MD330用户手册

用户手册BluOS 串流DAC 放大器M33®1. 阅读说明书- 在使用本设备前必须阅读所有的安全和操作说明。

2. 保留说明书 - 安全和使用说明书应妥善保管以备后用。

3. 注意警告 - 本设备和使用说明书中标识的所有警告应予遵守。

4. 遵照说明 - 所有的操作和使用说明应予遵守。

5. 清洁须知 - 请在清洁本设备前将电源插头从墙上的电源插座上拔下。

请勿使用液体清洗剂或喷雾清洗剂。

请使用干燥的布料进行清洁。

6. 附件 - 为防止发生危险，请勿使用未经本设备生产商推荐的配件。

7. 水源与潮湿 - 请勿在水源附近使用本设备，如浴缸、洗脸盆、厨房水池、洗衣缸、潮湿的地下室、或靠近游泳池及其它类似的场所。

8. 配件 - 请勿将本设备放置在不稳定的推车、支架、三脚凳、托架或桌子上，因为如本产品跌落，有严重伤害儿童或成人并严重损坏本产品之虞。

请只使用由生产商推荐使用或跟本产品出售的推车、支架、三脚凳、托架或桌子。

将本产品安装在墙上或天花板时须遵照生产商之使用说明进行，并且须使用生产商推荐的安装配件。

9. 推车 - 用推车运载本设备的时候需要小心。

如疾速停下、过分用力和不平的地面都可能导致车载的本产品倾覆。

10. 通风 - 本设备机箱上的狭槽和开口是供通风之用，为确保本设备可靠操作以及防止过热而设置的。

千万不能堵塞或覆盖这些开口。

绝不能将本产品放在床、沙发、毯子等等其材料会堵塞这些开口的软物体上。

除非有足够的通风或遵照了生产商指示，不得将本产品放在书橱或机架等封闭的装置内。

11. 电源 - 本设备使用的电源必须是标签上所示的电源类型，并连接到带有保护接地连接的电源插座。

如您不清楚您家里使用什么电源，请咨询您的产品经销商或当地电力公司。

12. 保护电线 - 电线应该合理排布，以使电线不易被踩踏或被放置在上面的物品触压，特别要注意与插头接合部位的电线、简便插座、以及在本设备连接处的电线。

13. 电源插头 - 在电源插头或电器耦合器被用作断开设备的情况下，断开设备应确保易于操作。

MD3000多功能金属探测器使用说明书北京斯达恒通科技有限公司----------------------------------------------中国*北京产品名称：MD3000多功能金属探测器产品品牌：斯达恒通MD3000是一款通用的、多用途的金属探测器，适合警察、军队和个人使用。

满足犯罪现场和区域搜索、爆炸物清除以及事件检查的要求。

MD3000基于具有优异性能的MD2000研制而成，被世界各地的警察认可和使用。

新的探测器简单化操作，并改进了人体工程学设计和电池管理系统。

它具有防水功能，可以承受苛刻的环境并能提高灵敏度。

MD3000非常易于使用，具有直观的控制。

只需选择好相应的灵敏度（3档可调）等级即可使用，同时指示灯将亮绿色，如果指示灯闪烁表明电池电量低。

面板上的LED指示灯及音调表明所探测的目标，可以通过内置扬声器或二级监听声音。

探测器采用微处理器控制，执行持续的背景诊断和先进的电池管理功能。

仪器使用易于更换的3节D 电池。

节能设计使得一组电池可以使用大约12小时，亦可使用镍氢充电电池。

MD3000包含一个可互换的探测盘：一个坚固的用于快速区域搜索的探测盘，一个在受限空间用于精确探测的探针。

为保证高度可靠，电子器件采用电脑控制的设备组装和测试，封装在一个长的、坚固的人体工程学的箱内。

技术参数主要特征LED显示及声音指示探测目标3档灵敏度设置探测头可互换：圆形用于快速区域搜索，探针用于沟道/涵洞等，自动自我调试和校准功能使得操作者更自信和易于使用。

