外文翻译 文献综述 电力系统低频振荡和储能系统

电力系统振荡阻尼采用先进的统一潮流控制摘要-文章介绍了一种先进的控制器的设计。

上述非线性控制器的目的是使电力系统中正在使用的统一潮流控制器（UPFC）的一台多机的内在区域的振荡阻尼减少。

系统在日常运行时的发电机将会经历持续的负载变化，并且当系统中出现故障时会出现剧烈的变化。

因此，非线性控制器的运行时独立的，这种器件可以比线性的控制器产生更好的效果。

将之前所提到的器件安装在系统中两个区域之间。

在不同的负载条件下把统一潮流控制器与传统的比例积分（PI）控制器所产生的效果作比较。

关键词-暂态稳定；非线性控制；振荡系统；统一潮流控制器。

Ⅰ.引文今年来由于能源，环境，位置和成本的影响阻碍了新型传输线路和发电设备的建设，而电力功率的需求却在日益增长。

回顾传统的电力系统实践和概念对当前情形是必要的。

这样是为了获得更好的运行灵活性，并且也是为了当前的电力系统更好的利用率。

在相互协调的电力系统中电压稳定，暂态稳定和小干扰稳定约束了功率传输。

可用传输通道的完全利用率由这些约束条件所限制[1],[2]。

在很多系统里面，摆幅稳定性不是限制因素，而是系统的振荡阻尼。

传统的方法是在发电机的励磁系统中通过增加一个电力系统稳定器（PSS）以增加该系统的阻尼[3]。

PSS的主要功能是通过励磁系统引入调制信号处理来增加转子振荡阻尼。

然而，在一些运行条件中，这些设备可能不会产生足够的阻尼，尤其是内在区域模型[4]和与PSS之外其他有效的选择设备。

在上个20年期间，电力系统在控制技术和大功率半导体设备方面已经产生很大的发展。

静止无功补偿器（SVC）仅仅在所选择的传输线终端控制[5],[6]。

由Hingorani提出的柔性交流输电系统(FACTS)[7]或者灵活交流输电系统的概念有着很大的效益，例如，极大功率潮流控制，电力系统震荡阻尼，少量的环境影响，并且和有选择性的传输系统固定装置相比柔性装置拥有潜力，花费也少[8]。

统一潮流控制器（UPFC）是FACTS装置中最常用的。
