulator 柱式绝缘子supporting insulator 支撑绝缘子suspending insulator 悬挂式绝缘子tension insulator 耐张绝缘子insulator绝缘子interlock 联锁inversetime lag 反时限inverter逆变器IPB = isolated phase bus duct 离相封闭母线Jtesting jack 试验端子Kkilovar (kVAR) 千乏kilovolt 千伏kilowatt(kW) 千瓦kilowatt-hour 千瓦时Llagging phase 滞后相lamp 灯left （right ）arrow lamp 单面出口标志灯portable lamp 行灯mercury lamp 水银灯metal halide lamp 金属卤化物灯high intensity discharge lamp 高强气体放电灯fluorescent lamp 荧光灯incandescent lamp 白炽灯self-ballasted lamp 自镇流灯tungsten halogen lamp 碘钨灯projection lamp 投光灯lampsocket 灯座layer-to-layer 层间LDD = luminaire dirt depreciation 照明器污秽减光系数leading phase 超前相down- light 筒灯light source (illuminant) 光源flood lighting 泛光照明locallighting 局步照明emergencylighting 应急灯lighting box 照明箱emergency lighting box 事故照明箱double-faced plate lighting fixture 双块板灯flush mounted fluorescent lighting fixture 嵌入式荧光灯tube fluorescent lighting fixture 简式荧光灯anticorrosive, dust-proof and water-resistant lighting fixture 三防灯具wrap-around fluorescent lighting fixture 全密封荧光灯garden lighting fixture 庭院灯waterproof fluorescent lighting fixture 防水荧光灯flameproof fluorescent lighting fixture 防爆耐火荧光灯road lighting fixture 路灯lighting fixture 灯具lightning 雷电tube type lightning arrester 管形避雷器valve type lightning arrester 阀型避雷器lightning arrester 避雷器lightning current 雷电流lightning protection 防雷lightning recorder 雷电记录器lightning rod 避雷针lightning strike 雷击lightning wave front shape 雷电波头形状lightning wire 避雷线live line connection 带电接线live line disconnection 带电拆线LLD = lamp lumen depreciation 光通量衰减系数Load 负荷target load 目标负荷load characteristic curve 负载特性曲线load rejection 甩负荷locked rotor current 转子堵转电流locked rotor torque 转子锁定转矩looping-off 解环loss 损耗copper loss 铜损ironloss 铁损load loss负载损耗no-load loss 空载损耗supplementaryload loss 附加损耗loss-ratio 损耗比louver 格栅louver all ceiling 大面积发光天棚lug 接线片ring lug 环型接线片spade lug 铲型接线片terminal lug 接线端子lumen 流明background luminance 背景亮度luminaries 照明器effective luminous intensity 有效光强LX = lux 勒克司Mmagnetic lock 电磁锁maintenance 维护malfunction 误动作manhole 人孔markingstrip 标识条MCB = miniature circuit breaker 微型断路器MCCB = moulded case circuit breaker 塑壳式断路器mechanical life 机械寿命megawatt (MW) 兆瓦metal clad 金属铠装meter表计gravity meter 比重计insulation supervision meter 绝缘监察表kVAR-hour meter 无功电度表kW-hour meter 有功电度表phase meter 相位表plier-type current meter 钳型表power factor meter 功率因数表secondary meter 二次表计single-phase kilowatt-hour meter 单相电能表three-phase kilowatt-hour meter 三相电能表voltage meter 电压表watt-hour meter 电度表MF = maintenance factor 维护系数MHF = mounting height above the floor 距地面安装高度MHWP = mounting height above the work-place 距工作面安装高度milliammeter 毫安表millivoltmeter 毫伏表mimic bus 模拟母线mis-operation 误操作MOC = mechanism operated cell switch 机构操作式开关motor 电动机adjustable speed motor 调速电动机commutator motor 整流子电动机governor motor 调速电动机horizontal type motor 卧式电动机induction motor 诱导电动机synchronous motor 同步电动机variable speed motor 可变速电动机vertical type motor 立式电动机motor maximum torque 电动机最大转矩mounted 镶嵌，安装standing pole mounted 立杆安装ceiling mounted 嵌入顶棚handrail mounted 扶手安装open mounted 明装wall mounted 吸壁flush mounted 暗装pendant mounted 悬挂stanchion mounted 柱上安装surface mounted 吸顶安装mounting type 安装方式movable type 移动式Nnameplate 铭牌negative pole 负极neutral point 中性点normal 正常NPB = non-segregated phase bus duct 共箱母线Oohm 欧姆OHM = ohmmeter 欧姆表oil level indicator 油位指示器OLTC = on-load tap-changer 有载分接开关open circuit characteristic curve 开路特牲曲线operate 操作operated in single phase 分相操作operated in three phase 三相操作operating dutycycle 操作顺序hydraulic operating mechanism 液压操作机构pneumatic operating mechanism 气动操作机构spring stored-energy operating mechanism 弹簧贮能操作机构operating mechanism 操作机构operation 运行load limit operation 限负荷运行open phase operation 非全相运行trial operation 试运行poleslip operation 滑差运行operation mode 运行方式oscilloscope 示波器outdoor type 户外式outgoing feeder gantry structure 出线门型架构outgoing line 出线direction of outgoing line 出线方向output 输出shaft output 轴功率output increment 增负荷output reduction 降负荷overhead line 架空线over-flux 过激磁over-voltage times 过电压倍数oxygen index 氧指数PP.U. value = per unit value 标幺值packing instruction 包装说明paging dispatching unit 扩音调度机panel 盘control panel 控制盘side panel 边屏parallel 并联parallel branch 并联支路parameter 参数partial discharge 局部放电periodic duty service 定期运行phase 相in-phase 同相phaseangle 相角phasesequence 相序phaseshifter 移相器phase to ground 相对地phase-angle difference 相角差plug-in unit 插件pole and tower杆塔pole plate 极板pole-mounting type 柱上式positive pole 正极potential电位 , 电势protective potential 保护电位step potential 跨步电压touchpotential 接触电压transferred potential 传递电位zero potential 零电位potentiometer 电位计power 功率 , 能量active power 有功功率apparent power 视载功率electric power 电功率loss ofpower 失电reactive power无功功率standby power 备用电源powerfactor 功率因数linepower flow 线路潮流power grid 电网auxiliary power ratio 厂用电率AC power source 交流电源DC power source 直流电源power system swing 系统振荡auxiliary power system 厂用电系统power system 电力系统printedwiring board 印刷电路板protection 保护back-up protection 后备保护branch overcurrent protection 分支过流保护busbar protection 母线保护cathodic protection 阴极保护differential protection 差动保护distance protection 距离保护freeze protection 防冻generator main protection 发电机主保护grounding protection 接地保护high-frequency protection 高频保护impedance protection 阻抗保护instantaneous overcurrent protection 速断保护longitudinal differential protection 纵差保护loss-of field protection 失磁保护low frequency protection 低频保护negative-sequence current protection 负序电流保护out-of step protection 失步保护over current protection 过流保护over excitation protection 过励磁保护reverse power protection 逆功率保护start-up protection 起动保护thermo-magnetic protection 热磁保护transverse differential protection 横差保护under voltage protection 低电压保护zero-sequence current protection 零序电流保护PT (=potential transformer) balance protection PT断线保护protection level at steep current 陡波冲击保护水平protective zone 保护范围PVC(polyvinyl chloride) insulated cable 聚氯乙烯绝缘电缆Qquality assurance 质量保证quality control 质量控制Rradio 无线电rated 额定rated input 额定输入rated output 额定输出rated value 额定值reactance 电抗capacitive reactance 容抗inductance reactance 感抗subtransient reactance次暂态电抗synchronous reactance 同步电抗transient reactance 暂态电抗reactive power compensation device 无功补偿装置reactor 电抗器current-limiting reactor 限流电抗器disruptive reactor 分裂电抗器grounding reactor 接地电抗器shunt reactor 并联电抗器receiver 接收机receptacle(socket) 插座receptacle plug插头re-close 重合闸recording 记录recording duration 记录时间recording instrument 记录仪表rectifier 整流器rectify 整流redial 重拨reflectance factor 反射系数reignite 重燃relative 有关的relay 继电器auxiliary relay 辅助（中间）继电器blocking relay 闭锁继电器Buchholtz relay 瓦斯/ 压力断电器closing relay 