DELL 10G 刀片配置文档

10 G刀片配置文档
Hugh li 8月7号
一． 初始化CMC IP
使用超级终端连接到CMC的COM口。1口用户连接CMC web界面。
2口用户级连。5为COM口，进行命令行的初始化。

超级终端的设置请从参考下面的图片。
获取CMC 的IP。
Web 界面登陆CMC.

用户名和密码为root ，calvin
二．CMC web界面管理刀片

CMC的基本信息
CMC 获取刀片的日志。

三．CMC进行FW 升级。
通过CMC launch iDRAC

通过i DRAC 卡launch CMC.
交换机的基本信息。

单个刀片的基本信息。
四．交换机配置登陆：
root
Password:

Welcome to the CMC firmware version X04.1.0.200710051639
$ connect switch-1
Connected to remote port.
Escape character is '^\'.

console>
console>en

console#show ip interface out-of-band
IP Address..................................... 0.0.0.0
Subnet Mask.................................... 0.0.0.0
Default Gateway................................ 0.0.0.0
ServPort Configured Protocol Current........... None
Burned In MAC Address.......................... 001C.237B.E3C2

console#show ip interface
Management Interface:
IP Address..................................... 192.168.1.250
Subnet Mask.................................... 255.255.255.0
Default Gateway................................ 0.0.0.0
Burned In MAC Address.......................... 001C.237B.E3BF
Network Configuration Protocol Current......... None
Management VLAN ID............................. 1

Routing Interfaces:
Netdir Multi
Interface IP Address IP Mask Bcast CastFwd
---------- --------------- --------------- -------- --------

console#show ip interface󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀
󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀show ip interface out-of-band󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀
󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀
󰀀configure
console(config)#ip address 192.168.1.250 255.255.255.0
console(config)#username add=󰀀 󰀀󰀀 󰀀min delldell level 15
^
% Invalid input detected at '^' marker.

console(config)#username admin delldell level 15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀
󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀 delldell level 15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀p
delldell level 15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀a delldell level
15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀s delldell level
15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀s delldell level
15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀w delldell level
15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀o delldell level
15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀r delldell level
15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀d delldell level
15󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀󰀀

console(config)#run󰀀 󰀀󰀀 󰀀󰀀 󰀀copy u󰀀 󰀀running-config󰀀 󰀀󰀀 󰀀ig startup
^
% Invalid input detected at '^' marker.

console(config)#copy running-config startup󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀
󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀x󰀀 󰀀xi󰀀
󰀀󰀀 󰀀exit

console#exit󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀copy running-config startup
This operation may take a few minutes.
Management interfaces will not be available during this time.

Are you sure you want to save? (y/n) n
Configuration Not Saved!
console#show󰀀 󰀀󰀀 󰀀󰀀 󰀀󰀀 󰀀wi󰀀 󰀀󰀀 󰀀exit

console>󰀀(b󰀀[mconnect: setting console redirection failed
$

五．登陆交换机后的web配置界面。
