VMware, Inc.1Configuration Maximums
VMware® vSphere 5.0When you select and configure your virtual and physical equipment, you must stay at or below the maximums supported by vSphere 5.0. The limits presented in the following tables represent tested, recommended limits, and they are fully supported by VMware.“Virtual Machine Maximums” on page1“ESXi Host Maximums” on page2“vCenter Server Maximums” on page6“vCenter Server Extensions” on page7The limits presented in this document can be affected by other factors, such as hardware dependencies. For more information about supported hardware, see the appropriate ESXi hardware compatibility guide. Consult individual solution limits to ensure that you do not exceed supported configurations for your environment.The Configuration Maximums for vSphere 5.0 covers ESXi and vCenter Server.Virtual Machine MaximumsTable1 contains configuration maximums related to virtual machines.Table1. Virtual Machine MaximumsItemMaximumComputeVirtual CPUs per virtual machine (Virtual SMP)32MemoryRAM per virtual machine1TBVirtual machine swap file size1TB1Storage Virtual Adapters and DevicesVirtual SCSI adapters per virtual machine42Virtual SCSI targets per virtual SCSI adapter 153Virtual SCSI targets per virtual machine60Virtual Disks per virtual machine (PVSCSI)60Virtual disk size2TB minus 512bytesIDE controllers per virtual machine14IDE devices per virtual machine45Floppy controllers per virtual machine1Floppy devices per virtual machine26Networking Virtual DevicesVirtual NICs per virtual machine107VMware, Inc.2Configuration Maximums
ESXi Host MaximumsThe following tables contain configuration maximums related to ESXi hosts.“Compute Maximums” on page2“Memory Maximums” on page3“Storage Maximums” on page3“Networking Maximums” on page5“Cluster and Resource Pool Maximums” on page6Compute MaximumsTable2 contains configuration maximums related to ESXi host compute resources.Virtual Peripheral PortsUSB controllers per virtual machine18USB devices connected to a virtual machine20Parallel ports per virtual machine3USB 3.0 devices per virtual machine1xHCI USB controllers92010Serial ports per virtual machine4Graphics video deviceVideo memory per virtual machine128MBMiscellaneousConcurrent remote console connections to a virtual machine401.Use VMFS3 with blocksize larger than 1MB for swap files larger than 255GB.2.Any combination of supported SCSI virtual storage controllers. Four Paravirtual SCSI adapters may be used only if the virtual machine boots from a device attached to an IDE controller, or from the network.3.Any combination of disk, CD‐ROM, or VMDirectPath SCSI target.4.Supports two channels (primary and secondary) each with a master and slave device.5.Devices can be either CD‐ROM or disk.6.BIOS is configured for one floppy device.7.Any combination of supported virtual NICs.8.Supports USB 1.x and USB 2.x devices.9.Supports USB 1.x, 2.x and 3.0 devices.10.Guest operating systems might have smaller limits than allowed by vSphere.Table1. Virtual Machine Maximums (Continued)ItemMaximum
Table2. Compute MaximumsItemMaximumHost CPU maximumsLogical CPUs per host160Virtual machine maximumsVirtual machines per host512Virtual CPUs per host2048Virtual CPUs per core251Fault Tolerance maximumsVirtual disks16VMware, Inc.3Configuration Maximums
Memory MaximumsTable3 contains configuration maximums related to ESXi host memory.
Storage MaximumsTable4 contains configuration maximums related to ESXi host storage.Virtual CPUs per virtual machine1RAM per FT VM64GBVirtual machines per host41.The achievable number of vCPUs per core depends on the workload and specifics of the hardware. For more information, see the latest version of Performance Best Practices for VMware vSphere.Table2. Compute Maximums (Continued)ItemMaximum
Table3. Memory MaximumsItemMaximumRAM per host2TB Number of swap files1 per virtual machineSwap file size1TB11.On VMFS3, use a block size larger than 1MB for swap files larger than 255GB
Table4. Storage MaximumsItemMaximum Virtual DisksVirtual Disks per Host2048iSCSI Physical LUNs per server256Qlogic 1Gb iSCSI HBA initiator ports per server4Broadcom 1Gb iSCSI HBA initiator ports per server4Broadcom 10Gb iSCSI HBA initiator ports per server4NICs that can be associated or port bound with the software iSCSI stack per server8Number of total paths on a server1024Number of paths to a LUN (software iSCSI and hardware iSCSI)8Qlogic iSCSI: dynamic targets per adapter port64Qlogic iSCSI: static targets per adapter port62Broadcom 1Gb iSCSI HBA targets per adapter port641Broadcom 10Gb iSCSI HBA targets per adapter port128Software iSCSI targets2561NAS2NFS mounts per host256Fibre ChannelLUNs per host256LUN size64TB5LUN ID255VMware, Inc.4Configuration Maximums
