1756 ControlLogix I/O Specifications 1756-OB32ControlLogix DC (10…31.2V) output moduleTechnical Specifications - 1756-OB32Attribute1756-OB32Outputs32 (16 points/group)Voltage category12/24V DC sourceOperating voltage range10…31.2V DCOutput delay timeOff to On On to Off 60 μs nom/1 ms max 200 μs nom/1 ms max 300 mACurrent draw @ 24V 2 mATotal backplane power 1.58 WPower dissipation, max 4.8 W @ 60 °C (140 °F) Thermal dissipation16.37 BTU/hrOff-state leakage current per point, max0.5 mA per pointOn-state voltage drop, max°C (140°F)Surge Current ChartSimplified SchematicCurrentTime0.5 A1 A1756-OB32Rockwell Automation Publication 1756-TD002J-EN-P - November 2016169170Rockwell Automation Publication 1756-TD002J-EN-P - November 20161756 ControlLogix I/O SpecificationsCurrent per point, max 0.5 A @ 50 °C (122 °F) linear derating 0.35 A @ 60 °C (140 °F)Current per module, max 16 A @ 50 °C (122 °F) linear derating 10 A @ 60 °C (140 °F)Surge current per point, max 1 A for 10 ms per point, repeatable every 2 s @ 60 °C (140 °F) Load current, min 3 mA per pointScheduled outputs Synchronization within 16.7 s max, reference to the Coordinated System Time States in Fault mode per point Hold last state, On or Off (Off is default)States in Program mode per point Hold last state, On or Off (Off is default)Isolation voltage250V (continuous), basic insulation type, outputs-to-backplane, and output group-to-group No isolation between individual group outputs Routine tested @ 1350V AC for 2 s Module keying Electronic, software configurableFusingNot protected. A fused IFM can be used to help protect outputs. See publication 1492-TD008. However, the ControlLogix system has been agency certified using only the ControlLogix RTBs, that is, 1756-TBCH, 1756-TBNH, 1756-TBSH, and 1756-TBS6H. Any application that requires agency certification of the ControlLogix system that uses other wiring termination methods can require application-specific approval by the certifying agency.Removable terminal block 1756-TBCH 1756-TBS6H RTB keying User-defined mechanical Slot width 1Wire category1(1)North American temperature code T3C IEC temperature code T3Enclosure typeNone (open-style)(1)Use this conductor category information for planning conductor routing as described in the system-level installation manual. See the Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.Environmental Specifications - 1756-OB32Attribute1756-OB32Temperature, operatingIEC 60068-2-1 (Test Ad, Operating Cold),IEC 