Quick SetupIMPORTANT: Before using this product, make sure you read these instructions and the safety instructions in the online User’s Guide.Note: These illustrations show the Pro EX9240, but the instructions are the same for the EX9230 unless otherwise noted.ContentsMake sure your projector box includes all of these parts (wireless LAN modulecover not included with Pro EX9240):Connect the projectorChoose from the following connections. See the sections below or the onlineUser’s Guide for details.ComputerHDMI portConnect one end of an HDMI cable to one of the projector’s HDMI ports andthe other end to an HDMI port on your computer.Computer portComputer port and thesheet). You can also connect an audio cable.USB portConnect the square end of a USB cable to the projector’s USB-B (square) port.Connect the flat end of the cable to any USB port on your computer.Windows Vista® or later: After turning on the projector, follow the on-screeninstructions to install the Epson® USB Display software (EMP_UDSE.EXE; onlyon first connection). If the software screen does not display automatically, openMy Computer, Computer, or This PC, then double-click EPSON_PJ_UD.OS X 10.7.x or higher: After turning on the projector, the setup folder forUSB Display appears in the Finder. Double-click USB Display Installer andfollow the on-screen instructions to install the Epson USB Display software(only on first connection).Video deviceConnect multiple video devices and use the Source Search button on theprojector or remote control to switch between them.RCA video cable(composite video)USB deviceConnect a supported digital camera, USB flash drive, or USB storage device tothe projector’s USB-A(flat) port.If you connect a digital camera, USB flash drive, or USB storage device, you canuse the projector’s PC Free feature. See the online User’s Guide for details.Turn on your equipment1 T urn on your computer or video source.2 P lug in the projector. The power light on the projector turns blue.3 O pen the A/V Mute slide all the way.4 P ress the power button on the projector or remote control. Theprojector beeps, the Status light flashes blue, and then stays on.Note: To shut down the projector, press the power button twice.5 U se the arrow buttons on the remote control to highlight any of theoptions on the Home screen that appears, then press to select it.You can switch between projection sources and quickly access variousadjustment options from this screen.6 T he default language of the menu system is English. To select anotherlanguage, press the Menu button on the projector or remote control.Select Extended and press . Select Language and press . Select yourlanguage and press . Press the Menubutton to exit the menu system.Adjust the image1 I f you don’t see an image, press the Source Search button on theprojector or remote control to select the image source.Note: If you still see a blank screen or have other display problems, seethe troubleshooting tips on the back of this sheet.2 T3 T4 T5 I6 YUsing the remote controlInstall the batteries as shown (two AA batteries).Choose which sourceto displayon and offmenusdisplay Access the HomescreenNavigate projectormenusFor more information on using the remote control, see the online User’s Guide.Setting up a wirelessconnectionFollow these steps to set up the projector for a wireless network connection.To project wirelessly, you need to install the optional wireless LAN module forthe EX9230 (part number V12H005A02).Note: The light on the wireless LAN module turns on when the module isinstalled and operating. The light flashes when the module is communicatingover the network.Select wireless network settings1 P ress the Menu button on the remote control.2 S elect the Network menu and press .3 S elect On as the Wireless LAN Power setting.4 S elect Network Configuration and press .5S elect the Wireless LAN menu and press.6S elect one of the following as the Connection Mode setting: •Q uick for a direct connection to a computer, tablet, or smartphone. •A dvanced to connect your projector to a router or access point.7 Select any other settings on the Wireless LAN menu