VE-24HSE-K-VD中文资料

  • 格式：pdf
  • 大小：131.16 KB
  • 文档页数：6

s FEATURESqUL, CSA, VDE recognizedq1 form A (SPST-NO) or 1 form C (SPDT) contact

qLow cost, miniature relay with big performance in smallpackage—Surge strength: 4,000 V or 6,000 V

qSlim type—meets high density mounting requirement

qWide operating range

qEasy circuit design with completely separated terminalarrangement (coil and contact terminals)

qPlastic sealed type backfilled with nitrogen

(a)Series NameVE: VE Series(b)Nominal VoltageRefer to the COIL DATA CHART(c)Contact RatingH: Heavy duty type(d)Contact ArrangementNil: 1 form C (SPDT)M: 1 form A (SPST-NO)

(e)Coil TypeNil: Standard typeS: High sensitivity type

(f)Contact Material (Rating)Nil: Gold overlay silver-nickel (N.C.: 3 A, N.O.: 5 A)E: Silver-nickel (N.C.: 3 A, N.O.: 5 A)5: Silver alloy (N.C.: 5 A, N.O.: 5 A)

(g)EnclosureK: Plastic sealed type(h)Surge StrengthNil: Standard type (4,000 V)HV: High dielectric strength type (6,000 V)

(i)StandardVD: UL, CSA, VDE approved typeNote:Actual marking omits the hyphen (-) of (*)

s ORDERING INFORMATIONVE–12HMSE–K–HV–VD[Example](a)(*)(b)(c)(d)(e)(f)(g)(h)(i)

VE SERIESFUJITSU TAKAMISAWACOMPONENT CATALOG

POWER RELAY1 POLE—5 A (MEDIUM LOAD CONTROL)

1

元器件交易网www.cecb2b.comVE SERIESs SAFETY STANDARD AND FILE NUMBERSUL508 (File No. E56140)C22.2 No. 14 (File No. LR35579)VDE0435Please note that UL/CSA ratings may differ from the standard ratings.

TypeNominal voltageContact ratingVE-H5 to 48 VDCNormally open:1/14 HP 125 VAC/250 VAC5 A 30 VDC/250 VAC, resistivePilot duty D300Normally close:1/14 HP 125 VAC/250 VAC3 A 30 VDC/250 VAC, resistivePilot duty D150

VE-HM5 to 48 VDC1/12 HP 125 VAC/250 VAC5 A 30 VDC/250 VAC, resistivePilot duty D300

VE-H55 to 48 VDCNormally open:VE-HM51/10 HP 125 VAC/250 VAC5 A 30 VDC/250 VAC, resistivePilot duty D300Normally close:1/14 HP 125 VAC/250 VAC5 A 30 VDC/250 VAC, resistive

元器件交易网www.cecb2b.comVE SERIESItemVE-( ) HME-KVE-( ) HE-KVE-( ) HM5-KVE-( ) H5-KVE-( ) HM-KVE-( ) H-K

ContactArrangement1 form A (SPST-NO) 1 form C (SPDT) 1 form A (SPST-NO) 1 form C (SPDT)MaterialGold overlay silver alloy Silver-cadmium oxide alloyStyleSingleResistance (initial) (at 1 A 6 VDC) Maximum 70 mΩ (VE-HM, H) Maximum 200 mΩMaximum 100 mΩ (VE-HME, HE)

Rating (resistive)5 A 250 VAC 5 A 250 VAC (N.O.) 5 A 250 VAC 3 A 250 VAC (N.C.)

Maximum Carrying Current7 AMaximum Switching Power1,250 VA 1,250 VA (N.O.) 1,250 VA 750 VA (N.C.)

Maximum Switching Voltage250 VAC, 150 VDCMaximum Switching Current5 A 5 A (N.O.) 5 A 3 A (N.C.)