60068-2-2 (Test Bd, Operating Dry Heat),IEC 60068-2-14 (Test Nb, Operating Thermal Shock)0…60 °C (32…140 °F)Temperature, surrounding air, max60 °C (140 °F)Temperature, nonoperatingIEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)-40…+85 °C (-40…+185 °F)Relative humidityIEC 60068-2-30 (Test Db, Unpackaged Damp Heat)5…95% noncondensing VibrationIEC 60068-2-6 (Test Fc, Operating) 2 g @ 10…500 Hz Shock, operatingIEC 60068-2-27 (Test Ea, Unpackaged Shock)30 g Shock, nonoperatingIEC 60068-2-27 (Test Ea, Unpackaged Shock)50 g EmissionsCISPR 11, Class ATechnical Specifications - 1756-OB32 (continued)Attribute 1756-OB32Rockwell Automation Publication 1756-TD002J-EN-P - November 20161711756 ControlLogix I/O SpecificationsESD immunity IEC 61000-4-2 6 kV contact discharges 8 kV air dischargesRadiated RF immunity IEC 61000-4-310V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz 10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz 10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz3V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz EFT/B immunity IEC 61000-4-4±4 kV at 5 kHz on signal portsSurge transient immunity IEC 61000-4-5±1 kV line-line (DM) and ±2 kV line-earth (CM) on signal ports Conducted RF immunity IEC 61000-4-610V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHzCertifications - 1756-OB32Certification (1)1756-OB32UL UL Listed Industrial Control Equipment. See UL File E65584.CSA CSA Certified Process Control Equipment. See CSA File LR54689C.CSA Certified Process Control Equipment for Class I, Division 2 Group A,B,C,D Hazardous Locations. See CSA File LR69960C.CEEuropean Union 2004/108/IEC EMC Directive, compliant with:•EN 61326-1; Meas./Control/Lab., Industrial Requirements •EN 61000-6-2; Industrial Immunity •EN 61000-6-4; Industrial Emissions•EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)European Union 2006/95/EC LVD, compliant with:EN 61131-2; Programmable Controllers (Clause 11)C-Tick Australian Radiocommunications Act, compliant with:AS/NZS CISPR 11; Industrial EmissionsExEuropean Union 94/9/EC ATEX Directive, compliant with:•EN 60079-15; Potentially Explosive Atmospheres, Protection "n"•EN 60079-0; General Requirements II 3 G Ex nA IIC T3 X GcFM FM Approved Equipment for use in Class I Division 2 Group A,B,C,D Hazardous Locations KCKorean Registration of Broadcasting and Communications Equipment, compliant with:Article 58-2 of Radio Waves Act, Clause 3(1)When marked. See the Product Certification link at for Declarations of Conformity, Certificates, and other certification details.Environmental Specifications - 1756-OB32 (continued)Attribute 1756-OB32。
