20 mm (0.8 inch)
Seven Segment Displays
Technical DataAlGaAs[1]HERYellowGreen
PackageHDSP-HDSP-HDSP-HDSP- DescriptionDrawingN150390042008600Common Anode Left Hand DecimalAN151390142018601Common Anode Right Hand DecimalB
N153390342038603Common Cathode Right Hand DecimalCN155390542058605Common Cathode Left Hand DecimalDN156390642068606Universal ±1. Overflow[2]E
Notes:1. These displays are recommended for high ambient light operation. Please refer to the HDSP-N10X AlGaAs data sheet for lowcurrent operation.2. Universal pinout brings the anode and cathode of each segment's LED out to separate pins. See internal diagram E.DevicesFeatures• Industry Standard Size• Industry Standard Pinout15.24 mm (0.6 in.) DIP Leads
on 2.54 mm (0.1 in.) Centers• Choice of ColorsAlGaAs Red, High EfficiencyRed, Yellow, Green• Excellent AppearanceEvenly Lighted SegmentsMitered Corners on SegmentsGray Package Gives OptimumContrast±50° Viewing Angle• Design FlexibilityCommon Anode or CommonCathodeLeft and Right Hand DecimalPoints±1. Overflow Character• Categorized for LuminousIntensityYellow and Green Categorizedfor ColorUse of Like Categories Yields aUniform Display• High Light Output• High Peak Current• Excellent for Long DigitString MultiplexingIntensity and ColorSelection OptionSee Intensity and ColorSelected Displays Data Sheet• Sunlight Viewable AlGaAs
DescriptionThe 20 mm (0.8 inch) LED sevensegment displays are designedfor viewing distances up to 10metres (33 feet). These devicesuse an industry standard sizepackage and pinout. All devicesare available as either commonanode or common cathode.These displays are ideal for mostapplications. Pin for pinequivalent displays are alsoavailable in a low current design.The low current displays are idealfor portable applications. Foradditional information see theLow Current Seven SegmentDisplays data sheet.HDSP-390X SeriesHDSP-420X SeriesHDSP-860X SeriesHDSP-N15X Series元器件交易网www.cecb2b.com2
Part Numbering System
Notes:1. For codes not listed in the figure above, please refer to the respective datasheet or contact your nearestAgilent representative for details.2. Bin options refer to shippable bins for a part number. Color and Intensity Bins are typically restricted to 1bin per tube (exceptions may apply). Please refer to respective datasheet for specific bin limit information.5082 -X X X X-X X X X XHDSP-X X X X-X X X X X
Mechanical Options[1]00: No Mechanical Option
Color Bin Options[1,2]0: No Color Bin LimitationZ: Color Bins 2- and 3+ Only (applicable for Yellow devices only)
Maximum Intensity Bin[1,2]0: No Maximum Intensity Bin Limitation
Minimum Intensity Bin[1,2]0: No Minimum Intensity Bin Limitation
Device Configuration/Color[1]0: Common Anode1: Common Anode3: Common Cathode
Device Specific Configuration[1]Refer to Respective Datasheet
Package[1]N: 20 mm (0.8 inch) Single Digit Seven Segment Display元器件交易网www.cecb2b.com3
HDSP-39xxPackage Dimensions
Internal Circuit Diagram
ED CBA元器件交易网www.cecb2b.com4
Absolute Maximum RatingsAlGaAs RedHERYellowGreenHDSP-N150HDSP-3900HDSP-4200HDSP-8600DescriptionSeriesSeriesSeriesSeriesUnitsAverage Power per Segment or DP96105105105mWPeak Forward Current per160[1]135[3]135[3]90[5]mASegment or DPDC Forward Current per40[2]40[4]40[4]30[6]mASegment or DPOperating Temperature Range –20 to +100[7] –40 to +100–40 to +100°CStorage Temperature Range –55 to +100°CReverse Voltage per Segment or DP 3.0VWave Soldering Temperature for3 Seconds (1.60 mm [0.063 in.] 250°Cbelow body)
Notes:1. See Figure 2 to establish pulsed conditions.2. Derate above 55°C at 0.8 mA/°C.3. See Figure 7 to establish pulsed conditions.4. Derate above 50°C at 0.73 mA/°C.5. See Figure 8 to establish pulsed conditions.6. Derate above 50°C at 0.54 mA/°C.7. For operation below –20°C, contact your local Agilent components sales office or an authorized distributor.元器件交易网www.cecb2b.com5DeviceSeries ParameterSymbolMin.Typ.Max.UnitsTest Conditions
Luminous Intensity/Segment[1,2,5]IV6.014.0mcdIF = 20 mA (Digit Average)
1.8VIF = 20 mAForward Voltage/Segment or DPVF2.03.0VIF = 100 mAHDSP-N15XPeak WavelengthλPEAK645nm
Dominant Wavelength[3]λd637nm
Reverse Voltage/Segment or DP[4]VR3.015VIR = 100 µA
Temperature Coefficient of∆VF/°C-2mV/°CVF/Segment or DP
Thermal Resistance LED Junction-RθJ-PIN430°C/W/to-PinSeg
High Efficiency Red
DeviceSeries ParameterSymbolMin.Typ.Max.UnitsTest Conditions33507000µcdIF = 100 mA Peak:Luminous Intensity/Segment[1,2]IV1 of 5 df (Digit Average)4800µcdIF = 20 mA
Forward Voltage/Segment or DPVF2.63.5VIF = 100 mAHDSP-390XPeak WavelengthλPEAK635nmDominant Wavelength[3]λd626nmReverse Voltage/Segment or DP[4]VR3.025VIR = 100 µATemperature Coefficient of∆VF/°C-2mV/°CVF/Segment or DPThermal Resistance LED Junction-RθJ-PIN375°C/W/to-PinSegAlGaAs RedElectrical/Optical Characteristics at TA = 25°C元器件交易网www.cecb2b.com
