2007. 2. 91/6SEMICONDUCTOR
TECHNICAL DATAKR32S018M/F~KR32S033M/F
BIPOLAR LINEAR INTEGRATED CIRCUIT
Revision No : 0300POWER LOW DROPOUT REGULATOR
The KR32SXXXM/F is an efficient linear voltage regulator with very low
dropout voltage (Typically 10mV at light loads and 250mV at 300)
The KR32SXXXM/F can be enabled, or shut down by a CMOS or TTL
compatible signal. When disabled. power consumption drops nearly to zero.
Dropout ground current is minimized to help prolong battery life. Other key
features include reversed battery protechion, current limiting, over temperature
shutdown, and low noise performance with an ultra-low-noise option
FEATURES
High output voltage accuracy : 1%
Low quiescent current. : IQ(OFF)=3
Very low ground current : 1.8(IOUT=150)
Low dropout voltage : 250mV (IOUT=300)
Built-in ON/OFF control terminal
Built -in over current , Over heat protection function
Reverse-battery protection
APPLICATIONS
Laptop, notebook, and palmtop computers
Cellular telephones and battery-powered equipment
Consumer and personal electronics
PC Card VCCand VPP regulation and switching
SMPS post-regulator/dc-to-dc modules
High-effciency linear power suppliesDIMMILLIMETERS
A
B
D
E
TSV2.9 0.2
1.6+0.2/-0.1
0.70 0.05
0.4 0.1
2.8+0.2/-0.3
1.9 0.2
0.95
0.16 0.05
0.00-0.10
0.25+0.25/-0.15C
F
G
H
I
J
K0.60
L0.55AFG
G
DBE
CL
HJJI2
315
4
2
315
4+_
+_
+_
+_
+_
1. VIN2. GND3. ON/OFF CONTROL4. BYPASS5. VOUT
LINE-UPDIM
A
B
D
E
G
H
K
SOT-89-5C
JIA
B
FMILLIMETERSC
G
HJK
ID
EF54
132
1233.00 0.03+_
0.42 0.03+_
1.50 0.03+_
0.47 0.03+_
0.31 0.02+_
1.50 0.07+_1.60 0.10+_
0.90 0.08+_
2.50 0.05+_4.50 0.10+_
4.30 0.15+_
1. BYPASS2. GND3. ON/OFF CONTROL4. VIN5. VOUT
* Heat sink is common to 2.GNDVOUT(V)TSVSOT-89-5
ITEMMARKINGITEMMARKING
1.8KR32S018MB18KR32S018FD1
2.5KR32S025MB25KR32S025FD2
2.6KR32S026MB26KR32S026FD3
2.7KR32S027MB27KR32S027FD4
2.8KR32S028MB28KR32S028FD5
2.85KR32S285MB2JKR32S285FD6
2.9KR32S029MB29KR32S029FD7
3.0KR32S030MB30KR32S030FD8
3.1KR32S031MB31KR32S031FD9
3.3KR32S033MB33KR32S033FD0元器件交易网www.cecb2b.com
2007. 2. 92/6KR32S018M/F~KR32S033M/FRevision No : 1Fig. 1 BLOCK DIAGRAM
Current Limit
Thermal ShutdownBandgapRef. VOUT
COUT VIN
GND+BYPASS
CBYPASS
ON/OFFCONTROL1
234
523154Lot No.Type Name
Fig. 2 TEST CIRCUIT / APPLICATION CIRCUIT
VOUT = 2.8V
COUT = 2.2 µF (tantalum) VIN = 3.8V
CBYPASS = 470pFON/OFF
CONTROL1
2
3
45
KR32S028MMARKING
PIN NO.NAMEFUNCTION
1VINSupply Input
2GNDGround
3ON/OFF
ControlEnable/Shutdown (Input):CMOS conpatible
input. Logic high = Enable, Logic
low or open = Shutdown
4BypassReference Bypass : Connect external 470pF
capacitor to GND to reduce output
noise. May be left open
5VOUTRegulator OutputPIN DESCRIPTIONS
54
132Lot No.
Type NamePIN DESCRIPTIONSMARKING
PIN NO.NAMEFUNCTION
1BypassReference Bypass : Connect external 470pF
capacitor to GND to reduce output
2GNDGround
3ON/OFF
ControlEnable/Shutdown (Input):CMOS conpatible
input. Logic high = Enable, Logic
low or open = Shutdown
4VINSupply Input
5VOUTRegulator Output< SOT-89-5 >< TSV >元器件交易网www.cecb2b.com
2007. 2. 93/6KR32S018M/F~KR32S033M/FRevision No : 1ELECTRICAL CHARACTERISTICS
(Unless otherwise specified, VIN=VOUT+1V, IOUT=100, COUT=4.7, Tj=25) MAXIMUM RATINGS (Ta=25)
Note) Package mounted on a ceramic board. (600m20.8m)CHARACTERISTICSYMBOLRATINGUNIT
Supply Input VoltageVIN16V
ON/OFF Control VoltageVC5V
Output CurrentIOUT300
Power Dissipation (Note)TSVPD900mW
SOT-89-5
Junction TemperatureTj150
Operating Junction TemperatureTopr-40~125
Storage TemperatureTstg-55~150CHARACTERISTICSYMBOLTEST CONDITIONMIN.TYP.MAX.UNIT
Output Voltage KR32S018M/F
VOUTVIN=VOUT+1V1.7821.81.818
VKR32S025M/F2.4752.52.525
KR32S026M/F2.5742.62.626
KR32S027M/F2.6732.72.727
KR32S028M/F2.7722.82.828
KR32S285M/F2.82152.852.8785
KR32S029M/F2.8712.92.929
KR32S030M/F2.973.03.03
KR32S031M/F3.0693.13.131
KR32S033M/F3.2673.33.333
Load RegulationReg LoadIo=100~300-0.050.7%
Line RegulationReg LineVIN=VOUT+1V~12V-0.0090.05%/V
Dropout VoltageVD-1IOUT=100-1060
VD-2IOUT=50-115175
VD-3IOUT=150-175300
VD-4IOUT=300-250400
Temperature Coefficient of output voltageTCVoTj=-40125-4080ppm/
Ripple RejectionRRf=120Hz-75-
Output Noise VoltageVNOIOUT=50, COUT=2.2,
CBYPASS=470pF-30-rms
Output ON-state voltage for controlVC(ON)-2.0--V
Output ON-state current for controlIC(ON)VC=2.0V2520
Output OFF-state voltage for controlVC(OFF)---0.4V
Output OFF-state current for controlIC(OFF-1)VC=0.4V-0.01-1
IC(OFF-2)VC=0.18V-0.01-2
Quiescent CurrentIQ1VC=3V, IOUT=100-80130
IQ2VC=3V, IOUT=50-350650
IQ3VC=3V, IOUT=150-1.82.5
IQ4VC=3V, IOUT=300-4.05.5
Quiescent Current (OFF Mode)IQ(OFF-1)VC=0.4V-0.053
IQ(OFF-2)VC=0.18V-0.108元器件交易网www.cecb2b.com
