A. product overview
Along with raising the level of the national economy, the car
retains the quantity is rising continuously, have a favorite car
is an exciting thing, but, you do not know the riders have not
considered a very easily neglected problems? Automobile engine
room into a mouse playground! Mouse likes the dark,warmplace,is
the ideal choice of automobile cabin. Every time when the
temperature is low, there are always some owners complain in the
engine room and into the mouse. Those damned rats, fatally damage
to the car, they will bite the wires, causing a short circuit caused
by spontaneous combustion of the automobile, serious when can
crash!
Guangzhou Ke Jie Technology Co, the company invested nearly three
years of time, finslly the research and development of automotive
electronic rat repelling device successful domestic most advanced.
Big Cat brand Electronic Pest Repeller, using high frequency
ultrasound and LED light , imitate the dark of the cat’s eye,
flooding the rat, has the characteristics of low power consumption,
no pollution and good effect. At the same time, Big Cat Pest
Repeller has licensing Exclusive Sensing power supply variation
and Vibration start-stop technology, according to auto start stop,
to achieve energy-saving, deratization effect.
B. technical parameters
Electric performance parameters:
Working
Voltage: 12V DC
Working
current ＜40mA
Ultrasonic
Frequency: 20---60KHz
Indicator light
Driving: 60 seconds Pest Repeller stops working: light is off
Parking: 90 seconds Pest Repeller start working: Mode 1 red, 2
blue, 3 purple, 4 red and blue flashing
Fully automatic stop: when the car is exercising about 10 seconds
after the car stops working, when the car stops ( the engine is off)
About 90 seconds, Pest Repeller start work.
C. Method of use
（1） first, open the car engine cover, The big cat brand Pest
Repeller is fixed in the cabin interior a suitable place. Then, will
be a period of silicone power line of the products come with insertion
products power input port, the other end to the positive poles are
respectively connected to the battery cell. Press the ON/OFF switch,
select the ultrasonic mode.
The product innovation with the vibration switch and voltage detection technology, According to whether the engine vibration and
the engine is started automatically switch control Pest Repeller.
When the automobile is started,rat repelling device stops working,
enter the sleep state; when the car flameout, mouse drive began to
work.
Red and blue lights each represents an ultrasonic wave.
(2)the product of the insurance tube anode wire connection in the
power supply line above. Insurance current of 0.5A. If it is found
that the machine does not work, first consider whether the fuse is
burned.
(3) Big Cat brand Pest Repeller, high frequency ultrasonic
technology, Let the mouse inside the cabin irritability and escaped.
(4) the product by ultrasonic and glare flooding rat
technology ,specific technical parameters ,please refer to the
instructions second.
(5)Press the on / off switch,is set as follows: Long press 2 seconds
off→
①silent mode ( normal rat repelling ) →②in a low voice mode
( enhancement mode ) → ③l oudly mode ( super mode ) →④mode(①―③mode cycle). The user can choose according to need, mode.
(6)This product is built in voltage sensor, when the car is close
to the lowest starting voltage, the drive is closed. Put an end to
a long time not to drive, the car is hard to start.
D. The matters needing attention (1)not professionals do not open the shell;
(2)do not use in humid environment;
(3)if the product quality problems, please contact as soon as
possible Ke jie technology.
一、产品概述
随着经济水平的提高，全国汽车保有量不断上升，拥有一部心仪的汽车是一件令人兴奋的事。但是，不知道各位车友有没有考虑过一件非常容易忽视的问题呢？汽车发动机舱变成老鼠的游乐场！老鼠喜欢黑暗、温暖的地方，汽车发动机舱是理想的选择。每到气温较低的时候，总有一些车主抱怨发动机舱中又进了老鼠。这些可恶的老鼠，会给汽车带来致命的伤害，它们会咬破电线，造成短路引发汽车自燃，严重时可车毁人亡！
广州科捷科技有限公司投入近三年时间，终于研发成功国内最先进的汽车电子驱鼠器。大猫牌智能驱鼠器，采用高频率的超声波和LED强光，模仿黑暗中的猫眼，进行驱鼠，具有低功耗、无污染、效果好的特点。同时，大猫牌智能驱鼠器具有独家专利的感知电源变化加震动启停技术，可根据汽车启停，达到节能、驱鼠的效果。
二、技术参照
性能参数：
工作电压： 12V DC
工作电流 ＜40mA
超声波频率 20―60KHz
指示灯功能
行车： 60秒驱鼠器自动停止工作：指示灯熄灭
停车： 90秒驱鼠器自动启动工作：模式1红，2蓝，3紫，4红、蓝闪动
全自动启停：当汽车行驶约60秒内驱鼠器自动停止工作，当汽车停止（发动机关闭）约90秒内驱鼠器自动启动开始工作。
三、安装使用方法
（1）首先，打开汽车发动机机盖，将大猫牌驱鼠器固定在机舱内部一个合适的地方。然后，将本产品附带的防火电源线的一段插入产品电源输入插口，将另一端按着正负极分别接到电瓶上。按动ON/OFF开关，指示灯亮，开始工作。再按按钮，可选择超声波工作模式。
本产品创新性的采用震动开关和电压检测技术，可根据发动机是否震动和发动机是否启动来控制驱鼠器开关。当汽车发动时，驱鼠器自动停止工作，进入休眠状态；当汽车熄火时，驱鼠器自动开始工作。
红色灯、蓝色灯、紫色灯、红蓝灯闪动各代表一种驱鼠。
(2)本产品的保险管连接在电源的正极线上面。保险电流为0.5A。如果发现
