BA282/BA283Document Number 85526Rev. 1.7, 05-Dec-07Vishay Semiconductorswww.vishay.com1

94 9367For technical support, please contact: Diodes-SSP@vishay.com

Band Switching DiodesFeatures •Silicon planar diodes •Low differential forward resistance •Low diode capacitance •High reverse impedance •Lead (Pb)-free component •Component in accordance to RoHS 2002/95/ECand WEEE 2002/96/EC

Applications •Band switching in VHF-tuners

Mechanical DataCase: DO35 glass caseWeight: approx. 125 mgCathode band color: blackPackaging codes/options:TR/10 k per 13" reel (52 mm tape), 50 k/boxTAP/10 k per ammopack (52 mm tape), 50 k/box

Parts Table

Absolute Maximum RatingsTamb = 25°C, unless otherwise specified

Thermal CharacteristicsTamb = 25°C, unless otherwise specified

PartType differentiationOrdering codeType markingRemarksBA282rf = max. 1.0 Ω at IF = 3 mABA282-TR or BA282-TAPBA282Tape and reel/ammopackBA283rf = max. 1.2 Ω at IF = 3 mA

BA283-TR or BA283-TAPBA283Tape and reel/ammopack

ParameterTest conditionSymbolValueUnitReverse voltageVR35VForward continuous currentIF100mA

ParameterTest conditionSymbolValueUnitThermal resistance junction to ambient airl = 4 mm, TL = constantRthJA350K/WJunction temperatureTj150°CStorage temperature rangeTstg- 55 to +150°C

e2元器件交易网www.cecb2b.comwww.vishay.com2Document Number 85526Rev. 1.7, 05-Dec-07

BA282/BA283Vishay Semiconductors

For technical support, please contact: Diodes-SSP@vishay.comElectrical CharacteristicsTamb = 25°C, unless otherwise specified

Typical CharacteristicsTamb = 25°C, unless otherwise specified

Package Dimensions in millimeters (inches): DO35

ParameterTest conditionPartSymbolMin.Typ.Max.UnitForward voltageIF = 100 mAVF1000mVReverse currentVR = 20 VIR50nA

Diode capacitancef = 100 MHz, VR = 1 VCD1.7pFf = 100 MHz, VR = 3 VBA282CD1.5pFBA283CD1.2pF

Differential forward resistancef = 200 MHz, IF = 3 mABA282rf1.0Ω

BA283rf1.2Ωf = 200 MHz, IF = 10 mABA282rf0.7Ω

BA283rf0.9ΩReverse impedancef = 100 MHz, VR = 1 Vzr100kΩ

Figure1. Differential Forward Resistance vs. Forward Current0.11100.1110100rf - Differential Forward Resistance (Ω)IF - Forward Current (mA)10094 9072BA282BA283f = 200 MHzTj = 25 °CFigure2. Diode Capacitance vs. Reverse Voltage0.111000.51.01.52.03.0

CD - Diode Capacitance (pF)

10094 9073

2.5VR - Reverse Voltage (V)

Tj = 25 °Cf = 200 MHzBA283BA282

94 936626 min. (1.024)3.9 max. (0.154)26 min. (1.024) 0.

5

5

max. (0.022)Cathode Identification

1.7 (0.067)1.5 (0.059)Rev. 6 - Date: 29. January 2007Document no.: 6.560-5004.02-4

元器件交易网www.cecb2b.comBA282/BA283Document Number 85526Rev. 1.7, 05-Dec-07Vishay Semiconductorswww.vishay.com3For technical support, please contact: Diodes-SSP@vishay.com

Ozone Depleting Substances Policy StatementIt is the policy of Vishay Semiconductor GmbH to1.Meet all present and future national and international statutory requirements.2.Regularly and continuously improve the performance of our products, processes, distribution and operatingsystems with respect to their impact on the health and safety of our employees and the public, as well astheir impact on the environment.

It is particular concern to control or eliminate releases of those substances into the atmosphere which areknown as ozone depleting substances (ODSs).

The Montreal Protocol (1987) and its London Amendments (1990) intend to severely restrict the use of ODSsand forbid their use within the next ten years. Various national and international initiatives are pressing for anearlier ban on these substances.

Vishay Semiconductor GmbH has been able to use its policy of continuous improvements to eliminate the useof ODSs listed in the following documents.

1.Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendmentsrespectively

2.Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the EnvironmentalProtection Agency (EPA) in the USA

3.Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C (transitional substances) respectively.Vishay Semiconductor GmbH can certify that our semiconductors are not manufactured with ozone depletingsubstances and do not contain such substances.

We reserve the right to make changes to improve technical design and may do so without further notice.Parameters can vary in different applications. All operating parameters must be validated for each customer application by the customer. Should the buyer use Vishay Semiconductors products for any unintended or unauthorized application, the buyer shall indemnify Vishay Semiconductors against all claims, costs, damages, and expenses, arising out of, directly or indirectly, any claim of personal damage, injury or death associated with such unintended or unauthorized use.
