NFPA318無塵室防護標準(Standard for the Protection of Cleanrooms;1995 Edition)第一章概述1.1範圍此標準適用於所有本篇所定義之無塵室及潔淨區之半導體廠。
1.2目的本標準旨在提供無塵室避免火災及相關危害合理的安全防護,而這些防護措施可避免或減少人員及財產之損害。
1.3應用此標準所考慮是以合理的預防火災及爆炸,避免造成人員傷亡及財產之損害,此時所需考慮之環境狀況及活動狀態為本標準所討論之重點;除非其它地方有所規範,否則本標準不用於要求已經安裝完成設備除非在該狀態下已造成生命危害或鄰進近地區之財產損失。
1.4名詞定義§高架地板系統(Access Floor System)配電盤架設於基座上以提供地面下空間供安裝機械通訊或作為供風或回風空間。
§管轄權(Authority Having Jurisdiction)組織部門或個人負責對設備安裝或製程之認可,在NFPA,管轄權會隨區域有所變化,可能是聯NFPA 318 CLEAN ROOM無塵室防護標準---1邦,州,地區或地區部門,或個人可能是消防首長,副首長,州消防局長機動小組或衛生局營建部門及其它經法律授權的單位。
保險公司亦有檢查權,原設計或擁有者亦有此權利。
§潔淨區(Clean Zone)定義為區間內之空氣中之灰塵粒子濃度控制在一定的範圍內。
§無塵室(Clean Room)定義為房間內之空氣中之灰塵粒子濃度控制在一定的範圍內。
§壓縮氣體(Compressed Gas)xx容器中之任何氣體或混合氣體其在70OF(21.1℃)時,絕對壓力大於40psi(275.8Kpa);或在70OF時絕對壓力小於40psi,但在130OF(54.4℃)時其壓力大於104psi;或易燃性氣體在100OF(37.8℃)時,其蒸氣壓大於40psi稱為壓縮氣體。
§爆炸(Explosion)氣體體積突然的擴增,可能為化學性質(如氧化)的改變或物理性質(壓力筒破裂)的變化。
