Philips EssentialLED Bulb 3000K/6500K 230VPhilips Essential LED Bulb is a sustainable green light bulb to ensure direct replacement of GLS bulbs in indoor application.With latest LED technology, Essential LED Bulb o ers over 83% energy saving and lasts 10 years (if lit 2.7 hours per day across 365 days) to save your total investment cost.From LED chips chosen to the nal assembly, di erent kinds of professional quality control methods are adopted to guarantee the light quality consistency through product lifetime.The product is professionally designed to endure surge and environmental tests to make sure it can be adapted into di erent indoor application situations.Design highlights• Form factor is designed as a direct retrofit into A60 fixtures • Over 85% energy-saving compared with GLS• Long lifetime of 10 years (if lit 2.7 hours per day across 365 days)• Warm white CCT 3000K and cool daylight CCT 6500K available • Environmental friendly, no Mercury or any other hazardous substances • Low Carbon FootprintApplication areasApplication notes• Operating temperature range is between -20 °C and 45 °C ambient• Only to apply in dry or damp locations and most of open fixtures with E27/B22 lamp- holders that offer sufficient space (10 mm free air space)• Not intended for use with emergency light fixtures or exit lights • Not intended for enclosed luminaires The qualified light makes it suitable for general indoor applications such as:• Elite shops• Corridors / Stairways / Washrooms • Lobby / Reception areas • Hotel rooms / Bars• HomeProduct type Voltage Wattage Cap Bulb CCT Lumen Luminous Lifetime CRI EEIshape e cacy label(V) (W) (K) (Lm) (=lm/W) (hours)ESS LEDBulb 4W E27 3000K 230V A60 TR 220-240V 4.0 E27 A60 3000 300 75 10000 80 A+ ESS LEDBulb 4W E27 6500K 230V A60 TR 220-240V 4.0 E27 A60 6500 310 78 10000 80 A+ ESS LEDBulb 6W E27 3000K 230V A60 TR 220-240V 6.0 E27 A60 3000 490 82 10000 80 A+ ESS LEDBulb 6W E27 6500K 230V A60 TR 220-240V 6.0 E27 A60 6500 510 85 10000 80 A+ ESS LEDBulb 8W E27 3000K 230V A60 TR 220-240V 8.0 E27 A60 3000 610 76 10000 80 A+ ESS LEDBulb 8W E27 6500K 230V A60 TR 220-240V 8.0 E27 A60 6500 640 80 10000 80 A+ ESS LEDBulb 4W E27 3000K 230V A60 UAE 220-240V 4.0 E27 A60 3000 300 75 10000 80 4 star ESS LEDBulb 4W E27 6500K 230V A60 UAE 220-240V 4.0 E27 A60 6500 310 78 10000 80 4 star ESS LEDBulb 6W E27 3000K 230V A60 UAE 220-240V 6.0 E27 A60 3000 490 82 10000 80 4 star ESS LEDBulb 6W E27 6500K 230V A60 UAE 220-240V 6.0 E27 A60 6500 510 85 10000 80 4 star ESS LEDBulb 8W E27 3000K 230V A60 UAE 220-240V 8.0 E27 A60 3000 610 76 10000 80 4 star ESS LEDBulb 8W E27 6500K 230V A60 UAE 220-240V 8.0 E27 A60 6500 640 80 10000 80 4 star ESS LEDBulb 4W B22 3000K 230V A60 UAE 220-240V 4.0 B22 A60 3000 300 75 10000 80 4 star ESS LEDBulb 4W B22 6500K 230V A60 UAE 220-240V 4.0 B22 A60 6500 310 78 10000 80 4 star ESS LEDBulb 6W B22 3000K 230V A60 UAE 220-240V 6.0 B22 A60 3000 490 82 10000 80 4 star ESS LEDBulb 6W B22 6500K 230V A60 UAE 220-240V 6.0 B22 A60 6500 510 85 10000 80 4 star ESS LEDBulb 8W B22 3000K 230V A60 UAE 220-240V 8.0 B22 A60 3000 610 76 10000 80 4 star ESS LEDBulb 8W B22 6500K 230V A60 UAE 220-240V 8.0 B22 A60 6500 640 80 10000 80 4 star ESS LEDBulb 4W E27 3000K 230V A60 SA 220-240V 4.0 E27 A60 3000 300 75 10000 80 C ESS LEDBulb 4W E27 6500K 230V A60 SA 220-240V 4.0 E27 A60 6500 310 78 10000 80 C ESS LEDBulb 6W E27 3000K 230V A60 SA 220-240V 6.0 E27 A60 3000 490 82 10000 80 C ESS LEDBulb 6W E27 6500K 230V A60 SA 220-240V 6.0 E27 A60 6500 510 85 10000 80 C ESS LEDBulb 8W E27 3000K 230V A60 SA 220-240V 8.0 E27 A60 3000 610 76 10000 80 C ESS LEDBulb 8W E27 6500K 230V A60 SA 220-240V 8.0 E27 A60 6500 640 80 10000 80 C ESS LEDBulb 4W B22 3000K 230V A60 SA 220-240V 4.0 B22 A60 3000 300 75 10000 80 C ESS LEDBulb 4W B22 6500K 230V A60 SA 220-240V 4.0 B22 A60 6500 310 78 10000 80 C ESS LEDBulb 6W B22 3000K 230V A60 SA 220-240V 6.0 B22 A60 3000 490 82 10000 80 C ESS LEDBulb 6W B22 6500K 230V A60 SA 220-240V 6.0 B22 A60 6500 510 85 10000 80 C ESS LEDBulb 8W B22 3000K 230V A60 SA 220-240V 8.0 B22 A60 3000 610 76 10000 80 C ESS LEDBulb 8W B22 6500K 230V A60 SA 220-240V 8.0 B22 A60 6500 640 80 10000 80 CLEDbulbB22E27Spectral Power DistributionSpectrum Essential LED Bulb 3000KTemperature300/310lm T c Max: 102 o C 490/510lm T c Max: 90 o C610/640lm T c Max: 105 o CTc pointSpectrum Essential LED Bulb 6500KEssential LEDBulb 4W E27/B22 3000K 230V A601 x 300 lmLight output ratio 1.00Service upward 0.81Service downward 0.19CIE ux code7 26 56 19 100UGRcen (4Hx8H, 0.25H )16Essential LEDBulb 4W E27/B22 6500K 