优化的电源功耗低电压指示控制关/灵敏度：旋钮4个档位瞬间零：下按按钮音频报警：旋转调节指示器：绿色LED指示电源开，闪烁表明电压低红色LED表示探测信号强度声音：不同的声音表明不同的探测目标周期的卡嗒声确保使用者正确使用电池电池：3节LR20电池操作时间：12小时连续操作（使用标准碱性电池，正常使用）重量：使用探针时：2.1kg使用使用探测盘时：2.4kg组成2部分组成，控制主体加可互换的探测盘或者探针式探头电子微处理器控制，自我校准探测电路，使用表面贴装PCB 温度范围-20°C -+50°C湿度：95%震荡可承受从0.75m摔落到混凝土上《北京斯达恒通科技有限公司》主营产品：环境安全检测仪器、消防救护破拆装备、应急救援器材、食品安全检测仪器、通风测绘仪表、粉尘测量及效验仪器、堵漏器材、安防安检防护器材等，已广泛应用于煤矿、救护队、石油化工、学校、实验室、建筑、交通、民航、物流、政府机构，以及各种厂矿企业。

REV1.3.0 1910011858User GuideFor TP-LINK Auranet Access PointsCOPYRIGHT & TRADEMARKSSpecifications are subject to change without notice. is a registered trademark of TP-LINK TECH NOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders.No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECH NOLOGIES CO., LTD. Copyright © 2016 TP-LINK TECH NOLOGIES CO., LTD. All rights reserved.FCC STATEMENT (EAP110/EAP320/EAP330/EAP225)This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:•Reorient or relocate the receiving antenna.•Increase the separation between the equipment and receiver.•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.•Consult the dealer or an experienced radio/ TV technician for help.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:1）This device may not cause harmful interference.2）This device must accept any interference received, including interference that may cause undesired operation.Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.FCC STATEMENT (EAP120/EAP220)This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radiocommunications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:1）This device may not cause harmful interference.2）This device must accept any interference received, including interference that may cause undesired operation.Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.FCC RF Radiation Exposure Statement:This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.‘‘To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.’’For EAP220/EAP320/EAP330/EAP225:This device is restricted in indoor environment only.CE Mark Warning(EAP110)This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.(EAP120)This is a class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.(EAP220)This is a class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.(EAP320/EAP330/EAP225)This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.RF Exposure InformationThis device meets the EU requirements (1999/5/EC Article 3.1a) on the limitation of exposure of the general public to electromagnetic fields by way of health protection.The device complies with RF specifications when the device used at 20 cm from your body.National Restrictions (EAP220/EAP320/EAP330/EAP225)Restricted to indoor use.Canadian Compliance StatementThis device complies with Innovation, Science and Economic Development Canada license-exempt RSSs. Operation is subject to the following two conditions:1）This device may not cause interference, and2）This device must accept any interference, including interference that may cause undesired operation of the device.Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1）l’appareil ne doit pas produire de brouillage;2）l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement.Caution (EAP220/EAP320/EAP330/EAP225)1）The device for operation in the band 5150---5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;2）For devices with detachable antenna(s), the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p.limits specified for point-to-point and non-point-to-point operation as appropriate; and The high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interferenceand/or damage to LE-LAN devices.Avertissement1）Le dispositif fonctionnant dans la bande 5150-5250 MHz est réservé uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux;2）Le gain maximal d'antenne permis pour les dispositifs avec antenne(s) amovible(s) utilisant la bande 5725-5850 MHz doit se conformer à la limitation P.I.R.E spécifiée pour l’exploitation point à point et non point à point, selon le cas.En outre, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.Radiation Exposure StatementThis equipment complies with ISEDC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance (20cm for EAP110/120, 26cm for EAP 220, 35cm for EAP 320, 46cm for EAP330, and 24cm for EAP225) between the radiator & your body.Cet équipement est conforme aux limites ISEDC d'exposition aux rayonnements établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé à une distance minimale (entre la source de rayonnement et votre corps) indiquée ci-après : Modèle DistanceEAP110/120 20 cmEAP220 26 cmEAP225 24 cmEAP320 35 cmEAP330 46 cmDéclaration d'exposition aux radiationsCet équipement est conforme aux limites d'exposition aux rayonnements ISEDC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 26 cm de distance entre la source de rayonnement et votre corps.(EAP220)Cet équipement est conforme aux limites d'exposition aux rayonnements ISEDC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 46 cm de distance entre la source de rayonnement et votre corps.(EAP330) Innovation, Science and Economic Development Canada Statement(EAP110/EAP320/EAP330/EAP225)CAN ICES-3 (B)/NMB-3(B)Innovation, Science and Economic Development Canada Statement(EAP120/EAP220)CAN ICES-3 (A)/NMB-3(A)Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних документів та вимогам, що передбачені чинними законодавчими актами України.Safety Information●When product has power button, the power button is one of the way to shut off the product;When there is no power button, the only way to completely shut off power is to disconnect the product or the power adapter from the power source.●Don’t disassemble the product, or make repairs yourself. You run the risk of electric shockand voiding the limited warranty. If you need service, please contact us.●Avoid water and wet locations.●Adapter shall be installed near the equipment and shall be easily accessible.●The plug considered as disconnect device of adapter.For EAP110(EU):Use only power supplies which are provided by manufacturer and in the original packing of this product. If you have any questions, please don't hesitate to contact us.NCC Notice & BSMI Notice注意！依據低功率電波輻射性電機管理辦法第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性或功能。

