钢结构焊缝疲劳裂纹检测技术及适用性分析摘要：在钢结构桥梁领域，钢结构桥梁焊缝疲劳裂纹不易发觉，疲劳裂纹进一步扩展会对结构受力、桥面板等产生不利影响，甚至可能导致结构关键部件的突然断裂。
文章论述了钢结构疲劳裂纹开裂机理及影响因素，提出了检测焊疲劳裂纹的相关技术原理和方法以及进行其适用性分析。
关键词：钢结构；焊缝疲劳裂纹；检测方法；适用性分析钢结构桥梁是一种以钢材为原料制造的桥梁，和钢筋混凝土桥梁相比，它具有强度高、自重轻、跨越能力大、抗震好、结构牢靠、环保节能、施工便捷等优点。
随着我国综合实力的增强和钢材质量、产量的大幅提升，钢结构桥梁将会迅速发展。
但随着钢桥的服役年限的增加，桥梁的运营维护就会出现较多问题。
钢结构桥梁主要存在腐蚀、涂装劣化和疲劳三种病害。
腐蚀、涂装劣化病害在桥梁运营维护过程中较易发现，也能够及时采取相应维护措施，而疲劳开裂具有产生机理复杂、开裂初期不容易被发现、检测与修复难、且修复成本高等特点，已经成为钢结构桥梁运营养护过程面临的核心难题之一。
随着钢结构桥梁服役时间的增加，我国的一些大跨径钢结构桥梁也出现了疲劳开裂问题，如虎门大桥、海沧大桥[1-3]等。
钢桥初期疲劳裂纹不易发觉，疲劳裂纹进一步扩展会对结构受力、桥面板等产生不利影响，甚至可能导致结构关键部件的突然断裂，产生事故，造成巨大的经济损失。
钢桥常见疲劳破坏可以分为连接部位结点疲劳开裂、正交异性钢桥面板疲劳开裂、缆索及锚箱疲劳开裂，在这三种常见疲劳开裂模式中，疲劳开裂大多数发生在焊缝处，焊缝疲劳损伤是影响钢结构疲劳破坏的主要因素之一，甚至是首要因素。
相关研究表明，钢结构疲劳损伤多数在焊缝位置处产生[4-5]。
目前对钢结构桥梁焊缝疲劳破坏的研究已成为疲劳破坏领域中的一个重点研究方向，在这一方向中，又可分为疲劳裂纹开裂机理与影响因素研究、疲劳寿命评估研究、疲劳裂纹检测/监测研究、疲劳开裂后的防护措施研究等几个方面。
其中疲劳裂纹检测研究是至关重要的，因为它是识别钢结构桥梁是否发生疲劳裂纹，进而判断结构是否安全、以及确定是否需要采取措施提升性能的关键。