230V A601 x 310 lmLight output ratio 1.00Service upward 0.81Service downward 0.19CIE ux code7 26 56 19 100UGRcen (4Hx8H, 0.25H )16Essential LEDBulb 6W E27/B22 3000K 230V A601 x 490 lmLight output ratio 1.00Service upward 0.81Service downward 0.19CIE ux code7 26 56 19 100UGRcen (4Hx8H, 0.25H )17Light output ratio 1.00Service upward 0.81Service downward 0.19CIE ux code7 26 56 19 100UGRcen (4Hx8H, 0.25H )18Essential LEDBulb 6W E27/B22 6500K 230V A601 x 510 lmLight output ratio 1.00Service upward 0.81Service downward 0.19CIE ux code7 26 56 19 100UGRcen (4Hx8H, 0.25H )18Light output ratio 1.00Service upward 0.81Service downward 0.19CIE ux code7 26 56 19 100UGRcen (4Hx8H, 0.25H )18Essential LEDBulb 8W E27/B22 3000K 230V A601 x 610 lmEssential LEDBulb 8W E27/B22 6500K 230V A601 x 640 lmLifetime + SustainabilityFailure Rate Curve of Essential LED bulb 3000K/6500K50%45%40%35%30%25%20%15%10%5%0%500010000T o t a l F a i l u r e R a t eHoursEssential LED Bulb has a lifetime exceeding 10,000 hours de ned as (F50L70), where:F50L70, meaning 50% in total of whole population of lamps either fail without light output or lumen maintenance lower than 70% of initial value.Lifetime estimation based on the application environment condition: at room temperature (25°C), free air burning,baseup burning position, and at rated voltage.© 2016 Philips LightingAll rights reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner. The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof does not convey nor imply any license under patent or other industrial or intellectual property rights.。
Part NumberEmitting Color (Material)Lens TypeIv (mcd) @ 20mA [2] Viewing Angle [1]Min. Typ. 2θ1/2L-7104PBC-A■ Blue (InGaN)Water Clear 400 30°900DESCRIPTIONSzThe Blue source color devices are made with InGaN on SiC Light Emitting Diodez Electrostatic discharge and power surge could damage the LEDsz It is recommended to use a wrist band oranti-electrostatic glove when handling the LEDs z All devices, equipments and machineries must be electrically groundedFEATURESzLow power consumptionz Popular T-1 diameter package z General purpose leads z Reliable and ruggedz Long life - solid state reliability z Available on tape and reel z RoHS compliantAPPLICATIONSz Status indicator z Illuminatorz Signage applicationsz Decorative and entertainment lightingzCommercial and residential architectural lightingATTENTIONObserve precautions for handlingelectrostatic discharge sensitive devicesPACKAGE DIMENSIONSL-7104PBC-AT-1 (3mm) Solid State LampSELECTION GUIDENotes:1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value.2. Luminous intensity / luminous flux: +/-15%.3. Luminous intensity value is traceable to CIE127-2007 standards.Notes:1. All dimensions are in millimeters (inches).2. Tolerance is ±0.25(0.01") unless otherwise noted.3. Lead spacing is measured where the leads emerge from the package.4. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice.ABSOLUTE MAXIMUM RATINGS at T A =25°CELECTRICAL / OPTICAL CHARACTERISTICS at T A =25°CNotes:1. 1/10 Duty Cycle, 0.1ms Pulse Width.2. 2mm below package base.3. 5mm below package base.4. Relative humidity levels maintained between 40% and 60% in production area are recommended to avoid the build-up of static electricity – Ref JEDEC/JESD625-A and JEDEC/J-STD-033.Notes:1. The dominant wavelength (λd) above is the setup value of the sorting machine. (Tolerance λd : ±1nm. )2. Forward voltage: ±0.1V.3. Wavelength value is traceable to CIE127-2007 standards.4. Excess driving current and / or operating temperature higher than recommended conditions may result in severe light degradation or premature failure.ParameterSymbol Value Unit Power Dissipation P D 120 mW Reverse Voltage V R 5 V Junction Temperature T j 125 °C Operating Temperature T op -40 to +85 °C Storage Temperature T stg -40 to +85°C DC Forward Current I F 30 mA Peak Forward CurrentI FM [1]100 mA Electrostatic Discharge Threshold (HBM) -1000VLead Solder Temperature [2] 260°C For 3 Seconds Lead Solder Temperature [3]260°C For 5 SecondsParameterSymbol Emitting ColorValue Unit Typ. Max. Wavelength at Peak Emission I F = 20mA λpeak Blue 468 - nm Dominant Wavelength I F = 20mA λdom [1] Blue 465 - nm Spectral Bandwidth at 50% Φ REL MAX I F = 20mA Δλ Blue 21 - nm CapacitanceC Blue 100 - pF Forward Voltage I F = 20mA V F [2] Blue 3.2 4 V Reverse Current (V R = 5V)I RBlue-10uATECHNICAL DATABLUERECOMMENDED WAVE SOLDERING PROFILENotes:1. Recommend pre-heat temperature of 105°C or less (as measured with a thermocoupleattached to the LED pins) prior to immersion in