种植屋面：西卡轻钢屋面防水系统
1.产品简介：
轻钢屋面系统采用西卡渗耐专用固定配件，将PVC防水卷材固定于屋面结构钢板上，通过热风焊接形成完整的防水层（固定件被覆盖于防水卷材搭接边下）。

构造层次：
1．屋面压型钢板—建议采用0.8mm及以上厚度，以保证螺钉的绝对拉拔力及动态荷载下的抗松动性能。

板型由结构计算决定并需考虑所需保温材料的种类和厚度。

2．隔汽层—通常采用0.3mm厚的聚乙烯膜，其隔汽性能由厂家进行检测，所有连接及收口部位均采用胶带密封。

3．保温板层（挤塑聚苯乙烯、岩棉等）—保温板的选择与建筑物本身的保温、屋面压型钢板的板型、荷载等要求有关，并须具有一定的抗压要求（抗压强度为60kPa时变形率小于10%，EN826；点荷载为500N时，变形小于5mm，EN12430）。

4．隔离层-采用无纺布或玻璃丝布，当卷材与基层不相容或者基层粗糙不平时，应当设立隔离层。

5．PVC防水卷材-作为轻钢屋面系统的核心防水层，其机械固定的施工方法要求卷材具有较强的拉伸强度、撕裂强度及较低的延伸率，S327 L卷材严格参照Q/TBYJ1-2004企业标准（部分引用欧洲标准EN13956），为轻钢屋面系统的首选卷材，而F610 F、F10 F和Sikaplan®G 卷材亦适用于该系统。

2.产品特点：
1）良好的防水、保温、隔汽性能。

2）自重轻。

3）抗风能力强。

4）采用机械固定，受天气和基层影响小，可以在寒冷地区正常施工。

5）施工快捷。

3.适用范围：
适用于轻钢屋面的防水。