G e P re m ière u t L o g it e
c h ® W ir e le s s M o
© 2011 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned
by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice.
© 2011 Logitech。

著作权及其他知识产权声明：本产品及其包装与相关手册文件上所印载的「罗技」、「Logitech」，以及其他由罗技公司创作或发明之图案、文字、软件，其上所存之知识产权或其他权利（包含但不限于商标权、著作权、专利权），皆属罗技公司所有并保留一切权利。

凡未经合法授权而使用或复制上述罗技权利，将依法追究。

其他 非罗技商标，仍由各该商标所有人拥有其权利。

罗技对于本手册中可能出现的任何错误不承担任何责任。

本文中包含的信息如有更改，恕不事先通知。

620-003457.006。

MVP3300智能电气阀门定位器 Intelligent Electropneumatic valve Positioner用户手册User Manua1用户须知 (1)1.1安全指示 (1)1.2开箱清单 (1)1.3重要信息提示 (1)2概述 (1)2.1功能介绍 (2)2.2特点 (2)2.3防雷特性 (2)3技术参数 (3)4安装说明 (4)4.1外形尺寸 (4)4.2机构安装 (4)4.3气路连接 (7)4.4电气连接 (7)5调节操作 (9)5.1操作界面说明 (9)5.2用户菜单 (10)5.3初始化 (12)5.4诊断 (14)5.5报警 (14)5.6参数列表 (16)6参数解释 (17)7使用异常与维护保养 (21)7.1异常状况排除 (21)7.2维护保养 (22)8运输和贮存 (22)9订货须知 (23)9.1产品型号 (23)9.2其它可选项 (23)1用户须知1.1安全指示定位器先上电，后供气源；产品使用过程中，不要随意的触摸反馈连接装置；产品必须正确安装、正确操作和正确维护。

1.2开箱清单MVP3300智能阀门定位器；安装配件；用户手册；另外订制附件，详见装箱清单。

1.3重要信息提示为了您能更好地应用这份说明，以及保障你在调试，运行和维修这台仪器时的安全，请注意下列符号的用途：符号标语解说注意注意注意指潜在的危险，如不能避免，可能会损害产品本身或周围物体。

（危险物）提示提示提示是指有用的或特别的被忽视的能影响操作条件或产品功能的事物。

（不包含危险的或有害的情形）在安装和调试前请认真阅读此手册。

2概述MVP3300智能阀门定位器为深圳万讯自控股份有限公司推出的智能型两线制现场仪表。

本定位器作为气动阀门的配套控制部件，广泛运用于石油、化工、电力、冶金、轻工等领域的自动控制系统中。

MVP3300智能阀门定位器接受来自控制系统的4~20mA阀位设定信号，通过A/D转换得到阀位设定值；同时通过位置传感器得到实际的阀位信号;两者经过控制软件的计算处理，从而控制气动执行机构的进气与排气，驱动阀位到达设定点（如图1所示）MVP3300智能阀门定位器其采用德国原装进口压电阀等核心部件，是基于微处理器技术的高性能电/气阀门定位器，能很好地克服摩擦力和阀芯上的不平衡力，提高调节阀的响应速度，使其定位迅速准确。

FDR-330-M/Q面板型分界控制器（DC24V）安装使用说明书User’s Manual版本号：v 3.0尊敬的用户：为了您和设备的安全，在安装及使用本装置前，请认真阅读本说明书。

