Friction，Lubrication of Bearing
In many of the problem thus far,Friction has been disregard or neglect friction. Actually,friction is present to some degree whenever two parts are in contact and move on each other.The term friction refers to the resistance of two or more parts to movement.
Friction is harmful or valuable depending upon where it occurs.friction is necessary for fastening devices such as screws and rivets which depend upon friction to hold the fastener and the parts together. Belt drivers, brakes, and tires are additional applications where friction is necessary.
The friction of moving parts in a machine is harmful because it reduces the mechanical advantage of the device.The heat produced by friction is lost energy because no work takes place.Although greater power is required to overcome the increased friction.Heat is destructive in that it causes expansion.Expansion may cause a bearing or sliding surface to fit tighter.If a great enough pressure builds up because made from low temperature materials may melt.
There are three types of friction which must be overcome in moving parts: starting,sliding,and rolling.Starting friction is the friction between two solids that tend to resist movement.When two parts are at a state of rest,the surface irregularities of both parts tend to interlock and form a wedging action.To produce motion in these parts,the wedge-shaped peaks and valleys of the stationary surfaces must be made to slide out and over each other.The rougher the two surfaces,the greater is starting friction resulting from their movement.
Since there is usually no fixed pattern between the peaks and valleys of two mating parts,the irregularities do not interlock once the parts are in motion but slide over each other.The friction of the two surfaces is known as sliding friction.As shown in figure,starting friction is always greater than sliding friction.
Rolling friction occurs when roller devces are subjected to tremendous stress which cause the parts to change shape or deform.Under these conditions,the material in front of a roller tends to pile up and forces the object to roll slightly uphill.This
changing of shape,known as deformation,causes a movement of molecules.As a result,heat is produced from the added energy required to keep the parts turning and overcome friction.
The friction caused by the wedging action of surface irregularities can be overcome partly by the precision machining of the surfaces. However,even these smooth surfaces may require the use of a substance between them to reduce the friction still more.This substance is usually a lubricant which provides a fine,thin oil film.The film keeps the surfaces apart and prevents the cohesive forces of the surfaces from coming in close contact and producing heat.
Another way to reduce friction is to use different materials for the bearing surfaces and rotating parts.This explains why bronze bearings,soft alloys,and copper and tin iolite bearings are used with both soft and hardened steel shaft.The iolite bearing is porous.Thus,when the bearing is dipped in oil,capillary action carries the oil through the spaces of the bearing.This type of bearing carries its own lubricant to the points where the pressures are the greatest.
Moving parts are lubricated to reduce friction,wear,and heat.The most commonly used lubricants are oils,greases,and graphite compounds.Each lubricant serves a different purpose.The conditions under which two moving surfaces are to work determine the type of lubricant to be used and the system selected for distributing the lubricant.
On slow moving parts with a minimum of pressure,an oil groove is usually sufficient to distribute the required quantity of lubricant to the surfaces moving on each other.
A second common method of lubrication is the splash system in which parts moving in a reservoir of lubricant pick up sufficient oil which is then distributed to all moving parts during each cycle.This system is used in the crankcase of lawn-mower engines to lubricate the crankshaft,connecting rod ,and parts of the piston.
A lubrication system commonly used in industrial plants is the pressure system. In this system,a pump on a machine carries the lubricant to all of the bearing surfaces at a constant rate and quantity.
