2003 THRU2024
x = digit to identify specific device. Characteristic shown applies to family ofdevices with remaining digits as shown. See matrix on next page.Data Sheet29304F
Ideally suited for interfacing between low-level logic circuitry andmultiple peripheral power loads, the Series ULN20xxA/L high-voltage,high-current Darlington arrays feature continuous load current ratingsto 500 mA for each of the seven drivers. At an appropriate duty cycledepending on ambient temperature and number of drivers turned ONsimultaneously, typical power loads totaling over 230 W (350 mA x 7,95 V) can be controlled. Typical loads include relays, solenoids,stepping motors, magnetic print hammers, multiplexed LED andincandescent displays, and heaters. All devices feature open-collectoroutputs with integral clamp diodes.The ULN2003A/L and ULN2023A/L have series input resistorsselected for operation directly with 5 V TTL or CMOS. These deviceswill handle numerous interface needs — particularly those beyond thecapabilities of standard logic buffers.The ULN2004A/L and ULN2024A/L have series input resistors foroperation directly from 6 to 15 V CMOS or PMOS logic outputs.The ULN2003A/L and ULN2004A/L are the standard Darlingtonarrays. The outputs are capable of sinking 500 mA and will withstandat least 50 V in the OFF state. Outputs may be paralleled for higherload current capability. The ULN2023A/L and ULN2024A/L willwithstand 95 V in the OFF state.These Darlington arrays are furnished in 16-pin dual in-line plasticpackages (suffix “A”) and 16-lead surface-mountable SOICs (suffix“L”). All devices are pinned with outputs opposite inputs to facilitateease of circuit board layout. All devices are rated for operation over thetemperature range of -20°C to +85°C. Most (see matrix, next page) arealso available for operation to -40°C; to order, change the prefix from“ULN” to “ULQ”.FEATURESI TTL, DTL, PMOS, or CMOS-Compatible InputsI Output Current to 500 mAI Output Voltage to 95 VI Transient-Protected OutputsI Dual In-Line Plastic Package or Small-Outline IC PackageHIGH-VOLTAGE, HIGH-CURRENTDARLINGTON ARRAYS
Dwg. No. A-959416151413126117108912345
Note that the ULN20xxA series (dual in-linepackage) and ULN20xxL series (small-outlineIC package) are electrically identical and sharea common terminal number assignment.ABSOLUTE MAXIMUM RATINGSOutput Voltage, VCE(ULN200xA and ULN200xL)........ 50 V(ULN202xA and ULN202xL)........ 95 VInput Voltage, VIN................................ 30 VContinuous Output Current,IC................................................. 500 mAContinuous Input Current, IIN........... 25 mAPower Dissipation, PD(one Darlington pair)..................... 1.0 W(total package)....................... See GraphOperating Temperature Range,TA.................................. -20°C to +85°CStorage Temperature Range,TS................................. -55°C to +150°C查询2003供应商2003 THRU 2024HIGH-VOLTAGE,HIGH-CURRENTDARLINGTON ARRAYS
115 Northeast Cutoff, Box 15036Worcester, Massachusetts 01615-0036 (508) 853-5000VCE(MAX)50 V95 VIC(MAX)500 mA500 mALogicPart Number5VULN2003A*ULN2023A*TTL, CMOSULN2003L*ULN2023L6-15 VULN2004A*ULN2024ACMOS, PMOSULN2004L*ULN2024L*Also available for operation between -40°C and +85°C. To order, changeprefix from “ULN” to “ULQ”.
Dwg. No. A-9651COM7.2K3K2.7K
X = Digit to identify specific device. Specification shown applies to family ofdevices with remaining digits as shown. See matrix above.Copyright © 1974, 1998 Allegro MicroSystems, Inc.Dwg. No. A-9898AULN20x4A/L (Each Driver)COM7.2K3K10.5K50751001251502.5
0.50ALLOWABLE PACKAGE POWER DISSIPATION IN WATTS
AMBIENT TEMPERATURE IN °C2.01.51.025SUFFIX 'L', R = 90°C/WθJADwg. GP-006ASUFFIX 'A', R = 60°C/WθJAULN20x3A/L (Each Driver)DEVICE PART NUMBER DESIGNATION
PARTIAL SCHEMATICS2003 THRU 2024HIGH-VOLTAGE,HIGH-CURRENTDARLINGTON ARRAYS
www.allegromicro.comTestApplicableLimits Characteristic SymbolFig.Devices Test ConditionsMin.Typ.Max.UnitsOutput Leakage CurrentICEX1AAllVCE = 50 V, TA = 25°C—< 150µAVCE = 50 V, TA = 70°C—< 1100µA1BULN2004A/LVCE = 50 V, TA = 70°C, VIN = 1.0 V—< 5500µACollector-EmitterVCE(SAT)2AllIC = 100 mA, IB = 250 µA—0.91.1VSaturation VoltagelC = 200 mA, IB = 350 µA—1.11.3VIC = 350 mA, IB = 500 µA—1.31.6VInput CurrentIIN(ON)3ULN2003A/LVIN = 3.85 V—0.931.35mAULN2004A/LVIN = 5.0 V—0.350.5mAVIN = 12 V—1.01.45mAIIN(OFF)4AlllC = 500 µA, TA = 70°C5065—µAInput VoltageVIN(ON)5ULN2003A/LVCE = 2.0 V, lC = 200 mA——2.4VVCE = 2.0 V, IC = 250 mA——2.7VVCE = 2.0 V, lC = 300 mA——3.0VULN2004A/LVCE = 2.0 V, lC = 125 mA——5.0VVCE = 2.0 V, lC = 200 mA——6.0VVCE = 2.0 V, IC = 275 mA——7.0VVCE = 2.0 V, lC = 350 mA——8.0VInput CapacitanceCIN—All—1525pFTurn-On DelaytPLH8All0.5 EIN to 0.5 EOUT—0.251.0µsTurn-Off DelaytPHL8All0.5 EIN to 0.5 EOUT—0.251.0µsClamp DiodeIR6AllVR = 50 V, TA = 25°C——50µALeakage CurrentVR = 50 V, TA = 70°C——100µAClamp DiodeVF7AllIF = 350 mA—1.72.0VForward VoltageComplete part number includes suffix to identify package style: A = DIP, L = SOIC.Types ULN2003A, ULN2003L, ULN2004A, and ULN2004LELECTRICAL CHARACTERISTICS at +25°C (unless otherwise noted).