the solder wave with a maximum solder bath temperature of 260°C2. Peak wave soldering temperature between 245°C ~ 255°C for 3 sec (5 sec max).3. Do not apply stress to the epoxy resin while the temperature is above 85°C.4. Fixtures should not incur stress on the component when mounting and during soldering process.5. SAC 305 solder alloy is recommended.6. No more than one wave soldering pass.PACKING & LABEL SPECIFICATIONSPRECAUTIONSStorage conditions1. Avoid continued exposure to the condensing moisture environment and keep the product away from rapid transitions in ambient temperature.2. LEDs should be stored with temperature ≤ 30°C and relative humidity < 60%.3. Product in the original sealed package is recommended to be assembled within 72 hours of opening. Product in opened package for more than a week should be baked for 30 (+10/-0) hours at 85 ~ 100°C.2. When soldering wires to the LED, each wire joint should be separately insulated with heat-shrink tube to prevent short-circuit contact. Do not bundle both wires in one heat shrink tube to avoid pinching the LED leads. Pinching stress on the LED leads may damage the internal structures and cause failure.3. Use stand-offs (Fig.1) or spacers (Fig.2) to securely position the LED above the PCB.4. Maintain a minimum of 3mm clearance between the base of the LED lens and the first lead bend (Fig. 3 ,Fig. 4).5. During lead forming, use tools or jigs to hold the leads securely so that the bending force will not be transmitted to the LED lens and its internal structures. Do not perform lead forming once the component has been mounted onto the PCB. (Fig. 5 )LED Mounting Method1. The lead pitch of the LED must match the pitch of the mounting holes on the PCB during component placement.Lead-forming may be required to insure the lead pitch matches the hole pitch.Refer to the figure below for proper lead forming procedures.Note 1-3: Do not route PCB trace in the contact area between the leadframe and the PCB to prevent short-circuits." ○" Correct mounting method " x " Incorrect mounting methodLead Forming Procedures1. Do not bend the leads more than twice. (Fig. 6 )2. During soldering, component covers and holders should leaveclearance to avoid placing damaging stress on the LED duringsoldering.(Fig. 7)3. The tip of the soldering iron should never touch the lens epoxy.4. Through-hole LEDs are incompatible with reflow soldering.5. If the LED will undergo multiple soldering passes or face otherprocesses where the part may be subjected to intense heat,please check with Kingbright for compatibility.PRECAUTIONARY NOTES1. The information included in this document reflects representative usage scenarios and is intended for technical reference only.2. The part number, type, and specifications mentioned in this document are subject to future change and improvement without notice. Before production usage customer should refer tothe latest datasheet for the updated specifications.3. When using the products referenced in this document, please make sure the product is being operated within the environmental and electrical limits specified in the datasheet. Ifcustomer usage exceeds the specified limits, Kingbright will not be responsible for any subsequent issues.4. The information in this document applies to typical usage in consumer electronics applications. If customer's application has special reliability requirements or have life-threateningliabilities, such as automotive or medical usage, please consult with Kingbright representative for further assistance.5. The contents and information of this document may not be reproduced or re-transmitted without permission by Kingbright.6. All design applications should refer to Kingbright application notes available at /application_notes。
Agradecemos su compra!Por favor, lea el manual de instrucciones antes de la instalación y consérvelo a mano para consultas futuras.Luminaria con disipador térmico de aluminio fundido de alta pureza, alta luminosidad, chip SMD Nichia, con un driver Sosen de corriente constante. La campana lineal LED LEN-Y, es una campana lineal que en los momentos más comprometidos actúa como una luz de emergencia. Diseño del PCB para media y gran altura en industria: producción, almacenes diáfanos con estanterías a media altura, talleres, gasolineras, centros comerciales, mercados, peajes de autopistas y otras aplicaciones.ProblemaPosible CausaSolucionesLED no funciona El cable de red no está conectado Conecta el cable de red.El enchufe está sueltoConéctelo firmemente a la toma de corriente. El driver del