请妥善保存本说明书，以备查阅。

由于本产品技术不断更新，因此而引起的产品功能和性能的改变不包含在本说明书内，敬请谅解。

如果在安装及使用中遇到问题请与我司联系。

本说明书的解释权归我司，并保留一切权利。

安全信息本设备为交流220V 弱电设备，但在现场安装、维护时，附近有危险电压！本设备不能替代可见断开点，工作时应遵循所有当地批准的安全规程；否则，将因触高压导致严重人身伤亡。

本说明书并不能概括设备的安装、运行、维护等等的所有细节，如有问题请与我司联系。

接收、验货及存储每台FDR-330-M/Q 控制器在出厂前都经过了完整的装配、测试及检验，并进行了精心的校核、调整，运输前已经处于良好的状态。

接收时，仔细检查控制器在运输中有无损坏，如有问题，请立即向承运者提出书面报告。

包装件在装卸时小心轻放，避免碰伤和冲击，运输时应注意防水，严禁腐蚀性物品与包装件在同一车箱内运输。

如果本设备在安装前要存放相当长的时间，应放在清洁、通风良好的地方，空气中不得含有腐蚀性气体，存放时应小心，谨防损坏。

若控制器的后备电源为铅酸电池，其储存时间超过3 个月，应每过3 个月为电池充电一次，保证电池的使用寿命。

充电不少于24 小时。

目录1 概述 (4)1.1 应用 (4)1.2 特点 (4)2 技术性能指标 (5)2.1 使用环境条件 (5)2.2 电气技术参数 (5)2.3 主要技术指标 (6)2.4 电磁兼容 (7)2.5 绝缘耐压 (8)3 功能介绍 (8)3 主要功能 (8)3.1 遥控、遥测、遥信功能 (8)3.2 参数设置功能 (10)3.3 电源失电保护功能 (10)3.4 对时功能 (10)3.5 自诊断功能 (10)3.6 历史记录及上报功能 (11)3.7 故障检测 (11)3.8 通信功能 (12)3.9 当地调试功能 (12)3.10 高级故障处理功能 (12)4 参数说明 (14)4.1 盘面 (14)4.2 参数列表 (14)4.3 拨码盘整定值设置 (15)4.4 保护定值选择指南（以下所指电流为一次值） (16)5 附录 (17)5.1 线缆 (17)5.2 安装尺寸 (18)5.3 运输 (18)5.4 验收 (18)5.5 贮存 (18)6 检修：设备异常处理 (19)1.概述1.1应用FDR-330-MB 系列控制器是采用高速采样芯片和32 位高速单片机控制芯片相结合的新型高压开关控制器，能快速稳定的完成对高压开关的监控。

MODEL P330 说明书第三部分：软件功能CTROL PANEL 控制面板如图3－1所示包括显示面板，三个键盘和校验仪插件，表3－1所示DISPLAY PANEL 显示面板显示面板分为三部分：输入（进校验仪）和输出（从校验仪）和状态行/软格，图3－2显示了两种典型的显示，第一幅为状态行显示，第2幅为软格显示。

INPUT DISPLAY输入显示输入显示表示到校验仪中，例如，在P－V任务模式中，校验仪向传送器传送数据并从传送器接收一个信号，显示为电压，如上图3－2所示OUTPUT DISPLAY 输出显示输出显示表示从校验仪输出，同样在P－V任务模式中，校验仪送出压力信号给传送器并从传送器中接一个电压信号，输出显示为压力如图3－2所示STATUS LINE/SOFT BOX DISPLAY 状态行/软格显示若显示面板中只有一个显示行，则为状态行显示，若分为两格则为软格显示状态行显示指的是，校验仪在任务模式下，状态行显示任务模式名和存模式设置如图3－2所示：软格显示指的是，作出一个选择必须直接用三个功能键之一，按F1选择左软格的选项，按F2选择右软格的选项，按EXIT不作任何选择。

THE KEYPADS 键盘校验仪有3组键，如图3－3所示：ARROW KEYS(箭头键)：控制面板的下面，这些用来选择，显示面板中选项菜单，在选项内部切换，并输入数字和字母FUNCTION KEYS（功能键）:在显示的下方HARD KEYS (硬键)：控制面板的左边，硬键用法见表3－3箭头键用法见表3－2所示第四部分校验仪设置SETTING INTERNAL PARAMETERS 内部参数设置内部参数用SETUP键来设置，参数如下：背光储存模式，对比度，设置（包括单位，语言，RS232，校验，电源关闭）注意：SETUP键的使用参考页3－5表3－4所示注意：出厂前第一次使用校验仪，在基本任务模式下，请修改任务模式进入SETUP（设置）菜单。