合闸继电器control relay 控制继电器current relay 电流继电器current-limiting relay 限流继电器delayedrelay 延时继电器digital type protection relay 数字式继电保护directional relay 方向继电器distance relay 距离继电器flicker relay 闪光继电器lockout relay 出口继电器micro-processor based protective relay 微机继电保护pilot relay 辅助继电器plugging relay 防逆转继电器position relay 位置继电器reclosing relay 重合闸继电器reed relay 舌簧继电器self-starting relay 自启动继电器SIC protection relay 半导体继电保护thermal relay 热继电器time relay 时间继电器tripping relay 跳闸继电器two zone distance relay 两段距离继电器voltage relay 电压继电器voltage-controlled overcurrent relay 电压控制过电流继电器relay 继电器combined protection relay 综合保护继电器protection relay panel 继电保护屏relay protection 继电保护relay station 中继站relevant 相关的repeater 中继器repeater circuit 中继电路repeater group 中继组resistance 电阻high resistance 高阻low resistance 低阻arc suppression resistor 灭弧电阻dynamic braking resistor 制动电阻non-liner resistor 非线性电阻standard resistor 标准电阻startingresistor 起动电阻resistor 电阻器resolution 分辨率rheostat 变阻器slider-type rheostat 滑线式变阻器start rheostat 起动变阻器ripple contain factor 波纹系数RMS = root-mean-square 有效值rotor 转子squirrel-cage type rotor 鼠笼型转子wound type rotor 绕线式转子rotor conductor slot 转子线槽rotor retaining ring 转子护环rotor slip ring 转子滑环rotor winding 转子线圈rubber cushion 橡皮绝缘垫SS/MH = spacing-to-mounting height ratio 距高比sampling frequency 采样频率saturation 饱和saturation characteristics 饱和特性saturation factor 饱和系数scanner 扫描器scope 范围scope of supply 供货范围scope of work 工作范围seismic 地震self-holding 自保持sensitivity 灵敏度series 串联serial capacitor compensation device 串联电容补偿装置service level 服务级别setting range 整定范围setting value 整定值SF6 gas leakage detector SF6 气体泄漏检测器SF6 gas moisture analyzer SF6 气体湿度分析仪SF6 gas reclaiming equipment SF6 气体回收设备shade and railing 遮栏sheath 护套inner sheath 内护套outer sheath 外护套shield 屏蔽short circuit 短路three-phase short circuit 三相短路two-phase short circuit 两相短路system short circuit capacity 系统短路容量short circuit characteristic curve 短路特牲曲线short circuit ratio 短路比short time parallel 短期并列signal 信号failure signal 事故信号flashsignal 闪光信号status signal状态信号signal indicator 信号指示器SIL = switching impulse level 操作冲击水平silicon-steel sheet 硅钢片single-phase 单相sinusoid正弦波slight pressure device 微正压装置soil resistivity 土壤电阻率solidstate rectifier 固态整流器solverplated 镀银spacer 间隔棒spare parts 备品备件special tool 专用工具splice 接头factory splice 工厂接头field splice 现场接头SS = select switch 选择开关stabilized power supply device 稳压电源装置starter 起动器full-voltage starter 全电压启动器reduced-voltage starter 降压启动器rotor resistance starter 转子电阻启动器star-delta starter 星- 三角起动器magnetic starter 磁力起动器stator 定子stator core 定子铁芯statorend cover 定子端盖statorhousing 定子外壳statorwinding 定子线圈storage 贮存storage battery 蓄电池substation 变电站sub-synchronous resonance 低频共振surge 冲击浪涌surge absorber 过电压吸收装置zinc- oxide surge arrester 氧化锌避雷器surge arrester 避雷器magnetic blow surge arrester 磁吹避雷器SVC = static VAR compensator 静态无功补偿装置switch 开关disconnecting switch 隔离开关double earthing switch 双接地刀electronic switch 电子开关fuse-switch 熔断器式开关grounding (earthing) switch 接地开关iron clad switch 铁壳开关proximity switch 极近开关single earthing switch 单接地刀static transfer switch 静态转换开关voltmeter change-over switch 电压表切换开关switch 开关dimmer switch 调光开关knife switch 刀开关pull switch 拉线开关single pole switch 单极开关switch off 断开switchon 合上switch-fuse 负荷开关switchgear 配电装置in-door switchgear 