LED tiene una avería Reemplace el driver con uno nuevo.El chip LED está dañado Puede ser reparado sólo por Venalsol. La luz LED se enciende y apaga La salida del driver es anómala Reemplace el driver por uno nuevo.El chip LED tiene una averíaPuede ser reparado sólo por Venalsol.Venalsol garantiza sus productos, dentro de las condiciones generales de suministro, siempre que se trate de un defecto de fabricación o materiales por un período de cinco años a partir de la fecha de compra. La garantía consiste en la reparación/sustitución de las partes o conjuntos que se consideren defectuosos. No se aplicará por lo tanto a los artículos que presenten daños como consecuencia de no haber seguido correctamente las instrucciones de uso, o cuando la instalación haya sido realizada por personal no especializado. Así mismo, quedan excluidos los daños ocasionados por uso indebido del aparato y averías producidas en el transporte.Para realizar una reclamación de garantía, es necesario notificarlo por escrito a su vendedor, aportar factura de compra y cumplir con los demás requisitos de garantía. Siempre será necesario la devolución del producto averiado con su original placa identificativa de Venalsol Smart Light y su número de serie. Los costes de transporte están excluidos.1. La decisión de si el producto es defectuoso será tomada por Venalsol, que comprobará el mal funcionamiento del producto. SiVenalsol comprueba que el producto es defectuoso, decidirá si se ha de reparar o reemplazar por uno nuevo. Venalsol se reserva el derecho de utilizar productos nuevos o reparados en el proceso de reparación o sustitución del producto en garantía. El producto que se haya reparado o reemplazado, se garantizará durante el período de garantía original que le quede. El coste de personal y el coste de la maquinaria necesaria para la sustitución queda excluido. La responsabilidad total de Venalsol respecto al producto defectuoso estará siempre limitada al dinero pagado por el comprador por ese producto originalmente.2. En caso de solicitud de un producto en buen estado, previo al envío del producto defectuoso, con el fin de facilitar las labores de sustitución, Venalsol podrá aceptar suministrarlo y éste será facturado. Esta factura será abonada si procede, una vez sea recibido y verificado el producto supuestamente averiado. De no cumplir los requisitos de garantía, o no recibirse el material averiado, pasados 60 días de la reposición previa, se procederá al cobro de la factura.La garantía no cubrirá las siguientes circunstancias:1. Daños causados por fuerza mayor como guerras, revueltas, sabotajes, ciclones, terremotos, inundaciones explosiones, incendios, etc.2. Daños causados por uso inapropiado durante el período de entrega, defectos causados por su mal uso, tratamiento erróneo o destrucción de la maquinaria.3. Desmontaje, modificación o mantenimiento inapropiado productos reparados sin autorización del proveedor.4. Daños causados por el comprador o instalador usando cableado de baja calidad o otros componentes no compatibles con el producto.5. Esta garantía no es válida si el producto es usado para propósitos diferentes para los que está originalmente diseñado.150W - 200WVenalsol Smart Light S.L.C/ Garbí nº15. - Polígono Industrial Palma de Gandía - 46724 - Palma de Gandía Valencia (España) - Atención al cliente: +34 962 808 219 *****************< VER FICHA TÉCNICATodos los derechos reservados - Copyright ©2017Manual de instruccionesRegulable 1-10Vcc1.Desconecte el suministro de energía antes de la instalación o del mantenimiento de la luminaria.2. Es estrictamente obligatorio conectar el cable de tierra (Amarillo/Verde) con el conexionado de tierra de la instalación.3. No toque la fuente de alimentación cuando la lámpara esté en funcionamiento.4. Para evitar daños, descargas eléctricas o incendios, no desmonte o reemplace la lámpara (PCB CHIP LED).5.Para evitar daños, caídas, descargas eléctricas o incendios, por favor no modifique o reemplace los accesorios originales por otros que no lo sean, sin consultar y estar autorizado por Venalsol con anterioridad.6. Sólo personal cualificado puede realizar la sustitución o instalación de la luminaria y asegúrese de que sigue las instrucciones del manual. Si la instalación no se realiza adecuadamente, puede causar caídas, descargas eléctricas, incendios u otros daños.7. Desconecte el suministro de energía si sale humo o produce olor, ya que podría producirse un incendio o descarga eléctrica.8. Consulte a personal cualificado para la inspección y mantenimiento de la lámpara.9. Si