AGS可调变径稳定器
一、作用
可调变径稳定器是一种在钻进过程中,用于控制或调整井眼的井斜角的一种工具。
它通过调整稳定器的尺寸大小,改变下部钻具的井斜控制能力,从而较准确地控制井眼的井斜角。
这是美国Sperry-Sun公司生产的可调变径稳定器Adjustable Gsuge Stabilizer,简称AGS。
二、结构示意图一
AGS可调变径稳定器示意图一
三、AGS可调变径稳定器的工作原理
AGS的每一个翼片有四个或五个活塞,如有五个活塞,就有五个活动斜面体,每一个斜面体调节三个活塞,每一个活塞有一个斜面.所有的斜面体是一起活动.当压差作用在活塞下部的斜面体上时,活塞向外伸展.活塞的伸缩,是通过凸轮筒控制的.活塞通过压差保持工作状态.当带有斜面的心轴通过作用在自身的压差向下移动时,斜面同时作用所有活塞,活塞从自由状态向外移动,并通过压差控制,在凸轮筒保持固定.当停泵消除压差时,内部弹簧回弹,心轴恢复原位,活塞收缩,并引导凸轮筒到达下一个位置.
重新开泵将引导AGS工具从自由状态到另一个工作状态,这时活塞通过压差在凸轮筒中保持固定.当压差如上减小,活塞重新恢复下一个状态.活塞将一直保持伸展状态,直到在停泵时才收缩。
钻压不对工具或活塞产生影响。
通过记录钻柱在一定排量的压力,然后停泵、开泵,记录在同样排量下的新的压力值,来确立AGS的位置(工作状态)。
如果新的压力值高,这时活塞全部伸展,反之亦然。
压力升高=尺寸增大。
只有当信号清晰时,信号的压力值才不重要。
当再一次停泵、开泵时,活塞又将从一种工作状态转到另一种工作状态。
由于这种工具可以通过泵简单且快速的调节,所以能够对井斜进行精确的控制。
在水平段,通过调节每一个立柱的进尺,可以精确的控制TVD(垂深)。
一旦司钻、定向井工程师、MWD工程师建立交流,那么这种工具就非常简单和安全。
四、AGS可调变径稳定器的技术规格
Sperry-Sun 8-1/2″Adjustable Gsuge Stabilizer(AGS)
井眼尺寸 8-1/2″心轴通孔 1-3/4″
重量870 Ibs 硬饰面厚度 1/8″
本体材料4145 HTSR
屈服强度率) 2.38 最大MW 18ppg(磅/加仑)
最大流量 600gl/min(35L/s)运转温度范围 0~400°F(112.5°C)
翼片覆盖范围右旋360°螺旋翼片
(当活塞伸出时,立管压力增加值)
位置信号 150~250
psi
本体尺寸
本体直径 6-3/4″鱼颈长 46″
翼片直径 7-7/8″~8″螺旋翼片长度 21-1/4″
位置尺寸
伸出 8-1/2″缩回 7-7/8″~8″
活塞
活塞直径 2-1/2″每套工具数量 15个
五、操作方法
1、AGS可调规径稳定器的组装与地面测试
(1)在BHA中组装AGS。
活塞处于静止位置,在齐平位置以下。
(2)接钻头。
AGS下的压降必须至少400psi,确保仪器顺利工作。
(3)接方钻杆或顶驱。
(4)开泵并且提高流量直至活塞运动。
压力越高效果越好。
允许设定压力并记录冲程。
(5)测量AGS。
(6)如果活塞处于齐平位置,下一个位置它将伸出(?)
(7)关泵:AGS仪器将恢复静止时的压降。
(8)开泵。
按照第四步记录的数据设定冲程。
(9)AGS仪器将从静止状态循环到下一操作位置。
(10)再测量一次AGS仪器。
(11)记录齐平与伸出位置系统的不同压力。
(12)AGS仪器在齐平与伸出状态交替循环。
2、检测AGS活动压力
记录最低压力值为450psi(31bar),最高压力为3500psi(240bar)。
3、检测活塞位置信号
(1)确保至少有400psi的压降。
(2)确保安装在工作室的孔板(尺寸印在仪器的表面上)能够接收到稳定的信号,通常为150—250psi,越高越好。
(3)要与所用钻具一致,检查连通孔,底部接头的连接,管线的塞子等,确保密封,谨防刺漏危险。
(4)将仪器向上放到BHA里,通过两次完全循环进行地面测试(开—关,开—关)。
(5)当开泵循环一次后AGS将改变规径,并且当泵再次循环时规径将恢复到最初位置。
(6)在开始钻进之后,尽可能快地确定地面压力/活塞的延伸或齐平位置。
并且记录下来,建议保留规范的泵冲数和压力记录。
活塞伸出系统加信号压力
活塞齐平系统压力活塞静止循环1 循环2 循环1 循环2 零压力
(7)依据钻井要求,建立一日常的联结,如果能够与MWD符合,开泵传递测量数据,然后关掉它
并与MWD联结好,这样在再次开始时AGS将恢复到原来位置。
4、关闭
(1)当通过转盘时,用水龙带循环清洗伸出的活塞直至冲掉泥浆与固体。
(2)尽可能快的放下AGS仪器,将外部擦干净并用水将内部冲洗干净。
5、注意事项
(1)要严格按操作规程进行使用。
(2)使用后要及时进行维修保养。
