XX大学本科生毕业论文开题报告
建环专业毕业设计（酒店）指导书
设计题目：XX农业银行商住楼空调设计
一、任务要求
1、完成商住楼空调设计施工图一套，及配套设计说明书；
2、按照二、1～10项编写说明书，说明书要求写出英文摘要和参考
文献；
3、设计说明书要求书写工整，插图美观，数据引用需要注明出处。
二、设计步骤
1、熟悉土建资料和酒店空调的设计规范；
2、空调负荷计算；
3、空调分区、方案的选择、空调方案的经济性比较；
4、气流组织计算、空气处理计算、空调设备选择计算；
5、水力计算、水泵选择；
6、消声减震计算；
7、管道保温计算；
8、卫生间通风系统、大楼及中央空调系统防火排烟；
9、中央空调系统对BAS的要求；
10、施工图预算
11、绘制空调设计施工图，包括（按照下列顺序编写图纸编号和
目录）
●首页图：包括设计施工说明，设备材料表，图纸目录
●各层空调平面、剖面图
●水系统图
●机房平面、剖面图
●机房系统图或系统原理图
●非标设备制作及主要设备安装大样图
摘要:本设计为广州中央空调系统工程设计，共十二层，地下两层，建筑总面积13000，空调面积6526.6，根据房间功能，全楼采用集中供给空调方式，制冷机组采用直燃型溴化锂吸收式制冷机组两台，型号分别为BZ-40单台制冷量分别为465KW.
根据各不同功能房间，将该集中系统分为二种空调送风方式，高大空间如餐厅、活动用房等采用全空气系统，新风直接从室外引进与回风混合（一次回风）后送风；住户、公寓等采用了风机盘管加独立新风系统，新风机组从室外引入新风处理到室内空气焓值，风机盘管承担室内全部冷负荷及部分的新风湿负荷。全空气系统选用圆型散流器平射流形式，而风机盘管加独立新风系统有百叶风口侧送和散流器平送的形式。水系统采用闭
式双管同程式，冷水泵三台，两用三备，；冷却水泵选三台，两用一备。卫生间通风统一由排风扇接出，在末端安装止回阀。楼梯间采用自然排风排烟；标准层以上由于小于500m2所以采用自然排风；地下室、设备房、一层及二层设置防排烟系统，，选用变速风机，平时排风，发生火灾时排烟。
空调水系统只设有一个系统，每层均设有回水同程管。
关键词：风机盘管加独立新风系统全空气系统防排烟散流器制冷机组
Abstract:This design is about the central air conditioner engineering of Yingcai Hotel that locates in Beijing. There are 12 floors and two floor underground. The gross floor area is about 13000m2,and the air
conditioner area is about6526.6. The cold duty is 874kw, We choose 2 immediate-combustion and absorption LiBr, and the models are BZ40H.Their maximal burning of natural gas are 465kw when refrigerating; According to different functions, The first system is in the supplies air. The second system is in other little room. It adopts the PAU+FCU system. FCU system deals with the fresh air. PAU system carries on the whole cold duty and part wet duty. PAU+FCU systems can send air from the side and the upside; it uses the circular air diffuser to supply air. There are five water-cooling pumps; three can be used when summer, two of five are for using and another three are for preparing; in winter, two for using and one for preparing. The system in washroom can ventilate by itself. The system in the staircase and the standard floors can exhaust air and smoke by itself. The preventing and exhausting smoke system is used for the underground room, the equipment room and the first and second floor and it adopts the same way to exhaust air and smoke: choosing the dual wind velocity fans which exhaust air at ordinary times, while exhausting smoke when the fire disaster machine