el cableado propio de la luminaria está dañado, sólo puede ser reemplazado por Venalsol.Normativa aplicableHa pasado los test y verificaciones necesarios para la obtención del Marcado CE. Este producto cumple con los estándares de aplicación sobre Baja Tensión (LVD) 2014/35/EU: EN60598-1:2015, EN60598-2-24:2013, EN60598-2-1:1989, EN62031:2008, EN62471:2008, EN62493:2010 y Compatibilidad Electromagnética (EMC)2014/30/EU: EN61000-3-2:2014, EN61000-3-3:2013, EN61547:2009, EN55015:2013.Este símbolo indica que el producto al final de su vida útil deberá eliminarse por separado de los demás desechos, puesto que se identifica como un aparato de uso eléctrico o electrodoméstico según el Real Decreto 208/2005. Por lo tanto, al final del uso, deberá hacerse cargo de entregar el producto a un centro de recogida selectiva o a un gestor de residuos autorizado. Venalsol está registrado en el Registro Nacional de Aparatos Eléctricos y Electrónicos con número de inscripción registral 3493 y se encuentra adherida a un Sistema de Gestión de Residuos de Aparatos Eléctricos y Electrónicos para los productos con la categoría de "aparatos de alumbrado".Las luminarias LED Venalsol son respetuosas con el Medio Ambiente. No contienen mercurio y los componentes electrónicos utilizados cumplen con lo establecido en la normativa RoHS de transposición al Real Decreto 208/2005.Parámetros TécnicosEspecificaciones del producto 150W200WVoltaje de entrada AC100-277V 50/60Hz Clase I ( Necesita toma de tierra )CRIRa80Ángulo del Haz de Luz 30x70º, 120º, 90º, 40x120º, 50x90ºClasificación IP IP20Dimensiones (mm) 137 x 718 x 102 mm137 x 948 x 102 mmPeso neto de la luminaria 5.7 ±0.3kg6.7 ±0.3kgFactor de potencia 0.92Vida útil≥50000Hrs (LM70@35°C)Temperatura de funcionamiento 0 ~ +40°C Humedad de funcionamiento 15% ~ 90%RH Temperatura de almacenaje-40 ~ +70°CAmarillo/VerdeAzulAzul137mmB2. Extraer1. Presiona el candadoInsertar el hilo2 PCS102mmPulsador para deshabilitar la función de emergencia.Indicador de funcionamiento Insertar el hilo。
第8页光源系列 LAMP Series闪射系列 FLASHING SERIES外形设计美观、烟尘式散热排气孔Beautiful and decent appearance design, Smoke-Dust cooling exhaust hole产品特性 PRODUCTS FEATURES灯体采用6063航空铝材，冷锻式一体成型，外形新颖，美观大方；独有烟尘式散热设计，通过散热排气孔能更快的带走热量，散热效率高；电源采用美国BCD方案设计，高精度智能控制电路，具有过载欠压等保护，使用更安全；进口一体化透镜，透光率高达93%，表面鳞面设计，更好的防止眩光；新型EMC超导热大功率灯珠，具有高光效，高显指，采用陶瓷支架，散热效果更好，将低光衰。
The lamp body is made of 6063 aviation aluminum with novel and beautiful appearance. Product Category: Cold Forging, Integrated molding.Cooling Design: Unique Smoke-Dust Type, it can take away heat faster through the vent holes, so the cooling efficiency is very high.Power source: Using BCD solution design from US with precision smart control circuit, overload & under voltage protection, keeps it more secure.Lens: Integrated lens imported from abroad, light transmission rate is as high as 93%, and the surface design uses Scaly surface, so it can prevent glare much better;New EMC Lamp beads: superconducting heat and high power, high luminance, and high color render index.Ceramic bracket: provides better heat dissipation and low light decay.应用范围商业重点照明、酒店重点照明、装饰照明、专卖店、咖啡厅、KTV、超市、写字楼、书房、面包店、书店、家居等场所。
特点⏹临界模式工作，无需电感补偿⏹内置500V 功率MOSFET ⏹栅极驱动，无需辅助绕组供电⏹高达±3%的LED 电流精度⏹高达93%以上的系统效率⏹LED 短路保护⏹CS 采样电阻短路保护⏹智能温度控制技术，避免高温灯闪⏹芯片过温保护⏹外部可调输出开路/过压保护⏹外置PWM 调光功能应用领域⏹球泡灯⏹面板灯⏹LED 灯管概述WS9442P 是一款高精度的LED 恒流驱动芯片，适合于85V-265V 全范围交流输入电压的非隔离降压型LED 恒流电源系统。
WS9442P 内部集成500V 功率MOSFET ，只需要很少的外围元件，即可实现优异的恒流特性。
芯片工作在电感电流临界模式，系统输出电流不随电感量和LED 工作电压的变化而变化，实现优异的负载调整率。
芯片工作电流只有200uA ，无需辅助绕组供电，简化设计，降低系统成本。
内部采用了独特的智能温度控制，可以轻易解决高温时灯闪的问题。
具有外置调光引脚，此引脚输入PWM 信号，可通过改变PWM 信号占空比来调光。
具有多重保护功能，包括LED 开路/短路保护、电流采样电阻短路保护和芯片过温保护。
WS9442P 提供7-Pin 的DIP7封装。
典型应用图非隔离降压型LED 恒流驱动芯片引脚定义与器件标识WS9442P 提供了7-Pin 的DIP-7封装，顶层如下图所示：引脚功能说明电路内部结构框图引脚名引脚号功能说明1GND 芯片地2ROVP 输出开路保护电压调节端，必须接电阻到地，不可以悬空3DIM 调光端，不用时悬空。
4VCC 芯片电源端5,6DRAIN内部功率管漏端7CS电流采样端，接电流检测电阻到地WS9442PD7P ：Product Code A ：产品编码X ：内部代码BCY ：内部品质管控代码YMX ：D/C订购信息封装形式芯片表面标识采购器件名称7-Pin DIP-7,Pb-free WS9442PD7P WS9442PD7P输出功率范围型号封装形式输入电压最大输出功率WS9442PD7P DIP7单电压（175VAC-264VAC）120V/280mA160V/220mA 全电压（90VAC-264VAC）80V/300mA极限参数符号(symbol)参数（parameter）极限值单位（unit）V DS内部高压MOSFET漏极到源极峰值电压-0.3~500VI CC_MAX最大电源电流10mAV ROVP LED开路保护电压调节端-0.3~7VV CS CS电流采样端电压-0.3~7VP DMAX功耗0.9WT J最大工作结温150℃T STG最小/最大储藏温度-55~150℃注意：超过上表中规定的极限参数会导致器件永久损坏。
TINMY LED 日光灯管系列说明书产品特点1. 采用先进工艺，LED 采用优质芯片和先进的封装工艺。
2. 散热能力好，外壳采用铝合金型材和高透光外罩。
3. 恒流驱动，低功耗，功率因素高达90%以上，相同照明效率比传统日光灯节电75%以上4. 长寿命，达到5万小时以上，是传统日光灯寿命的10倍以上。
5. 显色指数高达85%以上。
6. 安装或替换方便（普通支架不用更改线路，只需取下启辉器）。
7. 本系列产品已通过CE RoHS认证。
产品性能LED 灯管是一种新型的室内照明灯管，亮度及显色指数高，光线柔和。