IMPORTANTPlease make certain that the person who is to use this equipment carefully reads and understands these instructions before starting operations.Double Insulated SPEED-BLOC ®Finishing SanderMODEL 330Some dust created by power sanding, sawing, grinding, drilling,and other construction activities contains chemicals known (to theState of California) to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:●lead from lead-based paints●crystalline silica from bricks and cement and other masonry products ●arsenic and chromium from chemically-treated lumberYour risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well ventilated area, and work with approved safety equipment, always wear NIOSH/OSHA approved, properly fitting face mask or respirator when using such tools.indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.indicates a potentially hazardous situation which, if not avoided,could result in death or serious injury.indicates a potentially hazardous situation which, if not avoided,may result in minor or moderate injury.used without the safety alert symbol indicates potentially hazardous situation which, if not avoided, may result inproperty damage.CALIFORNIA PROPOSITION 65It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information.GENERAL SAFETY RULESRead all instructions. Failure to follow allinstructions listed below may result in electric shock, fire and/orserious injury. The term "power tool" in all of the warnings listedbelow refers to your mains-operated (corded) power tool orbattery-operated (cordless) power tool.SAVE THESE INSTRUCTIONS1)Work area safetya)Keep work area clean and well lit. Cluttered or dark areas inviteaccidents.b)Do not operate power tools in explosive atmospheres, such as in thepresence of flammable liquids, gases or dust.Power tools createsparks which may ignite the dust or fumes.c)Keep children and bystanders away while operating a power tool.Distractions can cause you to lose control.2)Electrical safetya)Power tool plugs must match the outlet. Never modify the plug in anyway. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electricshock.b)Avoid body contact with earthed or grounded surfaces such aspipes, radiators, ranges and refrigerators.There is an increased risk of electric shock if your body is earthed or grounded.c)Do not expose power tools to rain or wet conditions.Water entering apower tool will increase the risk of electric shock.d)Do not abuse the cord. Never use the cord for carrying, pulling orunplugging the power tool. Keep cord away from heat, oil, sharpedges or moving parts. Damaged or entangled cords increase the riskof electric shock.e)When operating a power tool outdoors, use an extension cordsuitable for outdoor e of a cord suitable for outdoor use reduces the risk of electric shock.3)Personal safetya)Stay alert, watch what you are doing and use common sense whenoperating a power tool. Do not use a power tool while you are tiredor under the influence of drugs, alcohol or medication.A moment of inattention while operating power tools may result in serious personalinjury.b)Use safety equipment. Always wear eye protection.Safety equipmentsuch as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.c)Avoid accidental starting. Ensure the switch is in the off-positionbefore plugging in. Carrying power tools with your finger on the switchor plugging in power tools that have the switch on invites accidents.d)Remove any adjusting key or wrench before turning the power toolon.A wrench or a key left attached to a rotating part of the power toolmay result in personal injury.e)Do not overreach. Keep proper footing and balance at all times.Thisenables better control of the power tool in unexpected situations.f)Dress properly. Do not wear loose clothing or jewelry. Keep yourhair, clothing and gloves away from moving parts.Loose clothes,jewelry or long hair can be caught in moving parts.g)If devices are provided for the connection of dust extraction andcollection facilities, ensure these are connected and properly used.Use of these devices can reduce dust-related hazards.4)Power tool use and carea)Do not force the power tool. Use the correct power tool for yourapplication.The correct power tool will do the job better and safer at the rate for which it was designed.b)Do not use the power tool if the switch does not turn it on and off.Any power tool that cannot be controlled with the switch is dangerousand must be repaired.c)Disconnect the plug from the power source before making anyadjustments, changing accessories, or storing power tools.Such preventive safety measures reduce the risk of starting the power tool accidentally.d)Store idle power tools out of the reach of children and do not allowpersons unfamiliar with the power tool or these instructions tooperate the power tool. Power tools are dangerous in the hands ofuntrained users.e)Maintain power tools. Check for misalignment or binding of movingparts, breakage of parts and any other condition that may affect the