One Step 的使用方法在Autoform 中，onestep 功能可以快速的查看制件的成型性，从而加快设计和规划进程。

下面图1所示为onestep 的功能选项卡。

一步法的选择是在geometry generator 下将数型进行处理后，在进入input generator 时进行选择的。

图2中的Simulation type 选项中下边的选择项就是一步法。

当点击此项后，会弹出图3所示对话框。

点击OK 即可进入图1所示界面。

图1图2 图3Geometry 选项卡1.类型(Type)一步法中有五种模拟方式可选。

任何一种方式下都要对OS boundary 选项进行设置，此项用来给出拉延结束后制件的边界线，而非拉延前的坯料线。

此处统一说明，后边重复处不再做解释。

A 无补充无压边圈如图4所示为此种方式。

由于没有压边圈也没有补充，因此binder 选项和OS punch opening 选项是不可选的。

此种方式是最简单也最粗糙的一种算法。

B 无补充有压边圈图5所示为此中方式。

此方式激活binder 选项，若在geometry generator 中就生成压边圈，则此选项会自动将其添加。

由于一步法多用来粗算，压边圈多采用自动生成，因此此处会自动添加。

计算相对上一种方式也多了压边圈闭合过程。

图4图5C 无补充有分模线如图6中所示，此种方式需要输入产品最终边界线和分模线。

其计算过程中没有补充。

D 有补充无压边圈图7中为此方式。

与上一种方式相比较此方式没有压边圈，因此没有压边过程。

E 有补充有压边圈图6图7图8此方式下需要给出分模线和拉延后的坯料线。

以上五种方式从前向后逐步增加复杂程度。

BLANK选项卡如图9所示，此选项卡下需输入料厚以及材料种类。

也可以增加称线以及板料的冲孔等。

Process选项卡图10和图11给出了此选项卡的设置内容。

限制条件的类型共有自由、锁死、约束、压边压强和压边力五种可选项。

当没有压边圈时，后两项是不可选的。