1. 安装方便：外型、尺寸与传统日光灯一样，可适用传统日光灯支架，直接替换传统日光 灯（去除启辉器即可），降低使用成本，方便操作。
2. 散热效果：散热器采用高导热系数铝合金型材，确保产品的散热能力，保证了产品的稳定性和超长寿命。
3. 环保节能，寿命长，低耗电能仅为传统灯管的1/4，正常使用寿命高达5万小时。
4. 无闪烁，无紫外线，不干扰高精度电器设备的使用。
低光衰，3000小时衰减<2%。
5. 是替代普通照明灯管的理想选择。
产品型号功率（W）LED数量工作电压流明（lm）功率因数色温TM-T8-8W6008SMD108AC85-265V 6000.953000K-7000K TM-T8-9W6009SMD120AC85-265V 6800.953000K-7000K TM-T8-10W60010SMD144AC85-265V7900.953000K-7000K TM-T8-13W60013SMD204AC85-265V11200.953000K-7000K TM-T8-15W60015SMD228AC85-265V12500.953000K-7000K TM-T8-13W60218SMD276AC85-265V15600.953000K-7000K TM-T8-13W60320SMD288AC85-265V16000.953000K-7000K TM-T8-13W60423SMD336AC85-265V19000.953000K-7000K TM-T8-13W60525SMD360AC85-265V20000.953000K-7000K 节能效益LED 日光灯有着良好的节能效果，一般情况下较传统荧光灯节能70%左右。
Proof 1 — December 28, 2021 12:34 PMExpand your dimming universeEaton’s W iring Devices Universal dimmers2Eaton’s Wiring Devices Universal dimmersDimming done right.Eaton’s universal dimmers are ergonomically designed and provide flicker-free dimming for seamless ambiance.Highly versatileCompatible with dimmable LED/CFL, INC, HAL, dimmable FLR, EL V and ML V light sources.Adjustable high and low-end trimSet the minimum and maximum light levels for each switch using a simple control Flicker-free dimmingLatest technology enhances performance and delivers seamless dimming.Visit /led-dimming for compatibility informationUniversal dimmer familyUniversal dimmers intro 4Universal decorator dimmer 5Universal full slide dimmer 6Universal slide dimmer7Universal phase selectable slide dimmer 8Universal toggle dimmer 9Universal dimmer sensors10Universal decorator dimmer Universal full slide dimmer Universal slide dimmer Universal toggle dimmer Universal phase selectable dimmer Universal dimmer sensor3Eaton’s Wiring Devices Universal dimmersRated for common lighting loadsDimmable Light-Emitting Diodes (LED)Dimmable Compact Fluorescent (CFL)Electronic & Magnetic Low-Voltage (ELV & MLV)Incandescent/Halogen (INC/HAL)Fluorescent (FLR)Eaton's Wiring Devices Universal dimmers offer a versatile option for any dimming application - fine tune the dimming performance to match your exact needs and change colors as needed to suit any décor.Flexibility & innovationColor flexibility•Single pole or 3-way wiring in one unit •Separate ON/OFF and DIM/BRIGHT controls allow easy return to favorite light levels •Interchangeable faceplates available in 3 different color change kit optionsColor change kits come with three color faceplates, offering design flexibility within one product. Select models are available in 4 different color combination packs.Enjoy flexibility and optimal dimming performance with a variety of light sources and functionalityUniversal dimmers provide rating flexibilityDUL06P SUL06P SUF7Dimmer featuresDecoratordimmer (DUL06P)Slidedimmer (SUL06P)Phase selectable dimmer (SUF7)T oggledimmer (TUL06P)Full slidedimmer (FSUL06)Adjustable low-end trim ✓✓✓✓✓Adjustable high-end trim ✓✓–✓–Wiring configurations Single pole or 3-waySingle pole or 3-waySingle pole or 3-way Single pole or 3-waySingle pole Color change kits ✓✓–✓–De-rating required––– (LED/CFL)–– (INC/FLR/HAL)TUL06P Eaton’s universal dimmers offer flexibility in design with the latest dimming technologyLA (Light Almond), W (White), V (Ivory)LA C2 Color Change KitC6 Color Change KitSG (Silver Granite), W (White), RB (Oil Rubbed Bronze)WC7 Color Change KitBK (Black), B (Brown), GY (Gray)BKFSUL064 Eaton’s Wiring Devices Universal dimmerssingle pole/3-way preset back and side wireDUL06P-___600120INC, HAL, FLR, MLV, ELV _________DUL06P Color change faceplateB, BK, GY, LA, V, WDCK1-___See instruction sheet for de-rating informationColor ordering informationFor ordering devices, include Catalog no. followed by the Color suffix: B (Brown), BK (Black), GY (Gray), LA (Light Almond), V (Ivory), W (White), C2 (Color Change Kit: LA, W, V), C6 (Color Change Kit: W, RB, SG), C7 (Color Change Kit: BK, B, GY)DUL06PSingle pole and 3-way•Preset feature allows user to return to previous light level when turning lights ON•Adjustable high and low level trim setting for additional energy savings and optimal lamp compatibility •Integrated full-slide control for easy, precise operationUniversal decorator dimmersFeatures• Device can be wired into either 3-way location (load side or line side)• Radio frequency interference filtering is standard on all models • Neutral is not required for installation of device• Compatible with most common dimmable light loads (Forward phase-cut)• Compatible with any decorator wallplate or screwless decorator wallplate •Color change kits are available with packout