一、中央处理器单元(CPU)ControlLogix控制器带有大量的内存,可寻址大量的I/O点。
控制器既可控制本地I/O,又可通过Ethernet/IP、ControlNet、DeviceNet以及通用远程I/O网络来控制远程I/O。
⚫可用的用户内存:750K字节或1.5M字节或3.5M字节,最大可达8M.⚫最大数字量I/O点数:128000点⚫最大模拟量I/O点数:4000点⚫程序扫描时间:≤0.06ms/1k⚫所有模块不需要冷却风扇⚫在同一机架中可多处理器并存,实现分布式运算。
即可随意安放处理器模块、输入输出模块和通信模块,而没有任何的数量、位置和类型限制。
⚫用户无需更换处理器,通过替换更大容量的内存即可扩充系统处理能力。
⚫具有RUN运行模式、PROGRAM编程模式、REMOTE远程模式的钥匙开关。
⚫CPU自带一节锂电池,掉电后程序至少可保存63天。
⚫用户程序、I/O数据或系统参数能够以文件形式存放于数据存储卡(需另配)或CPU内存中。
⚫基站和扩展I/O的框架采用同系列规格的框架,所有的I/O模块采用和CPU 对应同一系列的模块。
⚫所有的I/O模块的配置及编制通过软件实现,无跳线及DIP开关;且每个槽位都是通用的,即模块不存在对槽位的依赖。
⚫具有可直接插入机架的以太网、控制网、设备网模块,支持以太网、控制总线、设备总线,并支持多网配置,而且不需要处理器进行干预。
⚫中断功能:定时中断,掉电中断,I/O中断,外部中断,事件中断。
⚫具有内置时钟/日历。
⚫实时多任务系统内核:多达32个任务,包括1个连续任务以及31个周期任务;有15个优先级可选以保证重要任务优先。
每个任务中可编制32个程序,并分别拥有单独数据区。
⚫完全标签变量编程方式,采用动态内存管理技术,无需用户进行内存分配管理。
没有定时器/计数器等使用个数的强行限制,支持数据类型的自动转换。
⚫支持多维数组、标准数据结构及用户自定义数据结构。
⚫具有带电插拨功能;⚫具有CSA、UL、CE认证二、I/O模块1. 数字量交流输入模块:1756-IA8D;⚫输入点数:8点;诊断⚫电压类型:120 VAC;⚫输入信号延迟时间:on→off=9ms或18ms;⚫工作电压:79-132VAC;(47~63HZ);⚫最大导通状态电流:5mA@79VAC(60HZ)、16mA@132VAC(60HZ);⚫最大断开状态电流:2.5mA;⚫背板电流:100mA@5Vdc,3mA@24Vdc;⚫具有带电插拨功能;⚫具有可拆卸端子块: 1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;2. 数字量交流输入模块:1756-IA16;1756-IA32;⚫输入点数:16点/32点;⚫电压类型:120 VAC;⚫输入信号延迟时间:on→off=9ms或18ms;⚫工作电压:74-132VAC;(47~63HZ);⚫最大导通状态电流:5mA@74VAC(60HZ)、13mA/10mA@132VAC(60HZ);⚫最大断开状态电流:2.5mA;⚫背板电流:105mA/165mA@5Vdc,2mA@24Vdc;⚫具有带电插拨功能;⚫具有可拆卸端子块: 1756-TBNH(20针)/1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;3. 数字量交流输入模块:1756-IA16I;⚫输入点数:16点单独隔离;⚫电压类型:120 VAC;⚫输入信号延迟时间:on→off=9ms或18ms;⚫工作电压:79-132VAC;(47~63HZ);⚫最大导通状态电流:5mA@79VAC(60HZ)、13mA@132VAC(60HZ);⚫最大断开状态电流:2.5mA;⚫背板电流:125mA@5Vdc,3mA@24Vdc;⚫具有带电插拨功能;⚫具有可拆卸端子块: 1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;4. 数字量交流输入模块:1756-IM16I⚫输入点数:16点单独隔离;⚫电压类型:220 VAC;⚫输入信号延迟时间:on→off=9ms或18ms;⚫工作电压:156-265VAC;⚫最大导通状态电流:5mA@156VAC(60HZ)、13mA@265VAC(60HZ);⚫最大断开状态电流:2.5mA;⚫背板电流:100mA@5Vdc,3mA@24Vdc;⚫具有带电插拨功能;⚫具有可拆卸端子块: 1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;5. 数字量交流输入模块:1756-IN16;⚫输入点数:16点;⚫电压类型:24 VAC;⚫输入信号延迟时间:on→off=9ms或18ms;⚫工作电压:10-30VAC;(47~63HZ);⚫最大导通状态电流:5mA@10VAC(60HZ)、1.2mA@30VAC(60HZ);⚫最大断开状态电流:2.75mA;⚫背板电流:100mA@5Vdc,2mA@24Vdc;⚫具有带电插拨功能;⚫具有可拆卸端子块: 1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;6. 数字量交流输出模块:1756-OA8/OA16;⚫输出点数:8/16点;⚫电压类型:220VAC;⚫工作电压:74~265VAC;47~63HZ;⚫背板负载电流:200/400mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点输出电流额定值:2A@60度(线性递减);⚫每个模块最大输出电流额定值:5A@30度,4A@60度(线性递减);⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;7. 