清洁能源与新能源水平轴风力机叶片翼型流场的数值模拟闫海津,李佳,胡丹梅(上海电力学院能源与环境工程学院,上海200090)摘 要:为了直观形象地探讨水平轴风力机叶片翼型的气动特性,利用计算流体力学软件FLUENT对水平轴风力机叶片常用翼型NACA63425流场进行了数值模拟,得出了翼型NA-CA63425在不同来流攻角下的升力系数、阻力系数、升阻比和不同流攻角下的流场流线图和翼型表面的压力分布。
根据模拟结果对不同攻角下尾迹漩涡分离流动进行了分析和比较,得出该翼型气动特性随攻角的变化规律。
关键词:翼型;流场;尾迹分离;数值模拟中图分类号:T K83 文献标志码:B 文章编号:1005-7439(2010)02-0081-04Numerical Simulation on the Airfoil Flow Field of Horizontal Wind Turbine BladesYAN Ha-i jin,LI-Jia,HU Dan-mei(Scho ol of T hermal power&Environmental Engineer ing,Shanghai U niv ersity of Electr ic Po wer Shang hai200090,China)Abstract:T o discuss and analyze the air foil of ho rizo ntal wind tur bine blades mor e dir ect v iew ing and viv id,the airfo il N ACA63425used widely in the hor izontal w ind tur bine blades is numerically investigated by the Co mputatio na l F luid Dy namics softw are.T he co ef ficient s of lift and drag as well as the pr essure and velo city distr ibut ion are calculated in different angle of flow at tack fo r air foil N A CA63425.A nalysis and co mpar ison the vor tex separat ion flo w under the different ang le of flow attack,which wo rks o ut the aero dy namics cha racterist ics o f the airfo il N A CA63425.Keywords:a irfo il;flow;vo rtex separ ation;numerical simulation水平轴风力机运行时,如果翼型来流的攻角较大,绕翼型的流动边界层就会严重分离,因此准确获得翼型的气动特性对于风力机叶片设计非常重要,但是这种复杂的分离流动现象采用试验的方法测量非常困难,而且大量的试验将使翼型的设计周期延长和成本增加。
