SF1604PT中文资料

  • 格式：pdf
  • 大小：107.36 KB
  • 文档页数：2

PIN 1PIN 3Positive CTPIN 2

SF1601PT THRU SF1606PT 16.0 AMPS. Glass Passivated Super Fast Rectifiers Voltage Range 50 to 400 Volts Current 16.0 Amperes

Features 󰀂 Dual rectifier construction, positive center-tap 󰀂 Plastic package has Underwriters Laboratory Flammability Classifications 94V-0 󰀂 Glass passivated chip junctions 󰀂 Superfast recovery time, high voltage 󰀂 Low forward voltage, high current capability 󰀂 Low thermal resistance 󰀂 Low power loss, high efficiency 󰀂 High temperature soldering guaranteed: 260oC / 10 seconds, 0.16”(4.06mm) lead lengths at 5 lbs.,

(2.3kg) tesion

Mechanical Data

󰀂 Cases: JEDEC TO-3P/TO-247AD molded plastic 󰀂 Terminals: Leads solderable per MIL-STD-750, Method 2026 󰀂 Polarity: As marked 󰀂 Mounting position: Any 󰀂 Weight: 0.2 ounce, 5.6 grams

TO-3P/TO-247AD Dimensions in inches and (millimeters) Maximum Ratings and Electrical Characteristics

Rating at 25℃ambient temperature unless otherwise specified. Single phase, half wave, 60 Hz, resistive or inductive load. For capacitive load, derate current by 20% Type Number SymbolSF 1601PTSF 1602PT SF 1603PT SF 1604PT SF 1605PT SF 1606PTUnits

Maximum Recurrent Peak Reverse Voltage V

RRM

50 100150200300 400 V

Maximum RMS Voltage VRMS 35 70 105140210 280 V

Maximum DC Blocking Voltage VDC 50 100150200300 400 V

Maximum Average Forward Rectified Current at Tc=100℃ I(AV) 16 A

Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC method ) IFSM

200 A

Maximum Instantaneous Forward Voltage @8.0A VF 0.95 1.3 V

Maximum D.C. Reverse Current @ Tc=25℃ at Rated DC Blocking Voltage @ Tc=100℃ IR 10.0 500 uA

uA Maximum Reverse Recovery Time(Note 2) TJ=25℃Trr 35 nS

Typical Junction Capacitance (Note 1) Cj 85.0 pF

Typical Thermal Resistance (Note 3) Rθ

JC 2

℃/W

Operating Junction Temperature Range TJ -55 to +150 ℃

Storage Temperature Range TSTG -55 to +150 ℃

Notes: 1. Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C. 2. Reverse Recovery Test Conditions: IF=0.5A, IR=1.0A, Recover to 0.25A. 3. Mounted on Heatsink. Size of 3" x 5" x 0.25" Al-Plate.-237-

FIG.6-TYPICALREVERSECHARACTERISTICSINSTANTANEOUSREVERSECURRENT.(A)

020406080100120140

10000.11.010100

PERCENTOFRATEDPEAKREVERSEVOLTAGE.(%)TC=25C0TC=100C0

FIG.1-REVERSERECOVERYTIMECHARACTERISTICANDTESTCIRCUITDIAGRAM50WNONINDUCTIVE

1WNONINDUCTIVE

OSCILLOSCOPE

(NOTE1)

PULSEGENERATOR(NOTE2)

DUT(+)50Vdc(approx)(-)

NOTES:1.RiseTime=7nsmax.InputImpedance=1megohm22pf2.RiseTime=10nsmax.SourseImpedance=50ohms

(-)(+)

10WNONINDUCTIVE

-1.0A-0.25A0+0.5Atrr

1cmSETTIMEBASEFOR

5/10ns/cm

RATINGSANDCHARACTERISTICCURVES(SF1601PTTHRUSF1606PT)

FIG.3-MAXIMUMNON-REPETITIVEFORWARDSURGECURRENTPERLEG

PEAKFORWARDSURGECURRENT.(A)

1.02.05102010050

50

12515017520010075

NUMBEROFCYCLESAT60Hz

8.3msSingleHalfSineWaveJEDECMethodTj=Tjmax.

FIG.4-TYPICALJUNCTIONCAPACITANCEPERLEGCAPACITANCE.(pF)

.1.51.05.010.050100102050100200

500

1000

REVERSEVOLTAGE.(V)Tj=25Cf=1MHzVsig=50mVp-p

o

FIG.2-MAXIMUMFORWARDCURRENTDERATINGCURVE

AVERAGEFORWARDCURRENT.(A)

050100150

0

4.08.012.016.020.0CASETEMPERATURE.(C)oFIG.5-TYPICALINSTANTANEOUSFORWARDCHARACTERISTICSPERLEG

INSTANTANEOUSFORWARDCURRENT.(A)

.4.6.81.01.21.41.61.82.0.20.11.00.40.2

10.02.04.0

20

10040

FORWARDVOLTAGE.(V)PulseWidth=300s2%DutyCycle

SF1601PT-04PT25C0125C0SF1605PT-06PT
