PolyWorks培训指南PolyWorks版本12.1适用于WindowsInnovMetric软件公司2013版权所有。
未经InnovMetric软件公司许可，严禁以任何方式复制部分或全部手册内容。
手册内容可用于以下明确目的：PolyWorks 授权分销商复制全部或部分内容，用以培训PolyWorks注册用户。
所有材料遵循:“经InnovMetric软件公司许可所复制的内容受InnovMetric软件公司2013 版权保护”。
文件内容仅供参考。
未经通知不得变更。
InnovMetric 软件公司对本文件所出现的任何错误或不准确不承担任何责任或义务。
PolyWorks Software Shanghai Co.LtdRoom B&C, 8th Floor, HUAMIN EMPIRE PLAZA, NO.728, Yan'an Road(W),Shanghai, PRC上海市长宁区延安西路728号华敏翰尊国际大厦8楼B、C座（邮编：200050）Tell: +86 21 6226 1617Fax: +86 21 5283 2153PolyWorks V12.1软件培训指南PolyWorks软件安装Win 7安装请注意：需要更改“控制面板”中的“用户账户控制设置”设置才能安装。
步骤如下：控制面板”导入许可证第一次运行PolyWorks 软件时，会自动弹出“许可证管理”的对话框。
单击“Add License Keys ”把许可证檔添加进去即可。
软件使用期限该许可证可使用的模块工作管理器的一些常用设置更改语言单击菜单栏里的“选项”按钮选择“Display”页面在Language里面选择语言。
Tips:如果选择中文的话，请安装Arial Unicode字体，这样就不会在软件里面出现乱码的问题。
更改完语言，一定要重起软件才能生效。
启动插件选择“插件”页面，把要使用的硬件插件名称“打勾”工作管理器主界面模块介绍模块图标向导窗口工作区目录树检测基本流程导入数模输入CAD模型或三角化模型作为理论数据获取实测数据可以通过导入点云或三角化模型作为实测数据，也可通过硬件的插件实时采集数据建立坐标系将实测数据和理论数据进行对齐解析数据通过彩图比较，断面线，量规，比较点等方法分析数据输出报告生成一个自动格式化报告，如有需要，还可自定义报告模板检测模块硬探测点击工作管理器里模块图标中的“检测模块”PolyWorks检测模块主接口导入数模在主对象菜单栏中点击“输入”点击“输入CAD模型”导入过程中，会弹出一个缀补公差的对话框，一般按默认的“0.01”设置就可以了。