as necessary. See the online User’s Guide for details.8When you are finished, select Complete and follow the on-screen instructions to save your settings and exit the menus.Install the optional softwareIf you connected a computer to the projector, you can download and installoptional software to perform various tasks wirelessly, such as monitoring or controlling your projector and projecting from multiple computers.You can download the optional software and its manuals from the Epson website, as described in “Where to get help.”Using web remoteYou can use a standard web browser to control the projector through the network. A virtual remote control on your computer screen lets you perform many of the same functions as you can with the physical remote control.1Open your web browser and enter the IP address of the projector you want to monitor in the browser’s address box.If you’re not sure what the IP address of the projector is, turn the projector on and select Net. Info. - Wireless LAN from the Networkmenu to display the IP address of the projector. (Do not enter the leading zeroes.)2 E nter EPSONWEB as the user name and admin as the password, then click OK . The Epson Web Control menu opens.3 S elect Basic Control . If you see a login screen, enter EPSONREMOTE as the user name and guest as the password.4Use the on-screen buttons to operate the projector, as you would using the remote control. See the online User’s Guidefor details.Select image sourceAdjust volumeSearch for sourcesTurn off pictureand soundUsing the Epson iProjection appYou can project wirelessly from a mobile device (iOS, Android™, or Chromebook™) using the Epson iProjection™ app and a QR code.1Use the following QR code to download and install the Epson iProjection app.2 If you connected the projector to a network wirelessly, make sure to connect your mobile device to the same network.3 Press the LAN button on the remote control to display a QR code on the projector screen.4S tart Epson iProjection on your mobile device.5U se the QR code reader feature to read the QR code displayed.6F ollow the app instructions to connect your device to the projector. For more information on setting up and using this app, visit/iprojection (U.S.) or www.epson.ca/iprojection (Canada).Mirroring a mobile deviceIf your mobile device (laptop, smartphone, or tablet) supports Miracast ®, you can project or mirror your device’s screen wirelessly (Pro EX9240). You do not need any additional software to use this feature.Note: Some restrictions apply. See the online User’s Guide for details.Select screen mirroring settings1 P ress the Menu button on the remote control.2 Select the Network menu and press.3S elect On as the Screen Mirroring setting.4 S elect Screen Mirroring Settingsand press . Press again.5Select any of the Screen Mirroring Settings options as necessary. See the online User’s Guide for details.6When you finish selecting settings, select Set and follow the on-screen instructions to save your settings and exit the menus.Connect your device1 Press the LAN button on the remote control. You see the Screen Mirroring standby screen.2Use the Miracast function on your device to search for the projector. You see a list of available devices.Note: See your device’s documentation for details on using its Miracast function.3If you see a PIN entry screen on your device, enter the PIN code displayed on the Screen Mirroring standby screen or at the bottom right of the projected image.The projector displays the image from your device once a connection is established.Caution: It may take some time to establish a connection. Do not disconnect the projector’s power cord while it is connecting to your device. Doing so may cause your device to freeze or malfunction.Troubleshooting• If you see a No signal message after turning on the projector, make sure your computer or video device is properly connected.•I f you see a blank screen, check the following: •Make sure the A/V Mute slide is open. • Make sure the power light on the projector is blue and notflashing.•P ress the power button to wake the projector from standby or sleep mode, if necessary.