For further information, contact:
Mittal Steel South Africa Limited, PO Box 2, Vanderbijlpark 1900. Toll free number 0800 005043, Fax (016) 889-0070
e-mail address: datasheets@
Care has been taken to ensure that the information in this data sheet is accurate. Mittal Steel South Africa Limited does not, however,
assume responsibility for any inaccuracies or misinterpretations of this data. We are continuously engaged in product development and
revised data sheets will be issued from time to time. Please ensure that you have the most recent issue. Effective date: October 2005 Page 1 of 3 File reference: A1.6 Price Lists reference 110 and 111
General description
This data sheet serves as an introduction to all the steel specifications that are generally available from
the plate mill at Mittal Steel South Africa. This data sheet does not address all the steels that Mittal Steel
South Africa produces. It merely indicates the generally available specifications. Please note that the
dimensions for all steel plates in the as rolled, normalised and quenched and tempered conditions are
described in the data sheet: Plate Mill Product Dimensions, file reference A1.3.
When a steel type is selected, reference should be made to the relevant data sheet and the original
material specification to determine the prescribed heat-treated condition for a particular thickness. This
information must be used to determine which dimensions are available.
Mittal Steel South Africa produces material of 4,5mm to 100mm thick (depending on the quality) as well
as from 900mm to 3200mm wide on the plate mill. Material thinner than 13,0mm and narrower than
1 870mm is generally produced in the hot strip mill. Mittal Steel South Africa reserves the right to select
the processing route.
Technical information on steel making practice, mechanical properties and chemical composition of the
most popular steels is available from data sheets published for these particular steels. These data sheets
should be consulted to ensure that the correct steel is selected for each application.
Steel types
The maximum thickness of all steel types in Tables 1 to 5 is also a function of ultrasonic test requirements.
Refer to the data sheet: Plate Mill Products (file reference A1).
Table 1. Commercial steel specifications
Specification Thickness
(mm) Data sheet file reference
Commercial Quality
SAE/AISI 1006 ‘95
SAE/AISI 1008 ‘95
SAE/AISI 1010 ‘95
SAE/AISI 1012 ‘95
Flange & Profile Cut 4,5 - 100
4,5 - 100
4,5 - 100
4,5 - 100
4,5 - 100
10 - 65 A2.1
A2.1
A2.1
A2.1
A2.1
Price list 110
Data sheet: A1.6
Steel Types Available to the Domestic Plate Market
Plate mill products
For further information, contact:
Mittal Steel South Africa Limited, PO Box 2, Vanderbijlpark 1900. Toll free number 0800 005043, Fax (016) 889-0070
e-mail address: datasheets@
Care has been taken to ensure that the information in this data sheet is accurate. Mittal Steel South Africa Limited does not, however,
assume responsibility for any inaccuracies or misinterpretations of this data. We are continuously engaged in product development and
revised data sheets will be issued from time to time. Please ensure that you have the most recent issue. Effective date: October 2005 Page 2 of 3 File reference: A1.6 Price Lists reference 110 and 111
Table 2. Structural steel DUAL specifications
Specification Thickness
(mm) Minimum
yield
strength
(MPa) Tensile
strength
(MPa) Data sheet
file
reference
EN 10025 S355 JR /
BS 4360 Gr 50B
EN 10025 S355 J0 /
BS 4360 Gr 50C
EN 10025 S355 J2G3 /
BS 4360 Gr 50D
SANS 1431 Gr 300WA /
BS 4360 Gr 43A
6,0 – 80
4,5 – 80
4,5 – 80
6,0 – 100
355
355
355
300
490 – 630
490 – 630
490 - 630
450 - 620
A3.4 / A3.2
A3.4 / A3.2
A3.4 / A3.2
A3.3 / A3.2
Table 3. Structural steel specifications
Specification Thickness
(mm) Minimum yield
strength
(MPa) Tensile strength
(MPa) Data sheet
file reference
BS 4360 Gr 43A
BS 4360 Gr 43B
BS 4360 Gr 43C
BS 4360 Gr 43D
BS 4360 Gr 43EE
BS 4360 Gr 50B
BS 4360 Gr 50C
BS 4360 Gr 50D
BS 4360 Gr 50DD
BS 4360 Gr 50EE
SANS 1431 Gr 240WA
SANS 1431 Gr 240WC
SANS 1431 Gr 240WDD
SANS 1431 Gr 300WA
SANS 1431 Gr 300WC
SANS 1431 Gr 300WDD
SANS 1431 Gr 350WA
SANS 1431 Gr 350WC
SANS 1431 Gr 350WDD
ASTM A36
ROQ-tuf® AM700 (Structural
6,0 – 100
6,0 – 100
6,0 – 100
6,0 – 100
6,0 – 63
4,5 – 100
4,5 – 100
4,5 – 100
6,0 – 80
6,0 – 63
4,5 – 100
6,0 – 100
6,0 – 80
4,5 – 100
4,5 – 100
4,5 – 80
4,5 – 100
4,5 – 80
6,0 – 80
4,5 – 100
6,0 – 80
265
265
265
265
265
345
345
345
345
345
240
240
240
300
300
300
350
350
350
250
700
430 - 580
430 - 580
430 - 580
430 - 580