数字量交流输出模块:1756- OA8D⚫输出点数: 8点;诊断⚫电压类型:120VAC;⚫工作电压:74~132VAC;47~63HZ;⚫背板负载电流:175mA@5V,250mA@24V;⚫具有带电插拨功能;⚫每点输出电流额定值:1A@30度,0.5A@60度(线性递减);⚫每个模块最大输出电流额定值:8A@30度,4A@60度(线性递减);⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;8. 数字量交流输出模块:1756- OA8E⚫输出点数: 8点;电子熔断⚫电压类型:120VAC;⚫工作电压:74~132VAC;47~63HZ;⚫背板负载电流:200mA@5V,250mA@24V;⚫具有带电插拨功能;⚫每点输出电流额定值:2A@60度;⚫每个模块最大输出电流额定值:8A@30度,4A@60度(线性递减);⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;9. 数字量交流输出模块:1756- OA16I;⚫输出点数: 16点;单独隔离⚫电压类型:220VAC;⚫工作电压:74~265VAC;47~63HZ;⚫背板负载电流:300mA@5V,3mA@24V;⚫具有带电插拨功能;⚫每点输出电流额定值:2A@30度,1A@60度(线性递减);⚫每个模块最大输出电流额定值:5A@30度,4A@60度(线性递减);⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;10. 数字量交流输出模块:1756-ON8;⚫输出点数:8点;⚫电压类型:24VAC;⚫工作电压:10~30VAC;47~63HZ;⚫背板负载电流:200/400mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点输出电流额定值:2A@60度(线性递减);⚫每个模块最大输出电流额定值:5A@30度,4A@60度(线性递减);⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;11. 数字量直流输入模块:1756-IB16、1756-IB32⚫输入点数:16点或32点;⚫电压类型:24VDC;⚫输入信号延迟时间:on→off=2ms;⚫工作电压:10~31.2VDC;⚫最大导通状态电流:2mA@10VDC、10mA@31.2VDC;/2mA@10VDC、5.5mA@31.2VDC;⚫最大断开状态电流:1.5mA;⚫具有带电插拨功能;⚫背板负载电流:100/120mA@5V,2mA@24V⚫具有可拆卸端子块:1756-TBNH(20针);/1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;12. 数字量直流输入模块:1756-IB16D;⚫输入点数:16点;⚫电压类型:24VDC;直流诊断⚫输入信号延迟时间:on→off=4ms;⚫工作电压:10~31.2VDC;⚫最大导通状态电流:2mA@10VDC、13mA@31.2VDC;⚫最大断开状态电流:1.5mA;⚫具有带电插拨功能;⚫背板负载电流:150mA@5V,3mA@24V⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;13. 数字量直流输入模块:1756-IB16I;⚫输入点数:16点;单独隔离⚫电压类型:24VDC;⚫输入信号延迟时间:on→off=4ms;⚫工作电压:10~31.2VDC;⚫最大导通状态电流:2mA@10VDC、10mA@31.2VDC;⚫最大断开状态电流:1.5mA;⚫具有带电插拨功能;⚫背板负载电流:100mA@5V,3mA@24V⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;14. 数字量直流输入模块:1756-IB16ISOE;⚫输入点数:16点;单独隔离,事件序列⚫电压类型:24/48VDC;⚫输入信号延迟时间:on→off=50us;⚫工作电压:10~55VDC;⚫最大导通状态电流:2mA@10VDC、5.5mA@55VDC;⚫最大断开状态电流:1.5mA;⚫具有带电插拨功能;⚫背板负载电流:100mA@5V,3mA@24V⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;15. 数字量直流输入模块:1756-IH16ISOE;⚫输入点数:16点;单独隔离,事件序列⚫电压类型:125VDC;⚫输入信号延迟时间:on→off=75us;⚫工作电压:90~140VDC;⚫最大导通状态电流:1.15mA@90VDC、1.85mA@140VDC;⚫最大断开状态电流:0.3mA;⚫具有带电插拨功能;⚫背板负载电流:275mA@5V,2mA@24V⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;16. 数字量直流输入模块:1756-IC16;⚫输入点数:16点;⚫电压类型:48VDC;灌入⚫输入信号延迟时间:on→off=4ms;⚫工作电压:30~60VDC;⚫最大导通状态电流:2mA@30VDC、7mA@60VDC;⚫最大断开状态电流:1.5mA;⚫具有带电插拨功能;⚫背板负载电流:100mA@5V,3mA@24V⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;17. 