of 3 different colors for increased flexibility and convenience • Soft gradual ON feature •CA Title 24 compliantDUL06P(PJS26W wallplate sold separately)Universal series dimmersLA (Light Almond), W (White), V (Ivory)C2 Color Change Kit(Brown)(Black)(Gray)(Light Almond)(Ivory)(White)C6 Color Change KitC7 Color Change KitC7 Color Change Kit(Black, Brown, Gray)(Light Almond, White, Ivory)(White, Silver Granite, Oil Rubbed Bronze)W (White), RB (Oil Rubbed Bronze),SG (Silver Granite)BK (Black), B (Brown), GY (Gray)5Eaton’s Wiring Devices Universal dimmersFSUL06Single pole• Neutral is not required for installation of device • Integrated full-slide control for easy, precise operation •Adjustable low- level trim setting for additional energysavings and optimal lamp compatibilityCompatible lamp typesDimmable LED/CFL and side wire FSUL06-___600120INC, HALSee instruction sheet for de-rating informationColor ordering informationFor ordering devices, include Cat. no. followed by the color code: LA (Light Almond), W (White)Universal full slide dimmersFeatures• Radio frequency interference filtering is standard on all models• Compatible with any decorator wallplate or screwless decorator wallplate • Compatible with incandescent, halogen, LED, and CFL (forward phase-cut)• Soft gradual ON feature •CA Title 24 CompliantFSUL06P(PJS26W wallplate sold separately)Full slide series dimmers(Lt. Almond)(White)6 Eaton’s Wiring Devices Universal dimmersSUL06P(PJS26W wallplatesold separately)SUL06PSingle pole and 3-way•Adjustable high and low- level trim setting for additional energy savings and optimal lamp compatibility •Integrated ergonomic full-slide control for easy, precise operation•Reduced ON/OFF switch size for a more aesthetic designUniversal slide dimmersFeatures• Compatible with any decorator wallplate or screwless decorator wallplate • Soft gradual ON feature • No de-rating required• Compatible with most common dimmable lighting loads (Forward phase-cut)• Radio frequency interference filtering is standard on all models • Neutral is not required for installation of device•Device can be wired into either 3-Way location (load side or line side)• Preset feature allows user to return to previous light level when turning lights ON •CATile 24 compliantCompatible lamp TypesDimmable LED/CFL single pole/3-way preset,back and side wireLA, W SUL06P-___600120INC, HAL, FLR, MLV, ELVSee instruction sheet for de-rating informationUniversal series dimmersColor ordering informationFor ordering devices, include Cat. no. followed by the color code: B (Brown), BK (Black), GY (Gray), LA (Light Almond), V (Ivory), W (White)C2 (Color Change Kit: LA, W, V), C7 (Color Change Kit: BK, B, GY)(Brown)(Black)(Gray)(Lt. Almond)(Ivory)(White)C7 Color Change KitLA (Light Almond), W (White), V (Ivory)C2 Color Change KitBK (Black), B (Brown), GY (Gray)7Eaton’s Wiring Devices Universal dimmersUniversal series dimmers450277LA, V, W 6501000120277INC, HAL, ELVSUF7Universal phase selectable slide dimmersFeatures• Compatible with most common dimmable lighting loads (Forward or Reverse phase-cut)• Neutral is required for installation of device• Radio frequency interference filtering is standard on all models • Precise color matching•Preset feature allows user to return to previous light level when turning lights ONSingle pole and 3-way•Select between forward and reverse phase cut dimming for the most optimal dimming compatibility. Integrated full-slide control for easy, precise operation•Adjustable low-level trim setting for additional energy savings and optimal lamp compatibility•Dual rated for 120V/AC and 277V/AC. Suitable for commercial and residential applicationsSUF7(PJS26W wallplate sold separately)Color ordering informationFor ordering devices, include Cat. no. followed by the color code: B (Brown), BK (Black), GY (Gray), LA (Light Almond), V (Ivory), W (White)B(Brown)Compliances, specifications and availability are subject to change without notice.8 Eaton’s Wiring Devices Universal dimmersUniversal series dimmersTUL06PSingle pole and 3-way•Preset feature allows user to return to previous light level when turning lights ON• Integrated full-slide control for easy, precise operation •Adjustable high and low- level trim setting for additional energy savings and optimal lamp compatibilityColor change kit optionsC2 Color Change Kit(Light Almond/White/Ivory)C7 Color Change Kit(Black/ Brown/Gray)Compatible lamp typesDimmable LED/CFL single pole/3-way preset, back and side wire600120INC, HAL, FLR, MLV, ELV _________TUL06P Color change faceplateB, BK, GY, LA, V, WSee