power tools operation. If damaged, have the power tool repairedbefore use.Many accidents are caused by poorly maintained powertools.f)Keep cutting tools sharp and clean.Properly maintained cutting toolswith sharp cutting edges are less likely to bind and are easier to control.g)Use the power tool, accessories and tool bits etc., in accordancewith these instructions and in the manner intended for theparticular type of power tool, taking into account the workingconditions and the work to be e of the power tool foroperations different from those intended could result in a hazardoussituation.5)Servicea)Have your power tool serviced by a qualified repair person using onlyidentical replacement parts.This will ensure that the safety of thepower tool is maintained.1.Hold power tools by insulated gripping surfaces when performing anoperation where the cutting tool may contact hidden wiring or its own cord. Contact with a "live" wire will make exposed metal parts of the tool "live" and shock the operator.2.Always disconnect the sander cord plug from the power circuit beforechanging abrasive sheets. Such preventive safety measures reduce the risk of starting the power tool accidentally.e proper safety equipment.Wear safety goggles to protect your eyesand wear a protective mask to minimize breathing in the fine dust created while sanding.4.Sanding of lead-based paint is not recommend. Lead-based paint shouldonly be removed by a professional.5.Wear eye and hearing protection. Always use safety glasses. Everydayeyeglasses are NOT safety glasses. USE CERTIFIED SAFETY EQUIPMENT.Eye protection equipment should comply with ANSI Z87.1 standards.Hearing equipment should comply with ANSI S3.19 standards.e of this tool can generate and disburse dust or otherairborne particles, including wood dust, crystalline silica dust and asbestos dust. Direct particles away from face and body. Always operate tool in well ventilated area and provide for proper dust removal. Use dust collection system wherever possible. Exposure to the dust may cause serious and permanent respiratory or other injury, including silicosis (a serious lung disease), cancer, and death. Avoid breathing the dust, and avoid prolonged contact with dust. Allowing dust to get into your mouth or eyes, or lay on your skin may promote absorption of harmful material.Always use properly fitting NIOSH/OSHA approved respiratory protection appropriate for the dust exposure, and wash exposed areas with soap and water.SYMBOL DEFINITIONV........................voltsA........................amperesHz........................hertzW........................wattskW........................kilowattsF........................faradsµF........................microfaradsl........................litresg........................gramskg........................kilogramsbar........................barsPa........................pascalsh........................hoursmin........................minutess........................secondsn0........................no-load speed…/min or …min-1.........Revolutions or reciprocations per minuteor d.c. ................direct currentor a.c. ................alternating current2........................two-phase alternating current2N........................two-phase alternating current with neutral3........................three-phase alternating current3N........................three-phase alternating current with neutral........................rated current of the appropriate fuse-link in amperes........................time-lag miniature fuse-link where X is the symbolfor the time/current characteristic, as given in IEC 60127........................protective earth........................class II toolIPXX........................IP symbolExtreme care should be taken when removing paint. Thepeelings, residue, and vapors of paint may contain lead, whichis poisonous. Exposure to even low levels of lead can causeirreversible brain and nervous system damage. Young andunborn children are particularly vulnerable.Before beginning any paint removal process you should determine whether the paint you are removing contains lead. This can be done by your local health department or by a professional who uses a paint analyzer to check for lead. Lead-based paint should only be removed by a professional.Persons removing paint should follow these guidelines:1.Keep the work area well ventilated.Open the windows and put an exhaust fan in one of them. Be sure the fan is moving air from inside to outside.2.Remove or cover any carpets, rugs, furniture, clothing, cooking utensils, and air ducts.Such preventive safety measures reduce the risk of exposure.3.Place drop cloths in the work area to catch any paint chips or peelings. Wear protective clothing such as extra work shirts, overalls and hats.Such preventive safety measures reduce the risk of exposure.4.Work in one room at a time.Furnishings should be removed or placed in the center of the room and covered. Work areas should be sealed off from the rest of the