数字量直流输入模块:1756-IG16;⚫输入点数:16点;⚫电压类型:5VDC;TTL拉出⚫输入信号延迟时间:on→off=0.25ms;⚫工作电压:4.5~5.5VDC;⚫最大导通状态电流:0⚫最大断开状态电流:4.1mA;⚫具有带电插拨功能;⚫背板负载电流:110mA@5V,2mA@24V⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;18. 数字量直流输入模块:1756-IV16;⚫输入点数:16点;⚫电压类型:24VDC;拉出⚫输入信号延迟时间:on→off=2ms;⚫工作电压:10~30VDC;⚫最大导通状态电流:2mA@10VDC、10mA@31.2VDC;⚫最大断开状态电流:1.5mA;⚫具有带电插拨功能;⚫背板负载电流:110mA@5V,2mA@24V⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;19. 数字量直流输入模块:1756-IV32;⚫输入点数:32点;⚫电压类型:24VDC;拉出⚫输入信号延迟时间:on→off=2ms;⚫工作电压:10~30VDC;⚫最大导通状态电流:2mA@10VDC、3.5mA@31.2VDC;⚫最大断开状态电流:1.5mA;⚫具有带电插拨功能;⚫背板负载电流:120mA@5V,2mA@24V⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;20. 数字量直流输入模块:1756-IH16I;⚫输入点数:16点;单独隔离⚫电压类型:125VDC;⚫输入信号延迟时间:on→off=6ms;⚫工作电压:30~60VDC;⚫最大导通状态电流:2mA@10VDC、7mA@31.2VDC;⚫最大断开状态电流:1.5mA;⚫具有带电插拨功能;⚫背板负载电流:125mA@5V,3mA@24V⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;21. 数字量直流输出模块:1756-OB8⚫输出点数:8点;⚫电压类型:24VDC;拉出⚫工作电压:10~31.2VDC;⚫背板负载电流:165mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:2A@60度;⚫每个模块最大负载电流额定值:8A@60度;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;22. 数字量直流输出模块:1756-OB8EI⚫输出点数:8点;电子熔断+单独隔离⚫电压类型:24VDC;⚫工作电压:10~31.2VDC;⚫背板负载电流:250mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:2A@60度;⚫每个模块最大负载电流额定值:16A@55度(线性递减),10A@60度;⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;23. 数字量直流输出模块:1756-OC8⚫输出点数:8点;⚫电压类型:48VDC;拉出⚫工作电压:30~60VDC;⚫背板负载电流:165mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:2A@60度;⚫每个模块最大负载电流额定值:8A@60度;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;24. 数字量直流输出模块:1756-OG16;⚫输出点数:16点;⚫电压类型:5VDC;TTL拉出⚫工作电压:4.5~5.5VDC;⚫背板负载电流:165mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:24MA@60度;⚫每个模块最大负载电流额定值:384MA@60度;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;25. 数字量直流输出模块:1756-OB32⚫输出点数:32点;⚫电压类型:24VDC;⚫工作电压:10~31.2VDC;⚫背板负载电流:300mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:0.5A@50度,0.35A@60度(线性递减)⚫每个模块最大负载电流额定值:16A@50度,10A@60度(线性递减);⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;26. 数字量直流输出模块:1756-OH8I⚫输出点数:8点;⚫电压类型:120VDC;⚫工作电压:90~146VDC;⚫背板负载电流:300mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:2A@60度;⚫每个模块最大负载电流额定值:8A@60度;⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;27. 数字量直流输出模块:1756-OB16D;⚫输出点数:16点诊断;⚫电压类型:24VDC;拉出⚫工作电压:19~31.2VDC;⚫背板负载电流:250mA@5V,140mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:2A@30度,1A@60度(线性递减);⚫每个模块最大负载电流额定值:8A@30度,4A@60度(线性递减);⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;28. 