instruction sheet for de-rating informationColor ordering informationFor ordering devices, include Cat. no. followed by the color code: B (Brown), BK (Black), GY (Gray), LA (Light Almond), V (Ivory), W (White), C2 (Color Change Kit: LA, W, V), C7 (Color Change Kit: BK, B, GY)Universal toggle dimmersFeatures• Soft gradual ON feature• Device can be wired into either 3-way location (load side or line side)• Neutral is not required for installation of device • Faceplate is removable to allow for color changes• Radio frequency interference filtering is standard on all models•Compatible with any traditional toggle wallplate or screwless toggle wallplate • Compatible with most common dimmable lighting loads (Forward phase-cut)••CA TUL06P(PJS1W wallplate sold separately)(Brown)(Black)(Gray)(Lt. Almond)(Ivory)(White)C7 Color Change KitLA (Light Almond), W (White), V (Ivory)C2 Color Change KitBK (Black), B (Brown), GY (Gray)9Eaton’s Wiring Devices Universal dimmersOSUL06D/VSUL06USingle pole and 3-way•Provides 180 degree field of view and 1000 sq. ft. of major motion coverage•Preset light level change is easily shown with horizontal row of green LEDs•Single green LED indicates load status and motion detectionUniversal series dimmersMotion sensorsRating W/VA V/ACCompatible lamp loadsDescriptionColor suffixCatalog no.300600120120LED/CFL/Fluorescent INC, HAL, ELV, MLV Motion sensor with dimmer C2, C4, C5, C7 OSUL06D-__•300600120120LED/CFL/Fluorescent INC, HAL, ELV, MLVVacancy sensor with dimmerC2, C4, C5, C7VSUL06D-__•Note: Sensors are rated for 120V/AC unless otherwise noted. cULus Listed to UL773A, file no. E1916390SUL06D(PJS26W wallplate sold separately)Universal dimmer sensorsFeatures• Soft ON/fade OFF• Convenient patented built-in wire strippers allow for fast installation•Selectable time delay of 5 seconds (test), 5 minutes, 10 minutes and 20 minutes for lights to remain ON after room is vacated•Occupancy Sensors time delay default set to 5 minutes; Vacancy Sensors time delay default set to 20 minutes•Occupancy Sensor provides a selectable ambient light override preventing lights from switching ON when there is acceptable natural light•Occupancy Sensor allows to toggle between Auto ON/Auto OFF or Manual ON/Auto OFF mode with a simple press and hold of switch•Occupancy Sensor provides for a bypass feature to allow the sensor to perform as a traditional switch (Manual ON/Manual OFF)• Electrostatic discharge protection • No leakage to load in OFF mode• Color change faceplate kits provide for a simple in field change • Neutral required for installation of device •CA Title 24 compliantLA (Light Almond), W (White), V (Ivory)LAWVC2 Color Change KitC4 Color Change KitBK (Black), W (White), V (Ivory)BKWVC5 Color Change KitW (White), BK (Black), GY (Gray)WBKGYC7 Color Change KitBK (Black), B (Brown), GY (Gray)BKBGYColor ordering information:For ordering devices, include Catalog no. followed by the Color suffix: C2 (Color Change Kit: LA, W, V), C4 (Color Change Kit: BK, W, V), C5 (Color Change Kit: W, BK, GY), C7 (Color Change Kit: BK, B, GY)Compliances, specifications and availability are subject to change without notice.CA Title 24 compliant10 Eaton’s Wiring Devices Universal dimmers11 Eaton’s Wiring Devices Universal dimmersAt Eaton, we believe that power is a fundamental part of just about everything people do. Technology, transportation, energy and infrastructure-these are things the world relies on every day. That’s why Eaton is dedicated to helping our customers find new ways to manage electrical, hydraulic and mechanical power more efficiently, safely and sustainably. To improve people’s lives, the communities where we live and work, and the planet our future generations depend upon. Because that’s what really matters. And we’re here to make sure it works.See more at /whatmatters*We make what matters work.*Follow us on social media to get thelatest product and support information.Eaton is a registered trademark. All other trademarks are property of their respective owners.Eaton 1000 Eaton Boulevard Cleveland, OH 44122United States © 2021 Eaton All Rights Reserved Printed in USA Publication No. BR610065EN June 2021Electrical Sector 203 Cooper Circle Peachtree City, GA 30269United States /wiringdevices Electrical Sector Canada Operations 5925 McLaughlin Road Mississauga, Ontario, L5R 1B8Canada EatonCanada.ca /wiringdevices Electrical Sector Mexico Operations Carr. Tlalnepantla -Cuautitlan Km 17.8 s/n Col. Villa Jardin esq.Cerrada 8 de Mayo Cuautitlan, Mexico CP 54800Mexico Eaton.mx /wiringdevices。