dwelling by sealing doorways with drop cloths.5.Children, pregnant, or potentially pregnant women and nursing mothers should not be present in the work area until the work is done and all cleanup is complete.Such preventive safety measures reduce the risk of injury.6.Wear a dust respirator or a dual filter (dust and fume) respirator mask which has been approved by the Occupational Safety and Health Administration (OSHA), the National Institute of Safety and Health (NIOSH), or the United States Bureau of Mines.These masks and replaceable filters are readily available at major hardware stores. Be sure the mask fits. Beards and facial hair may keep the masks from sealing properly. Change filters often. DISPOSABLE PAPER MASKS ARE NOT ADEQUATE.7.Keep food and drink out of the work area.Wash hands, arms, and face and rinse mouth before eating or drinking. Do not smoke or chew gum or tobacco in the work area.8.Clean up all removed paint and dust by wet mopping the floors. Use a wet cloth to clean all walls, sills and any other surfaces where paint or dust is clinging. DO NOT SWEEP, DRY DUST OR VACUUM. Use a high phosphate detergent or trisodium (TSP) to wash and mop areas.9.At the end of each work session, put the paint chips and debris in a double plastic bag, close it with tape or twist ties and dispose properly.Such preventive safety measures reduce the risk of exposure.10.Remove protective clothing and work shoes in the work area to avoid carrying dust into the rest of the dwelling.Wash work clothes separately. Wipe shoes off with a wet rag, then wash that rag with the work clothes. Wash hair and body thoroughly with soap and water.SAVE THESE INSTRUCTIONS!MOTORMany Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. current only. Refer to the specification plate on your tool for proper voltage and current rating.Do not operate your tool on a current on which the voltage is notwithin correct limits. Do not operate tools rated A.C. only on D.C.current. To do so may seriously damage the tool.EXTENSION CORD SELECTIONIf an extension cord is used, make sure the conductor size is large enough to prevent excessive voltage drop which will cause loss of power and possible motor damage. A table of recommended extension cord sizes will be found in this section. This table is based on limiting line voltage drop to 5 volts (10 volts for 230 volts) at 150% of rated amperes.If an extension cord is to be used outdoors it must be marked with the suffix W-A or W following the cord type designation. For example – SJTW-A to indicate it is acceptable for outdoor use.SAVE THESE INSTRUCTIONS!FOREWORDYour Porter-Cable Finishing Sander is equipped to accept Stikit™ adhesive backed abrasives (41/2" width) or conventional abrasive sheets (41/2" x 51/2").This Sander is suitable for coarse, medium or fine sanding of wood, plaster, metal and plastics. It is ideal for leveling wallboard joints, finishing cabinets, rubbing and polishing furniture, fitting screens and doors and for general finishing work in the shop.NOTE:This tool is shipped completely assembled. No assembly time or tools are required.ABRASIVE ATTACHMENT TOOL IS REQUIRED- Wrench (furnished)SELECTING THE RIGHT ABRASIVE SHEETBy selecting the proper type of abrasive, the finest finishes can be attained. In general, coarser grit sizes will remove the most material and finer grit sizes will produce the best finishes.Naturally, in all sanding operations, best results will be obtained if you select the proper size and type of abrasives. Only garnet, aluminum oxide and silicon carbide are recommended for use with finishing sanders. Flint paper is not satisfactory for machine sanding, due to its weak structure.Before starting to work, make sure you have the right abrasive for the material on which the sander is to be used. Make sure you use the correct size abrasive paper or cloth. Cut, do not tear, the abrasive sheets to size.ATTACHING STIKIT™ ABRASIVEStikit™ abrasives (ten yard rolls) and a convenient dispenser are available from your Porter-Cable distributor.To install Stikit™ abrasive, cut a 41/8" long piece of abrasive from roll, align abrasive with sander pad and press in place as shown in Fig. 1.To remove, lift one corner of abrasive with fingernail and peel off. ATTACHING CONVENTIONAL ABRASIVEDisconnect tool from power source.1.Insert small end of wrench, furnished with sander, into slot (A), Fig. 2, with hump of the wrench in up position, and press wrench toward sander housing to open clamp.2.Slip one end of abrasive sheet under clamp, stretch sheet tight over pad, open rear clamp with wrench and slip free end of abrasive sheet under rear clamp.TO START AND STOP SANDERMake sure switch (A), Fig. 3, is in “OFF”position.1.Make sure power source voltage is the same as specified on the sander’s specification plate.2.Insert cord plug into power source outlet.3.While holding sander firmly and off of work surface, slide switch (A), Fig.3, to the “ON”position.4.Allow sander to reach full speed. Set it