Hydraulic Excavators液压挖掘机7．1Overview概述7.1.1 Basic Concept 基本概念An excavator is an engineering vehicle consisting of an articulated arm (boom, stick), bucket and cab mounted on a pivot (a rotating platform) atop an undercarriage with tracks or wheels. Their design is a natural progression from the steam shovel.挖掘机是一种由铰接臂杆（动臂和斗杆）、铲斗和安装于履带或轮式底盘上的转盘（一种旋转平台）所组成的工程机械（车辆）。

挖掘机是在蒸汽铲的基础上自然发展起来的。

The history of heavy excavating machinery began in 1835 when the dipper shovel was invented to excavate hard soil and rock and to load trucks. Of course, with the invention of gasoline-and diesel-powered vehicles, construction equipment became even more adaptable. Most construction equipment is powered by diesel engines, although electric-power, battery power, and propane tanks are used on specialized equipment.重型挖掘机的历史始于1835年，当时发明了拉铲式挖掘机用于开挖坚硬的土石方及装载卡车。