数字量直流输出模块:1756-OB16E;⚫输出点数:16点电子熔断;⚫电压类型:24VDC;拉出⚫工作电压:10~31.2VDC;⚫背板负载电流:250mA@5V,140mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:1A@60度;⚫每个模块负载最大电流额定值:8A@60度;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;29. 数字量直流输出模块:1756-OB16I;⚫输出点数:16点单独隔离;⚫电压类型:24VDC;⚫工作电压:10~31.2VDC;⚫背板负载电流:250mA@5V,140mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:2A@30度,1A@60度(线性递减);⚫每个模块最大负载电流额定值:8A@30度,4A@60度(线性递减);⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;30. 数字量直流输出模块:1756-OB16IS;⚫输出点数:16点单独隔离;8点已预订⚫电压类型:24VDC;⚫工作电压:10~31.2VDC;⚫背板负载电流:350mA@5V,2.5mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:2A@30度,1A@60度(线性递减);⚫每个模块最大负载电流额定值:8A@30度,4A@60度(线性递减);⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;31. 数字量直流输出模块:1756-OV16E⚫输出点数:16点;电子熔断;⚫电压类型:24VDC;直流灌入;⚫工作电压:10~31.2VDC;⚫背板负载电流:210mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:1A@60度;⚫每个模块最大负载电流额定值:8A@60度;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;32. 数字量直流输出模块:1756-OV32E⚫输出点数:32点;电子熔断;⚫电压类型:24VDC;直流灌入;⚫工作电压:10~31.2VDC;⚫背板负载电流:390mA@5V,2mA@24V;⚫具有带电插拨功能;⚫每点最大输出电流额定值:0.5A@50度,0.35A@60度(线性递减)⚫每个模块最大负载电流额定值:16A@50度,10A@60度(线性递减);⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;33. 数字量触点输出模块:1756-OW16I⚫输出点数:16点,每路单独隔离;⚫输入信号延迟时间:on→off=2ms;⚫输出触点类型:继电器常开触点;⚫工作电压:10~265VAC和5~150VDC;⚫输出电流:2A@240VAC和2A@24VDC;⚫具有带电插拨功能;⚫背板电流:150mA@5Vdc,150mA@24Vdc⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;34. 数字量触点输出模块:1756-OX8I⚫输出点数:8点,每路单独隔离;⚫输入信号延迟时间:on→off=2ms;⚫输出触点类型:继电器常开触点;⚫工作电压:10~265VAC和5~150VDC;⚫输出电流:2A@240VAC和2A@24VDC;⚫具有带电插拨功能;⚫背板电流:100mA@5Vdc,100mA@24Vdc⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有光电隔离,状态指示功能;⚫具有CSA、UL、CE认证;35. 模拟量输入模块:1756-IF8、1756-IF16⚫输入路数:8路单端,4路差分;或16路单端,8路差分;⚫电压范围:0~5.125V、0~10.25V、±10.25V;⚫电流范围:4~20mA;⚫分辨率:16位;⚫模块扫描所有通道的时间:8路单端为16~488 ms,4路差分为8~244 ms;或16路单端为16~488 ms,8路差分为8~244 ms;⚫精度(25℃):≤0.15%满量程(电流);⚫背板电流:150mA@5Vdc,40/65mA@24Vdc⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有CSA、UL、CE认证;36. 模拟量输入模块:1756-IF6CIS⚫输入路数:6路隔离,电流拉出型⚫电压范围:0⚫电流范围:0~21mA;⚫分辨率:16位;⚫模块扫描所有通道的时间:对于整数最少10ms;对于浮点数最少25ms;⚫精度(25℃):≤0.1%满量程;⚫背板电流:250mA@5Vdc,275mA@24Vdc⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBNH、-TBSH(20针);⚫具有CSA、UL、CE认证;37. 模拟量输入模块:1756-IF6I;⚫输入路数:6路隔离,⚫电压范围:0~5.25V、0~10.5V、±10.25V;⚫电流范围:0~21mA;⚫分辨率:16位;⚫模块扫描所有通道的时间:对于整数最少10ms;对于浮点数最少25ms;⚫精度(25℃):≤0.1%满量程;⚫背板电流:250mA@5Vdc,100mA@24Vdc⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBNH、-TBSH(20针);⚫具有CSA、UL、CE认证;38. 