down on the work evenly andmove it slowly back and forth in wide overlapping arcs (see SANDING PROCEDURE section of this manual).5.When you are finished sanding, lift sander up off work and slide switch(A), Fig. 3, to the “OFF”position to stop sander.SANDING PROCEDUREThe Porter-Cable Finishing Sander has been designed for one-hand operation (Fig.3). Because it is light in weight, vibration-free and perfectly balanced, the sander can be easily guided over the work surface with one hand. The normal weight of the machine is sufficient for efficient sanding.Do not put additional pressure on the machine. This would only slow down the speed of the pad, reducing the sanding efficiency and put an additional burden on the motor. In addition, it might cause the sander to jump on the work. Let the sander do the work.OPERATIONFig. 1Fig. 2AFig. 3AFINE FINISHINGThe action of the Porter-Cable Finishing Sander causes thousands of tiny abrasive grits to move in circular orbits against the work at high speed. Each grain moves in the same direction at a constant speed so the cutting action is uniform over the entire pad surface. Crossing and re-crossing of the abrasive grits from all directions quickly levels surface irregularities to a fine, uniform smoothness. Start the work with an abrasive grit just coarse enough to remove the high spots and excessive roughness. Follow with a second sanding using a grit one or two grades finer. Continue with successively finer grits until the desired finish is obtained. DO NOT GO FROM A COARSE GRIT TO A VERY FINE GRIT IN ONE STEP.Going from a coarse grit to a very fine grit in one step could make it difficult to remove swirl marks that might have been made by the coarse grit abrasive. Use the finest grits practical for the roughing operation and then finish by using successively finer grits.REMOVING PAINT AND VARNISHRead and follow all instructions in the ADDITIONAL SAFETY RULES FOR PAINT REMOVAL section of this manual.Your sander will do a good job of removing old paint and varnish if two precautions are taken. First, be sure to use a coarse, open coat abrasive to avoid the usual clogging of the abrasive surfaces. Second keep the machine moving over new areas to avoid heating and softening the material being removed. Try to work the entire surface down at the same time by working in wide, overlapping arcs. Do not concentrate on small areas. If liquid removers or heaters are used to speed the work, be sure the surface is cool and dry and the excess material has been scraped away with a putty knife or other suitable scraping tool before applying the sander.CABINETS AND DOORSThe orbital motion of the Porter-Cable Finishing Sander is ideally suited for finishing doors, cabinet fronts and other installations where wood grain is often perpendicular to that of a joining piece. Since the motion is circular, the machine may be moved in any direction and crossed from one part to the other without regard to direction of grain. A uniform and smooth finish will result on both parts. The same procedure may be used when evening joints in all types of cabinet work. The sander may be worked on both sides and in all directions to obtain a smooth, matching joint. By properly changing from coarser to finer grit abrasives, an excellent finish will result.RUBBING AND POLISHINGThe finishing sander is excellent for all types of polishing and rubbing on flat or round surfaces. Felt rubbing pads, available as accessory equipment can be quickly attached for rubbing operations. With it, metal parts, enameled surfaces and woodwork may be polished. Use rouge or paste wax for polishing with the finishing sander.KEEP TOOL CLEANPeriodically blow out all air passages with dry compressed air. All plastic parts should be cleaned with a soft damp cloth. NEVER use solvents to clean plastic parts. They could possibly dissolve or otherwise damage the material.Wear ANSI Z87.1 safety glasses while using compressed air.FAILURE TO STARTShould your tool fail to start, check to make sure the prongs on the cord plug are making good contact in the outlet. Also, check for blown fuses or open circuit breakers in the line.LUBRICATIONThis tool has been lubricated with a sufficient amount of high grade lubricant for the life of the unit under normal operating conditions. No further lubrication is necessary.BRUSH INSPECTION (If applicable)For your continued safety and electrical protection, brush inspection and replacement on this tool should ONLY be performed by an AUTHORIZED PORTER-CABLE SERVICE STATION or a PORTER-CABLE•DELTA FACTORY SERVICE CENTER.At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricated with fresh lubricant. Have new brushes installed, and test the tool for performance.Any loss of power before the above maintenance check may indicate the need for immediate servicing of your tool. DO NOT CONTINUE TO OPERATE TOOL UNDER THIS CONDITION. If proper operating voltage is present, return your tool to the service station for immediate service.。
