整理_立体车库外文翻译

Abstract

Along with the our country economy rapid development, the urban population

increases day by day, specially since along with the Reform and open policy, the

automobile total quantity is more and more. Formerly that kind of Single-Layer plane

parking lot could not satisfy the demand of the market. To the mufti- parking spots, little occupies of the space, the use operation is simple. "Three-Dimensional Garage",which is the effective solution of stops difficult in the present big city.

The Three-Dimensional Garage, which takes the single-layer plane parking lot aesthete core, is the mulch-dimensional space parking garage. It uses the programmable-controller (Programming Logic Controller, also called PLC) to realize multiplication plane stops by controlling the berth space position the change. Vertical-horizontal moving underground car parks, which realize multilevel berth-fluctuation deposits and withdraws the vehicles by shifting the tray to produce theoretical channel.

The article researches the theory of the Three-Dimensional Garage, introduce the professionalization three-dimensional garage. The system simulation uses controls

configuration software MCGS, which is based thereon WINDOWS platform. Through

establishing the database of transfiguration constructs, connecting the animation, preparing the control flow and-debugging the procedures, it has realized the three-dimensional garage monitoring-system.

Keyword:Three-Dimensional Garage, Programmable Controller, Lifting and

moving type stereo garage The Stereo Garage

1.1 An overview of the stereo garage

Vehicles parked nowhere is the problem of the urban social, economic and

transport development to a certain extent the result, Garage Equipment

development in foreign countries, especially in Japan nearly 30-40 years. Whether

technically or in terms of experience had been a success. China is also in the

beginning of the 1990s developed mechanical parking equipment, which was 10

years in the past. Because a lot of new residents in the district with the ratio of 1:1.

To address the size of parking spaces for tenants and business areas contradictions

3D mechanical parking equipment with an average size of a small motorcycle's

unique characteristics, the majority of users have been accepted.

Compared with the traditional natural underground garage, Machinery garage

demonstrates its superiority in many respects. First, the mechanical garage has a

prominent section of superiority. Past due to the underground garage must elapse

enough lanes, the average car will occupy an area of 40 square meters, If the use of

double-mechanical garage, which would enable ground to improve the utilization

rate-of around 80% to 90%, If using ground mufti-stormy (21 stormy),

three-dimensional garage, 50 square meters of land area will be placed on the 40

cars, which can greatly save the limited land resources, Civil and save development

costs.

To underground garage, Mechanical garage can be more effective to ensure

personal and vehicle safety in the garage or car kept prospective location, the entire

electronic control equipment would not operate. It should be said that the

mechanical garage from the management can do a thorough separation of people

and vehicles.

In the underground garage using mechanical parking, it also can remove the

heating ventilation; therefore, Operation of the power consumption than workers in the management of underground garage is much lower. Mechanical garage don't

usually do complete system, but as a single machine containers. This will give full play

to its small space, the advantages of decentralized, Each of the residential areas or

groups downstairs to make a complete circuit can be set up random mechanical

parking building. This garage of the district can solve the shortage of parking

difficulty in providing convenient conditions right now.

Currently, three-dimensional garage mainly in the following forms: lifting and

transferring, aisle stacking garage, vertical garage, vertical cycle, box-level cycle, the

level of circulating round.

1.1.1 Lifting and transferring

Lifting and transferring Garage modular design, each module can be designed

into two, three, four levels, the five-story, semi-submerged in various forms, such as

the number of parking spaces from a few to hundreds. Three-dimensional garage

applies to the ground and underground car parks, configuration flexibility and cost is

low. 1. Product features:

1) Save land, the configuration flexibility, and shorter construction period.

2) Low prices, firefighting and exterior decoration, with a total investment on small