• If you see a blank screen when a computer is connected, check the following:• On some Windows ® laptops, you may need to hold down the Fn key and press F7 or the function key that lets you display on an external monitor. It may be labeled CRT/LCD or have an icon such as .On Windows 7 or later, hold down the Windows key and press P at the same time, then click Duplicate .• If you’re using a Mac laptop, open System Preferences and select Displays . Click the Arrangement tab and select the Mirror Displays checkbox.• If the projector does not respond to remote control commands, make sure the batteries in the remote control are installed correctly. Replace the batteries if necessary.RegistrationRegister today to get product updates and exclusive offers. You can register online at /webreg .Where to get helpManualsFor more information about using the projector, you can view or download the online manuals from the Epson website, as described below.Internet supportVisit /support (U.S.) or www.epson.ca/support (Canada) and search for your product to download software and utilities, view manuals, get FAQs and troubleshooting advice, or contact Epson.Telephone support servicesTo use the Epson PrivateLine ® Support service, call (800) 637-7661. This service is available for the duration of your warranty period. You may also speak with a support specialist by calling (562) 276-4394 (U.S.) or (905) 709-3839 (Canada). Support hours are 6 AM to 8 PM , Pacific Time, Monday through Friday, and 7 AM to 4 PM , Pacific Time, Saturday. Days and hours of support are subject tochange without notice. Toll or long distance charges may apply.EPSON is a registered trademark, EPSON Exceed Your Vision is a registered logomark, and Epson iProjection is a trademark of Seiko Epson Corporation.PrivateLine is a registered trademark of Epson America, Inc.Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries. Mac and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.Android and Chromebook are trademarks of Google LLC.General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks.This information is subject to change without notice. © 2020 Epson America, Inc., 3/20CPD-58866Optional accessoriesFor a list of optional accessories, see the online User’s Guide .You can purchase screens or other accessories from an Epson authorized reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766). Or you can purchase online at (U.S. sales) or www.epsonstore.ca (Canadian sales).。
激光投影仪操作方法
以下是激光投影仪的操作方法：
1. 将激光投影仪放置在平稳的表面上，确保投影仪的风口不被阻塞。
2. 连接电源线，并插入电源插座，开启投影仪的电源开关。
3. 连接输入源，可以是电脑、DVD播放机等，通过HDMI、VGA或其他接口连接。
4. 打开输入源设备，在电脑上可以通过按下Windows键+P键来设置投影方式，选择“扩展”或“仅投影”，确保信号可以传输到激光投影仪。
5. 开启激光投影仪，等待一段时间，让激光灯充分启动。
6. 在投影屏幕或墙壁上调整投影仪的位置和角度，使用投影仪的调焦功能来调整投影画面的清晰度。
7. 使用遥控器或投影仪的功能按键来调整投影画面的亮度、对比度、色彩等参数，以获得最佳的视觉效果。
8. 调整投影画面的大小和位置，可以通过改变投影仪与投影面的距离来实现。
某些激光投影仪可能还提供梯形校正功能，用于消除画面投射时的变形。
9. 在使用完毕后，关闭输入源设备，再关闭投影仪的电源开关。
请注意，具体的操作方法可能会因激光投影仪的型号和品牌而有所不同，建议根据投影仪的使用说明书来进行具体操作。
用户使用说明书超短焦激光投影机-使用本产品前，请仔细阅读本手册，并妥善保管以备查询。
-使用本产品前，请务必仔细阅读“重要安全说明”。
声明版权深圳光峰科技股份有限公司保留所有权利。
未经深圳光峰科技股份有限公司事先书面许可，不得以任何形式或方式，包括电子、机械、磁性、光学、化学、手写或其它方式，对本文的任何部分进行复制、传输、转译、储存于检索系统或翻译成任何文字或电脑语言。
所有商标和注册商标均属其所有人所有。
免责声明深圳光峰科技股份有限公司未对本手册中的任何内容作出任何明示或暗示的陈述或保证，尤其对适销性或针对特定用途的适用性不提供任何保证。
此外，深圳光峰科技股份有限公司保留修订本出版物和随时修改本文档内容而无需通知任何人的权利。
保修在正常使用和存放情况下，深圳光峰科技股份有限公司对本产品的任何材料和工艺缺陷提供保修。
要求保修时必须提供购机日期证明。
如果在保修期内发现本产品有缺陷，深圳光峰科技股份有限公司唯一的义务和针对您的独家补救办法是更换任何有缺陷的部件（包括劳务费）。
当您购买的产品发现有缺陷时，应立即通知经销商，以获得保修服务。
重要事项：如果客户未按照书面用法说明使用本产品，将不适用上述保修。
尤其是环境湿度必须介于10%和90%之间、温度介于0°C和40°C之间，以及避免在多灰尘的环境下操作本投影机。
有关其他信息，请访问。
此标志警告用户投影机机身内未绝缘的电压可能足以导致电击。
因此与机身内任何部件进行任何形式的接触均存在触电危险。
此标志提醒用户注意一些与本机操作及维护有关的重要信息。
请仔细阅读此类信息以避免出现问题。
2目录声明 (2)目录 (3)重要安全说明 (4) 通用安全指示 (4) 安全提示 (4) 重要安全注意事项 (5) 废弃电器电子产品管理条例 (8) 有害物质声明 (8)简介 (9) 使用本手册 (9) 安全警告和指南 (9) 投影机特点 (10) 包装概览 (11) 投影机外观视图 (12) 控制装置和功能 (13) 遥控器 (14) 更换遥控器电池 (16)安装 (17) 安装方式 (17) 安装距离 (18)连接设备 (20) 连接电脑或显示器 (21) 连接视频源设备 (22) 连接音频 (22) 连接HDMI设备 ...............23操作 .. (24) 启动投影机 (24) 使用菜单 (24) 屏幕显示菜单 (25) 图像菜单 (27) 信号菜单 (28) 设置菜单 (29) 高级菜单 (31) 关于菜单 (33)串行接口 (34) 串行接口 (34) 通讯设备 (34)维护 (35) 维护投影机 (35)故障排查 (36) 指示灯 (37)3重要安全说明通用安全指示♦ 请在使用此设备之前仔细阅读本手册，并妥善保管以备将来参考。