模拟量输入模块:1756-IF4FXOF2F;⚫输入路数:4路高速低于毫秒级的差分;2路高速的电压或电流;⚫输入电压范围:0~5.25V、0~10.5V、±10.25V;⚫输出: ±10.25V⚫电流范围:0;⚫分辨率:14位;⚫模块扫描所有通道的时间: 4路差分为8~244 ms;⚫精度(25℃):≤0.15%满量程(电流);⚫背板电流:3375mA@5Vdc,100mA@24Vdc⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有CSA、UL、CE认证;39. 模拟量输出模块:1756-OF4、1756-OF8⚫输出路数:4路电流或电压;或8路电流或电压;⚫电压范围:±10.4V;⚫电流范围:4~20mA;⚫分辨率:15位;⚫模块扫描所有通道的时间:对于整数最少8ms;对于浮点数最少12ms;⚫精度(25℃):≤0.05%满量程(电流);⚫背板电流:200mA@5Vdc,120mA@24Vdc/150mA@5Vdc,210mA@24Vdc⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有CSA、UL、CE认证;40. 模拟量输出模块:1756-OF6CI、1756-OF6VI⚫输出路数:6路电流隔离;6路电压隔离⚫电压范围:0/±10.4V;⚫电流范围:0~21mA/0;⚫分辨率:15位;⚫模块扫描所有通道的时间:对于整数最少10ms;对于浮点数最少25ms;⚫精度(25℃):≤0.5%满量程;⚫背板电流:250mA@5Vdc,300mA@24Vdc/250mA@5Vdc,175mA@24Vdc⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有CSA、UL、CE认证;41. RTD热电阻输入模块:1756-IR6I⚫输入路数:6路隔离的RTD;⚫支持100Ω、200Ω、500Ω、1000Ω铂电阻,100Ω、120Ω、200Ω、500Ω镍电阻,10Ω铜电阻;⚫模块扫描所有通道的时间:对于整数最少10ms,对于浮点数最少25ms;⚫精度(25℃):≤0.1%满量程(电流);⚫具有带电插拨功能;⚫背板电流:250mA@5Vdc,125mA@24Vdc⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有CSA、UL、CE认证;42. 热电偶输入模块:1756-IT6I⚫输入路数:6路隔离的热电偶,1路冷端补偿温度;⚫支持的热电偶:B型(250℃-1820℃)、C型(0℃-2315℃)、E型(-270℃-1000℃)、J型(-210℃-1200℃)、K型(-270℃-1372℃)、N型(-270℃-1300℃)、R型(-58℃-1768℃)、S型(-50℃-1768℃)、T型(-270℃-400℃);⚫模块扫描所有通道的时间:对于整数最少10ms,对于浮点数最少25ms(毫伏)、对于浮点数最少50ms(温度);⚫分辨率:16位;⚫精度(25℃):≤0.1%满量程(电流);⚫背板电流:250mA@5Vdc,125mA@24Vdc⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有CSA、UL、CE认证;43. 热电偶输入模块:1756-IT6I2⚫输入路数:6路隔离的热电偶,2路冷端补偿温度;⚫支持的热电偶:B型(250℃-1820℃)、C型(0℃-2315℃)、E型(-270℃-1000℃)、J型(-210℃-1200℃)、K型(-270℃-1372℃)、N型(-270℃-1300℃)、R型(-58℃-1768℃)、S型(-50℃-1768℃)、T型(-270℃-400℃);⚫模块扫描所有通道的时间:对于整数最少10ms,对于浮点数最少25ms(毫伏)、对于浮点数最少50ms(温度);⚫精度(25℃):≤0.1%满量程(电流);⚫背板电流:250mA@5Vdc,125mA@24Vdc⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有CSA、UL、CE认证;三、专用模块1.高速计数器模块:1756-HSC⚫计数数量:2个;⚫工作方式:计数器→最大1MHz,速度测量→最大500KHz,编码器→最大250KHz,去抖动滤波器→最大70KHz;⚫输入点数:3(A、B、Z用于门极/复位);⚫输出点数:4(2输出/公共端);⚫背板负载电流:300mA@5V,3mA@24V;⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBCH(36针);⚫具有CSA、UL、CE认证;2.1756-CFM可组态流量计模块:1756-TBSH;⚫每通道输入点数:2-流量计(F)输入,适用于所有模式;2-门极输入,用于校准/存储计数累加器模式.⚫工作方式:累加器计数和校准,±30V-可选择的输入电压阀值:50Ma,1.3Ma和4Ma; ±30V尖峰无终端开路电压-电磁性示波器;TTL兼容—输入电压高于1.3V直流电压逻辑为1,-0.7V~1.3V直流电压逻辑为0;12—24V直流电源供电的前置放大器输出-4V直流为阀值;⚫最大频率:100KHZ,⚫高分辨率:0.0005HZ⚫背板负载电流:300mA@5V,6mA@24V;⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有CSA、UL、CE认证;3.1756-PLS可编程限位开关模块:1756-PLS;⚫输入点数:16点;⚫输出点数:16点;⚫背板负载电流:1000mA@5V,125mA@24V;⚫具有带电插拨功能;⚫具有可拆卸端子块:1756-TBNH(20针);⚫具有CSA、UL、CE认证;四、通讯网络模块1. EtherNet/IP通讯接口模块1756-ENBTEtherNet/IP通讯模块通过EtherNet/IP网络来控制I/O。