屋内配电装置out-door type switchgear 户外配电装置day-night switching unit 昼夜开关step-up switchyard 升压站switchyard 开关站symmetrical 对称的synchronization 同期single phase synchro-control 单相同期控制synchronization checking 同期鉴定automatic quasi-synchronization 自动准同期manual quasi-synchronization 手动准同期synchronizing device 同期装置synchronous condenser 调相器synchroscope 同期表system 系统system oscillation 系统振荡Ttap lead 抽头tap position indicator 分接头位置指示器tapping 分接tapping range 分接范围tapping step 分接级TEFC = totally enclosed with fan cooler全封闭风冷型telecontrol 遥控telemetering 遥测telephon 电话telephon set 电话机automatic exchange telephone 自动交换机dispatching telephone 调度电话机extension telephone 电话分机noise-reducing telephone 抗噪音电话机talking on the telephone 通话video telephone 可视电话telephone booth 电话亭telephone handset 电话听筒teleregulation 遥调telesignalisation 遥信terminal 端子compression terminal 压缩端子compression type terminal 压接型端子terminal block 端子排terminal screw 端子螺钉test 试验AC withstand voltage test 交流耐压试验continuous breaking capability test 连续开断能力试验DC withstand voltage test 直流耐压试验evolving fault breaking test 开断发展性故障试验insulation withstanding test 绝缘耐受试验mechanical performance test 机械性能试验out-of-phase breaking test 失步开断试验parallel breaking test 并联开断试验partial discharge test 局部放电试验performance test 性能试验rain proof test 防雨试验routine test 例行试验routine test 常规试验sealing test 密封试验seismic test 抗震试验short circuit test 短路试验short circuit making and breaking test 短路关合和开断性能试验short-line fault test 近区故障试验site test 现场试验standard type test 标准型式试验static test 静态试验switching no-load long line test 分合空载长线试验switching no-load transformer test 分合空载变压器试验switching shunt reactor test 分合并联电抗器试验temperature rise test 温升试验test report 试验报告test voltage 试验电压pen tester 试电笔TEWAC = totally enclosed with water cooled air cooler 全封闭水空冷型thermo-couple 热电偶thermometer 温度计thyristor element 硅整流元件auto-reclosing dead time 自动重合闸无电流时间time 时间breaking time 分闸时间inherent closing time 固有合闸时间inherent opening time 固有分闸时间reclosing time 重合闸时间Max.breaking time 最大全分闸时间time delay de-engergizing 延时释放time delay energizing 延时带电time lead 导前时间tin galvanized 镀锡TOC = truck operated cell switch 小车操作式开关torque 转矩breakdown torque 破坏转矩starting torque 起动转矩torsional stress 扭应力transducer 变送器transformer 变压器auto- transformer 自耦变压器booster transformer 增压变压器busbar straight-through current transformer 母线式电流互感器bushing current transformer 套管式电流互感器core type transformer 芯式变压器coupling-capacitor voltage transformer 耦合电容式电压互感器current transformer 电流互感器dry type transformer 干式变压器isolated transformer 隔离变压器lighting transformer 照明变压器low voltage auxiliary transformer 低压厂用变压器low voltage common transformer 低压公用变压器main transformer 主变压器maintenance transformer 检修变压器measuring transformer 测量用互感器oil-immersed type transformer 油浸变压器protecting transformer 保护用互感器PT = potential transformer 电压互感器shell type transformer 壳式变压器single-phase transformer 单相变压器split winding type transformer 分裂变压器start-up/stand by transformer 起动/ 备用变压器step-down transformer 降压变压器step-up transformer 升压变压器three-phase transformer 三相变压器tie transformer联络变压器transformer变压器auxiliary building transformer 辅助厂房变压器transformer angular displacement 变压器联接组别current transformer calibrating device 电流互感器校验装置transformer cooling system 变压器冷却系统transformer fitted with O.L.T.C (on-load tap-changer) 有载调压变压。