Minimum Switching Load*110 mA, 5 VDC (VE-HM, H), 100 mA 5 VDC (VE-HME, HE, HM5, H5)CoilNominal Power (at 20°C)Standard type: 0.36 W. High sensitivity type: 0.25 WOperate Power (at 20°C)Standard type: 0.177 W. High sensitivity type: 0.13 WOperating TemperatureStandard: –40°C to +85°C. High sensitivity: –40°C to +90°C (no frost)Time ValueOperate (at nominal voltage)Maximum 10 msRelease (at nominal voltage)Maximum 5 msInsulationResistance (at 500 VDC)Minimum 1,000 MΩ between open 1,000 VAC 1 minute 750 VAC 1 minute 1,000 VAC 1 minute 750 VAC 1 minute

Dielectric contacts

Strength between coil

2,000 VAC 1 minute and contacts

Surge StrengthStandard type: 4,000 V (at 2 × 10 µs)High dielectric strength type: 6,000 V (at 2 × 10 µs)

LifeMechanical1 × 107 operations minimumElectrical (at Rating)Standard Type: 1 × 105 ops. min. High sensitivity type: 5 × 104 ops. min.OtherVibration Misoperation10 to 55 Hz (double amplitude of 3.3 mm)Resistance Endurance10 to 55 Hz (double amplitude of 3.3 mm)

Shock Misoperation 100 m/s2 (11 ±1 ms)Resistance Endurance500 m/s2 (6 ±1 ms)

WeightApproximately 8 g

s SPECIFICATIONS*1 Minimum switching loads mentioned above are reference values. Please perform the confirmation test with the actualload before production since reference values may vary according to switching frequencies, environmental conditionsand expected reliability levels.

元器件交易网www.cecb2b.comVE SERIESs COIL DATA CHARTMODELNominalCoilMustMustNominalVE-( ) HM VE-( ) HMEVE-( ) HM5voltageresistanceoperatereleasepowerVE-( ) HVE-( ) HEVE-( ) H5(±10%)voltagevoltage

VE- 5H (M) (E)-KVE- 5H (M) (E) 5-K 5 VDC 69 Ω 3.5 VDC0.25 VDC360 mWVE- 6H (M) (E)-KVE- 6H (M) (E) 5-K 6 VDC 100 Ω 4.2 VDC0.3 VDC360 mWVE- 9H (M) (E)-KVE- 9H (M) (E) 5-K 9 VDC 225 Ω 6.3 VDC0.45 VDC360 mWVE 12H (M) (E)-KVE-12H (M) (E) 5-K12 VDC 400 Ω 8.4 VDC0.6 VDC360 mWVE-18H (M) (E)-KVE-18H (M) (E) 5-K18 VDC 900 Ω12.6 VDC0.9 VDC360 mWVE-24H (M) (E)-KVE-24H (M) (E) 5-K24 VDC1,600 Ω16.8 VDC1.2 VDC360 mWVE-48H (M) (E)-KVE-48H (M) (E) 5-K48 VDC6,400 Ω33.6 VDC2.4 VDC360 mWVE- 5H (M) S (E)-KVE- 5H (M) S5-K 5 VDC 100 Ω 3.6 VDC0.25 VDC250 mWVE- 6H (M) S (E)-KVE- 6H (M) S5-K 6 VDC 145 Ω 4.3 VDC0.3 VDC250 mWVE- 9H (M) S (E)-KVE- 9H (M) S5-K 9 VDC 325 Ω 6.5 VDC0.45 VDC250 mWVE 12H (M) S (E)-KVE-12H (M) S5-K12 VDC 575 Ω 8.6 VDC0.6 VDC250 mWVE-18H (M) S (E)-KVE-18H (M) S5-K18 VDC1,300 Ω13.0 VDC0.9 VDC250 mWVE-24H (M) S (E)-KVE-24H (M) S5-K24 VDC2,310 Ω17.3 VDC1.2 VDC250 mWVE-48H (M) S (E)-KVE-48H (M) S5-K48 VDC9,220 Ω34.7 VDC2.4 VDC250 mWHi
