Page 1U□38□4X SeriesSingle Color φ3 Flush Mount Round Shape Type
Recommended ApplicationsAmusement Equipment,Electric Household Appliances, OA/FA, Other General Applications
・Outer Dimension φ3 Round shape type・Operation temperature range.Storage Temperature:-40℃～100℃Operating Temperature:-40℃～85℃・Lead–free soldering compatible・RoHScompliant
Dominant wavelengthBlue: 470nm (UB)Blue Green: 505nm (UC)Green: 525nm (UG)Yellow: 590nm (UY)Red: 626nm (UR)
Product features
Half Intensity AngleDie materialsUB,UC,UG : InGaN, UY,UR : AlGaInP
UB,UC,UG: 56 deg.UY,UR: 66 deg.
FeaturesPackageφ3 Round shape type,
UB,UC,UG: Water Clear epoxy UY: Pale Yellow Clear epoxy UR: Pale Red Clear epoxy
Rank grouping parameterSoldering methodsESDPackingTTW (Through The Wave) soldering and manual solderingInGaN: Less than 1kV(HBM),AlGaInP: More than 2kV(HBM)Bulk : 200pcs(MIN.)Sorted by luminous intensity per rank taping2006.7.31
元器件交易网www.cecb2b.comColor and Luminous Intensity
Page 2TYP.IFMIN.TYP.IF
UB3804XInGaNBlue4702024067220
UC3804XInGaNBlue Green505206722,68820UG3804XInGaNGreen525209602,68820UY3864XAlGaInPYellowPaleYellow5902025050020UR3864XAlGaInPRedPaleRed6302022044020
WaterClear
Part No.MaterialEmittedColorLensColor
ClearIv (mcd)
Luminous IntensityDominantWavelength
λd (nm)
2004.10.29Single Color φ3 Flush Mount Round Shape TypeU□38□4X Series(Ta=25℃)
元器件交易网www.cecb2b.comPage 3Absolute Maximum Ratings
UBUCUGUYURPower DissipationPd105105105150150mW
Forward CurrentIF2525255050mA
Pulse ForwardCurrent ※1IFRM606060100100mA
Derating(Ta=25℃ or higher)⊿IF0.330.330.330.670.67mA/℃
Reverse VoltageVR55555V
OperatingTemperatureTopr℃StorageTemperatureTstg℃ItemSymbolUnitAbsolute Maximum Ratings-40~+85
-40~+100
2004.10.29
Single Color φ3 Flush Mount Round Shape TypeU□38□4X Series※1 IFRM Measurement condition : Pulse Width≦1ms., Duty≦1/20.(Ta=25℃)
元器件交易网www.cecb2b.comElectro-Optical Characteristics
Page 42004.10.29
Single Color φ3 Flush Mount Round Shape TypeU□38□4X Series ConditionsUBUCUGUYURTYP.3.73.73.72.22.2MAX.4.24.24.22.82.8Reverse CurrentVR=5VIRMAX.100100100100100μAPeak WavelengthIF=20mAλpTYP.465502517592641nmDominantWavelengthIF=20mAλdTYP.470505525590630nm
Spectral Line HalfWidthIF=20mA⊿λTYP.2630351818nm
Half Intensity AngleIF=20mA2θ1/2TYP.5656566666deg.
ItemSymbolUnitForward VoltageIF=20mAVFV
Characteristics(Ta=25℃)
元器件交易网www.cecb2b.comLuminous Intensity Rank
Page 5Single Color φ3 Flush Mount Round Shape TypeU□38□4X Series(Ta=25℃)
MIN.MAX.MIN.MAX.MIN.MAX.MIN.MAX.MIN.MAX.A6721,344250500220440
B9601,920350700300600
C2404801,3442,6889601,9205001,000440880
D3366721,9203,8401,3442,6887001,4006001,200
E4809602,6885,3761,9203,8401,0002,0008801,760
F6721,3443,840-2,6885,3761,400-1,200-
G9601,9203,8407,680
H1,344-5,376-
RankUCUGUYConditionIF = 20mAURUB
IV（mcd）
Please contact our sales staff concerning rank designation of UYand UR.
2004.12.27
元器件交易网www.cecb2b.comSpectral DistributionRelative Intensity vs. WavelengthCondition : Ta = 25℃, IF= 20mA
Wavelength[nm]
Page 62004.10.29
Single Color φ3 Flush Mount Round Shape TypeU□38□4X Series Spatial Distribution ExampleCondition : Ta = 25℃
Relative Intensity
Forward Voltage vs. Forward CurrentCondition : Ta = 25℃Forward Voltage VF(V)Forward Current IF(mA)Forward Current vs. Relative IntensityCondition : Ta = 25℃
Forward Current IF(mA)Relative Intensity
Technical Data(UB)元器件交易网www.cecb2b.comPage 72004.10.29
Single Color φ3 Flush Mount Round Shape TypeU□38□4X Series Ambient Temperature vs. Relative IntensityCondition : IF=20mAAmbient Temperature : Ta(℃)DeratingAmbient Temperature vs. Maximum Forward CurrentRepetition Frequency : f ≧50Hz
Ambient Temperature : Ta(℃)Maximum Forward Current : IFMAX. (mA)
Relative Intensity
Technical Data(UB)
Ambient Temperature vs. Forward VoltageAmbient Temperature : Ta(℃)Forward Voltage VF(V)Power Dissipation vs. Ambient TemperatureAmbient Temperature : Ta(℃)Power Dissipation : Pd (mW)
